Dimplex TDTR175C User manual

Table1
Model Rails Watts Weight (kg)
TDTR175C 12 120 6
TDTR175W 12 175 6
TDTR350C 18 250 11
TDTR350W 18 350 11
Important Safety Advice
WARNING - THE SURFACE OF THIS RADIATOR CAN BE HOT.
In order to be effective the towel rail will get hot, however
momentary contact with any part of it should not cause
injury.
The heater is to be installed so that switches and other
controls cannot be touched by a person in the bath or
shower
CAUTION - This appliance is not intended for use by
chidren or other persons without assistance or
supervision if their physical, sensory or mental
capabilities prevent them from using it safely. Children
should be supervised to ensure that they do not play
with the appliance.
Precautions should be taken to ensure that prolonged
contact with the towel rail cannot occur. Particular
care should be taken in confined areas where
accidental prolonged contact with the rail could be
more likely to occur.
This appliance should only be used to dry fabrics washed
in water using commonly available detergents.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
IMPORTANT - If the towel rail is to be installed in a place
used by the public, a warning notice should be placed
adjacent to the rail advising that the surface can be hot.
WARNING - the towel rail is a sealed unit and is filled and
sealed under controlled conditions. Under no
circumstances should the seal of the unit be
compromised
WARNING - In order to avoid a hazard for very young
children, this appliance should be installed so that the
lowest heated rail is at least 600mm above the floor.
General
The TDTR towel rail is designed to provide an all year round service
for airing towels and articles of clothing. It is not intended to provide
a sole heating service, but the larger model will take the chill off an
average size bathroom, lavatory or en suite. Your rail will be in one
of two sizes and will have either silver chromium plated or white
stove-enamel finish.
No routine maintenance is necessary apart from occasional cleaning.
Both models are splashproof to IPX5 standard.
Electrical
WARNING - This appliance must be earthed
The electrical installation of this towel rail must be carried out by a
competentelectrician inaccordance withthe currentI.E.E Regulations
for Electrical Equipment. The towel rail is suitable for use on anA.C.~
electrical supply. Before installation check that the supply voltage
corresponds with that marked on the rail.
IMPORTANT - The wires in the mains lead are coloured in
accordance with the following code:
BLUE - NEUTRAL
BROWN - LIVE
GREEN/YELLOW - EARTH
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured GREEN and YELLOW must be
connected to the terminal in the plug which is marked with the letter
Eor by the earth symbol or coloured green or green and yellow.
The wire which is coloured BLUE must be connected to the terminal
which is marked with the letter Nor coloured black.
Thewire whichis colouredBROWN mustbe connectedto theterminal
which is marked with the letter Lor coloured red.
This appliance must only be used on A.C. mains supply of 230/240
Volts~.
Installation
If fitted in a room containing a bath or shower, to comply with the
current I.E.E. Regulations, a cable outlet will be
necessary with the supply to the heater controlled by a
double-pole pull-cord switch having a contact separation of 3mm in
each pole. The body of the switch should be situated as to be
normally inaccessible to a person using a bath or shower.
IMPORTANT - Protect the electrical connection whilst
handling the towel rail.
The towel rail must be permanently fixed to the wall using the wall
brackets supplied. The rail must be mounted vertically as shown
observing the minimum clearances stated.
WARNING - The towel rail is heavy. Care must be taken when lifting
and fitting the towel rail.
IMPORTANT : THESEINSTRUCTIONSSHOULDBE READ CAREFULLYANDRETAINEDFORFUTURE REFERENCE
Dimensions
(millimetres)
Installation and Operating Instructions
TDTR Towel Rails
Models : TDTR175C, TDTR175W, TDTR350C & TDTR350W
Fig. 1
Issue 5
B
100 min.
A
shelf 150
min.
Mode l A B
TDTR 175 610 453
TDTR 350 843 602

Wall mounting
The wall mounting accessory pack contains:
TDTR175 & (a) 4 mounting brackets
TDTR350 Models: (c) 4 wall mounting screws/washers/wall plugs
(d) 4 depth adjusting screws
Procedure for wall mounting
Note: TDTR 175 can be fitted in arrangement (1) or (2) from below
Fig. 2,using eitherthree or four wall mountingbrackets. Fourbrackets
must be used on the TDTR350 models
Step 1
Marksuitable mountinghole positions forthe fixingbrackets (ensuring
they are horizontal) - see Fig. 2, ensure to allow enough room above
and below to maintain the minimum clearance stated.
Step 2
Drill and plug the wall to suit - see Fig. 3.
Step 3
Secure the outer wall bracket sleeves (a) to the wall using the
screws provided - see Fig. 3.
Step 4
Attach the inner wall bracket sleeves (b) to the towel rail with the
clamping pieces (c & d) and screw (e) as shown in Fig. 4.
Ensure the clamping pieces are aligned correctly as shown (x & y).
Thescrew should beleft loose enoughto allow horizontal adjustment.
Step 5
Align the wall bracket sleeves on the towel rail according to the
dimensions shown in Fig. 2.
Step 6
Lift the towel rail complete with the inner sleeve assembly and align
with the outer sleeve previously fixed to the wall. When all the inner
sleeves are inserted correctly into the outer sleeves, determine the
desired distance of the rail from the wall and secure in place using
the fixing screw (f) - see Fig. 5.
Step 7
Tighten the clamping screws (e) and install the end cap (g) on the
front clamping piece.
Note: to assist with the alignment, the outer sleeve position may be
adjusted using the slot provided.
Drying and Airing Towels
It is recommended that for efficient drying, no more than two layers
of towels or similar fabric should be draped over the rail. Items
should be placed evenly over the whole surface of the rail where
possible.
It is not advisable to leave very damp towels or clothes on the towel
rail when not in use, as this may in time, affect the paint finish.
The rail, although hot to the touch is not hot enough to scorch or burn
fabrics. However, soap and detergents remaining in articles after
washing can cause discoloration. Therefore care should be taken
to thoroughly rinse articles before airing.
Fig. 2
Fig. 3
Fig. 4
A B
TDTR 175 250 390
TDTR 350 380 625
B
A
B
A
C
L
TDTR 175 TDTR 350
(1) (2)
a
b
a
c
d
e
g
c
d
f
f
e
g
20mm Max.
Fig. 5

Operation (Electrical)
Heat will be distributed along each of the rails.
Some variation in the temperature across the surface of the rail is
also normal. When the appliance is covered the heating pattern of
the rails may alter, and generally temperatures at the upper part of
that rail will rise.
The towel rail may be switched on and off at the isolating wall
switch which must be positioned outside the bathroom, or operated
by means of a pull cord switch.
A further means of control would be to link the towel rail to a room
thermostat and/or timer. A room thermostat will
ensure that the rail automatically switches off in warmer weather. A
timer will allow for short periods of use.
Note: If the towel rail is located in a bathroom the
adjustment for these controls must be located outside the bathroom.
Maintenance
There are no user serviceable parts on the towel rail.
WARNING - The Bleed screw on the rear of the product is
intended for the use of the service agent only and should
never be opened.
The rail is filled with a precise quantity of special liquid and should
never need draining or refilling. Repairs requiring the opening of the
liquid-tight seal must only be made by the manufacturer’s Service
Agent. Any leakage must be reported to the manufacturer’s Service
Agent.
The element and cable are a single unit and any maintenance must
be carried out by the manufacturers service agent using the
recommended Parts
Cleaning
The finish on your towel rail can be maintained by occasionally
wiping over with a damp cloth and lightly finishing with a soft dry
cloth. This should only be carried out when the rail is cold. Do not
use abrasive cleaning powders as this could damage the surface
finish.
