Nordpeis N-20 T User manual

N-20 T
GB User manual 2
Product no: IN-0N20T-010
Test report No: RRF: 29 15 3996
Last updated: 14.12.2018
DE Montageanleitung 9
FR Manuel d’installation 20

Index
1. Prior to assembling the insert 3
Chimney Draft 3
 Shareduegassystem 3
Air Supply 3
2. Technical Information 3
3. Safety distances 4
4. Assembly 4
Assembling and adjusting the legs 4
Air inlet 4
Flue colar 4
Front frame 5
Ignition air handle 5
Back frame 5
Door assembling 5
Operational control 5
5. Lighting the re for the rst time 5
6. Maintenance 6
Cleaning and inspection 6
Ashes 6
Thermotte™ 6
Door and glass 6
7. Warranty 7
8. Advice on lighting a re 7
Some advice in case of combustion problems 8
IMPORTANT SAFETY PRECAUTIONS!
1. Please follow the installation manual when
connectingyourstove/replacetothechimney/
uepipe.Ifconnecteddi󰀨erentlyfrominstruction
please,considertheheatradiationfromtheue
pipe to the surrounding materials.
2. Before use, please carefully read the user manual
and follow the instructions.
3.Integratedordenedconvectionopeningsmay
never be reduced or partially obstructed. This may
lead to overheating, which again can cause house
reorseriousdamagetotheproduct.
4.Useonlydesignatedrestarters.Never use
gasoline, diesel or other liquids to start the re.
This may cause explosions!
5. Never use other fuel than natural dry chopped
wood. Briquettes, peat, coke, coal and waste
from construction materials develops far higher
temperatures and emissions than natural wood.
Since your product has been designed for use
with natural wood only, other fuels may damage
the product, chimney and surrounding
constructions.
6. In case of damage to glass or door gasket, all use
of the product must be discontinued until the
damage has been repaired.
Failure to follow these precautions will leave your
warranty void and expose people and property to
danger.
Advise: Even if not required in your area, it is always
wisetohaveaqualiedstove/replacetterdothe
installation,oratleastthenalinspectionbeforeuse.
2
GB

1. Prior to assembling the insert
All our products are tested according to the latest
European requirements and also to the Norwegian
standard NS 3058 and NS 3059, which include particle
tests. However, several European countries have local
regulationsforinstallationofreplaces,whichchange
regularly. It is the responsibility of the client that these
regulations are complied with in the country/region
wherethereplaceisinstalled.NordpeisASisnot
responsible for incorrect installation.
Important to check
(please note that this list is not exhaustive):
•distancefromreboxtocombustible/ammable
materials
• insulation materials/requirements between
replacesurroundandbackwall
•sizeofoorplatesinfrontofreplaceifrequired
•ueconnectionbetweenreboxandchimney
•insulationrequirementsifuepassesthrougha
ammablewall
•anaccessforcleaningtheappliance,theuegas
connector,thechimneyuemustbeprovided
Chimney draft
Compared with older models, the clean burning inserts
oftodayputsignicantlyhigherdemandsonthe
chimney. Even the best insert will not work properly
if the chimney does not have the right dimensions or
is not in good working order. The draught is mainly
controlled by gas temperature, outside temperature, air
supply as well as the height and inner diameter of the
chimney. The diameter of the chimney should never
belessthanthatoftheue/chimneycollar.Fordraft
requirements at nominal heat output, see technical
table
The draught increases when:
• The chimney becomes warmer than the outside air
• The active length of the chimney over the hearth
increases
• Good air supply to the combustion
Itcanbedi󰀩culttoobtaintherightdraughtconditions
in case the chimney is too large relative to the insert,
as the chimney does not heat up well enough. In such
cases you may want to contact professional for
evaluation of possible measures. Draught that is too
strong can be controlled with a damper. If necessary,
contact a chimney sweeper.
Attention! Adverse ue draught or adverse weather
conditions, e. g. mist, wind etc., may interfere the
necessary ue draught. This should be checked be-
fore lightening the replace. If there is no necessary
ue draught in the chimney, the use of the replace
should be avoided.
Shared ue gas system
Appliancecanbeconnectedtoshareduegaspipe
sytem. In case of simultaneous operation with other
heatingappliances,theremustbesu󰀩cientcombustion
air provided.
