Dillon FI-521 Series User manual
FI-521
Indicator Series
User Instructions
AWT 35-501775
Issue AA
FI521_u_en_501775.book
Dillon is part of Avery Weigh-Tronix. Avery Weigh-Tronix is a trademark of the Illinois Tool Works group of companies whose
ultimate parent company is Illinois Tool Works Inc (“Illinois Tool Works”). Copyright © 2018 Illinois Tool Works. All rights reserved.
No part of this publication may be reproduced by making a facsimile copy, by the making of a copy in three dimensions of a two-dimensional
work and the making of a copy in two dimensions of a three-dimensional work, stored in any medium by electronic means, or transmitted in
any form or by any means, including electronic, mechanical, broadcasting, recording or otherwise without the prior written consent of the
copyright owner, under license, or as permitted by law.
This publication was correct at the time of going to print, however Avery Weigh-Tronix reserves the right to alter without notice the
specification, design, price or conditions of supply of any product or service at any time.
FI-521 User Manual 3
Table of Contents
page
Chapter 1 General Information and Warnings ........................................................................................ 5
About this Manual ..............................................................................................................5
Text Conventions ........................................................................................................ 5
Special Messages ....................................................................................................... 5
Warnings ............................................................................................................................ 6
Electrical Installation .................................................................................................... 6
Routine Maintenance .................................................................................................. 6
Safe Use ............................................................................................................................ 7
Cleaning the Indicator ................................................................................................. 7
Training .......................................................................................................................7
EMC Compliance ........................................................................................................ 7
Declaration of Compliance ................................................................................................. 8
Chapter 2 Specifications ........................................................................................................................... 9
FI-521 Series Models ......................................................................................................... 9
Housing and Outline Dimension ........................................................................................ 9
Housing ....................................................................................................................... 9
Outline Dimension ....................................................................................................... 9
Power Supply ...................................................................................................................10
Display ............................................................................................................................. 10
Keypad ...................................................................................................................... 10
Environment ............................................................................................................. 10
Loadcell Excitation .................................................................................................... 10
Communication ................................................................................................................ 11
Analog Circuitry ................................................................................................................ 11
Capacity and Division ...................................................................................................... 11
Accuracy .......................................................................................................................... 11
Real Clock ........................................................................................................................ 11
Remote Digital Input ........................................................................................................ 11
Digital Output (Setpoint Output) ....................................................................................... 11
Analog Voltage Output ..................................................................................................... 12
Other Main Functions ....................................................................................................... 12
Chapter 3 Introduction ............................................................................................................................ 13
Front Panel ...................................................................................................................... 13
Display ............................................................................................................................. 13
Keyboard .......................................................................................................................... 14
Navigating the Normal Force Mode ................................................................................. 16
Power on Indicator .................................................................................................... 16
Power off Indicator .................................................................................................... 16
Zero ...........................................................................................................................16
Print Data .................................................................................................................. 16
Change Measure Unit ............................................................................................... 16
Select Loadcell .......................................................................................................... 16
Display Force or Captured Peak Data ....................................................................... 17
Chapter 4 Configuration .......................................................................................................................... 19
Entering the Setup Mode ................................................................................................. 19
Navigating the Main Menu ............................................................................................... 19
Configuration Menu Parameters ...................................................................................... 21
Config Menu .............................................................................................................. 21
User Menu ................................................................................................................. 25
4 FI-521 User Manual
Misc Menu ................................................................................................................. 31
Test Menu ................................................................................................................. 31
IN.OUT Menu ............................................................................................................ 32
CELL Menu ............................................................................................................... 33
Exit the Setup Menu ........................................................................................................ 33
Display and Set Time ...................................................................................................... 33
Display and Set Date ....................................................................................................... 34
Display Firmware Version ................................................................................................ 34
Display Interface Type of COM2 ..................................................................................... 35
Display Test ..................................................................................................................... 35
Keyboard and Buzzer Test .............................................................................................. 35
Input Test .................................................................................................................. 35
Output Test ............................................................................................................... 36
Serial Port1/2 (COM1/2) Receiving Test ......................................................................... 36
Serial Port1/2(COM1/2) Transmitting Test ...................................................................... 36
Output Setting ........................................................................................................... 38
Remote Input Selection ............................................................................................. 39
Analog Voltage Output .............................................................................................. 39
Chapter 5 Connections and Jumpers .................................................................................................... 40
RS-485 Serial Port Connections and Jumpers ................................................................ 40
Communication Jumpers ................................................................................................. 41
Chapter 6 Serial Communication ........................................................................................................... 42
Com Port 1 ...................................................................................................................... 42
Com Port 2 ...................................................................................................................... 42
Protocol ........................................................................................................................... 42
Transaction String ........................................................................................................... 42
Commands and Response .............................................................................................. 44
Single ........................................................................................................................ 44
Multiple ...................................................................................................................... 46
EDX ........................................................................................................................... 47
Chapter 7 Troubleshooting ..................................................................................................................... 48
Display Characters .......................................................................................................... 48
Display Symbols .............................................................................................................. 49
Error Messages and Troubleshooting ............................................................................. 50
FI-521 User Manual 5
1 General Information and Warnings
1.1 About this Manual
This manual is divided into chapters by the chapter number and the large text at the top
of a page. Subsections are labeled as shown by the 1 and 1.1 headings shown above.
