Dimplex MICRO STOVE User manual

08/53475/0 Issue 2
OCN:11503
MICRO STOVE
UK
CHICO
EN : This product is only suitable for well insulated rooms or occasional use. DE : Dieses Produkt ist nur für gut isolierte Bereiche oder gelegentli-
che Verwendung geeignet. FR : Ce produit convient uniquement à des endroits bien isolés ou pour un usage occasionnel. IT : Questo prodotto è
adatto solo per spazi ben isolati o per uso occasionale. ES : Este producto sólo es adecuado para espacios bien aislados o un uso ocasional. NL :
Dit product is uitsluitend geschikt voor goed geïsoleerde ruimten of voor sporadisch gebruik. PL : Produkt ten jest odpowiedni wyłącznie do dobrze
odizolowanych miejsc lub do okazjonalnego użytku. NO : Dette produktet egner seg kun for godt isolerte rom eller sporadisk bruk. RO : Acest
produs este adecvat exclusiv spaţiilor bine ventilate sau utilizării ocazionale. CZ : Tento výrobek je vhodný pouze do dobře izolovaných prostor
nebo k příležitostnému použití. DK : Dette produkt er kun egnet til velisolerede rum eller lejlighedsvis brug. PT : Este produto somente é ade-
quado para espaços bem isolados ou uso ocasional. SE : Denna produkt är endast avsedd för välisolerade utrymmen eller tillfällig användning.
FI : Tämä tuote soveltuu ainoastaan hyvin eristettyihin tiloihin tai satunnaiseen käyttöön. SK : Tento výrobok je vhodný len pre dobre izolované
priestory alebo na občasné použitie. SI : Ta izdelek je primeren le za dobro izolirane prostore ali za občasno uporabo. HR : Ovaj proizvod je
pogodan samo za dobro izolirane prostore ili povremenu upotrebu. HU : Ez a termék csak jól szigetelt terekhez vagy eseti használatra alkalmas.
This product complies with all the required Product Safety, Electromagnetic Compatibility and Environmental
Standards. This product is fully compliant with the LVD, EMC, RoHS and Eco Design Directives.

1
2
max
min
T
1
2
3
I
I
II
II

Technical Information
With mechanic thermostat room temperature control.
General
Unpack the heater carefully and retain the packaging for possible future
use, in the event of moving or returning the re to your supplier.
These models are designed to be free standing and are normally
positioned against a wall.
The re incorporates a ame effect, which can be used with or without
heating, so that the comforting effect may be enjoyed at any time of
the year. Using the ame effect on its own only requires little electricity.
A choice of 600W or 1200W heat output is provided by the fan heater,
which is located at the bottom of the unit.
Before connecting the heater check that the supply voltage is the same
as that stated on the heater.
Please note: Used in an environment where background noise is very
low, it may be possible to hear a sound which is related to the operation
of the ame effect. This is normal and should not be a cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage marked
on the heater must correspond to the supply voltage. Before switching
on, please read the safety warnings and operating instructions.
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
- MicroStove, MCFSTV12E, DXCS12E UK
Important Safety Advice
When using electrical appliances, basic
precautions should be followed to reduce
the risk of re, electric shock, and injury to
persons, including the following:
If the appliance is damaged, check imme-
diately with the supplier before installation
and operation.
Do not use this appliance in the immediate
surroundings of a bath, shower or swimming
pool.
Do not use outdoors.
This appliance must not be located imme-
diately above or below a xed socket outlet
or connection box.
WARNING : The appliance carries the
Warning Symbol indicating that it must
not be covered or has a Do not cover
label. Do not cover or obstruct in any way
the heat outlet grille located underneath the
appliance Overheating will result if the appli-
ance is accidentally covered. Do not place
material or garments on the appliance, or
obstruct the air circulation around the appli-
ance, for instance by curtains or furniturn, as
this could cause overheating and a re risk.
In the event of a fault unplug the heater.Un-
plug the appliance when not required for long
periods.The supply cord must be placed on
the right hand side of the heater away from
the heat outlet underneath the appliance.
Although this appliance complies with safety
standards, we do not recommend its use on
deep pile carpets or on long hair type of rugs.
This appliance can be used by children aged
form 8 years and above and persons with
reduced physical, sensory or mental capabil-
ities or lack of experinence and knowledge if
they have been given supervision or instruc-
tion concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintaince shall not be
made by Children without supervision.
Children of less than 3 years should be
kept away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position
and they have been given supervision or
instruction concerning use of the appliance
in a safe way and understanding the hazards
involved. Children aged from 3 years and
less than 8 years shall not plug in, regulate
and clean the appliance or perform user
maintaince.
The appliance must be positioned so that
the plug is accessible.
If the supply cord is damaged it must be
replaced by the manufacturer or service
agent or similarly qualied person in order
to avoid a hazard.
CAUTION: In order to avoid a hazard due
to inadvertent resetting of the thermal cut-
out, this appliance must not be supplied
through an external switching device, such
as a timer, or connected to a circuit that is
regularly switched on and off by the utility.
CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This instructions can be found at
www.Dimplex.co.uk
Model No: MCFSTV12E, DXCS12E
Heat Output 230V 240V
Nominal Heat Output P Nom 1.1 - 1.2 kW
Minimum Heat Output P min 0.5 - 0.6 kW
Maximum Continous Heat Output P max,c 1.1 - 1.2 kW
Auxiliary Electricity Consumption
In Standby mode el SB 0.02 - 0.02 W

