Digium TE435B User manual

TE430 Series
TE435B/TE435/TE436B/TE436
User Manual
601-00026 Rev. B

Digium, Inc. Page 2
© Digium, Inc. 2014
All rights reserved.
No part of this publication may be copied, distributed, transmitted, transcribed, stored in a
retrieval system, or translated into any human or computer language without the prior written
permission of Digium, Inc.
Digium, Inc. has made every effort to ensure that the instructions contained in this document
are adequate and error free. The manufacturer will, if necessary, explain issues which may
not be covered by this documentation. The manufacturer’s liability for any errors in the
documents is limited to the correction of errors and the aforementioned advisory services.
This document has been prepared for use by professional and properly trained personnel,
and the customer assumes full responsibility when using it.
Adobe and Acrobat are registered trademarks, and Acrobat Reader is a trademark of Adobe
Systems Incorporated.
Asterisk, Digium, Switchvox, and AsteriskNOW are registered trademarks and Asterisk
Business Edition, AsteriskGUI, and Asterisk Appliance are trademarks of Digium, Inc.
Any other trademarks mentioned in the document are the property of their respective owners.
Digium, Inc.
445 Jan Davis Drive NW
Huntsville, AL 35806
United States
Main Number: 1.256.428.6000
Tech Support: 1.256.428.6161
U.S. Toll Free: 1.877.344.4861
Sales: 1.256.428.6262
www.digium.com
www.asterisk.org
www.asterisknow.org

Digium, Inc. Page 3
Compliance Information
Compliance information for this product is available at
http://www.digium.com/compliance.

Digium, Inc. Page 4
Introduction to TE430 Series Documentation
This manual is a user guide for Digium’s TE430 Series cards. The Digium
TE430 Series cards are a T1/E1 capable card series created for voice. The
cards in this series are as follows:
TE430 Series Cards
Model Features Type
TE435B
TE435
TE436B
TE436
4 Ports, Echo Cancellation
4 Ports
4 Ports, Echo Cancellation
4 Ports
PCI Express
PCI Express
PCI
PCI

Digium, Inc. Page 5
Document Organization
The TE430 Series user’s guide is organized in the following manner:
Chapter/
Appendix Title Description
1Overview Identifies the features of the card you received. This
chapter covers applications and uses of the TE430
Series cards in the real world.
2Card Installation Provides instructions for installing the card in your
PC, acquiring correct drivers, and checking device
compatibility.
3Configuration Provides examples for configuring dial plan options.
4Troubleshooting Explains resolutions to common problems and
frequently asked questions pertaining to card
installation and usage.
APin Assignments Lists the connectors and pin assignments.
BSpecifications Details card specifications.
CGlossary and
Acronyms
Defines terms related to this product.

Digium, Inc. Page 6
Symbol Definitions
Caution statements indicate a condition where damage to the unit or
its configuration could occur if operational procedures are not
followed. To reduce the risk of damage or injury, follow all steps or
procedures as instructed.
The ESD symbol indicates electrostatic sensitive devices. Observe
precautions for handling devices. Wear a properly grounded
electrostatic discharge (ESD) wrist strap while handling the device.
The Electrical Hazard Symbol indicates a possibility of electrical
shock when operating this unit in certain situations. To reduce the
risk of damage or injury, follow all steps or procedures as
instructed.

Digium, Inc. Page 7
Important Safety Instructions
Save these instructions for future reference.
User Cautions
Servicing.
Do not attempt to service this card unless specifically instructed to do
so. Do not attempt to remove the card from your equipment while
power is present. Refer servicing to qualified service personnel.
Water and Moisture.
Do not spill liquids on this unit. Do not operate this equipment in a
wet environment.
Heat.
Do not operate or store this product near heat sources such as
radiators, air ducts, areas subject to direct, intense sunlight, or other
products that produce heat.
Caution. To reduce risk of fire, use only No. 26 AWG or larger
telecommunication line cord.
Attention. Pour réduire les risques d’incendie, utilizer uniquement
des conducteurs de télécommunications 26 AWG au de section
supérleure.
Static Electricity.
To reduce the risk of damaging the unit or your equipment, do not
attempt to open the enclosure or gain access to areas where you are
not instructed to do so. Refer servicing to qualified service personnel.