Air supply (mm=AIR)
A set for fresh air supply is available as an accessory.
This will ensure that the air supply to the combustion
chamberislessa󰀨ectedbyventilationsystems,kitchen
fans and other factors which can create a down-draught
in the room. In all new constructions, we strongly
recommend the product is designed and prepared
for direct supply of outside air. In older houses also,
the use of fresh air supply set is also recommended.
Insu󰀩cientairsupplycancausepoordraughtand
therebylowcombustione󰀩ciencyandtheproblemsthis
entails:sootstainsontheglass,ine󰀩cientutilisationof
the wood and a soot deposits in the chimney.
For your own safety, fully comply with the assembly
instructions. All safety distances are minimum distances.
Installation of the insert must comply with the current rules
and regulations of the country where the product is installed.
Nordpeis AS is not responsible for wrongly assembled inserts.
Subject to errors and changes.
For the latest updated version of the manual go to www.
nordpeis.com
2. Technical information
Inserts from Nordpeis all have secondary combustion
and are clean burning. The combustion takes place
intwophases:rstthewoodburnsandthenthe
gases from the fumes are lit by the heated air. This
ensures that new inserts have minimal emissions of
soot particles and un-burnt gases (such as CO) and
are thus better for the environment. Clean burning
inserts require a small amount of wood to obtain good
heatoutput.Useexclusivelycleananddrywood.We
recommendseasonedhardwoodwithamaximum
moisture content of 20%.
Warning! In case of the appliance connected to
shared ue gas pipe system - the Self Closing
Door system must be operational. See FIG 15
Warrning! Extractor fans when operating
in the same room or space as the appliance
may cause problem.
Warning: Keep the air intakes, supplying
combustion and convection air free from blocka-
ge. If the requirements for ventilation are
NOT complied with, the product can overheat.
This can cause a re.
3
GB

3. Safety distances
Firewall
Ensurethattheminimumsafetydistancesarefullled
(FIG 1).
Whenconnectingasteelchimneytothetopoutletuse
the security distances required by the manufacturer.
Important! When placing the insert on
a combustible oor, a steel plate of at least
0.7mm must cover the entire oor surface inside
the surround. Any ooring made of combustible
material, such as linoleum, carpets etc. must be
removed from underneath the steel plate.
4. Assembly FIG 3 - to FIG 12
Assembling and adjusting the legs FIG 3
The insert is delivered with adjustable legs. The legs
are mounted on to the insert using the added bolts and
washers.
Fasten the screws on to the insert with a 13 mm
wrench.
Adjust legs to the desired height before returning the
insert to an upright position (do not tilt the insert).
The height varries according to the surround.
Air inlet FIG 4
Assemble air inlet connector to the insert body with pro-
vided fasteners and tool, as shown on the drawing.
Flue colar FIG 5
The insert is equipped in connector which enable top
uechimneyconnection.
Assemble connector with provided fasteners and tools.
Attention! Our inserts are prepared for connecting
the smoke pipe on the outside of the ue collar
Ø150.
*Alternativeversionsoftheuecollarexistdueto
Nationalrequirements.Fortheueconnectiontothe
chimney, follow the recomenndations from the chimney
manufacturer.
The insert expands when in use, and for
this reason the surround must NEVER rest
on the insert, but have a gap of about 3 mm.
The insert must neither rest on the bench plate or
against the sides. It is recommended to dry stack
the surround in order to adjust the insert prior
to perforating the chimney for the ue connection.
Technical TABLE
Insert N-20T
Material Steel
Surface treatment Heat resistant varnish
Weightofinsert(kg) 99 kg
Draught system Ignition air vent control
and air vent control
Combustion system Clean burning
(Secondary combu-
stion)
Combustion air consumption (m³/h) 8-22,5
Maximumfuellength(cm) 40
Flue outlet Top
Flue collar (Ø mm) Outer 150
*alternate versions exists due to nationa requirements
Fluegastemperatureatue
connector (°C)
313
Fluegasmassow[g/s] 8,0
Draftatueconnector
recommended (Pa)
12-25
Data according to EN 13 229
Area of convection air vent under
insert (cm2)
300
Area of convection air vent over
insert (cm2)
450
Minimum distance conv. air outlet
to ceiling (mm)
700
Nominalheatoutput(kW) 6,8
E󰀩ciency(%) 78
CO @ 13% O2(%) 0,08
Flue gas temperature (°C) 261
Draft (Pa) >12
Fuel recommended: Woodlogs
Fuel length recommended (cm) 25-30
Fuel charge (kg) 1,55
Refueling interval (minutes) 45
Opening of the air vent control (%) 40-50
Operation* Intermittent*
* Intermitent combustion refers to normal use of a replace,
i.e. new wood is inserted when the previous load has burned
down to ember
Warning: If the requirements for ventilation are
NOT complied with, the cooling airow around the
product will be considerably reduced and
the product can overheat.
