Valued Customer,
Thank you and congratulations for purchasing a Dimplex
 electricreplace.Overtheyears,valuablememories
will occur around the warmth and comfort of your
 replace.Thankyouforallowingourproducttobethe
 backdropforthosespecialmoments.
SerialNumber
ModelNumber
PartNumber
Qualitycheckedby:
Owner’s Manual
Model Numbers:
DF3003
DFB6016

2
QUICK REFERENCE GUIDE
1.Priortotherstuseofthereplaceverifythe
 following:
• Arethecircuitbreakersfortheuniton?
• Arethelightbulbsinyourreplaceloose?(to
check, follow the instructions for replacing
thelightbulbsundertheMaintenance
section of this manual)
2.Theheateronyourreplacemayemitaslight,
harmlessodorwhenrstused.Thisodorisa
normalconditioncausedbytheinitialheatingof
internalheaterpartsandwillnotoccuragain.
3.Theinformationregardingthemodelofyour
replacecanbefoundontheratingplate
locatedonthetopoftheunit.
4.Ifyouhaveanytechnicalquestionsorconcerns
regardingtheoperationofyourreplace,or
requireservicecontactDimplexNorthAmerica
customerserviceat1-888-DIMPLEX
(1-888-346-7539)beforereturningtheproduct
tothepointofpurchase.

3
CONTENTS
PAGE 4  ImportantInstructions
PAGE 6  ModelandSerialNumber
     Information  
PAGE 7 Site Selection and Preparation
PAGE 10  FireplaceInsertInstallation
PAGE 11  Operation
PAGE 14 Maintenance
PAGE 17 Warranty

4
IMPORTANT INSTRUCTIONS
Please Retain This User’s Guide For Future Reference
Whenusingelectricalappliances,basicprecautionsshouldalwaysbefollowed
toreducetheriskofre,electricshock,andinjurytopersons,includingthe
following:
1. Readallinstructionsbeforeusingtheelectricreplace.
2. Theheaterishotwheninuse.Toavoidburns,donotletbareskintouch
 hotsurfaces.Thetrimaroundtheheateroutletbecomeshotduringheater
 operation.Keepcombustiblematerials,suchasfurniture,pillows,
 bedding,papers,clothes,andcurtainsatleastthree(3)feet(0.9m)from
thefrontoftheunit.
3. Extremecautionisnecessarywhenanyheaterisusedbyornearchildren
 orinvalidsandwhenevertheunitisleftoperatingandunattended.
4. Alwaysunplugtheelectricreplacewhennotinuse.
5. Donotoperateanyunitwithadamagedcordorplug,oriftheheaterhas
 malfunctioned,oriftheelectricreplacehasbeendroppedordamagedin
 anymanner.Returnheatertoauthorizedservicefacilityforexamination,
 electricalormechanicaladjustment,orrepair.
6. Donotuseoutdoors.
7. Theelectricreplaceisnotintendedforuseinbathrooms,laundryareas
 andsimilarindoorlocations.Neverlocateheaterwhereitmayfallintoa
 bathtuborotherwatercontainer.
8. Donotrunthecordundercarpeting.Donotcovercordwiththrowrugs,
 runners,orthelike.Arrangecordawayfromtrafcareaandwhereitwill
 notbetrippedover.
9. Todisconnecttheunit,turnthecontrolsoff,thenremovetheplugfromthe
 outlet.
10.Donotinsertorallowforeignobjectstoenteranyventilationorexhaust
 openingasthismaycauseanelectricshockorre,ordamagetothe
 heater.
11.Topreventapossiblere,donotblockairintakeorexhaustinany
 manner.Donotuseonsoftsurfaces,likeabed,whereopeningsmay
 becomeblocked.
12.Allelectricalheatershavehotandarcingorsparkingpartsinside.Donot
 useinareaswheregasoline,paint,orammableliquidsareusedorstored
 orwheretheunitwillbeexposedtoammablevapors.
13.Donotmodifytheelectricreplace.Useitonlyasdescribedinthis
 manual.Anyotherusenotrecommendedbythemanufacturermaycause
 re,electricshockorinjurytopersons.

