Planet IECC-210T User manual

Industrial EtherCAT Media Converter Kit
IECC-210T/IECC-210R
User’s Manual

Table of Contents
1. Package Contents................................................................................. 3
2. Product Features .................................................................................. 4
3. ProductSpecications ........................................................................... 5
4. Hardware Introduction .......................................................................... 6
4.1 Three-View Diagram....................................................................... 6
4.2 Wiring the Power Inputs................................................................. 8
4.3 Grounding the Device..................................................................... 9
5. Installation ........................................................................................ 10
5.1 DIN-rail Mounting Installation ....................................................... 10
5.2 Wall-mount Plate Mounting ........................................................... 11
5.3 Side Wall-mount Plate Mounting.................................................... 11
6. Getting Started .................................................................................. 12
6.1 Connecting the Power and the Host PC.......................................... 12
 6.2 CongurationandOperation ......................................................... 14
Customer Support.................................................................................... 16

3
1. Package Contents
Thank you for purchasing PLANET Industrial EtherCAT Media Converter Kit. In
the following sections, the term “Industrial EtherCAT Media Converter Kit”
means the IECC-210T and IECC-210R.
Open the box of the Industrial EtherCAT Media Converter Kit and carefully
unpackit.Theboxshouldcontainthefollowingitems:
IECC-210T and IECC-210R QRcodesheetx1
Wall-mountKitx2 SFPdustcapx2 Copperdustcapx2
If any of these are missing or damaged, please contact your dealer
immediately; if possible, retain the carton including the original packing
material, and use them again to repack the product in case there is a need to
return it to us for repair.

4
2. Product Features
z1x100BASE-TXRJ45businterface
z1x100BASE-FXSFPslotinterface
zLED indicators for the input status
z9 ~ 48V DC wide input voltage range
zSupportsEtherCATDistributedClock(DC)mode
zEtherCATconformance testtoolveried

5
3.ProductSpecications
Model IECC-210T IECC-210R
Communication Interface
Copper
Port 1x100BASE-TXRJ45
Distancebetween
Stations max.100m(100BASE-TX)
Data Transfer Medium Ethernet/EtherCATcable(min.cat5),
shielded
Fiber
Port 1x100BASE-FXSFPslot
Distancebetween
Stations DependingontheabilityofSFPmodule
Data Transfer Medium DependingontheabilityofSFPmodule
EtherCAT
Protocol EtherCAT
Power
Input Voltage Range 9~48V DC
Power Consumption 1.92Wmax.
Mechanical
Dimensions(WxDxH) 33x70x104mm
Installation DIN-rail mounting and wall mounting
Case Material IP30 metal
Environment
OperatingTemperature -40~75°C
Storage Temperature -40~75°C
Relative Humidity 5~95%(non-condensing)

6
4. Hardware Introduction
4.1 Three-View Diagram
The three-view diagram of the Industrial EtherCAT Media Converter Kit
consists of one 100BASE-TX RJ45 copper, one 100BASE-FX SFP slot, and
one removable 4-pin power terminal block. The LED indicators are also
located on the front panel.
104.00
30.00
70.00
18.00
9.00
91.00
52.00 52.00
50.00
30.00
21.69
28.65
28.00
48.80 40.00
18.00
40.00
18.00
147.00
Mounting Kit Mounting Kit
DIN-Rail Kit
Unit: mm
Rear ViewSide View Side View
Top View
Front View
Bottom View
P1 P2 Run
IECC-210T
ACTLNK
TP IN
SFP OUT
LNK/ ACT
100BASE-FX
V2+
PWR2
V1+
PWR1
DC Input:
9-48V
, 0.6A max.
Figure 1: IECC-210T/IECC-210R Three-View Diagram

7
Front View
P1 P2 Run
IECC-210T
ACTLNK
TP IN
SFP OUT
LNK/
ACT
100BASE-FX
P1 P2 Run
IECC-210R
ACTLNK
TP OUT
SFP IN
100BASE-FX
LNK/
ACT
Figure 2: IECC-210T/IECC-210R Front View
LED Denition:
System
LED Color Function
P1 Green Lights to indicate power 1 has power.
P2 Green Lights to indicate power 2 has power.
Run Green
Light The device is in the state of operation.
Single
Flash The device is in the state of operation without risk.
Blinking Thedevice isreadytobeoperated.
O The device is in the initialization mode