This can cause a re.
4
GB

Front frame FIG 6
Assemble frame to the insert body with provided screws
and tools as shown on the drawing. Pay attention to
correct postion of air lath and the air valve handle.
Ignition air handle FIG 7
Before assembling the handle screw in the fastening
pins.Whenignitionhandleinplacecheckseveraltimes
if it is kept on position, work properly and smoothly.
Back frame FIG 8
Assemble back frame with fasteners and tools provided.
Assembling heat shields FIG 9 - FIG 11
1. Assemble side covers on insert pins as shown on
drawing FIG 9.
2. Place a rear top cover. Check on both sides FIG 10b
and on a frame FIG 10c correct postion.
3. Asseble a front top cover. Pay attention to proper
overlapping of sides FIG 11a & b.
4.Whenallcoverareinplacejoinittoghetherbyprovi-
ded screws - FIG 11c.
Door assembling & Self closing door mechanism
FIG 12 - FIG 15
In some countries self-closing door mechanism is obli-
gatory by law.
Attention: If you deavtivate the system where is obliga-
tory you risk serious conseqenses enforced by local law.
Attention: If in your country it is not required you can
desactivate it.
Deactivation & Door assembling FIG 12 - FIG 15
The insert doors are provided with tensioned door
springs. Unscrew fastener as shown on FIG 12,
when you hear a noise the mechanism is deactivated.
To assemble door follow steps shown on drawing
FIG 13 - FIG 15.
Door assembling & Activation FIG 13 - FIG 15
Assemblethedoorasshownondrawings.When
the door is on it’s place unscrew the fastener and
realease tensioned spring. Now, the mechanism
is activated.
Attention: The same procedure is applicable to back
door assembling.
Attention: The door can be deinstalled by following
the same steps in reverse order.
Multipurpose key
The insert is equipped with an handle, which is intended
for operating, ie.: air vents, opening and closing doors -
see FIG 16 - FIG 19.
Operational control
Whentheinsertisinuprightposition,andprior
to mounting the surround, control that all functions
are easy to maneuver and appear satisfactory.
A. Ignition vent control B. Air vent control
Pushed in = closed
Pull out = open
Left position = closed
Right position = open
5. Lighting a re for the rst time
Whentheinsertisassembledandallinstructionshave
beenobserved,arecanbelit.
Take care when inserting logs into the burn chamber, in
order not to damage the Thermotte plates.
This will be resolved once the humidity has evaporated.
Ifneededleavethedoorslightlyopentherst2-3times
the insert is used.
It is advisable to ventilate the room well when using
for the rst time as the varnish on the product may
release some smoke or smell. Both the smoke and
smell will disappear and are not hazardous.
Warning!
In order to avoid injuries, please be aware that the
surfaface may become hot during operation and
extra care need to be taken to avoid skin burn.
Lighting a re
Kindling wood
Finely chopped (diameter of 3-5cm)
Length: 25-30cm
Ca. amount pr lighting : 2 kg
Place the air vent control in ignition (FIG A) (Pull out).
Insert small, dry pieces of wood, ignite and ensure the
ameshavetakenproperholdofthewood.Whenthe
amesarestableandthechimneyiswarm,pushinthe
aircontroloutoftheignitionmodeandregulatethere
normally.
Whenthereisaglowinglayerofash,newwoodlogs
can be inserted. Pull the hot ember to the sides of
the combustion chamber when inserting new logs so
that the wood is ignited from the bottom. Insert 2 logs
positionedpararellytotheglassdoor.Thereshould
burnwithbrightandlivelyames.
