Dinex Smart-Therm DX811220 Operating instructions

Operating and Maintenance Manual
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
Smart•Therm®
Model: DX811220 (208-240V 50/60Hz, 1-Phase)
CONTENTS
INTRODUCTION ......................................................................... 2
APPLICATION & USE .................................................................. 2
SAFETY ....................................................................................... 2
INSTALLATION............................................................................ 2
OPERATION INSTRUCTIONS....................................................... 4
MANAGER OPTIONS .................................................................. 4
INFORMATIONAL WARNING5
TROUBLESHOOTING .................................................................. 5
ERROR CONDITIONS .................................................................. 5
MAINTENANCE .......................................................................... 7
FREIGHT CLAIMS........................................................................ 8
DINEX®WARRANTY.................................................................... 8
For Service Information, call 1.888.673.4639
Please provide the following information:
Model number
_______________________
Serial number (from bottom of unit)
________________________________

Smart•Therm®
2
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
INTRODUCTION
Congratulations! You have purchased the new
Dinex®Smart▪Therm®Induction Charger. Your
Dinex®Smart▪Therm®induction heated base system,
when used within a controlled hot food tray line
process and covered with Dinex®insulated domes,
will keep hot plated food up to 60 minutes depending
on menu and initial temperature of food and plate.
Please read thismanual for helpful guidelines on how
to use your new equipment. Should you have any
questions concerning the equipment, please call
Dinex®Service at 1-888-673-4639.
APPLICATION & USE
The equipment is for commercial use only. Not for
household use. It provides maximum induction
heating compatible with Dinex®bases. Use with
Dinex®Smart▪Therm®bases only and use only for
the purpose described.
SAFETY
The instructions contained in this manual provide
important guidelines for the equipment user
regarding correct and safe installation. As you read
this manual, particular attention should be paid to the
precautions given in various parts of this manual with
the following indicators.
! ATTENTION: Use of this symbol identifies a
potentially hazardous situation which, if not avoided,
may result in damage to the machine or injury to the
operator.
! CAUTION: If the product is used without observing
the information given under this symbol, personal
injury, or damage to equipment may result.
! IMPORTANT: Key information for use and
maintenance of the equipment.
GENERAL SAFETY PRECAUTIONS:
! IMPORTANT: The following instructions reduce the
risk of fire, electric shock, injury, and damage to
equipment.
!Do not attempt to repair this equipment.
Repairs and service work must be performed
by qualified service technicians. Service work
performed by anyone other than authorized
Dinex®service agents will void the warranty.
!Do not allow water near the charger. Allowing
water near the charger may cause a fire or
electric shock.
!Do not ever put a base in the microwave. A
microwave will damage the base.
!Do not stack the bases on the charger,
charge ONLY one base at a time.
!Do not use damaged bases.
!Do not leave bases unattended on the
charger.
!Do not attempt to heat anything other than a
Dinex®base. Use of other than genuine
Dinex®bases and/or replacement parts will
void the warranty.
!Do not use the equipment as a work surface
or cutting board.
!Do not use corrosive cleaners on the
equipment. Use only mild detergents.
INSTALLATION
SET UP
1. Carefully remove any packing material from the
induction charger and check loose packing
material for small parts or accessories. Inspect
the charger for concealed damage before placing
packing material aside. Keep the packaging until
you are confident with the equipment’s
performance.
2. The Smart▪Therm®Charger must be installed on
top of a flat, level countertop or shelving. Be
careful to maintain at least two inches of

