Digoo DG-TH11300 User manual

OPERATING INSTRUCTIONS
Model: DG-TH11300
HD Weather Station with Negative Color Screen

OVERVIEW
FEATURES
1. Buttons:
2. Barometric pressure with unit settable and trend arrow index
3. Weather forecast: Sunny, Partly cloudy, Cloudy, Rainy, Stormy
4. Current time:12/24H switchable
5. Dual alarms with snooze function
6. Built-in calendar in either Month/Date or Date/Month format
7. Indoor temperature range:-10℃~50℃
LL.L℃/ ℉& HH.H℃/℉will display when out of range
8. Outdoor temperature range:-30℃~60℃
LL.L℃/ ℉& HH.H℃/℉will display when out of range
9. Indoor and outdoor humidity range: 20%~95%
20% or 95% will display when out of the range
10. Max/Min temp. and humidity data traceable
11. Low power indicator for transmitter
12. Frozen point indication
13. Receives data from up to 3 external sensors
DG-TH11300
HD Weather Station w/ Negative Color Screen
220-240V ~ 50Hz / 3 x AA, 4.5V
Made in China
BN:E17-07020
www.mydigoo.com

Plug in the adapter to get the main unit started, or open the battery compartment cover
and insert 3xAA batteries to main unit and 2xAAA batteries to transmitter according to
the correct polarity showed in the compartment. After powering on, the weather station
will take about 3 minutes to connect with the outdoor transmitter.
(Under adapter mode: press button on top to turn on or off the backlight.
Under battery driven mode: press button to switch on the backlight lasting 5
seconds.)
1. The weather station will automatically receive signal sending back from the external
sensor after powering on, the receiving status will last for max 3 minutes, the recei-
ving antenna signal will flash, if no signal received in 3 minutes, will exist and
stop receiving outdoor signal.
2. Press “ ” button on main unit to alternate the readings of different channels’ dis-
play. The channel switch order is CH1 --> CH2--> CH3 -->Channel scan (from CH1
to CH2 to CH3, 10 seconds intervals).
3. Press and hold “ ” button for more than 3 seconds, then manually enter into RF
re-registration.
1. The distance of main unit or transmitter should be at least 5~6.5 feet (1.5~2 meters)
away from any interfering sources such as computer monitors or TV sets.
2. The main unit cannot stand close to metal window frames.
3. Please do not use other electrical products such as headphones or speakers oper-
ating on the same signal frequency, which may cause interference.
4. Neighbors using electrical devices operating on the same signal frequency can also
cause interference.
GETTING STARTED
RF(OUTDOOR TEMP. & HUMIDITY)
REMARKS

1. In standard mode, press button to check “Current time Alarm 1 Alarm
2 Current time”.
2. When it’s current time displaying mode, press and hold more than 2 seconds
to enter time setting mode.
3. The values to be set will be flashing.
4. The setting order is: 12/24H→Hour→Minute→Year→Month→Date→Date/Month &
Month /Date →Snooze time(5-60 minutes) →hpa/inHg →exit
5. Press and to change the setting;
Press and hold and to quickly increase or decrease the data.
6. Press to confirm the setting.
(If there’s no operation within 15 seconds, it will turn to normal time displaying mode
automatically.)
TEMP. AND HUMIDITY
1. Indoor temperature range: -10℃~50℃
Outdoor temperature range: -30℃~60℃
2. Indoor and outdoor humidity range: 20~95%
3. In normal time displaying mode, press and release the “MEM/▼” key repeatedly.
The current indoor/outdoor temperature and indoor/outdoor humidity will alternate
between the MIN/MAX recordings and the current value.
4.Frozen point indication: When external temperature is under 3℃，the weather station
will automatically give a frozen point indicator with snow flakes on the display.
BAROMETER AND WEATHER FORECAST
1.Weather forecast: Sunny, Partly cloudy, Cloudy, Rainy, Stormy
2.Barometric pressure range: 800hpa~1100hPa
3.Barometric pressure unit hPa/mB or inHg settable (pls see below)
4.Default: calendar display; To check barometer values, press and hold “MEM” button
TIME SET

1. In standard mode, press button to check “Current time Alarm 1 Alarm
2 Current time”.
2. When it’s Alarm 1 displaying mode, press and hold to enter alarm setting mode.
3. The setting sequence is: Hour→Minute→exit
4. Press and to change the setting;
Press and hold and to quickly increase or decrease the data.
5. Press button to turn on or off the alarm.
(When the alarm is on, the bell symbol will appear on the display.)
1. In standard mode, press button to check “Current time Alarm 1 Alarm
2 Current time”.
2. When it’s Alarm 2 displaying mode, press and hold SET/AL SET to enter alarm set-
ting mode.
3. The setting sequence is: Hour→Minute→exit
4. Press and to change the setting;
Press and hold and to quickly increase or decrease the data.
5.Press button to turn on or off the alarm.
(When the alarm is on, the bell symbol will appear on the display.)
Alarm ring:
1. Ringing will last for 2 minutes.
2. Alarm tone:
AL1: BIBIBIBI
AL2: BIBI
3. While the alarm is ringing, press “ ” button to get 5 minutes of snooze time,
the “Zz” will flash on the LCD. To cancel snooze, press on the back of the
main unit.
ALARM 1 SET
ALARM 2 SET
SNOOZE FUNCTION

1. In batteries driven mode, press on top to have five-second backlight.
2. In adapter driven mode, the backlight could either be on permanently or turned off
by pressing the button on top.
The weather station can be positioned in 2 ways as desired.
A. Pull out the table stand bracket from the rear of the clock, place on table or desk
as desired.
B. Hang on the wall by hanging hole.
BACKLIGHT
POSITIONED METHODS
Do not clean any part of the product with benzene, thinner or other solvent che-
micals. When necessary, clean it with a soft cloth.
Never immerse the product in water. This will damage the product.
Do not subject the product to extreme force, shock, or fluctuations in temperature
or humidity.
Do not tamper with the internal components.
Do not mix new and old batteries or batteries of different types.
Do not mix alkaline, standard or rechargeable batteries with this product.
Remove the batteries if storing this product for a long period of time.
Do not dispose of this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.
PRECAUTIONS
4.The snooze function has no limit, so it will repeat infinitely.
5. The alarm will be on again after 24 hours if it is still set.
