Digitus DN-95358 User manual

16+2 Port 10/100/1000 Mbps
+ 2 Gigabit SFP PoE Switch
Quick Installation Guide
DN-95358

2
1. Introduction
DN-95358 is a 16-port 10/100/1000Mbps PoE + 2G Gigabit RJ45 +2 Gigabit SFP
PoE switch. The PoE ports can automatically detect IEEE 802.3af/at-compliant
Powered Devices (PDs) and supply them with power. Your network is able to
extend power and data transmission via a single cable to locations where there
are no power lines or outlets that you could use to install devices such as APs, IP
cameras or IP phones and the like. The PoE switch offers a simple, cost-effective
and non-blocking wire-speed performance with 11-inch metal form for rack
installation in office or department networks.
2. Features
16*10/100/1000Mbps PoE RJ45 connections
2*10/100/1000Mbps RJ45 connections
2*1000Mbps SFP connections
Standard: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x
Corresponds to IEEE802.3af/at Power over Ethernet
PSE Power on RJ45: Mode A 1/2(+), 3/6(-), Mode B 4/5(+), 7/8(-)
Supports PoE power up to 32W for each PoE port
PoE power budget: 185W
Energy supply: 200W
Automatic detection of power supply device
Remote supply of power and data up to 100 m
Flow control for full duplex operation and back pressure for half duplex
operation
Supports VLAN and CCTV function
8K MAC address, automatic address learning and address aging
Supports energy-efficient Ethernet (EEE) function EEE802.3az
Supports the PD alive function
LED: PWR, PoE, LINK/ACT, PoE Max
Transmission mode: Store and forward
Switching capacity: 40Gps
Packet forwarding rate: 29.76Mpps
Packet buffer: 4M bit

3
3. Package Contents
PoE Switch x 1
User Guide x 1
Power Cord x 1
Hanging ears x 2
Rubber Feet x 4
Screw x 8
4. Specifications
Model
16+2 Port 10/100/1000 Mbps + 2 Gigabit SFP
PoE Switch
Standard
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z,
IEEE802.3x, IEEE802.3af, IEEE802.3at
Network Media (Cable)
10BASE-T: UTP category 3,4,5 cable (≤100m)
100BASE-TX: UTP category 5 cable (≤100m)
1000BASE-T: UTP category 5e cable (≤100m)
1000BASE-X: MMF or SMF SFP module
MAC Address Table
8K Auto-learning, Auto-aging
Transfer mode
Store-and-Forward
Frame Forward Rate
10Base-T: 14881pps/Port
100Base-TX: 148810pps/Port
1000Base-T/X: 1488095pps/Port
Switching Capacity
40Gbps
Dimensions (L*W*H)
280*180*44mm
Fan
1*Fan
PoE Power budget
185W
Power Input
AC: 100~240V, 50/60Hz
PoE Port
Port1~16
PoE Power on RJ45
Mode A 1/2(+), 3/6(-) Mode B 4/5(+), 7/8(-)
PoE Power Output
Voltage: 55V DC Power: 32W(Max)
PoE Power budget
185W
Temperature
Operating Temperature: 0°C ~ 40 °C (32 °F ~104°F)
Storage Temperature: -40 °C ~ 70 °C
(-40 °F~158°F )
Humidity
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing

4
5. Hardware Description
Front Panel
The Front Panel Consists of 16-Port 10/100/1000Mbps Auto-Negotiation Ethernet
RJ45 Ports, 2-Port Gigabit RJ45 Port and 2*1000Mbps SFP port. The LED
indicators also on located on the panel.
LED
indicator
DIP
Switch
16*10/100/1000Mbps
PoE Port
2*10/100/1000
Mbps port
2*1000 Mbps
SFP port
LED indicator
LED
Color
Function
PWR
Green
Off: No Power supply
Light: Indicates the switch has power
LNK/ACT
Green
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully.
Blink: Indicates that the Switch is actively sending or
Receiving data over that port.
PoE
Orange
Off: No PoE powered device (PD) connected
Light: There is a PoE PD connected to be port, which
supply power successfully.
Blink: Indicates port abnormal power supply
Max
Green
Off: PoE power is less than 80% of total power.
Light: PoE power above 80%.
DIP Switch: The DIP switch located on the left panel.
Default: the factory default mode, can normal communication between port 1~20.
VLAN: 1-16 port can be isolated each other but 1-16 port can connect to 17~20
port after open VLAN to stop broadcast storm to increase forwarding rate of frame.
CCTV: 1-16 port can be isolated each other but 1-16 port can connect to 17~20
port after open CCTV, 10Mbps Up to 250m PoE distance allows you to expand you
network via Ethernet cable but where you want to fix device such as IP Cameras.
Note: After change the mode, there is no need to restart manually to make the

5
corresponding configuration take effect.
Rear Panel
The rear panel of 16GE(PoE)+2GE+2G SFP PoE Switch indicates an AC inlet power
socket, Grounding Column.
Fan
Power Socket
Grounding Column
Installation the Switch
This part describes how to install your Ethernet Switch and make connections to
it. Please follow the following instructions in avoid of incorrect installation
causing device damage and security threat.
Before cleaning the switch, unplug the power plug of the switch first. Do not
clean the switch with wet cloth or liquid;
Do not place the switch near water or any damp area. Prevent water or
moisture from entering the switch chassis;
Do not place the switch on an unstable case or desk. The switch might be
damaged severely in case of a fall;
Ensure proper ventilation of the equipment room and keep the ventilation
vents of the switch free of obstruction;
Make sure that the operating voltage is the same one labeled on the switch;
Do not open the chassis while the switch is operating or when electrical
hazards are present to avoid electrical shocks.

6
Desktop Installation
Install the Switch on a desktop, please attach these cushioning rubber feet
provided on the bottom at each corner of the Switch in case of the external
vibration. Allow adequate space for ventilation between the device and the
objects around it. The installation diagram is as follows:
Rack-mountable Installation
The switch is rack-mountable and can be installed on an EIA-11 inch equipment
rack. To do this, first, please install the mounting brackets on the switch’s side
panels (one on each side), secure them with the included screws, and then use
the screws provided with the equipment rack to mount the switch on the 11 inch
rack.

7
Turn on the switch
Plug in the negative connector of the provided power cord into the power socket
of the device, and the positive connector
into a power outlet. After the device is powered on, it begins the Power-On Self-
Test. The PWR LED indicator will light on all the time
CE Mark Warning: This is a Class A product. In home environment, this product
may cause radio interference. In this case, the user may be required to take
appropriate measures.
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is
part of the shipping content. If the Declaration of Conformity is missing, you can
request it by post under the below mentioned manufacturer address.
