PureLink SC-DS1 User manual

SC-DS1
3G HDMI/DVI to HD-SDI/SDI Video Converter
User’s Manual
Dtrovision Locations
9A Bergen Tpke Little Ferry, NJ 07643 USA
Tel: [phone]
Fax: [phone]
E-mail: suppor[email protected]om
www.dtrovision.com
For order support, please contact your local dealer.
For technical support, please contact us at [email protected]

Unpacking
Each DTROVISION HD/SDI converter package includes the following items;
DTROVISION HD/SDI (SC-DS1) Unit
One (1) 5V, 3A Power SupplyAdapter
User manual
CONTENTS
Contents 1-1
Description, General Specification 1-2
Environmental and Reliability Specifications 1-3
Supported I/O Resolutions 1-4
Panel Descriptions 1-5
Mechanical Specification 1-6
Technical Specification 1-7
Warranty Information 1-8
Troubleshooting 1-9
1-1 Contents

DescriptionGeneralSpecification
DTROVISION SC-DS1
ITEM DESCRIPTION
Model Name SC-DS1
Input Signal DVI/HDMI
Output Signal HD-SDI
VIDEO
Input format RGB(444), YCbCr(444), YCbCr(422)
VIDEO
Output format YCbCr(422)
Input format
AUDIO I2S / 48Khz
Receptacle DC Power Jack for +5V power in the rear panel
Power Consumption DC +5V, 3A
Dimension 117 x 105 x 33 mm
1-2 Description, General Specification

EnvironmentalandReliabilitySpecifications

[Recommended Operating Conditions]
Parameter Symbol Min. Typ. Max. Units
Operating Temp. TA10 25 + 40 °C
Storage Temp. Ts-25 + 60 °C
StorageHumidityHs10 80 RH%


1-3 Environmental and Reliability Specifications

Supported I/O Resolutions
VIDEO INPUT
Input – Data Format DVI/HDMI format
RGB(444), YCbCr(444), YCbCr(422)
Input – Connector DVI-I / HDMI female connector
Input - Resolution 1080p(60/59.94), 1080i(60/59.94,50), 1080p(25/24/23.976) 720p(60/59.94/50), 480i(59.94),
576i(50)
VIDEO OUTPUT
Output - Data Format SMPTE format YCbCr(4:2:2)
Output - Connector SDI BNC
Output Signal Resolution
SMPTE-424M 1080p (60/59.94)
SMPTE-274M 1080i (60/59.94/50)
SMPTE-296M 1080p (25/24/23.976)
SMPTE-260M 720p(60/59.94/50)
SMPTE-259M 480i (59.94), 576i(50)
AUDIO DATA FORMAT
Data Format I2S
Sampling Rate 48 kHz
1-4 Supported I/O Resolutions

Panel Descriptions
< Front-Video Input >
zStatus indicator LED
1) Video sync detection LED
2) DVI input connection status LED
3) HDMI input connection status LED
zHDMI Input port
zDVI Input port
z5V power jack
< Rear-Video Output >
zPower switch
zPower indicator light
zFirmware update PS2 port (Programmer use only)
zHD-SDI outputs
1-5 Panel Descriptions

MechanicalSpecification
[Dimensions]
SC-DS1: 117 x 105 x 33 (mm)
[Connector]
DVI Connector: DVI-I 29-pin female (Digital only)
HDMI Connector: HDMI female
HDSDI/SDI Connector: BNC female
Firmware Download Port: PS2 female
[Power].
Power: +5V DC Toggle switch ON/OFF
[LED Indicators]
Power: Power On
HDMI: HDMI input
DVI: DVI input
1-6 Mechanical Specification

TechnicalSpecification
[Data rates and Maximum resolution]
Data rates and Resolution
Input Video Bandwidth 2.97Gbps
Output Video Bandwidth 2.97Gbps
Maximum Input Resolution 1920x1080p/60Hz
Maximum Output Resolution 1920x1080p/60Hz
※ The HDMI input is prior to DVI input when HDMI and DVI port is concurrently connected to video source.

1-7 Technical Specification
WarrantyInformation
1 (One) Year Warranty
DTROVISION warrants SC-DS1 HD/SDI converter to be free from defects in workmanship and materials,
under normal use and service, for a period of one (1) year from the date of purchase from DTROVISION
or its authorized resellers.
If a product does not work as warranted during the applicable warranty period, DTROVISION shall, at its
option and expense, repair the defective product or part, deliver to customer an equivalent product or part
to replace the defective item, or refund to customer the purchase price paid for the defective product.
All products that are replaced will become the property of DTRPVISION.
Replacement products may be new or reconditioned.
Any replaced or repaired product or part has a ninety (90) day warranty or the reminder of the initial
warranty period, whichever is longer.
DTROVISION shall not be responsible for any software, firmware, information, or memory data of
customer contained in, stored on, or integrated with any products returned to DTROVISION for repair
under warranty or not.
Warranty Limitation and Exclusion
DTROVISION shall have no further obligation under the foregoing limited warranty if the product has
been damaged due to abuse, misuse, neglect, accident, unusual physical or electrical stress,
unauthorized modifications, tampering, alterations, or service other than by DTROVISION or its
authorized agents, causes other than from ordinary use or failure to properly use the Product in the
application for which said Product is intended.
1-8 Warranty Information
