Dimension One Spas 01510-1030E Rev A Quick start guide

Export Sonic Immersion System
Table of Contents
OWNER’S MANUAL ......................................................................... 1
FEATURES OF THE SONIC IMMERSION................................................. 1
USING THE CD PLAYER...................................................................... 1
DEALER INSTALLATION .............................................................. 2
GETTING READY TO START................................................................ 3
Overview of the Installation........................................................... 3
Required Tools............................................................................... 3
Parts List........................................................................................ 5
REMOVING PANELS ............................................................................ 8
Remove Equipment Compartment Panel ....................................... 8
Remove the Sub Woofer Compartment Panel .............................. 10
INSTALLING THE SUB WOOFER COMPARTMENT ............................... 13
PRE WIRING FROM EQUIPMENT COMPARTMENT TO SUB WOOFER
COMPARTMENT ................................................................................ 19
INSTALLATION OF POWER SUPPLY ................................................... 25
Pre-Wire Power Supply ............................................................... 25
Installing Power Supply in Equipment Compartment.................. 28
Wiring the Power Supply ............................................................. 30
Determining Location of CD Weather Cover .............................. 32
Cutting Panel Hole for CD Player Door Assembly ..................... 33
Installation of CD Player Door and Bezel................................... 37
Installation of Panel and CD Player............................................ 38
INSTALLING THE SATELLITE SPEAKERS ............................................ 40
Installing the Satellite Speaker Wires .......................................... 42
SECURING THE AMPLIFIER................................................................ 47
COMPLETE THE INSTALLATION......................................................... 47
iii

Export Sonic Immersion System
iv

Export Sonic Immersion System Dealer Owners Manual
Owner’s Manual
Features of the Sonic Immersion
• Dealer installation allows you to add to any Sonic Immersion
System ready Dimension One Spa in stock
• Patented planar magnetic speaker technology (1/4” [6.35 mm]
thick) that generates unparalleled sound quality even in the
harshest environmental conditions
• Superior fidelity and low distortion
• Articulated speaker mount that allows multidirectional
capability and if the speakers are struck by an object,
speakers deflect without being damaged
• Remote operation
Using the CD Player
The manufacturer of the Sonic Immersion System CD Player has
supplied a User Guide for the CD player. Please refer to this guide for
instructions on how on use of the CD player.
1

Export Sonic Immersion System Dealer Installation Guide
Dealer
Installation
This section intended for use by authorized dealer personnel only
2

Export Sonic Immersion System Dealer Installation Guide
Getting Ready To Start
The Sonic Immersion System can only be installed on spas with the
following serial numbers.
Table 1 Sonic Immersion System Ready Spas
Model Serial Number
Aurora HP 91275 or higher
Aurora II 91210 and higher (Also 91184)
Aurora XLT 91295 and higher
Caliente HP 91301 and higher (Also 91290 and
91299)
Californian 91198 and higher
Chairman 91245 and higher
Chairman II 91234 and higher
Diplomat 91197 and higher
Nautilus 91458 and higher (Also 91455)
Triad 91372
Triad II 91625 an higher (Also 91567)
Overview of the Installation
The installation of the Sonic Immersion System is a simple process
that includes removing the spa skirt, drilling a few holes using the
templates provided to guide you, and then connecting one or more
power cables. This guide is provided to help complete this task in a
quick and efficient manner.
Required Tools
You will need the following tools to complete the installation:
3

Export Sonic Immersion System Dealer Installation Guide
Table 2 Required Tools
Electric drill
1 ½ inch (3.8 mm) hole saw
¼ inch (6.35 mm) drill bit
3/8 inch (9.5 mm) drill bit
Saber Saw
Phillips screwdriver
Tape (masking, electrical, duct, or
packaging) ½ in (12.7 mm) width
Spring-loaded punch
(or other tool(s) that can be used to
mark drilling locations, such as a
hammer & nail)
Fine Point Marker
Measuring Tape
Fish Tape
Fish Tape Lubricant
Non Ratcheting PVC Pipe Cutter
4

Export Sonic Immersion System Dealer Installation Guide
Medium Size Needle Nose Pliers
Wire Stripper
Utility Knife
5/16” (7.94 mm) Nut Driver or wrench
Six inch (15.24 cm) square
Stapler and Staples
Straight Edge
Safety Glasses
Silicone caulking (clear)
Small Saw
Parts List
You should have received the following parts in the Sonic
Immersion System installation kit:
5

Export Sonic Immersion System Dealer Installation Guide
Table 3 Parts List
Description Qty Item
Number
This document 1 01510-
1030
Amplifier 1 01564-08
Coarse-
Threaded
Drywall Screws
5 01051-06
Template 1 Doc 74-
Rev A
Power Supply
Harness
1 01564-19
Power, supply,
stereo
1 01564-01
Main Harness 1 01564-20
Speaker, lead 2 01564-21
Speakers,
Satellite
2 01564-14
6

