2006 Aqua Fit 16' Specifications Dimension One Spas
Sha
p
e Oval
Seatin
g
Ca
p
acit
y
n/a
Shell Material DuraTex™
Dimensions 90¼" x 192" x 52" H /
(
229cm X 488cm x 132cm H
)
Corner Radii N/A
Water Ca
p
acit
y
1700 Gallons
(
6440 Liters
)
Dr
y
Wei
g
ht 2400 lbs
(
1090 k
g)
Shi
pp
in
g
Wei
g
ht 2400 lbs
(
1090 k
g)
Full Wei
g
ht 17100 lbs
(
7760 k
g)
Skirt Material Wood o
p
tional
Water Treatment S
y
stem CD - Ozone*
Plumbin
g
S
y
stems 2
Filters/Covera
g
e2/75s
q
. ft.
Gate Valves 8
VCR Jet® - Air Ad
j
ustable/Directional 0
VCR Jet® - Rotator 0
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port S
p
inner 0
VCR Jet® - Mini Rotator 4
VCR Jet® - Mini Directional 10
VCR Jet® - Euro Directional 0
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 0
T
yp
hoon Jet 0
Swim Jets 6
Ozone Jet 2 *
Heater Return Jet 1 *
Pum
p
Returns 5
Diverter Valves 1
Floor Drains 1
Skimmer 2 - 8” Weir
NeckFlex® Jet Pillows 0
Headrest Pillows 1
Optimounts™ 12
Tether Mount 2
Swim Bar 1
Swim Jet Air Valves 2
Swim Tether 1
Pump Information Domestic
(
60Hz
)
Export
(
50Hz
)
Motor Size – Peak
(
Continuous
)
HP 5.0
(
3.0
)
HP 3.6
(
2.0
)
HP
Jet Pum
p
s # of Pum
p
s/S
p
eed One / Dual & Two / Sin
g
le One / Dual & Two / Sin
g
le
Circulation
p
um
p
00
Electrical S
y
stem Domestic
(
60Hz
)
Export
(
50Hz
)
Volta
g
e240240
Am
p
era
g
e 60 or 60
(
htr
)
+ 50
(p
um
p
s
)
60 or 60
(
htr
)
+ 50
(p
um
p
s
)
Heater 11 kW * 11 kW *
Thermostat Electronic * Electronic *
Li
g
ht 2 Multi color LED** 2 Multi color LED**
Control S
y
stem S
p
a Builders * S
p
a Builders *
U
pp
er Control S
p
a Builders * S
p
a Builders *
General
Water System
Special Features

Note: 1. Subject to change without notice.
Specification, 2006, AquaFit 16'
Doc-1520 Rev - A Rev Date: 10/31/05
2006 AquaFit 16' Specifications Dimension One Spas
2006 AquaFit 16'
192 in [488cm] Shell
192 in [488cm] Shell
189 in [480cm] Frame
189 in [480cm] Frame
47 in [119cm]
47 in [119cm]
52 in [132cm]
52 in [132cm]
4 in [10cm]
4 in [10cm]
1 1/2 in [3.8 cm]
1 1/2 in [3.8 cm]
R 45 1/8 in [115cm] Shell
R 45 1/8 in [115cm] Shell
88 in [224cm] Frame
88 in [224cm] Frame
90 1/4 in [229cm] Shell
90 1/4 in [229cm] Shell
E
2. Engineering specs may differ slightly from brochure.
3. Optional cabinets may add significant weight. Ask your dealer for exact details.
4. Pumps and control panels are not supplied with builder's pack.
Page 2 of 2
Architectural Specification
Caution:
Due to manufacturing tolerances there could be some
minor differences between the actual spa and the drawing above.
If site planning is critical to such tolerances, be sure to measure your actual spa.
Legend
Pump - P
Electrical - E
Lower Control Panel - LCP
Upper Control Panel - UCP
AFS MUST BE FULLY SUPPORTED OVER THE ENTIRE BASE.
REFER TO D1 DOC-138 FOR INSTALLATION DETAILS.