Smart•Therm®
3
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
clearance on all sides of the charger for cooling.
Do not place over paper or loose material that
may inhibit air flow into the bottom air intakes.
Consider the Dinex®Induction Stand (Accessory
product) DXPICTABLEM (Mobile with casters)
DXPICTABLE (Not mobile).
3. The Smart▪Therm®induction charger isequipped
with a locking plug. This plug is part of a system
that will protect you from injury in the event of an
electrical malfunction inside the unit. Be sure the
plug is fully plugged into a matching socket that is
properly grounded.
! ATTENTION: DO NOT cut or break off the larger
angled prong on this plugor change the plug or power
in any way. Doing so will create a safety hazard and
will also void the warranty.
4. CONFIRM THAT INCOMING VOLTAGE
MATCHES THE CHARGER. The charger must
be plugged into a grounded 208V 1-phase, 20A
dedicated NEMA L6-20R receptacle. A dedicated
electrical outlet is required for EACH
Smart▪Therm®® charger. Make sure that your
Smart▪Therm®Charger is plugged into an
energized circuit.
! CAUTION: A product identification label on the
bottom of the unit specifies the operating voltage,
current, frequency, phase, and maximum wattage of
the charger. Plugging or wiring the charger into less
voltage than the charger is rated may significantly
decrease the performance of the unit or damage
internal electrical components.
! IMPORTANT: Each charger should be connected
to its own dedicated circuit. They should not be
connected to circuits sharing compressors or other
heavy current draw devices (i.e., plate heaters, steam
tables, etc.)
5. Do not use any Smart▪Therm®charger that has
a damaged cord orplug.Consult the warrantyand
follow the instructions for service.
6. Do not move the Smart▪Therm®Charger when it
is electrically connected.
7. Do not place foreign objects on the charger, or
between the Dinex®base and the charger
surface. Foreign objects may heat within the
induction field and cause damage to the charger
surface and/or base.
8. A grease filter is mounted to the bottom of the
unit. Assure the filter is seated and free of
excessive debris or grease. For replacement
filters order DXPLE9560.
9. Do not let the power cord touch hot surfaces.
10.The center of the charger may get hot to the touch
after hours of continuous use. Use caution when
loading and unloading bases.
11.The charger requires ample air flow to cool the
internal electronic components. Air is pulled in
from the bottom of the unit from the front and
sides, and exhausted towards the rear of the unit.
Assure that nothing obstructs the airflow about all
four sides of the unit. Allow at least two inches
from a wall or partition.
! ATTENTION: Do not attempt to open the charger
or perform service of any kind. This product can only
be serviced by a Dinex®Authorized Service Agent or
designated Dinex®personnel. Contact Dinex®at 1-
888-673-4639 for service information.
! IMPORTANT: Any installation not matching the
requirements discussed in this manual will
automatically void the product’s warranty.
! IMPORTANT: Every installation site has different
electrical wiring requirements. Because many
different local codes exist, it is the owner and
installer’s responsibility to comply with all federal,
state, and local codes. Dinex®is not responsible for
any consequential damages, either expressed or
implied, because of failure to comply with installation
requirements.

Smart•Therm®
4
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
OPERATION
INSTRUCTIONS
Make sure your Smart▪Therm®Induction Charger is
plugged into an energized circuit per the
requirements described in the previous section.
USER INTERFACE:
POWER button will turn the unit on and off.
LCD Info Center provides feedback on the status of
bases charging and equipment operation.
SELECT button will be used to reset error conditions,
clear informational messages, and select or set
options.
UP/DOWN arrow buttons are used to move among
Manager Options in the OPTIONS menu. (These are
just right of the SELECT button and not embossed.)
1. The Smart▪Therm®Charger is turned on by
pressing the POWER button on the left front of
the switch panel. The LCD Info Center will display
“Waiting for base…” indicating the Smart▪Therm®
Charger is turned on and ready for use.
2. Place a Dinex®SmartTherm®base on the charger
within the positioning rails. Confirm the base is
seated flat on the top. The charger will beep once
as it recognizes the base.
3. The LCD Info Center will display “Heating Base”
once it has begun charging. A status bar at the
bottom of the screen will continue to fill in to show
the progression of charge. If the base is removed
prior to the status bar being completely filled the
base will not be fully charged and may result in a
lower delivery temperature.
! IMPORTANT: You will hear three loud “BEEPS” if
you remove the base before it is fully charged.
4. Your Smart▪Therm®charger and Smart Base
system uniquely know the heat level of your
bases. You may return a base to the charger at
any time, and your Smart▪Therm®charger will top
off the heat in your base to assure proper delivery
temperature.
5. If the phrase “Waiting for base…” still appears
after placing a base on the charger, remove the
base and reposition –assuring the base is seated
flat to the top, and within the positioning rails.
6. The status bar tracks the progress of the base
charge. After the status bar is completely filled the
charger will display “Base Ready” and will beep
indicating that base is at full temperature. Charge
time for a base will be between 16 to 20 seconds.
Note: Low incoming voltage may increase charge
time.
! IMPORTANT: Fluctuations in voltage may affect
heating time.
7. If the charger sees no activity for an extended
period, it will beep 2 times and go into “Sleep”
mode to conserve power. This will be indicated by
the display reading “Power Save. Press any
button to return to previous mode”. Press any
button to exit “Sleep” mode.
8. Power off the Smart▪Therm®charger by
depressing the POWER button.
MANAGER OPTIONS
Your Smart▪Therm®charger can be set to display in
English, Spanish, or French languages. You may also
choose to disable information alerts (see item 4
below). These options may be changed through the
OPTIONS menu.
1. The unit must be powered down with DINEX®in
the display. Press and hold the SELECT button
for 5 seconds.
2. Release the SELECT button, and within two
seconds, press the POWER button once. The
OPTIONS menu should now be displayed.
3. Use the UP/DOWN arrow buttons to move the
caret symbol (>) to the desired option, and press
SELECT.