Digium, Inc. Page 8
TABLE OFCONTENTS
Chapter 1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Echo-Cancellation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
What is Asterisk®? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Asterisk as a Phone Switch (PBX) . . . . . . . . . . . . . . . . . . . . . . . . .18
Asterisk as a Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Asterisk in the Call Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Asterisk in the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Asterisk Everywhere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Chapter 2
Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Unpacking the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Shipment Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Identifying Communication Ports . . . . . . . . . . . . . . . . . . . . . . . . . .22
T1/E1 Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Connecting Timing Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Slot Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Installing Asterisk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Chapter 3
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Digium, Inc. Page 9
Table Of Contents
Configuring Card Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Configuring T1/E1 Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Testing Your Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Chapter 4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Appendix A
Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Appendix B
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Appendix C
Glossary and Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Digium, Inc. Page 10
List of Figures
Figure 1: Sample Legacy Phone Application . . . . . . . . . . . . . .14
Figure 2: Sample Channel Bank Application . . . . . . . . . . . . . .15
Figure 3: Sample IP Phone Application . . . . . . . . . . . . . . . . . .16
Figure 4: TE435B Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Figure 5: TE436B Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Figure 6: Timing Ports Example . . . . . . . . . . . . . . . . . . . . . . . .26
Figure 7: Motherboard Slots . . . . . . . . . . . . . . . . . . . . . . . . . .28
Figure 8: Insert the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Digium, Inc. Page 11
List of Tables
Table 1: Card Identifiers . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Table A-1: RJ45 Telco Port Connector . . . . . . . . . . . . . . . . . . . .57
Table B-2: Maximum Power Consumption . . . . . . . . . . . . . . . . .59

Digium, Inc. Page 12
Chapter 1
Overview
The Digium TE430 Series is a T1/E1 capable card series created for
voice. The cards in this series support industry standard protocols,
including Robbed Bit Signaling (also known as CAS or Channel
Associated Signaling), CCS (Common Channel Signaling), E&M, and
Primary Rate ISDN (PRI). The TE430 Series cards are capable of running
in E1, T1, or J1 modes. They are also capable of DACSing channels from
one span to another. The TE430 Series is ideal for connecting phones to a
channel bank, connecting to your T1/E1 switch, or connecting to a legacy
PBX.
This manual is for use with the TE435/TE435B PCI Express cards and the
TE436/TE436B PCI cards. These cards are identified collectively as the
TE430 Series cards throughout this manual.
Designed to be fully compatible with existing software applications and
integrate fully with the Asterisk platform, the TE430 Series cards allow
many advanced call features.

Digium, Inc. Page 13
Chapter 1: Overview
Voice Modes:
PRI CPE and PRI NET
–NI1
–NI2
–EuroISDN
–4ESS (AT&T)
–5ESS (Lucent)
–DMS100
–Q.SIG
E&M
–Wink
–Feature Group B
–Feature Group D
FXO and FXS
–Ground Start
–Loop Start
–Loop Start with Disconnect Detect
The TE430 Series cards can be used to connect your Asterisk machine to
the PSTN world, your channel bank, or even another PBX. This is
accomplished via a T1/E1 interface. The cards allow Asterisk software to
connect to your network, creating a professional telephony environment.
Figure 2 on page 15 shows an example of the card’s primary application.

Digium, Inc. Page 14
Chapter 1: Overview
Figure 1: Sample Legacy Phone Application
TE4xx
CLEC
T1
PRI
T1
T1
Asterisk
Server
Channel
Bank
Analog
Phones
Legacy
PBX
Legacy
PBX
Legacy
Phones

Digium, Inc. Page 15
Chapter 1: Overview
Figure 2: Sample Channel Bank Application
CLEC
Asterisk
Server
TE4xx
Analog
Phones
PRI
T1
T1
T1
Channel Bank
Channel Bank
Channel Bank

Digium, Inc. Page 16
Chapter 1: Overview
Figure 3: Sample IP Phone Application
CLEC
ASTERISK
SERVER
TE4xx
Switch
Eth
LAN
IP
Phones
PRI
T1
PRI
T1

