Dimension One Spas Triad II User manual

Page 1 of 2
Note: 1. Subject to change without notice.
2. Reference DOC-1237 REV A.
Specification, 2005, Triad II
Doc-1215 Rev -B Rev Date: 1/31/05
2005 Triad II Specifications Dimension One Spas
General Domestic (60Hz) Part # Export (50Hz) Part #
Shape Rectangular Rectangular
Ultralife™ / Granitex™ Ultralife™ / Granitex™
/ Geloy® / Geloy®
Height 30 ½ in. 77 cm
Width 83 ½ in. 212 cm
Length 66 ½ in. 169 cm
Corner Radii 16 in. 41 cm
Seating Capacity 3+ 3+
Water Capacity 200 Gallons 757 Liters
Dry Weight 640 lbs 291 kg
Shipping Weight 640 lbs 313 kg
Full Weight 2310 lbs 1048 kg
Skirt Material W ood or Synthetic W ood or Synthetic
Poly Floor Yes Yes
Water System
Motor Size – Peak(Continuous) HP 4.0 (2.5) HP 3.6 (2.0) HP
# Pumps/Speed One / Dual 01562-23A One / single 01562-29A
Plumbing Systems 1 1
Pump Returns 2 01510-559 2 01510-559G
Typhoon Jets 0 0
VCR Jet®- Air Adjustable/Directional 4 01510-418 4 01510-418G
VCR Jet®- Rotator 7 01510-415 7 01510-415G
VCR Jet®- Mini Rotator 2 01510-445 2 01510-445G
VCR Jet®- Mini Directional 6 01510-444 6 01510-444G
VCR Jet®- Mini Directional in NFJ 4 01510-595 4 01510-595G
VCR Jet®- Euro Directional 0 0
Ozone Jet 1 01510-201 1 01510-201G
Heater Return Jet 1 01510-275 1 01510-275G
Filters/Coverage 2 / 75 sq. ft. (2) 01561-00 2 / 6.97 sq. meters (2) 01561-00
Water Treatment System Ultra Pure™ Ultra Pure™
Gate Valves 2 01522-30 2 01522-30
Diverter Valves 0 0
Floor Drains 1 01510-231 1 01510-231G
Skimmer 8” Weir 01510-137 20 cm W eir 01510-137G
Electrical System
Voltage 240 240
Amperage 40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW 01781-20 FastFlo 2.9 kW 01781-20
Thermostat Electronic Electronic
Light 1 with optional LED 01512-003 (O) 1 with optional LED 01512-003 (O)
Control System MSPA-MP-D12 01710-1008 MSPA-MP-D11-CE 01710-1008E
Upper Control Scrolling Message Center 01580-0001 Scrolling Message Center 01580-0001
Auxiliary Upper Control No No
Programmable Yes Yes
Special Features
Dynamic Massage Sequencer PCA 01710-1001 PCA 01710-1001
w/ control panel UCP 01560-1005 UCP 01560-1005
NeckFlex®Jet Pillows 1 01510-598 1 01510-598
Headrest Pillows 2 01510-593 2 01510-593
Cup Holders 2 2
Tactile Therapy Floor pedestal Floor pedestal
Shell Material
Yes Yes

Note: 1. Subject to change without notice.
Specification, 2005, Triad II
Doc-1215 Rev -B Rev Date: 1/31/05
2005 Triad II Specifications Dimension One Spas
2005 Triad II
66 1/2 in [169 cm]
Shell
See Caution
66 in [168 cm]
Skirt
63 1/2 in [162 cm]
Pedestal
Base
Control
Spa Lip
Pedestal Base
Hose Bib/
Water Drain
THE EDGES OF SPA BASE.
SUPPORTED CONSISTENT WITH
ON BOTTOM OF SPA, TO BE
THIS 3 FOOT SQUARE AREA,
30 1/2 in [77 cm]
26 1/2 in [67 cm]
67 in [170 cm]
10 in [27 cm]
Hose Bib/
Water Drain
26 in [67 cm]
Recommended location for
Electrical
Inlet
R16 in [R41 cm]
16 in [41 cm]
16 in [41 cm]
25 1/2 in [64 cm]
36 1/2 in [92 cm]
47 in [119 cm]
58 in [147 cm]
83 in [210 cm]
Door Extends
Under Spa Lip
Vent
Control Panel
Front Side of Spa
Equipment
Compartment
Vent Vent
R16 in [R41 cm]
83 1/2 in [212 cm]
3 1/2 in [9 cm]
Sequencer valve
compartment
Page 2 of 2
2. Engineering specs may differ slightly from brochure.
3. For E-Z lifter installation allow 18” (45.7cm) clearance on the backside of the spa.
4. Alternative cabinets may add significant weight. Ask your dealer for exact details
5. This is the approximate location for drilling a hole if you must bring the power line in through the bottom of the spa.
Be careful not to puncture a plumbing line inside the equipment compartment(drill from the inside compartment out).
Caution:
Due to manufacturing tolerances there could be some
minor differences between the actual spa and the drawing above.
If site planning is critical to such tolerances, be sure to measure your actual spa.
Architectural Specification