Dimplex
Millbrook House
GrangeDrive
HedgeEnd
Southampton
Hampshire.SO30 2DF
TEL: [phone]
FAX: [phone]
WEBSITE: www.dimplex.co.uk
Republic of Ireland Tel: [phone]
UK UK
Controls - see Fig. 2
These switches provide a choice of heat settings, The appliance is in
standby mode when the mains lead is plugged in. This is indicated by
the red neon behind the ame effect screen.
The two selector switches are in the ON position when the side with
the markings on (i.e. I, or II) is pushed in.
Selector switch 1 (0) Press for ‘ON’ and ‘Standby’. If both selector
switches 2 and 3 are in the OFF position, the
product works on ame effect only.
Selector Switch 2 (I) Provides 600W heat output
Selector Switch 3 (II) Provides 1200W heat output.
Thermostat (T) - see Fig. 2
In order to maintain a certain room temperature, set the controller to
‘max.’. Operate the appliance at full power until the required room
temperature is reached. Set back the thermostatic controller until the
appliance switches off with an audible ‘click’. This temperature will be
kept almost constant by the thermostatic control switching on and off
automatically. Please note that the appliance can only be switched
on when the thermostat setting is higher then the room temperature.
Light Emitting Diode
This re is tted with LED (Light Emitting Diode) bulbs in place of
traditional incandescent bulbs. These generate the same light levels
as traditional bulbs, but use a fraction of the energy consumed.These
bulbs cannot be replaced.
Thermal Safety Cut-out
The built-in overheat cut-out switches off the appliance automatically in
the event of a fault. If this occurs switch off the appliance or disconnect
the mains plug from the socket. After a short cooling down phase, the
appliance is ready for use again. If the fault should occur again, see
your local dealer.
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
- MicroStove, MCFSTV12E, DXCS12E
Maintenance
WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.
Cleaning
For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully with a
soft cloth. DO NOT use proprietary glass cleaners.
To remove any accumulation of dust or uff the soft brush attachment
of a vacuum cleaner should occasionally be used to clean the outlet
grille of the fan heater.
Recycling
At the end of the electrical products useful life it should
not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or
retailer for recycling advice in your area.
After Sales Service
Your product is guaranteed for one year from the date of purchase.
Within this period, we undertake to repair or exchange this product free
of charge provided it has been installed and operated in accordance
with these instructions.
Your rights under this guarantee are additional to your statutory rights,
which in turn are not affected by this guarantee.
Should you require after sales information or assistance with this product
please go to www.dimplex.co.uk where you will nd our self help guide
by clicking on “After Sales” or ring our helpdesk on 0844 879 3588 (UK)
or 01 842 4833 (R.O.I.) .
Spare parts are also available on the website
www.dimplex.co.uk
Please retain your receipt as proof of purchase.