8
100BASE-TX RJ45 Port (Port Input/Port Output)
LED Color Function
LNK/
ACT Green
Light Indicating that the port is linked up.
Blinking Indicating that the module is actively sending or
receiving data over that port.
O Indicating that the port is linked down.
100BASE-FX SFP Port (Port Input/Port Output)
LED Color Function
LNK/
ACT Green
Light Indicating that the port is linked up.
Blinking Indicating that the module is actively sending or
receiving data over that port.
O Indicating that the port is linked down.
4.2 Wiring the Power Inputs
The4-contact terminal blockconnector on thetop panel of Industrial EtherCAT
Media Converter module is used for one DC power input. Please follow the
stepsbelowtoinsertthepowerwire.
When performing any of the procedures like inserting the wires
or tightening the wire-clamp screws, make sure the power is
OFFtopreventfromgettinganelectricshock.
1. Insert positive and negative DC power wires into contacts 1 and 2 for
POWER.
V2+
PWR2
V1+
PWR1
DC Input:
9-48V
, 0.6A max.
1 2 3 4
Figure 3: IECS-210T/IECC-210R Top View

9
2. Tighten the wire-clamp screws for preventing the wires from loosening.
1234
Power1 Power2
V1+ V1- V2+ V2-
1. The DC power input range is 9-48V DC.
2. The device provides input voltage polarity protection.
PWR1 and PWR2 must provide exactly the same DV voltage for
powerloadbalancewhileoperatingwithdualpowerinput.
4.3 Grounding the Device
Users MUST complete grounding wired with the device; otherwise, a sudden
lightning could cause fatal damage to the device.
V2+
PWR2
V1+
PWR1
DC Input:
9-48V
, 0.6A max.
1 2 3 4
Earth Ground
EMD(Lightning) DAMAGEISNOTCOVEREDUNDERWARRANTY.

10
5. Installation
This section describes the functionalities of the Industrial EtherCAT Media
Converter module’s components and guides you to installing it on the DIN rail
andwall.Pleasereadthischaptercompletelybeforecontinuing.
This following pictures show the user how to install the device,
and the device is not IECC-210-KIT.
5.1 DIN-rail Mounting Installation
1
2

11
5.2 Wall-mount Plate Mounting
5.3 Side Wall-mount Plate Mounting
You must use the screws supplied with the wall-mounting
brackets. Damage caused to the parts by using incorrect screws
would invalidate your warranty.

12
6. Getting Started
This chapter provides a basic overview of how to congure and operate your
IECC-210 series.
6.1 Connecting the Power and the Host PC
Step 1: Connect both the TP IN port of the IECC-210T and RJ45 Ethernet
port of Host PC.
 Ensurethat the network settings on the Host PC havebeen correctly
congured and are functioning normally. Ensure that the Windows
rewall and any anti-virus rewall is properly congured to allow
incomingconnections; ifnot,temporarilydisablethesefunctions.
Attaching an ESC (EtherCAT Slave Controller) directly to an
office network will result in network flooding, since the ESC will
reflect any frame – especially broadcast frames – back into the
network(broadcaststorm).
Step 2: Apply power to the IECS-210T
PC
V+
+
9-48V
DC
Connect the Host
device to the IN Port on
IECC-210T
Connect the V+ pin to positive
terminal on a 9-48V DC power
supply, and connect the V- pin to
the negative terminal.
V+
V+

13
Step 3: Verify the “P1” LED indicator on the IECC-210T module is Green;
“TP IN” LED indicator is Green.
P1 P2 Run
IECC-210T
ACTLNK
TP IN
SFP OUT
LNK/
ACT
100BASE-FX
ACTLNK
P1 P2

14
6.2 CongurationandOperation
BeckhoTwinCAT 3.x isthemost commonly used EtherCATMaster software to
operate the IECC-210T and IECC-210R.
ClickonthelinkbelowtodownloadBeckho TwinCAT3.x:
https://www.beckho.com/en-en/support/download-nder/software-and-tools/
Inserting into the EtherCAT network
InstallationofthelatestXMLdevicedescription(ESI).
Make sure to use the latest installation description to install the
latest XML device. This can be downloaded from PLANET website
(https://www.planet.com.tw/en/support/downloads?method=key
word&keyword=IECC-210-KIT)andchecktheonlineFAQsforthe
installationoftheXMLdevice.

15
Step 1: Automatic Scanning
zThe EtherCAT system must be in the safe, de-energized state before the
IECC-210-KIT module is connected to EtherCAT network.
zSwitchontheoperatingvoltage,opentheTwinCATSystemManaged(Cong
mode), and scan the devices as shown in the print screen instructions
below. Acknowledge all dialogs with “OK”, so that the conguration is in the
“FreeRun” mode.
Scanning the conguration
(I/O Devices -> right-click -> Scan Devices…)
Step 2: CongurationviaTwinCAT
In the left-hand window of the TwinCAT System Manager, click on the brand
of the EtherCAT Box you wish to congure (IECC-210T and IECC-210R in this
example).ClickBox1orBox2togetandcongurestate.

16
Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resource on PLANET web site rst to check if it could solve your issue. If you
need more support information, please contact PLANET switch support team.
PLANETonlineFAQs:
http://www.planet.com.tw/en/support/faq.php
Supportteammailaddress:
[email protected]
Copyright © PLANET Technology Corp. 2023.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