Reload size
Chopped wood (diametre of 6-9cm)
Length: 25-30cm
Normal load size. 1,55 kg /h
(Max load size: 2 kg/h)
FIG A FIG B
5
GB

After this, replacements can be purchased.If new plates
are needed, contact your dealer.
In case it is necessary to take out the insulation plates,
this is done in followieng order.
A. Side plate
B. Bottom plate
See also drawings from FIG 20 to FIG 23.
Pleasenote:Woodlogsthataretoolongcancause
additional strain and crack the plates, due to the tension
created between the side plates.
Door and Glass
Should there be any soot on the glass it may be
necessary to clean it. Use dedicated glass cleaner,
as other detergents may damage the glass. (NB! Be
careful, even dedicated glass cleaner can damage the
varnish on the door frame and the gaskets). A good
advice for cleaning the glass is to use a damp cloth or
kitchen roll paper and apply some ash from the burn
chamber.Rubaroundtheashontheglassandnisho󰀨
with a piece of clean and damp kitchen roll paper.
NB! Only clean when the glass is cold.
Periodically, it may be necessary to change the gaskets
on the door to ensure that the burn chamber is air tight
and working optimally. These gaskets can be bought as
a set, usually including ceramic glue.
Ceramic glass should
be disposed of as resid-
ual waste, together with
pottery and porcelain
CERAMIC GLASS
CANNOT BE
RECYCLED
Recycling of ceramic glass
Ceramic glass cannot be recycled. Old glass, breakage
or otherwise unusable ceramic glass must be discarded
as residual waste. Ceramic glass has a higher melting
temperature, and can therefore not be recycled together
withglass.Ifmixedwithordinaryglass,itwould
damage the raw material and could, in worst case end
the recycling of glass. It is an important contribution to
the environment to ensure that ceramic glass does not
end up with the recycling of ordinary glass.
Packaging Recycle
The packaging accompanying the product should be
recycled according to national regulations.
WARNING:
Never leave the air control in ignition mode for pro-
longed periods as this may lead to overheating.
Usingtheinsertwithlowcombustione󰀨ectandring
around the clock increase pollution as well as the risk
forareinthechimney.Neverallowtheinsertorueto
becomeglowingred.Turno󰀨theairventcontrolshould
this happen. Regulation of the air vent control takes
someexperience,butafteralittlewhileanaturalrhythm
fortherewillbefound.
6. Maintenance FIG 20 - to FIG 24
Cleaning and inspection
The insert should be inspected thoroughly and clened
at least once per season (possibly in combination with
the sweeping of the chimney and chimney pipes).
To see how to get access to the chimney in order to
chimney sweep see steps shown on FIG 20, FIG 21 &
FIG 24.
Ensure that all joints are tight and that the gaskets are
rightlypositioned.Exchangeanygasketsthatareworn
or deformed.
Remember that the insert must always be cold when
inspected.
The inspection shall be performed by the Professi-
onal servicemen.
Ashes
The ashes should be removed at regular intervals.
Be aware that the ashes can contain hot ember even
severaldaysafterthereisnished.Useacontainer
of non-combustible material to remove the ashes. It is
recommended to leave a layer of ashes in the bottom
as this further insulates the burn chamber.
Take care with the Thermotte plates when the ashes are
removed, particularly when using an ash shovel, so as
not to damage them.
Thermotte™
Theinsulationplates(Thermotte-FIG2)areclassied
as“wearandtear”partswhichwillrequiretobeexchan-
ged after some years.The wear time will depend on the
individual use of your product.
Nordpeiso󰀨ersaone-yearwarrantyontheseparts.
IMPORTANT! Always remember to open
the air vent control (preferably also the door)
before new wood logs are inserted into a hot burn
chamber. Let the ames get a good grip on the
wood before the air control setting is reduced.
When the draught in the chimney is low and
the vent is closed, the gas from the rewood
can be ignited with a bang. This can cause
damage to the product as well as the immediate
environment.
6
GB

7. Warranty
Warning!
Use replacement parts recommended only by the
Manufacturer.
Warning!
Any unauthorized modication of the appliance
without written permission of the Manufacturer
are prohibited.