5
14.Avoidtheuseofanextensioncord.Extensioncordsmayoverheatand
 causeariskofre.Ifyoumustuseanextensioncord,thecordmustbe
 No.14AWGminimumsizeandratednolessthan1875Watts.
15.Donotburnwoodorothermaterialsintheelectricreplace.
16.Donotstrikethereplaceglass.
17.Alwaysuseacertiedelectricianshouldnewcircuitsoroutletsberequired.
18.Alwaysuseproperlygrounded,fusedandpolarizedoutlets.
19.Disconnectallpowersupplybeforeperforminganycleaning,maintenance
 orrelocationoftheunit.
20.Whentransportingorstoringtheunitandcord,keepinadryplace,free
 fromexcessivevibrationandstoresoastoavoiddamage.
21.WARNING:Topreventoverheating,donotcoverheater.
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
NOUSER-SERVICEABLEPARTSINSIDE
SAVE THESE INSTRUCTIONS
!NOTE: Proceduresandtechniquesthatareconsideredimportantenough
toemphasize.
CAUTION:Proceduresandtechniqueswhich,ifnotcarefullyfollowed,will
resultindamagetotheequipment.
WARNING:Proceduresandtechniqueswhich,ifnotcarefullyfollowed,will
exposetheusertotheriskofre,seriousinjury,illnessordeath.
!NOTE: Thisequipmenthasbeentestedandfoundtocomplywiththe
limitsforClassBdigitaldevice,pursuanttopart15oftheFCCRules.
Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,uses
andcanradiateradiofrequencyenergyand,ifnotinstalledandusedin
accordance with the instructions, may cause harmful interference to radio
ortelevisionreception,whichcanbedeterminedbyturningtheequipment
offandon,theuserisencouragedtotrytocorrecttheinterferencebyone
ormoreofthefollowingmeasures:
· Reorientorrelocatethereceivingantenna.
· Increasetheseparationbetweentheequipmentandthereceiver.
· Connecttheequipmentintoanoutletonacircuitdifferentfromthatto
whichthereceiverisconnected.

6
· Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynot
causeinterferenceand;(2)thisdevicemustacceptanyinterference,including
interferencethatmaycauseundesiredoperationofthedevice.
Model and Serial Number Information
Ifyouhaveanyquestionsaboutourproductspleasehavetheproduct
modelandserialnumbersavailableuponcallingDimplexcustomer
service.Tolocatethemodelandserialnumberlabelsseebelow
(Figure1).
ModelNumber
SerialNumber
Model
Number
Label
Model
Number
Label
Serial
Number
Label
Serial
Number
Label
Figure 1
Firebox Carton

7
Site Selection and Preparation
Thissectionprovideseasystepbystepinstructionsforselectinga
locationandpreparingthesitetoinstallthereplaceinto:
• Existingreplace
• Newwallconstruction
• Dimplexmantelsurroundkitorcustommademantelsurround
!NOTE: A15Amp,120Voltcircuitisrequired.Adedicatedcircuit
ispreferredbutnotessentialinallcases.Adedicatedcircuitwill
berequiredif,afterinstallation,thecircuitbreakertripsorfuse
blowsonaregularbasiswhentheheaterisoperating.Additional
appliances on the same circuit may exceed the current rating of the
circuitbreaker.
WARNING: Ensurethepowercordisnotinstalledsothatitis
pinched or against a sharp edge and ensure that the power cord is
storedorsecuredtoavoidtrippingorsnaggingtoreducetheriskof
re,electricshockorinjurytopersons.
Construction and electrical outlet wiring must comply with local
buildingcodesandotherapplicableregulationstoreducetheriskof
re,electricshockandinjurytopersons.
 Donotattempttowireyourownnewoutletsorcircuits.Toreduce
theriskofre,electricshockorinjurytopersons,alwaysusea
licensedelectrician.
!NOTE: Thereplaceinsertcomescompletelyassembledand
wired.Sometoolsmayberequiredtopreparethesiteand
assembly/installthetrim.
 Thedimensionsofthereplaceinsertare301/4inch(76.8cm)
wideX251/2inch(64.8cm)highX111/2inch(29.2cm)deep
(Figure2).
 Youshouldallow1/4inch(6.4cm)aroundthereplaceinsertfor
easeofinstallation.Thisreplacedoesnotrequireanyventing.
CAUTION: Clearanceforaircirculationbeneaththereplaceinsert
isprovidedbyfour(4)rubberfeet(Figure2).Do not install the
replaceinsertdirectlyoncarpetorsimilarsurfaceswhich

