Digitus DA-70135-1 User manual

USB 2.0 Sharing Switch
User Manual
Model: DA-70135-1 & DA-70136-1
Getting started with USB 2.0 Sharing Switch
Thank you for choosing the USB 2.0 Sharing Switch.
Today, USB connections can be found in various devices, from PC cameras to
scanners, printers, Hubs, and KVM switches, As USB technology continues its
reign in the computer peripheral market, USB 2.0 Sharing Switches offer a
completely cost-effective solution for the small business and home user to
manage their network layout.
These sharing switches are ideal for multiple PCs to share one USB
device. The USB 2.0 sharing Switch has designed a user-friendly interface that
makes device sharing easier. No more extra complex driver download
procedures are necessary. Only a few clicks and you can start to explore the
USB adventures.

Installation
DA-70135-1
2 x USB B Type connectors connect to each PC and 1 USB A Type connector
attaches to the USB device(s).
Installation
DA-70136-1
4 x USB B Type connectors to each PC and 1 USB A Type connector attaches
to the USB device(s).

Software Installation
First insert the CD (AP Software) into your CD-ROM drive. The language dialog
box will pop up.
If installation does not start automatically, start Windows Explorer, navigate to
your CD-ROM drive and double-click the setup.exe file.
Confirm the English (or the required languages) is selected as the installed
language, and then click OK. The installation setting dialog box is displayed.

The default directory is C:\Program Files\USB Sharing. If the drive letter where
you would like to install is different from C, browse the drive instead. Click “Next”
to confirm the change.
When the Installation successful, the dialog is display, click “Finish” to close all
of the open windows, and then reboot your computer.

After your computer is rebooted, there will be as shortcut on your desktop
and a icon on the lower right corner of your screen.

Operation

It is important for end users to realize that storage devices such as, external hard
drives, and printers, will continue to send signals back and forth to your
computer when ever they are connected. While this is happening, USB auto
sharing will be confused by this signal and an indication icon will appear red and
blinking. If you would like to have the controlling power of USB auto sharing
without device busy considerations, simply press “Ctrl” + F11. The confirmation
message will then pop up. Simply click “Yes” to confirm the switch.
You still can switch from one computer to another even though the application is
not installed (Mac Linux OS). When the LED light is lit that indicates the PCs are
already connected with the device. Please be aware that switching computers by
the panel Select button will force the device to switch with the computer.
Note: Please refer to read me file for more detail if you have other
questions.

Software Un-installation
1. In order to completely remove the software application from your PC, please
insert the CD-ROM into your CD-ROM drive. Confirm the default language in
English and click OK. The file deletion dialog will appear and click OK to confirm.
2. Also, you can uninstall the software from “Add or Remove Programs” under
Control Panel. Click “Add or Remove” button and the Choose Setup Language
box will display. Confirm the default language in English and click OK. The file
deletion dialog box will appear and click OK to confirm.
Click “Finish” The software un-installation has been completed.
