DigitaLinx DL-HD2100 User manual

DL-HD2100 Quick Install Guide
This guide is for quick installa on only.
For complete owners manual go to www.libav.com or use a QR reader to access the
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet
11675 Ridgeline Drive
Colorado Springs, CO
80921
Rev 181211 Phone: [phone]
Toll-Free: 800-530-8998
Fax: [phone]

The DigitaLinx DL-HD2100 HDBaseT extender set extends HDMI audio, video as well as control
up to 100m / 330’ using a single Category 6 cable. Supports HDMI 2.0a, HDR10 and HDCP 2.2
as well as Dolby Atmos and DTS:X audio formats. Control extension supports bidireconal IR,
Ethernet, ARC and RS232. Built in re-clocking circuitry ensures that extender set is backwards
compable with older HDMI version chip sets.
The DigitaLinx DL-HD2100 can transport HDMI data rates up to 18Gbps up to 100 meters.
The system enables high data rates by ulizing visual lossless compression at a 2:1 data
compression rate when the signal surpasses 10Gbps, anything under 10Gbps will never be
compressed. Supports stac HDR (HDR10) only when data rate exceeds 18Gbps, supports
dynamic HDR (HDR10+ / Dolby Vision) when data rate is 10Gbps or less.
Built-in surge protecon and diagnosc LEDs ensure hassle-free and robust installaons.
Flexible power design allows the units to be powered at either the TX or RX end, and only one
power supply is required to power the set. The 12 volt power supply is secured with a screw-
on connector to prevent the power from being accidentally disconnected.
The DL-HD2100 is sold only as a set. The individual transmier and receiver are not compable
with other HDBaseT devices due to proprietary PoE circuitry.
Product Overview
Package Contents
• (1) DL-HD2100 Transmier and Receiver Set
• (2) IR Receivers (Eye)
• (2) IR Transmiers (Emier)
• (1) IR-AC IR Coupler Cable
• (3) 3 pole Terminal Block (aached to extenders)
• (1) DC12v US Power Supply with US, UK, EU and AU adapters
• (4) Mounng Brackets with screws

Transmi er
1. FRONT PANEL DIAGNOSTIC LEDs;
• POWER -Solid, the DL-HD2100 extender is receiving power from the power supply or from the remote extender
via Category 6 cabling.
• STATUS - Flashes once per second, the HDBaseT processor is running.
• HDCP - Solid, HDCP signal is present in the HDMI stream. Flashes quickly, non-encrypted HDCP signal is present
in the HDMI stream.
• LINK - Solid, the two DL-HD2100 components are communica ng via Category cabling.
2. DC 12V
• Locking power port, connect DC12V power adapter to transmi er (either power port on transmi er and
receiver can power en re set)
3. HDBT OUT
• RJ45 HDBaseT connec on. Connect Cat6 cable to receiver
4. IR In / IR OUT
• 3.5mm IR input port for connec on to IR receiver or IR system
• 3.5mm IR output port for connec on to IR emi er
5. AUDIO OUT
• Analog audio de-embedding port for rou ng stereo audio to audio ampli er / mixer
6. RS232
• 3 pin Phoenix connector port for connec ng / passing RS232 control to receiver / display loca on
7. HDMI In
• HDMI input port for connec ons to video sources
8. Ethernet
• RJ45 port for passing Ethernet to receiver / display loca on
9. TOSLINK OUT
• Digital audio return channel output port for rou ng mul -channel from DL-HD2100 receiver to audio ampli er
or mixer
1 2 3 4 5 67 8 9

Receiver
1. FRONT PANEL DIAGNOSTIC LEDs;
• POWER -Solid, the DL-HD2100 extender is receiving power from the power supply or from the remote extender
via Category 6 cabling.
• STATUS - Flashes once per second, the HDBaseT processor is running.
• HDCP - Solid, HDCP signal is present in the HDMI stream. Flashes quickly, non-encrypted HDCP signal is present
in the HDMI stream.
• LINK - Solid, the two DL-HD2100 components are communica ng via Category cabling.
2. DC 12V
• Locking power port, connect DC12V power adapter to receiver (either power port on transmi er and receiver
can power en re set)
3. HDBT IN
• RJ45 HDBaseT connec on. Connect Cat6 cable to transmi er
4. IR In / IR OUT
• 3.5mm IR input port for connec on to IR receiver or IR system
• 3.5mm IR output port for connec on to IR emi er
5. AUDIO CONTROL
• ARC - When ARC mode is selected, an HDMI cable from the HDMI OUT should connect to an ARC compa ble
input on a display, digital audio will then de-embed from the TOSLINK OUT on the DL-HD2100 transmi er
• TOSLINK - When TOSLINK mode is selected, a Toslink cable should be connected from the displays digital audio
output to the TOSLINK IN on the DL-HD2100 receiver, digital audio will then de-embed from the TOSLINK OUT
port of the DL-HD2100 transmi er
6. RS232
• 3 pin Phoenix connector port for connec ng / passing RS232 control from transmi er loca on
7. HDMI In
• HDMI input port for connec ons to video sources
8. Ethernet
• RJ45 port for passing Ethernet from transmi er
9. TOSLINK IN
• Digital audio return channel input port for injec ng digital audio signal from display (only in TOSLINK mode)
1 2 3 4 5 67 8 9

