Dimplex DTR175C User manual

Table1
Model Rails Watts Weight (kg)
DTR175W/C 12 175 4.4
DTR350W/C 18 350 7.9
Important Safety Advice
WARNING - THE SURFACE OF THIS RADIATOR CAN BE HOT.
In order to be effective the towel rail will get hot, however
momentary contact with any part of it should not cause
injury.
CAUTION - This appliance is not intended for use by
chidren or other persons without assistance or
supervision if their physical, sensory or mental
capabilities prevent them from using it safely. Children
should be supervised to ensure that they do not play
with the appliance.
Precautions should be taken to ensure that prolonged
contact with the towel rail cannot occur. Particular care
should be taken in confined areas where accidental
prolonged contact with the rail could be more likely to
occur.
This appliance should only be used to dry fabrics washed
in water using commonly available detergents.
IMPORTANT - If the towel rail is to be installed in a place
used by the public, a warning notice should be placed
adjacent to the rail advising that the surface can be hot.
WARNING - In order to avoid a hazard for very young
children, this appliance should be installed so that the
lowest heated rail is at least 600mm above the floor.
General
The DTR towel rail is designed to provide an all year round service
for airing towels and articles of clothing. It is not intended to provide
a sole heating service, but the larger model will take the chill off an
average size bathroom, lavatory or en suite. Your rail will be in one
of two sizes and will have either silver chromium plated or white
stove-enamel finish.
No routine maintenance is necessary apart from occasional cleaning.
Both models are splashproof to IPX4 standard.
Electrical
The electrical installation of this towel rail must be carried out by a
competentelectrician in accordancewith the currentI.E.E Regulations
for Electrical Equipment. The towel rail is suitable for use on anA.C.~
electrical supply. Before installation check that the supply voltage
corresponds with that marked on the rail.
IMPORTANT - The wires in the mains lead are coloured in
accordance with the following code:
BLUE - NEUTRAL
BROWN - LIVE
This appliance must only be used on A.C. mains supply of 230/240
Volts~.
Installation
If fitted in a room containing a bath or shower, to comply with the
current I.E.E. Regulations, a cable outlet will be
necessary with the supply to the heater controlled by a
double-pole pull-cord switch having a contact separation of 3mm in
each pole. The body of the switch should be situated as to be
normally inaccessible to a person using a bath or shower. Should
Equipotential Earth Bonding be required the earthing conductor in the
supply cord is deemed to provide the supplementary bonding
connection (see Regulation 547-03-0, ’16th’ Edition I.E.E. Wiring
Regulations.
IMPORTANT - Protect the electrical connection whilst
handling the towel rail.
The towel rail must be permanently fixed to the wall using the wall
brackets supplied. The rail must be mounted vertically as shown
observing the minimum clearances stated.
WARNING - The towel rail is heavy. Care must be taken when lifting
and fitting the towel rail.
Wall mounting
The wall mounting accessory pack contains:
(a) 4 mounting brackets
(b) 1 allen key
(c) 4 wall mounting screws, washers and wall plugs
(d) 4 hex. stud screws
IMPORTANT : THESE INSTRUCTIONS SHOULD BE READ CAREFULLYANDRETAINED FOR FUTURE REFERENCE
Dimensions
(millimetres)
Installation and Operating Instructions
DTR Towel Rails
Models : DTR175W, DTR175C, DTR350W & DTR350C
Fig. 1
08/50116/1 (UK) Issue 1
DTR 350
602
100 min.
843
shelf