8
mayrestrictaircirculation.Ifinstallingthereplaceinacarpeted
area,placeaone-piece,solid,atsurfaceunderthereplaceinsert.
Ensurethatallfouroftheinsert’sfeetrestsecurelyonthissurface.
ExistingFireplaceInstallation
1. Sealalldraftsandventswithnon-brousinsulationmaterialsto
preventchimneydebrisfromfallingintothereplaceinsert.Donot
installintoanexistingreplacethatispronetoleaksordampness.
2. Capthetopofthechimneyuetopreventrainfromentering.
3. Planyourelectricalpowersupply(refertoNOTE1).
4. Thepowercordcanrunalongthefrontofthehearthtoanoutlet
nearthereplace.
!NOTE 1: A15Amp,120Voltcircuitisrequired.Adedicatedcircuit
ispreferredbutnotessentialinallcases.Adedicatedcircuitwill
berequiredif,afterinstallation,thecircuitbreakertripsorfuse
blowsonaregularbasiswhentheheaterisoperating.Additional
appliances on the same circuit may exceed the current rating of the
circuitbreaker.
Figure 2
AirCirculationAreas
Rubber
Feet
25 1/2”
(64.8cm)
301/4”(76.8cm)
11 1/2”
(29.2cm)

9
WARNING: Topreventpersonalinjuryyoushouldhirea
professionaltocapthechimneyueorcutaholeintheexisting
replaceforwiring.Ifyoureturnyourexistingreplacetoits
originaluse(example:woodburning),itshouldbeinspectedbythe
localbuildingdepartmentpriortousetoreducetheriskofreand
personalinjury.
New Wall Construction
1. Selectasuitablelocationthatisnotsusceptibletomoistureandis
awayfromdrapes,furnitureandhightrafc.
2. Placethereplaceinthedesiredlocationtoseehowitwilllookin
theroom.
3. Markthedesiredlocationontheoorandstorethereplaceina
safe,dryanddustfreelocation.
4. Usestudstoframeanopeningof303/4inch(78.1cm)wideX25
3/4inch(65.4cm)highX113/4inch(29.8cm)deep(Figure3).
5. Planyourelectricalpowersupply(refertoNOTE1).
Figure 3
30 3/4”
(78.1cm)
25 3/4”
(65.4cm)
11 3/4”
(29.8cm)

10
Option #1 -Thepowercordcanbeleadfrombehindthetrimand
 alongthewalltoanoutletnearthereplace.
Option #2 -Anewoutletcanbeinstalledinsidethenewframe
 construction.
DimplexMantelSurroundKitorCustomMadeMantel
Surround
1. Selectasuitablelocationthatisnotsusceptibletomoistureandis
awayfromdrapes,furnitureandhightrafc.
2. Placethereplaceinthedesiredlocationtoseehowitwilllookin
theroom.
3. Foreaseofelectricalhookupyoumaywishtolocatethereplace
nearanexistingoutlet(refertoNOTE1).
4. Storethereplaceinasafedryanddustfreelocation.
5. Assemblethemantelsurroundkit(refertothemantelassembly
instructions) or construct the custom surround with an opening of
303/4inch(78.1cm)wideX253/4inch(65.4cm)highX113/4
inch(29.8cm)deep(Figure3).
WARNING: Donotattempttowireyourownnewoutletsorcircuits.
Toreducetheriskofre,electricshockorinjurytopersons,always
usealicensedelectrician.
Fireplace Insert Installation
1. Makesuretheunit’sMainON/OFFswitchisswitchedOFF(referto
operatinginstructionsection).
2. Plugtheunitintoa15Amp/120Voltoutlet.Ifthecorddoesnot
reach,youmayuseanextensioncordratedforaminimumof1875
Watts.
3. Pushthereplaceintotheopeningbeingcarefulnottodamagethe
baseofthemantelorcabinetsothatthereplaceisushwiththe
mantelorcabinet.
4. Leveltheunitwithshimsifnecessary(notprovided).
5. Installthetrimontothereplace(refertotriminstallation
instructions).