Smart•Therm®
5
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
4. The “Set Language”, “Ignore Warnings”, and “Set
LCD Contrast” options will bring up sub-menus
where you may select the desired mode. “Set
Languages” allows you to choose between
displaying English, Spanish, or French. “Ignore
warnings” allows you to suppress the display of
certain informational warning messages. (For
example, you may suppress the display of “Low
Voltage” warnings during times of heavy electrical
demand where voltage on power lines may sag).
5. Choose “Exit” to back out of the displayed menu.
6. At any time, you may also press the POWER
button to cycle the unit back into normal
operation.
INFORMATIONAL
WARNING
Informational WARNING messages may appear
during operation. Make note of and correct the
condition as soon as is practical. Press the SELECT
button to continue normal operation.
1. “WARNING! Low voltage conditions exist.
Performance may suffer. Press SELECT to
continue”. This indicates that the unit senses the
line voltage has dropped and charge times may
be adversely affected. The unit will pause
operation until SELECT is pressed. No harm will
result if you continue to operate the unit. If these
warnings become excessive (for example, during
periods of high electrical demand), they may be
suppressed from the OPTIONS menu.
2. “WARNING! Reduced airflow detected. Check
grease filter. Press SELECT to continue.
TROUBLESHOOTING
! IMPORTANT: For the warranty to remain valid, any
repairs or part replacements must be completed by a
Dinex®qualified service technician authorized by
Dinex®.
Should you require service please call the Dinex®
Hotline at 1-888-673-4639.
The following section explains how to determine if
you are experiencing a problem and what can be
done to correct the problem. This information can be
very helpful if you are calling our Customer Service
department to report any operational difficulties.
1. Errors are displayed in easy-to-understand text
on the LCD Screen.
2. If an error occurs, remove the base from the
charger and turn the charger OFF and back ON
again.
3. If an error persists, remove the base from the
charger, turn the power off and unplug the
charger, wait 5 seconds, and then plug the
charger back in and turn the charger on by
pressing the “POWER” button.
4. When the display reads “Waiting for Base”, put
the base back on the charger to continue
charging. Make sure that the base is properly
positioned on the charger.
5. If the base still doesn’t heat, set it aside and take
it out of service. If other bases exhibit similar
conditions note the error code and call Dinex®
Service.
ERROR CONDITIONS
Errors are indicated by an error code and a message
on the LCD Info Center. Ifthere is more than one error
condition, the display will alternate between the error
messages. It will continuously repeat this cycle until
the errors are reset. Error messages may be reset by
pressing SELECT.
If the error persists after pressing SELECT, turn the
charger off, unplug the power cord, wait 5 seconds
and plug it in again. If the error reappears after this,
turn the charger off and call Dinex®Service
Department at 1-888-673-4639.
Message: Error! (1 or 2) “RFID Communications
problem. Possible bad base.”

Smart•Therm®
6
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
Condition: RFID read/write problem.
Check: Possible bad electronics chip on the
base, or RF antenna/reader problems. If
isolated to one or more bases, set them
aside and call service about those
bases. If the error occurs with many
bases, call service about the charger.
Message: Error! (3) “Incompatible base.”
Condition: Base draws too much current.
Check: Object being heated is not a Dinex®
base or internal charger problem.
Message: Error! (4) “Unit overheat! Check fan
operation. Allow to cool.”
Condition: Internal unit temperature too hot.
Check: Verify grease filters are not dirty or
blocked; airflow is not restricted to the
bottom of the unit. Listen for fan
operation, fan could be stalled. Ambient
operating temperature could be too hot.
If the error persists, call Dinex®service.
Message: Error! (6) “Incoming voltage too high.”
Condition: Line voltage measures greater than
110% of unit rated voltage.
Check: Line voltage spikes, possible voltage
sensing electronics fault. Have
maintenance verify line voltage.
Message: Critical Error! (7) “Unit requires service.”
Condition: Inverter drawing power when
commanded off.
Check: Possible internal electronics fault.
Unplug, wait 5 seconds, and replug unit.
If the error persists, call Dinex®service.
Message: Error! (8) “Check incoming voltage!”
Condition: Poor power quality.
Check: Major line voltage sags (severe brown
out) or internal electronics fault. Have
maintenance verify line voltage. Unplug,
wait 5 seconds, and replug unit. If the
error persists, call Dinex®service.
Message: Critical Error! (9) “Time corrupted.”
Condition: Internal system clock time incorrect.
Check: System clock backup battery dead,
system clock electronics fault, or
electronic noise spike. Cycle POWER
button. Unplug, wait 5 seconds, and
replug the unit. If the error persists, call
Dinex®service.
Message: Critical Error! (15) “RFID failure.”
Condition: RFID reader-to-host communications
failure
Check: RFID reader fault, internal power supply
electronics fault, CPU electronics fault,
bad internal interconnect. Call Dinex®
service.
Message: Critical Error! (16) “Electronics platform
fault.”
Condition: CPU memory corrupt.
Check: Internal CPU fault or electrical noise
spike. Cycle power. If the error persists,
call Dinex®service.