Digium, Inc. Page 17
Chapter 1: Overview
Echo-Cancellation
Users connecting their TE430 Series cards to the PSTN or other devices
are likely to be placing calls that will result, at some point, in an
unbalanced 4-wire/2-wire hybrid. The result of this hybrid is the
reflection of a near-end echo to the calling party. Elimination of this echo
is the responsibility of echo cancellation.
The TE430 Series cards, unless otherwise equipped, utilize Asterisk to
perform software-based echo cancellation. Asterisk maintains a number
of open source echo cancelers. These open source echo cancelers provide
a moderate level of echo cancellation, but are not capable of dealing with
higher levels of, or more advanced, echoes.
Digium recommends that those users concerned about echo cancellation
purchase the VPM128 hardware echo cancellation module. The VPM128
may be combined with the TE435 (as TE435B) or TE436 (as TE436B)
cards.
The VPM128 is designed to handle up to 128ms of echo cancellation
across all channels and provides a G.168 compliant echo cancellation
solution.
If equipped and not explicitly disabled in chan_dahdi.conf, the VPM128
will automatically operate and cancel all network echo within its tail
range (1024 taps). Users may also purchase Digium's commercial HPEC
software:
http://www.digium.com/en/products/software/hpec.php

Digium, Inc. Page 18
Chapter 1: Overview
What is Asterisk®?
Asterisk is the world’s leading open source telephony engine and tool kit.
Offering flexibility unheard of in the world of proprietary
communications, Asterisk empowers developers and integrators to create
advanced communication solutions...for free. Asterisk is released as open
source under the GNU General Public License (GPL), and it is available
for download free of charge. Asterisk is the most popular open source
telephony software available, with the Asterisk Community being the top
influencer in VoIP.
Asterisk as a Phone Switch (PBX)
Asterisk can be configured as the core of an IP or hybrid PBX, switching
calls, managing routes, enabling features, and connecting callers with the
outside world over IP, analog (POTS), and digital (T1/E1/J1/BRI)
connections.
Asterisk runs on a wide variety of operating systems including Linux,
Mac OS X, OpenBSD, FreeBSD, and Sun Solaris. It provides all of the
features you would expect from a PBX including many advanced features
that are often associated with high end (and high cost) proprietary PBXs.
Asterisk's architecture is designed for maximum flexibility and supports
Voice over IP in many protocols, and can interoperate with almost all
standards-based telephony equipment using relatively inexpensive
hardware.
Asterisk as a Gateway
It can also be built out as the heart of a media gateway, bridging the
legacy PSTN to the expanding world of IP telephony. Asterisk’s modular

Digium, Inc. Page 19
Chapter 1: Overview
architecture allows it to convert between a wide range of communications
protocols and media codecs.
Asterisk as a Feature/Media Server
Need an IVR? Asterisk’s got you covered. How about a conference
bridge? Yep. It’s in there. What about an automated attendant? Asterisk
does that too. How about a replacement for your aging legacy voicemail
system? Can do. Unified messaging? No problem. Need a telephony
interface for your web site? Okay.
Asterisk in the Call Center
Asterisk has been adopted by call centers around the world based on its
flexibility. Call center and contact center developers have built complete
ACD systems based on Asterisk. Asterisk has also added new life to
existing call center solutions by adding remote IP agent capabilities,
advanced skills-based routing, predictive and bulk dialing, and more.
Asterisk in the Network
Internet Telephony Service Providers (ITSPs), Competitive Local
Exchange Carriers (CLECs) and even first-tier incumbents have
discovered the power of open source communications with Asterisk.
Feature servers, hosted services clusters, voicemail systems, and pre-paid
calling solutions, all based on Asterisk have helped reduce costs and
enabled flexibility.

Digium, Inc. Page 20
Chapter 1: Overview
Asterisk Everywhere
Asterisk has become the basis for thousands of communications
solutions. If you need to communicate, Asterisk is your answer. For more
information on Asterisk, visit http://www.asterisk.org or
http://www.digium.com.