Connec vity Instruc ons
1. Verify all components included with the extender set are present before
installa on.
2. If the extenders are going to be permanently mounted to a surface, a ach the
included moun ng brackets with the supplied screws.
3. Turn off power and disconnect the audio/video equipment by following the
manufacturer’s instruc ons.
4. Connect Category 6 or greater twisted pair cable with RJ45 connectors between
the transmi er and the receiver. TIA/EIA-568B straight-through wiring connec ons
must be used with all HDBaseT extenders.
5. Connect an HDMI cable and any desired control accessories between the
display and the receiver.
6. Connect an HDMI cable and any desired control accessories between the source
and the transmi er.
7. Connect the included power supply to the transmi er or receiver and lock the
power supply to the power connector by twis ng the locking collar clockwise.
8. Power on a ached audio/video devices.
Passing IR Signals:
The DL-HD2100 is capable of passing IR signals between 33 and 55 KHz. To
prevent damage to any of the electronics, the extenders should be powered off
while inser ng or removing any IR components. Inser ng an IR transmi er into
the IR IN port may damage the IR circuit for that extender.
IR OUT: The IR transmi er (IR emi er) must be plugged into the IR OUT port.
IR IN: The IR receiver (IR eye) must be plugged into the IR IN port.
To connect to a 3rd party IR system such as a control system, connect the TS
connector of the IR-AC coupling cable to the IR output port of the control
system and connect the TRS connector of the IR-AC cable to the IR IN to either
transmi er or receiver of the DL-HD2100.

TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connec on between send and receive
units.
Cabling Requirements
RS232 Wiring
Connect the controller or device RXD signal
to Tx on the DL-HD2100 extender. Connect
the controller or device TXD signal to Rx on
the DL-HD2100 extender.
To ensure proper performance of the DL-HD2100, it is recommended that you use solid core
Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may perform well but may not
support power over HDBaseT reliably.
For op mized performance use the following Liberty Wire and Cable branded cabling;
Category 6 plenum; 24-4P-P-L6SH
Category 6 NON-plenum; 24-4P-L6SH
Category 6A plenum; 24-4P-P-L6ASH
Category 6A NON -plenum; 24-4P-L6ASH
When using shielded category cabling ALWAYS...
....use shielded connectors
....properly ground the category cable
Tx RXD
GND
Rx TXD
DL-HD2100
(TX/RX)
Controller or
Device

rev 181010
Liberty AV Soluons
11675 Ridgeline Drive
Colorado Springs, CO 80921
800-530-8998
[e-mail]
Technical Specicaons
Supported Audio and Video
Video Compliance HDMI 2.0+, HDCP 2.2, ARC (Audio Return Channel) and CEC (Consumer Electronics Control)
Input / Output Resoluon Support SMPTE: Up to 4096x2160@60Hz (4:4:4 chroma sub-sampling / 8 bit deep color)
VESA: Up to 1920x1200
Maximum Pixel Clock 594MHz
Embedded Audio Up to PCM 8 channel, Dolby Atmos, DTS: X, Dolby TrueHD, DTS-HD Master Audio, Dolby Digital
and DTS
IR Carrier Frequency Range 33-55kHz at 5 volts
RS232 Baud Rate Up to 115200 baud
HDBaseT Signal Characteriscs
Maximum Distance 1080p: 100 meters / 328 feet
4K@60Hz 4:4:4: 70 meters / 229 feet
Cable Requirements Solid core F/UTP Category 6 cable or greater with TIA/EIA-568B crimp paern
Bandwidth 18 Gbps (compressed) / 10.2 Gbps (uncompressed)
Chassis and Environmental
Dimensions TX- 195mm x 94.8mm x 21mm (7.7 in. x 3.7 in. x 0.8 in.)
RX- 195mm x 94.8mm x 21mm (7.7 in. x 3.7 in. x 0.8 in.)
Operang Temperature (Environment) TX/RX - 0° to +45° C (+32° to +113° F)
Operang Temperature (Chassis) 31° C (88° F) (TX); 38° C (100° F) (RX)
Operang Humidity (Environment) 10% to 90%, Non-condensing
Product Weight 0.4kg / 2.2 lbs
Power
Maximum Power Consumpon 27 was (TX)- when receiver is powered by transmier
27 was (RX) - when transmier is powered by receiver
Power Supply Input Voltage 100-240V AC at 50-60 Hz
Power Supply Output Voltage DC 12V 3A
ESD Protecon ±8kV(Air-gap discharge)/
±4kV(Contact discharge)
Surge Protecon Voltage: ±1 kV
Regulatory CE, FCC
Other
Standard Warranty 5 Years
Included Items (1) Transmier, (1) Receiver, (1) Quick Install Guide, DC 12V Power Supply with US, UK, EU
and AU adapters, (2) IR Transmiers, (2) IR Receivers, (1) IR-AC IR coupler cable, (4) Mounng
Brackets, Mounng Screws

Thank you for your purchase.
For Technical Support please call our toll free number at
800-530-8998 or email us at [e-mail]
www.libav.com