For detailed description of the warranty conditions see
the enclosed warranty card or visit our website
www.nordpeis.com
The CE mark is placed on the side of the insert.
8. Advice on lighting a re
Thebestwaytolightareiswiththeuseoflightening
briquettes and dry kindling wood. Newspapers cause
a lot of ash and the ink is damaging for the environment.
Advertisingyers,magazines,milkcartonsandsimilar
arenotsuitableforlightingare.Goodairsupplyis
importantatignition.Whentheueishotthedraught
increases and door can be closed
Usecleananddrywoodwithamaximummoisture
content of 20%. Humid wood requires a lot of air for the
combustion,asextraenergy/heatisrequiredfordrying
thehumidwoodandtheheate󰀨ectisthereforeminimal.
This in addition creates soot in the chimney with the risk
ofcreosoteandchimneyre.
In case of a chimney re, close the door and air
supplies on the stove / insert and call the Fire
Brigade. After a chimney re the chimney must in
all cases be inspected by an authorized chimney
sweeper before you use the appliance again.
Storing of wood
In order to ensure that the wood is dry, the tree should
be cut in winter and stored during the summer, covered
and in a location with adequate ventilation. The wood
pile must never be covered by a tarpaulin lying against
the ground as the tarpaulin will then act as a sealed lid
that will prevent the wood from drying. Always keep a
small amount of wood indoors for a few days before use
so that moisture in the surface of the wood can
evaporate.
Warning: NEVER use a lighting fuel such as petrol,
karosine, alcohol or similar for lighting a re. This
could cause injury to you as well as damaging the
product.
Warning: In order to avoid injuries, please be
aware that the surfaface may become hot during
operation.be hot and that extra care need to be
taken to avoid skin burn.
Usage
Not enough air to the combustion may cause the glass
tosoot.Hence,supplytherewithairjustafterthe
woodisadded,sothattheamesandgasesinthe
combustion chamber are properly burnt. Open the air
ventandhavethedoorslightlyajarinorderforthea-
mes to establish properly on the wood.
Note that the air supply for the combustion also can
betoolargeandcauseanuncontrollablerethatvery
quickly heats up the whole combustion chamber to an
extremelyhightemperature(whenusingwithaclosed
or nearly closed door). For this reason you should never
llthecombustionchambercompletelywithwood.
Warning!
The Firebox shall to be always closed except during
ignition, refueling and ash removal.
Choice of fuel
All types of wood, such as birch, beech, oak, elm, ash
andfruittrees,canbeusedasfuelintheinsert.Wood
specieshavedi󰀨erentdegreesofdensity-themore
dense the wood is, the higher the energy value. Beech,
oak and birch has the highest density.
Attention!
We do not recommend using fuel briquettes/ com-
pact wood in our products. Use of such fuel may
cause the product to overheat and exceed the tem-
peratures determined safe. Burning briquettes/
compact wood is done so at your own risk and only
small amounts (max 1/3 of normal load) should be
used for each load.
Warning:
Make sure the insert is not overheated it can cause
irreparable damage to the product. Such damage is
not covered by the warranty.
Source“Håndbok,e󰀨ektivogmiljøvennligvedfyring”
by Edvard Karlsvik SINTEF Energy Research AS and
Heikki Oravainen, VTT.
Warning:
NEVER use impregnated wood, painted wood,
plywood, chipboard, rubbish, milk cartons, printed
material or similar. If any of these items are used as
fuel the warranty is invalid.
Common to these materials is that during
combustion they can form hydrochloric acid and
heavy metals that are harmful to the environment,
yourself and the insert. Hydrochloric acid can also
corrode the steel in the chimney or masonry in a
masonry chimney. Also, avoid burning with bark,
sawdust or other extremely ne wood, apart from
when lighting a re. This form of fuel can easily
cause a ashover that can lead to temperatures
that are too high.
7
GB

Some advice in case of combustion problems
Error Explanation Solution
No draught
The chimney is blocked. Contact a chimney sweeper / dealer for more information or clean
theue,smokeba󰀪eandburnchamber.
Theueissootyorthereisaccumulatedsootonthe
smokeba󰀪e.
Thesmokeba󰀪eiswronglypositioned. Verifytheassemblyofthesmokeba󰀪e-seeassemblyinstructions.