W
Procedure for wall mounting
Step 1
Mark suitable hole positions for the four fixing brackets (ensuring
they are horizontal) - see Fig. 2, and allow enough room above and
below for the clearance stated.
Drill and plug the wall to suit - see Fig. 3.
Step 2
The hex. stud screw in the slot has to be removed using the allen key
provided first, to separate the inner ‘Z’ and outer ‘W’ sleeves of the
wall brackets - see Fig. 4.
Mount the four outer sleeve wall brackets in line with the drilled out
holes using the screws provided - see steps 1 - 4 in Fig. 3.
Note: the brackets have slot holes to allow for possible adjustment
later.
Step 3
Remove the cap ‘Y’ from
the inner sleeve
assembly, unscrew the
nut and remove the rail
support ‘X’ - see Fig. 5.
On the inner side (wall)
of the towel rail position
the inner sleeve
between the cross rails
as indicated in Fig. 1.
Position the rail support
to receive the bolt on the
inner sleeve and hand
tighten with the nut - see
Fig. 3.
Slide into position (see
suggested positions in
Fig. 1).
Step 4
Lift the towel rail now with the inner sleeve assembly in position, and
align with the outer sleeve previously fixed to the wall. When all four
inner sleeves are inserted correctly into the outer sleeves of the
brackets tighten each nut fully. Replace the cap ‘Y’ and the hex. stud
screw. The distance the towel rail can be positioned from the wall
can be varied by adjusting the hex. stud screws. When in the desired
location, tighten fully to secure the towel rail to the wall.
To assist with the alignment of the outer ‘W’ and inner ‘Z’ sleeves the
outer sleeve may be adjusted using the slot provided, refer to Note in
step 2.
Drying and Airing Towels
It is recommended that for efficient drying, no more than two layers
of towels or similar fabric should be draped over the rail. Items
should be placed evenly over the whole surface of the rail where
possible.
It is not advisable to leave very damp towels or clothes on the towel
rail when not in use, as this may in time, affect the paint finish.
The rail, although hot to the touch is not hot enough to scorch or burn
fabrics. However, soap and detergents remaining in articles after
washing can cause discoloration. Therefore care should be taken
to thoroughly rinse articles before airing.
Wiring
Wiring Diagrams : for DTR175 see Fig. 6, and DTR350 see Fig. 7.
A B
DTR 175 250 390
DTR 350 380 625
B
A
Fig. 2
Fig. 3
Z
W
Fig. 4
X
Y
W
Fig. 5
Fig. 6
Fig. 7
C2
C1
DTR 175
A
NL
NL
A - Terminal Block
C1 - Cut-out 1
C2 - Cut-out 2
A
L
N
C1
C2
L
N
DTR 350
A - Terminal Block
C1 - Cut-out 1
C2 - Cut-out 2

Operation (Electrical)
Heat will be distributed along each of the rails.
Some variation in the temperature across the surface of the rail is
also normal. When the appliance is covered the heating pattern of
the rails may alter slightly.
Cleaning
The finish on your towel rail can be maintained by occasionally
wiping over with a damp cloth and lightly finishing with a soft dry
cloth. This should only be carried out when the rail is cold. Do not
use abrasive cleaning powders as this could damage the surface
finish.

DimplexUK Limited
Millbrook House
Grange Drive
Hedge End
Southampton
Hampshire. SO30 2DF
[c] Dimplex UK Limited
All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Dimplex UK Limited.
The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility
(EMC) EN55014, EN60555-2 and EN60555-3 which cover the essential requirements of EEC Directives 73/23 and 89/336
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not
be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or
retailer for recycling advice in your country.
After Sales Service
Your product is guaranteed for two years from the date of purchase.
Within this period, we undertake to repair or exchange this product
free of charge (subject to availabilitiy) provided it has been installed
and operated in accordance with these instructions.
Your rights under this guarantee are additional to your statutory
rights, which in turn are not affected by this guarantee.
Should you require after sales service you should contact our
customer services help desk on 0845 600 5111. It would assist us if
you can quote the model number, series, date of purchase, and
nature of the fault at the time of your call. The customer services
help desk will also be able to advise you should you need to purchase
any spares.
Please do not return a faulty product to us in the first instance as this
may result in loss or damage and delay in providing you with a
satisfactory service.
Please retain your receipt as proof of purchase.
UK customer help line 8.00am–5.00pm Mon-Fri and 8:30am-1.00pm Sat (October-March)
Technical Services: Tel. [phone]
Fax. [phone]
e-mail [email protected]
Republic of Ireland Tel. [phone]