Export Sonic Immersion System Dealer Installation Guide
Stereo 1 01564-03
Sub-woofer sub
assembly
1 01564-09
Stereo cover,
marine
1 01564-04
Dual pole
antenna
1 01564-05
Preamp stereo,
cable
2 01570-24
Power supply
screw, sheet
metal, SS, PH
2 01011-38
Marine cover
screws, #8 x ½”
(1.3 cm) SS
Truss Head
4 01011-40
Cable Ty, 4”
(10.2 cm) black
10 01200-006
7

Export Sonic Immersion System Dealer Installation Guide
Cable Ty Mount 10 01200-005
Removing Panels
In order to install the system up to three panels must be removed
from the spa: the equipment compartment panel, the panel where the
sub woofer is installed, and the panel where the Satellite Speakers are
to be installed.
Remove Equipment Compartment Panel
Warning
Possible Electrical Shock Hazard
1. Turn off the main spa circuit breaker located in the
disconnect box or house panel.
2. Verify that all power has been turned off before continuing
installation.
Note
Refer to the Spa Service Manual to
determine how to confirm that all
power to the spa has been turned off.
3. Locate the spa’s Main Top Side Control, Figure 1.
8

Export Sonic Immersion System Dealer Installation Guide
Figure 1. Top Side Control
4. The Lower Control is located in the equipment compartment
behind the spa panel below the Main Top Side Control.
5. Use the screwdriver to remove the equipment compartment
panel screws, Figure 2.
Figure 2. Equipment Compartment Panel Screws
9

Export Sonic Immersion System Dealer Installation Guide
Note
The number of screws to be removed will depend on
the model of spa.
Remove the Sub Woofer Compartment
Panel
The installation location of the sub woofer compartment will vary
from one spa model to another. Use Table 4 to locate the
compartment on your spa. First, stand in front of the spa facing
the Top Side Control (at the 6 o’clock position, see below)
and then refer to Table 4 below.
10

Export Sonic Immersion System Dealer Installation Guide
Sub-Woofer Installation Locator
Top Side Control
Table 4 Model List
Model and Number Location of Installation
Aurora II and Chairman
Top Side Control
Chairman II and Aurora XLT
Top Side Control
Diplomat, Californian
Top Side Control
Nautilus
Top Side Control
11

Export Sonic Immersion System Dealer Installation Guide
Caliente HP, Triad II, Aurora
HP, and Triad
Top Side Control
1. Use the screwdriver to remove the spa panel screws, Figure 3.
Figure 3. Equipment Compartment Panel Screws
Note
The number of screws to be removed
will depend on the model of spa.
12

Export Sonic Immersion System Dealer Installation Guide
Installing the Sub Woofer
Compartment
The installation of the sub woofer compartment consists of removing
the panel, removing the paper cover, exposing the plug, removing the
plug, and installing the sub woofer compartment.
1. If you have a spa with wood siding you may skip to Step 2. If
your spa has EnviroTectsiding you will need to remove the
white foam sheeting, Figure 4.
Figure 4. Removing EnviroTectSheeting
2. Using a locking utility knife set for a depth of about ½ inch,
cut a 13” X 18.5” (33 cm X 47 cm) rectangle as shown in
Figure 5. Remove the paper and foam until you expose the
sub woofer plug. You may need to use a screwdriver or
other tool to remove the paper and foam.
Figure 5. Cutting Rectangle
13

Export Sonic Immersion System Dealer Installation Guide
Note
The photograph Figure 5 may not look
like your spa, refer to Table 4.
1. Sub-Woofer Plug
Figure 6. Sub-Woofer Plug
3. Once the plug is exposed, Figure 6, use a screwdriver to
punch holes in the foam large enough to insert your hands
and pull the plug out of the spa, Figure 7.
Note
The plug may not come out in one
piece.
14

Export Sonic Immersion System Dealer Installation Guide
Figure 7. Removing Plug
4. Use a medium size pair of needle nose pliers to remove the
large staples in the bottom rail where the plug was removed.
5. Remove all remnants of the plastic bag inside the
compartment where the plug was removed. This will expose
the electrical conduit, Figure 8.
Note
The electrical conduit may not always
be in this location. It will vary from spa
to spa.
15

Export Sonic Immersion System Dealer Installation Guide
1. Electrical Conduit Before Trimming
Figure 8. Electrical Conduit
6. Using a non-ratcheting PVC pipe cutter, trim the electrical
conduit flush with the foam wall, Figure 9.
1. Electrical Conduit After Trimming
Figure 9. Conduit After Trimming
16