The insert
release smoke
when ligh-
ting the re
and during
combustion
Downdraught in the room caused by no draught, that the
house is too “air tight”.
Lighttherewithanopenwindow.Ifthishelps,more/biggervents
must be installed in the room.
Downdraughtintheroom–causedbyextractorand/or
central ventilation system that pulls too much air out of
the room.
Turno󰀨/regulateextractorand/orotherventilation.Ifthishelps,more
vents must be installed.
Theuesfromtworeplaces/stovesareconnectedtothe
same chimney at the same height.
Oneuemustberepositioned.Theheightdi󰀨erenceofthetwoue
pipes must be of at least 30 cm.
Theueisinadecliningpositionfromthesmokedometo
the chimney.
Theuemustbemovedsothatthereisaninclinationofatleast
10º from smoke dome to chimney. Possibly install a smoke suction
device*.
Theueistoofarintothechimney.
Theuemustbereconnectedsothatitdoesnotenterintothechim-
ney but ends 5 mm before the chimney inner wall. Possibly install a
smoke suction device*.
Soot hatch in the basement or attic that is open and thus
creating a false draught.
Soot hatches must always be closed. Hatches that are not tight or
are defected must be changed.
Damper/topdraughtventsordoorsonreplacesthatare
not in use are open and create a false draught.
Closedamper,doorsandtopdraughtventsonreplacesthatare
not in use.
Anopenholeinthechimneyafterthatareplacehas
been removed, thus creating a false draught. Holesmustbecompletelysealedo󰀨withmasonry.
Defect masonry in the chimney, e.g. it is not airtight
aroundtheuepipeentryand/orbrokenpartitioninside
the chimney creating a false draught.
Seal and plaster all cracks and sites that are not tight.
The cross-section in the chimney is too large which
results in no or very low draught.
Thechimneymustberetted,possiblyinstallasmokesuction
device*.
The cross-section in the chimney is too small and the
chimney cannot carry out all the smoke.
Changetoasmallerreplaceorbuildnewchimneywithalarger
cross section. Possibly install a smoke suction device*.
The chimney is too low and hence a poor draught. Increase the height of the chimney and/or install a chimney cap/
smoke suction device*.
The replace
releases smoke
inside when
it is windy
outside.
The chimney is too low in relationship to the surrounding
terrain, buildings, trees etc.
Increase the height of the chimney and/or install a chimney cap/
smoke suction device*.
Turbulence around the chimney due to the roof being too
at.
Increase the height of the chimney and/or install a chimney cap/
smoke suction device*.
The replace
does not heat
su󰀩ciently.
Thereplacecombustionreceivestoomuchoxygendue
to a leakage under the lower border of the insert or too
strongchimneydraught.Di󰀩culttoregulatethecombus-
tion and the wood burn up too quickly.
Anypossibleleakagemustbesealedo󰀨.Adraughtregulatoror
possibly a damper can reduce the chimney draught. NB! A leakage
of only 5 cm2 is enough for 30% of the heated air to disappear.
Too much
draught
Thesmokebu󰀨eriswronglypositioned. Verifythepositioningofthesmokebu󰀨er–seeassemblyinstruc-
tions.
In case of using oven-dried wood, this requires less air
supply than when using normal wood. Turn down the air supply.
Thegasketsaroundthedoorarewornandtotallyat. Replace the gaskets, contact your dealer.
The chimney is too large. Contact chimneysweeper or other professional for more details.
The glass is
sooty
The wood is too wet. Onlyusedrywoodwithahumidityofmaximum20%.
The air vent control is closed too tightly.
Opentheairventcontroltoaddairtothecombustion.Whennew
wood logs are inserted all vent controls should be completely
openedorthedoorslightlyopeneduntiltheameshaveagood
take on the wood.
White glass
Bad combustion (the temperature is too low). Follow the guidelines in this user guide for correct combustion.
Using wrong material for combustion (such as: painted
or impregnated wood, plastic laminate, plywood etc). Ensure to use only dry and clean wood.
Smoke is rele-
ased when the
door is opened
A levelling out of pressure occurs in the burn chamber. Open the air vent control for about 1 min before opening the door –
avoid opening the door too quickly.
Thedoorisopenedwhenthereisareintheburn
chamber. Open the door carefully and/or only when there is hot ember.
