Digitus DN-80212 User manual

Gigabit Switch
Web Management
16-Port + 2 Gigabit SFP
(IPv6)
Quick Installation Guide
(DN-80212)
FCC Warning
This device has been tested and found to
comply with limits for a Class A digital device,
pursuant to Part 2 and 15 of FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates and radiates radio
frequency energy and, if not installed and
used in accordance with the user’s manual, it
may cause interference in which case users
will be required to correct interference at their
own expenses.
CE Warning
This is a Class A product. In a domestic
environment, this product may cause radio
interference in which case the user may be
required to take adequate measures.
Introduction
The Switch provides 16 x
10/100/1000Mbps NWAY RJ-45 ports and
additional 2 Gigabit SFP Open Slot to uplink.
It is designed for easy installation and high
performance in an environment where the
traffic on the network and the number of user
increased continuously. With the newest
Gigabit chip set, 19” Gigabit Ethernet switch
can fully support the highest speed without
hanging on problem even when Full-Duplex is
full loaded.
The switch also provides automatic
crossover detection functionality on each
port. It is simple and easy up-link to another
switch without any crossover cable.
The rack-mount size is specifically
designed for medium to large workgroups.
The switch can be installed where the space
is limited; moreover, it provides smooth
network migration and easy upgrade the
network capacity. The 19” size can be
rack-mount on 19” cabinet.
Key Features
Complies with IEEE 802.3 Ethernet,
IEEE 802.3u Fast Ethernet ,IEEE 802.3ab
Gigabit Ethernet Standards
Provides 16 x 10/100/1000Mbps RJ-45
ports and 2 Gigabit SFP Open Slot
19” rack-mount size
Non-blocking & Non-head-of-line blocking
full wire speed forwarding
Store-and-forward operation support
Supports 9 KB JUMBO packet
Provides 16K MAC address entry
Supports broadcast storm filtering
All ports provide Auto-Negotiation and Auto
-MDI/ MDI-X functions
Supports flow control: back pressure for
Half-duplex and IEEE 802.3x for Full-duplex
mode
Smart plug & play
Package Contents
Before you start to install this Switch, please
verify your package contain the following
items:
•One Gigabit Ethernet Switch
•Rack-mount Kit for Rack Installation
•One AC Power Cord
•One CD ( User’s Manual)
Note: If any of these items is missing or
damaged, please contact your local supplier for
replacement.
Front Panel (LEDs)
LED Indicators of 16 Ports Gigabit
+ 2 Gigabit SFP Ethernet Switch
LED Status Description
Power On Power on
off Power off
LINK/ ACT
Port 1~16
On Link
Flashing Data activating
1000M
Port 1~16
On Gigabit Speed
Off Not Gigabit Speed
SFP
Port 17 –
18
On SFP module is plugged
Off No SFP module is
plugged

Connections
Switch/Hub to this 16 Ports Gigabit
+ 2 Gigabit SFP Ethernet Switch
This switch provides automatic crossover
detection functionality for any port. It is
simple and easy up-link to another switch
without any crossover cable.
PC/Other devices to this 16 Ports
Gigabit + 2 Gigabit SFP Ethernet Switch
Via a twisted pair cable straight through, this
switch can be connected to PCs, servers and
other network devices.
Rear Panel (Power)
AC input
AC input (100~240V/AC, 50~60Hz)
Technical Specifications
Standards
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3ab 1000BaseT
IEEE 802.3z 1000BaseX
IEEE 802.3x Flow control
IEEE 802.3ad
Trunk (Link Aggregation)
IEEE 802.1Q VLAN
IEEE 802.1p Class of Service
IEEE 802.1x Port Based
Network Access Control
IEEE 802.1d
Spanning Tree Protocol
IEEE 802.1w Rapid
Spanning Tree Protocol
Features
RJ-45 Ports: 16
Gigabit SFP Ports: 2
MAC Address: 16K
Buffer Memory: 3.5Mb
Jumbo Frames: 9KB
Method: Store and Forward
Filtering/
Forwarding
Rates
1000Mbps port – 1,488,000pps
100Mbps port – 148,800pps
10Mbps – 14,880pps
Transmission
Media
10BaseT Cat. 3, 4, 5 UTP/STP
100BaseTX Cat. 5 UTP/STP
1000BaseT Cat. 5E UTP/STP
LED
Indicators
Per Port: LINK/ACT, 1000M ,
SFP
Per Unit: Power
Power
Requirement 100~240V/AC, 50~60Hz
Power
Budget 25 Watts
Dimensions 440 × 220 × 44 mm
(L x W x H)
Weight 2.75 kgs
Operating
Temperature 0 to 45°
Storage
Temperature -20 to 90°
Humidity 10 to 90% RH
(non-condensing)
Certifications FCC Class A, CE
