DIGITECH Audio AC1773 User manual

Dear Customer,
Thank you for purchasing this product. For optimum performance and safety, please
read these instructions carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
The HDMI to Composite Video Converter (with Audio) converts a digital HDMI video
source (with supporting audio) to work with analog Composite video televisions and
displays in both NTSC 480i and PAL 576i systems. Support for a wide range of HDTV
and PC input resolutions make this versatile HDMI converter a perfect solution for
using newer devices with existing legacy displays.
HDMI TO RCA CONVERTER
1.0 INTRODUCTION

Input Video Signal: HDMI
Output Video Signal: Composite
HDMI Input Resolution: [email protected]@60Hz, 1024x768@60Hz,
1280x720@60Hz, 1280x1024@60Hz, 1360x768@60Hz,
1600x1200@60Hz, 1920x1080@60Hz, 480i@60Hz,
480p@60Hz, 576i@60Hz, 576p@60Hz, 720p @50/60Hz,
1080i @50/60Hz 1080p @50/60Hz
Supported TV Standard: PAL/NTSC M.(NTSC-J)
Operating Temperature: 0° to 70°
Operating Humidity: 10% to 85% RH (no condensation)
Power Consumption: 5W
Weight: 42g
Dimensions: 67(W) x 21(H) x 57(D)mm
3.0 SPECIFICATION
4.0 BOX CONTENTS
5.0 PANEL DESCRIPTION
• The ability to convert HDMI input to be used with legacy televisions adds exibility and
saves the cost of upgrading hardware
•Compact form factor and simple plug-and-play installation for fast, easy integration into
your A/V environment
•Low power consumption
•Support NTSC and PAL two standard TV formats output
•Support HDMI input resolution up to 1080P@60Hz
2.0 FEATURE
The converter doesn’t support audio decoding. Please assure the output audio
format of the input device is set to LPCM in case there is no sound output for the
converter.
Specication is subject to change without notice.

Input Video Signal: HDMI
Output Video Signal: Composite
HDMI Input Resolution: [email protected]@60Hz, 1024x768@60Hz,
1280x720@60Hz, 1280x1024@60Hz, 1360x768@60Hz,
1600x1200@60Hz, 1920x1080@60Hz, 480i@60Hz,
480p@60Hz, 576i@60Hz, 576p@60Hz, 720p @50/60Hz,
1080i @50/60Hz 1080p @50/60Hz
Supported TV Standard: PAL/NTSC M.(NTSC-J)
Operating Temperature: 0° to 70°
Operating Humidity: 10% to 85% RH (no condensation)
Power Consumption: 5W
Weight: 42g
Dimensions: 67(W) x 21(H) x 57(D)mm
l. Main Unit
2.USB Power Cable
3.User Manual
3.0 SPECIFICATION
4.0 BOX CONTENTS
5.0 PANEL DESCRIPTION
• The ability to convert HDMI input to be used with legacy televisions adds exibility and
saves the cost of upgrading hardware
•
your A/V environment
•Low power consumption
•Support NTSC and PAL two standard TV formats output
•Support HDMI input resolution up to 1080P@60Hz
2.0 FEATURE
NOTE:
1. The converter doesn’t support audio decoding. Please assure the output audio
format of the input device is set to LPCM in case there is no sound output for the
converter.
2. Specication is subject to change without notice.

Distributed by:
TechBrands by Electus Distribution Pty. Ltd.
320 Victoria Rd, Rydalmere
NSW 2116 Australia
Ph: 1300 738 555
Int’l: [phone]
Fax: [phone]
www.techbrands.com
Note: The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and other countries.
6.0 CONNECTION & OPERATION
Composite
Video + Audio
TVGaming Console