White smoke The combustion temperature is too low. Increase the air supply.
The wood is humid and contains water damp. Ensure to use only dry and clean wood.
Black or grey/
black smoke Insu󰀩cientcombustion. Increase the air supply.
8
GB

Inhalt
1. Vor der Montage 10
Schornsteinzug 10
Gemeinsam genutztes Rauchgassystem 10
Zuluft (=mm AIR) 10
Bodenplatte 10
2. Technische Informationen 10
3. Sicherheitsabstände 11
4. Aufbau 11
Beinmontage und -einstellung 11
Lufteinlass 11
Rauchgasmanschette 11
Zündluftgri󰀨 12
Rückseitiger Rahmen 12
Montage der Hitzeschutzbleche 12
Türmechanismus 12
Montage von Tür 12
Funktionskontrolle 12
5. Erstbefeuerung 12
6. Pege 13
Reinigung und Inspektion 13
Asche 13
Thermotte™ 13
Tür und Glas 14
7. Garantie 14
8. Tipps zur Befeuerung 14
9. Grundsätzliche Anforderungen 14
Hinweise bei Verbrennungsproblemen 18
WICHTIGE SICHERHEITSHINWEISE:
1. Befolgen Sie beim Anschluss Ihres Kaminofens bzw.
Kamins an den Schornstein bzw. das Rauchgasrohr
dieInstallationsanleitung.WennSievonden
Anschlussanweisungen abweichen, beachten Sie die
WärmestrahlungvomRauchgasrohr,dieaufdie
umliegenden Materialien einwirkt.
2.LesenSievordemGebrauchsorgfältigdie
Bedienungsanleitung und befolgen Sie die
Anweisungen.
3.IntegrierteoderandershergestellteKonvektionsö󰀨
nungen dürfen niemals reduziert oder teilweise über-
deckt werden. Dies kann zu einer Überhitzung
führen,waswiederumHausbrändeoderschwere
SchädenamProduktverursachenkann.
4.VerwendenSienurzulässigeFeueranzünder.
Verwenden Sie zum Anzünden niemals Benzin,
Diesel oder andere Flüssigkeiten. Dies kann
Explosionen verursachen!
5.VerwendenSiealsBrennsto󰀨ausschließlich
geschla genes und getrocknetes Naturholz. Briketts,
Torf,Koks,KohleundBauabfälleerzeugenweitaus
höhere Temperaturen und Emissionen als Naturholz.
Da Ihr Produkt nur für eine Verwendung mit Naturholz
ausgelegtist,könnenandereBrennsto󰀨edas
Produkt, den Schornstein und die umliegenden
Bautenbeschädigen
6.BeiSchädenanGlasoderTürdichtungdarfdas
gesamte Produkt erst wieder verwendet werden,
nachdem eine Reperatur ausgeführt worden ist.
Eine Nichtbeachtung dieser Vorsichtsmaßnahmen
führt zu einem Erlöschen der Garantie und setzt
Personen sowie Eigentum Gefahren aus.
Hinweis: Auch wenn dies bei Ihnen nicht erfordert
wird, empehlt es sich stets, einen qualizierten
Kaminofen-/Kamininstallateur mit der Montage zu
beauftragen oder zumindest eine Endabnahme vor
der Inbetriebnahme ausführen zu lassen.
9
DE

1. Vor dem Aufbau des Gerätes
AlleunsereGerätesindgeprüftundentsprechenden
neuesteneuropäischenSicherheitsvorschriften.
VorderInstallationIhresGerätesbeachtenSiebitte
alle geltenden Bestimmungen. *1/ siehe Punkt 9 /
GrundsätzlicheAnforderungen.Nordpeisistnicht
für widerrechtliche oder inkorrekte Instalation Ihres
Gerätesverantwortlich.
Bitte prüfen Sie:
• Abstand zwischen Brennkammer und brennbarer
Umgebung
• Anforderungen an das Isoliermaterial
zwischen Verkleidung und Hinterwand
•GrößederBodenplattevordemGerät,falls
Sie eine brauchen
•RauchrohranschlußzwischenBrennkammer
und Schornstein
• Anforderungen an das Isoliermaterial, falls
dasRauchrohrdurcheinebrennbareWandgeht.