The names of the chapter and the next subsection level appear at the top of alternating
pages of the manual to remind you of where you are in the manual. The manual name
and page numbers appear at the bottom of the pages.
1.1.1 Text Conventions
The keys used to interface with the FI-521 are located on the front panel of the
indicator. The keystrokes are shown in BOLD in cased between brackets. (e.g.
[ZERO])
Displayed messages appear in bold italic type and reflect the case of the displayed
message.
1.1.2 Special Messages
Examples of special messages you will see in this manual are defined below. The
signal words have specific meanings to alert you to additional information or the relative
level of hazard.
CAUTION!
This is a Caution symbol.
Cautions give information about procedures that, if not observed, could result
in damage to equipment or corruption to and loss of data.
ELECTRICAL WARNING!
THIS IS AN ELECTRICAL WARNING SYMBOL.
ELECTRICAL WARNINGS MEAN THAT FAILURE TO FOLLOW
SPECIFIC PRACTICES OR PROCEDURES MAY RESULT IN
ELECTROCUTION, ARC BURNS, EXPLOSIONS OR OTHER HAZARDS
THAT MAY CAUSE INJURY OR DEATH.
NOTE: This is a Note symbol. Notes give additional and important information, hints
and tips that help you to use your product.
6 FI-521 User Manual
1.2 Warnings
Avoid lengthy exposure to extreme heat or cold. Your scale works best when operated
at normal room temperature. Always allow the scale to acclimate to a normal room
temperature before use.
1.2.1 Electrical Installation
The mains lead must be connected to a supply outlet with a protective earth contact.
The electrical supply at the socket outlet must provide over current protection of an
appropriate rating.
For your protection all mains (110V or 230V) equipment used out of doors or in wet or
damp conditions should be supplied from a correctly fused source and protected by an
approved ground fault protection device (RCD, GFCI etc.)
IF IN DOUBT SEEK ADVICE FROM A QUALIFIED ELECTRICIAN.
1.2.2 Routine Maintenance
CAUTION!
THE EQUIPMENT CONTAINS NO USER SERVICEABLE COMPONENTS.
Installation and maintenance of the equipment must only be carried out by
trained and authorised personnel.
IMPORTANT: This equipment must be routinely checked for proper operation
and calibration.
Application and usage will determine the frequency of calibration required for
safe operation.
ELECTRICAL WARNING!
TO AVOID THE POSSIBILITY OF ELECTRIC SHOCK OR DAMAGE TO
THE MACHINE, ALWAYS SWITCH OFF THE MACHINE AND ISOLATE
FROM THE POWER SUPPLY BEFORE CARRYING OUT ANY ROUTINE
MAINTENANCE.
TO AVOID THE RISK OF THE MACHINE FALLING, WHERE
APPLICABLE, ENSURE THAT IT IS PLACED SECURELY ON A FLAT
AND LEVEL SURFACE.
FI-521 User Manual 7
1.3 Safe Use
Do not use sharp objects such as screwdrivers or long fingernails to operate the keys.
1.3.1 Cleaning the Indicator
Harsh abrasives, solvents, scouring cleaners and alkaline cleaning solutions, such as
washing soda, should not be used especially on the display windows. Under no
circumstances should you attempt to wipe the inside of the indicator.
The outside of standard products may be wiped down with a clean cloth, moistened
with water containing a small amount of washing up liquid.
The outside of products waterproofed to IP65, IP66 and IP67 may be washed down
with water containing a small amount of proprietary detergent.
1.3.2 Training
Do not attempt to carry out any procedure on a machine unless you have received the
appropriate training or read the Instruction Manual.
1.3.3 EMC Compliance
Do not attempt to carry out any procedure on a machine unless you have received the
appropriate training or read the Instruction Manual.
WARNING!
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
