Dimplex DCP11MULTI User manual

For domestic household use only.
INSTRUCTION MANUAL
Multidirectional
Portable Air Conditioner
Model: DCP11MULTI & DCP14MULTI

IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND
RETAINED FOR FUTURE REFERENCE.
Note also the information presented on the appliance
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY
AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY
Please read the operating instructions carefully before using your Portable Air
Conditioner for the rst time and keep them in a safe place.
WARNING – This appliance must not be used in a bathroom.
WARNING – Do not use this appliance in the immediate surroundings of a bath, a
shower or a swimming pool.
• If the mains lead is damaged it must only be replaced by the manufacturers service
agent or a similarly qualied person in order to avoid a hazard.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the appliance.
• Prior to cleaning or other maintenance, the appliance must be disconnected from
the supply mains.
• Never immerse the appliance in water or other liquids.
• Operate this unit only on a rm, at surface to avoid the risk of water leakage.
Ensure that the unit is kept upright at all times.
• Do not place on soft, unstable or non-horizontal/angled surfaces.
• Never operate the appliance if a cable or connector has been damaged, after
appliance malfunction or if the appliance was dropped or is otherwise damaged.
• Please ask a professional service agent to repair the product. Improper repair may
cause danger to users.
• Disconnect the appliance from mains power whenever it is not in use, before
relocating it, and before cleaning.
• Operate the appliance only at the voltage specied on the rating label.
• Only connect the unit to a properly installed and easily accessible socket so that
you can quickly disconnect the plug if necessary.
• Do not connect this product to the mains using an extension lead.
• This product is only intended for INDOOR RESIDENTIAL applications. This product
should not be used for commercial or industrial or leisure applications or in small
enclosed spaces.
• Never use the mains lead as a carrying strap or pulling lead.
• To avoid a re or electrocution hazard, NEVER put the cord near heat registers,
radiator, stoves or heaters.
• DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.
• DO NOT route cord under furniture or appliances. Take care to position the cord
away from trac areas and where it will not be a tripping hazard.
• DO NOT use the unit near windows or where water collects. Rain and water collection
2

may lead to a risk of re or electric shock.
• Only operate this appliance with a minimum of 50cm clearance all around i.e. away
from walls, furniture and overhanging objects such as curtains or a shelf.
• WARNING: To avoid danger of suocation please remove all packaging materials
particularly plastic and EPS and keep these away from vulnerable people, children
and babies.
• NEVER drop or insert any object or ngers into any openings.
• Do not cover or obstruct the air inlet and outlets.
• Do not use the appliance in locations where paint, petrol or other ammable liquids
are used or stored.
• Do not use bug sprays or other ammable cleansers/vapour sprays on or around
the unit.
• Always switch o the unit and take the plug out of the socket:
• If you are not using the unit
• Before you clean or carry out maintenance on the unit
• If a fault occurs
• In the event of an electrical storm.
• Avoid electromagnetic interference. Keep the unit at least 1 metre away from
electrical appliances such as televisions & radios.
• The air conditioner must always be stored and transported upright. In case of doubt
we suggest you wait for at least 24 hours before operation. (Please keep unit upright
at all times).
• This portable air conditioner is tted with a compressor delay protection circuit.
This protects the unit from possible damage due to rapid starting and stopping of
its compressor. The compressor will begin operation 3.5 minutes after the unit has
been switched ON or if the mode is changed from dehumidify to cooling.
3
The appliance shall be installed in accordance with national wiring regulations.
•

Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
If an extension
lead may become
overloaded
Where there is risk
of re or close to
a naked ame
Where the power
cable may be
damaged
On a slope or
uneven surface
Where it may be
damaged by
chemicals
If there is a risk
of water falling on
the unit
Where there is a risk
of interference by
foreign objects
This product is not
made for DIY repair
4

