Digitus DN-16111 User manual

NETWORK
VIDEO RECORDER
10/100/1000 Mbps
4-CHANNEL/8-CHANNEL
16-CHANNEL
Quick Installation Guide
DN-16111 DN-16112 DN16113

2 DN-16111, DN-16112, DN-16113 - Quick Installation Guide
Table of Contents
System Overview ................................................................................................3
Front View...................................................................................................................... 3
Rear View ....................................................................................................................... 3
LED & Buttons Definitions........................................................................................... 3
HDD Installation ..................................................................................................4
1. Remove the cover ................................................................................................. 4
2. Install HDD................................................................................................................. 5
3. Install SATA Cable ................................................................................................ 5
Connect to the NVR ............................................................................................6
Use NVR Search Utility............................................................................................... 6
Access the NVR with its default IP address ............................................................. 11

System Overview
Front View
Rear View
LED & Buttons Definitions
LEDs Status Definitions
Power On Solid- Power on
Alarm On Blinking when a system/camera event occurs.
each event
None Goes off if reaches the 10-second duration, or when buzzer stop button is pressed
(if buzzer is triggered)
Status On *Solid- Normal operation
**Blinking after press and hold the reset button for 5 seconds indicates the device will enter the restore
default process. Other LEDs remain unchanged during this state.
*Blinking during firmware upgrade(web page upgrade or USB upgrade)
*Keep blinking for failed firmware upgrade through USB disk or web
None *When system is unable to start properly
Network On *Solid for activity on a 10/100M/1Gbps network
Buttons
Manual record ON Press and hold for 2 seconds
OFF Press and hold for 2 seconds
Reset Restore default Press and hold for 10 seconds
Restart Press and hold for 2-10 seconds
Buzzer stop STOP Press and release should stop buzzer right away

4
H
D
1.
R
Re
m
Re
m
DN-161
1
D
D Inst
a
R
emove
t
m
ove the s
m
ove the t
o
1
1, DN-161
1
a
llation
t
he cove
r
crews on
b
o
p case b
y
1
2, DN-161
r
b
oth sides
y
pulling it
t
13 - Quick I
and back
s
t
oward yo
u
nstallation
s
ide(2 on
e
u
.
Guide
e
ach side).

2. Install HDD
Put HDD on NVR.
Fix the HDD on NVR with screws.
3. Install SATA Cable
Install SATA cable on the HDD

6 DN-16111, DN-16112, DN-16113 - Quick Installation Guide
Connect to the NVR
There are various ways you can connect to the NVR and below are the
suggested methods for different network setup:
• The NVR is placed in a network with a DHCP server: Connect to the NVR
by using “NVR Search” Utility
• The NVR is placed in a network without DHCP server (or you are
connecting to it directly): Access the NVR with its default IP
Use NVR Search Utility
If the NVR is placed in a corporate network or a local area network where a
DHCP server is already presented, run the “NVR Search” utility from a computer
that is on the same network and locate the NVR with its IP address that is
assigned by the top-level DHCP server.

To begin, launch the “NVR Search” utility from the CD and proceed with the
installation:

8 DN-16111, DN-16112, DN-16113 - Quick Installation Guide
Once the installation is complete, check the “Launch the Search AP” option and
click “Finish”.
The search should start automatically and its status should be dis- played.

The NVR should be located and its IP address should be displayed.
Double-click on an NVR and the search program should automatically access the
NVR’s web administration page from your default browser.

10 DN-16111, DN-16112, DN-16113 - Quick Installation Guide
You should be prompted for the NVR’s username and password. Enter its
default username “admin” and password “admin” and then click ”OK” to
enter the system
Please make sure you are using Internet Explorer 7 or above
If you are running Windows Vista or 7, please make sure you are running
Internet Explorer with the “administrator” privilege.

Access the NVR with its default IP address
The NVR comes with a pre-configured static IP “192.168.0.10”. However, it is
only used when there is no DHCP server presented in the network. The NVR will
turn on its DHCP server function and act as the DHCP server in the network. To
connect to the NVR, use a PC that is on the same network over a switch or hub,
or connect the PC directly to the NVR using a crossover CAT5 Ethernet cable.
The PC that is connected directly to the NVR (or within the same local area
network) should receive an IP from the NVR. Simply access the NVR from your
web browser with its IP address