Schornsteinzug
Der Schornstein ist ein wichtiger Faktor für die volle
NutzungeinerFeuerstätte.SelbstdasbesteGerät
wird schlecht funktionieren, wenn der Schornstein
falsch dimensioniert oder nicht in einwandfreiem
Zustand ist. Der Schornsteinzug ist in erster Linie
von der Höhe und dem inneren Durchmesser des
Schornsteinsabhängig,sowievonderRauchgasund
Außentemperatur.DerDurchmesserdesSchornsteins
darf nie geringer als der Durchmesser des Rauchrohres
sein.MindestförderdruckbeiNennwärmeleistungmind.
12 Pa.
DerZug(Förderdruck)wirdstärker,wenn
•derSchornsteinwärmeristalsdieAußenluft
•beilängeremSchornstein
•guteLuftzufuhrbeiderVerbrennunggewährleistetist.
WennderDurchmesserdesSchornsteinsimVergleich
zurFeuerstättezugroßist,istesschwierigeinenguten
Zug zu erzielen, da sich der Schornstein nicht
genügenderwärmt.IndiesemFallholenSiebitteden
RatdesFachmannsein,derSiesicherberät.Beizu
starkem Zug hilft ein Zugreduzierer. Falls notwendig,
kontaktieren Sie einen Schornsteinfeger.
Hinweis! Ungünstige Zugverhältnisse oder widrige
Witterungsbedingungen, z.B. Nebel, Wind usw.,
können den Rauchgaszug beeinträchtigen, der für
das Befeuern erforderlich ist.
Diese Bedingungen sollten vor dem Anzünden des
Kamins überprüft werden. Liegt der erforderliche
Rauchgaszug im Schornstein nicht vor, sollte der
Kamin nicht genutzt werden.
Gemeinsam genutztes Rauchgassystem
DasGerätkannmiteinemgemeinsamgenutzten
Rauchgasrohrsystem verbunden werden. Bei einem
gleichzeitigenBetriebmitanderenHeizgerätenmuss
eine ausreichende Verbrennungsluftmenge zugeführt
werden.
Zuluft (=mm AIR)
Als Zubehör gibt es ein Zuluft-Kit (Anschluss an die
Außenluft).
Ggf.mussfüreinezusätzlicheFrischluftzufuhrgesorgt
werden. *2/ siehe Punkt 9 Verbrennungsluft.
Bodenplatte
Bei nicht feuerfestem Bodenbelag muss vor dem
GeräteinehitzebeständigeBodenplatteliegen.Diese
mussdieFeuerraumtürö󰀨nungvornummindestens
500 mm und seitlich um mindestens 300 mm überra-
gen.
Zu Ihrer eigenen Sicherheit halten Sie sich an die
Montageanleitung. Alle Sicherheitsabstände sind
Mindestabstände. Bei Installation Ihres
Kamineinsatzes beachten Sie die länderspezischen,
örtlichen und baurechtlichen Vorschriften. Nordpeis
trägt keine Verantwortung für falsch aufgestellte
Einsätze.
Vorbehaltlich Druckfehler und Änderungen.
Für die neuesten Informationen gehen Sie bitte auf die
Internetseite www.nordpeis.de.
2. Technische Information
Nordpeis-GerätestelleneineneueGenerationvon
FeuerstättendarundsindfreundlichzurUmwelt.Sie
ermöglicheneinebessereWärmenutzung,brennen
sauber und geben bei korrekter Befeuerung nur
geringsteMengenFeinstaubundKohlensto󰀨(CO)
ab.SauberbrennendeFeuerstättenverbrauchen
weniger Holz.
VerwendenSieausschließlichreinesundtrockenes
Brennholzmitmax.20%Feuchtigkeit.
Warnung! Wenn das Gerät mit einem mehrfach
belegtem Schornstein verbunden wird, muss das
selbstschließende Türsystem funktionsfähig sein.
Siehe Absatz 4 Montage – selbstschließende Tür.
Warnung!
Lufteinlässe, durch die Verbrennungsluft strömt,
dürfen nicht blockiert werden.
Warnung!
Aktive Abluftventilatoren im selben Raum oder Be-
reich wie das Gerät können Probleme verursachen.
10
DE