Model no. DCP11MULTI DCP14MULTI
Colour
White/Black
Power supply
220-240V~, 50Hz
Operating temperature 5-43°C
Thermostat range 17-30°C
Rated Input Power 1.28kW
1.6kW
Cooling Capacity 3.2kW 4kW
Dehumidication Capacity (30°C, 80%RH) 50L/day 70L/day
Noise Level Minimum (Lo) 69dB(A)
Noise Level Maximum (Hi) 70dB(A)
Air Volume (lo/Med/Hi)
Refrigerant R410A
Fan speeds 3
Modes Sleep/Dry/Cool/Auto
Timer 0-24 hours
Dimensions (w x d x h)
335 x 538 x 765mm
Min room size 15m² 18m²
Max room size 23m² 26m²
Weight net 30.5kg 31kg
Weight gross 34kg 34.5kg
Specication
• For greater precision, please always refer to the rating label placed on the product.
5
350/450/540

Parts
(1) Control panel
(2) Remote control receiver
(3) Hose adaptor
(4) Exhaust hose
(5) Upper drainage hole
1 x Exhaust hose 1 x Window slider kit (with hole)
1 x Window slider kit (without hole)
1 x Remote control
(6) Cool air inlet
(7) Cool air lter
(8) Hot air inlet
(9) Hot air lter
(10) Lower drain hole
6

Control Panel
LED Display
• The LED display indicates the current set temperature or the timer setting.
• When the set temperature or the timer is adjusted, the new setting is shown on the
• The LED display is also used to show error codes should a fault occur.
(1) Power button
(2) Function button
(3) Temp increase (+) button
(4) Temp decrease (-) button
(5) LED display screen
(6) Speed button
(7) Timer button
(8) Sleep button
(9) Swing button
Indicator lights:
*heating not applicable for all models.
7
The light only will be lighten when the unit has heating function
display.

Installation
PREPARATION
NOTE: All the illustrations in the manual are for explanatory purposes only. Your
machine may be slightly dierent. The unit can be controlled by the control panel or
with the remote control.
EXHAUST HOSE
The exhaust hose and adaptor must be installed or removed in accordance with the
set FUNCTION. For COOL & DRY functions, the exhaust hose must be installed. For
FAN only - the exhaust hose should be removed.
EXHAUSTING HOT AIR
In COOL function the appliance must be placed close to a window or opening so the
warm exhaust air can be expelled outside.
CHOOSING THE RIGHT LOCATION
Your installation location should meet the following requirements:
• Make sure that you install your unit on an even surface to minimize noise and
vibration.
• The unit must be installed near a sucient power outlet, and if using a continuous
drainage method, then the plug areas should be accessible.
• The unit should be located at least 50cm from the nearest wall to ensure proper
air circulation. The horizontal louvre blade should be at least 50cm away from
obstacles.
• The exhaust hose can be extended, however it's best to keep it to the minimum
length required. Ensure the hose doesnt have any sharp bends, sagging areas or
kinks
• DO NOT cover the Intakes, outlets or remote control signal receptor of the unit,
as this could cause damage to the unit.
8

Installation
EXHAUST HOSE INSTALLATION
1. Rotating the exhaust hose according to the direction in Fig (1) will remove the
hose from the unit.
2. Rotating the exhaust hose according to the direction in Fig (2) will attach the
hose to the unit.
3. Extend the exhaust hose to a length of no more than 400mm. The exhaust hose
must be kept parallel and must not be bent up or down.
NOTE: This unit has a self evaporative system which removes excess condensation
by means of evaporating water collected in the tank. Therefore saving you the hassle
of having to use a drip tray or drainage hose. Please make sure the rubber cap is
locked into position to avoid any leakage.
NOTE: In high humidity areas, there may be excess water condensation produced
that cannot be removed or evaporated. In this instance, the unit will need to be
drained. View the WATER DRAINAGE section for details. The unit will automatically
switch OFF when the internal water tank is full.
9

Installation
WINDOW KIT INSTALLATION
The window slider kit has been designed to t most standard vertical and horizontal
window applications, however it may be necessary for you to modify some aspects
of the installation procedures for certain types of windows. The window slider kit can
be fastened with screws (not supplied) if required.
Refer to Fig. 1 & Fig. 2 below:
Vertical Installation
Horizontal Installation