Smart•Therm®
7
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
MAINTENANCE
SMART▪THERM®CHARGER CLEANING
GUIDE
! ATTENTION: Do not submerge the charger in
water. Do not splash or pour water onto the charger’s
control panel or into intake/outlet vents. Possible
shock hazard may result, and the charger may be
damaged. Never spray, wash, or use excessive water
on the charger. Before cleaning it is absolutely
necessary to unplug the power plug.
1. Unplug the charger before cleaning.
2. Wipe the entire charger off with a damp cloth and
mild detergent. Dry the charger before connecting
it to its electrical source.
3. Do not use steel wool or abrasive cleaners or
chlorinated cleaners on the charger.
4. The heating surface is a high strength material.
Please use appropriate care in handling and
cleaning
5. Inspect the unit during cleaning. If the top is
broken or cracked, do not use the charger, call
Dinex®service.
GREASE AND AIR FILTERS
1. WEEKLY inspect and clean the bottom-mounted
grease filter for build-up of debris.
2. To clean, slide the filter out of its holder and run
under a faucet or in dishwasher to clear of debris
and grease.
! ATTENTION: FILTERS MUST BE DRY BEFORE
SLIDING BACK INTO THEIR HOLDERS. Do not
operate your Smart▪Therm®without properly fitted,
dry filters.
3. Replacement filters may be obtained by calling
Dinex®service. SKU:DXPLE9560.
INDUCTION BASE CONDITION & CARE
! ATTENTION: Never attempt to heat anything other
than a Dinex®base.
SMART▪THERM®BASES
•DX821003 - Onyx
•DX821061 –Cranberry
•DX821050 - Blue
•DX821084 –Sage
•DX821031 –Latte
•DX821044 –Graphite Grey
AFTER WASHING THE BASES, STORE IN DINEX®
DRYING RACK.
•DXIBDRS90 - HOLDS 90 INDUCTION BASES
•DXIBDRS180 - HOLDS 180 INDUCTION BASES
•DXIBDRS270 - HOLDS 270 INDUCTION BASES

Smart•Therm®
8
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
FREIGHT CLAIMS
Your Smart▪Therm®Induction Charger was carefully
inspected and packed before leaving our factory. The
transportation company assumes full responsibility
for the safe delivery of this equipment. Dinex® cannot
assume responsibility for damage or loss incurred in
transit. Visible damage or loss should be noted on the
freight bill and signed by the person making the
delivery.
A freight claim should be filed immediately with the
transportation company. If damage is unnoticed or
concealed until the equipment is unpacked, notify the
transportation company immediately and tell them
you want to file a concealed damage claim. This must
be done within seven (7) days after delivery was
made. Be sure to retain all packing materials and
cartons.
DINEX®WARRANTY
STANDARD WARRANTY
Except as indicated otherwise below, Dinex®
warrants that the Warranted Products will be free
from defects in title, material and workmanship under
normal use and service and will perform substantially
in accordance with Dinex®’s written technical
specifications for the Warranted Products (as such
specifications exist on the date the Warranted
Products are shipped) (the “Product Specifications”).
This warranty covers both parts and labor and is
available only to end-users (the “Customers”) that
purchase the Warranted Products from Dinex®or its
authorized distributors. For the purpose of these
warranties, a defect is determined by Dinex®after its
good faith investigation.
SUPPLIES AND ACCESSORIES
Dinex®’s warranty for its supplies and accessories
that are shipped with Warranted Products is covered
by a separate warranty statement, which is available
at www.carlislefsp.com.
SERVICES
Dinex®warrants that any service it provides to
Customer will be performed by trained individuals in
a workmanlike manner.
DURATION
Dinex®provides a two-year warranty for the
Warranted Products. The warranty period begins on
the date the Warranted Products are shipped to
Customer. The warranty period for any Warranted
Product or part furnished to correct a warranty failure
will be the unexpired term of the warranty applicable
to the repaired or replaced Warranted Product.
REMEDIES
If Customer promptly notifies Dinex®of Customer’s
warranty claim and makes the Warranted Product
available for service, Dinex®will, at its option, either
repair or replace (with new or exchange replacement
parts) the non- conforming Warranted Product or
parts of the Warranted Product. With respect to
Dinex®’s licensed software, Dinex®will, at its option,
either correct the non-conformity or replace the
applicable licensed software. Warranty service will be
performed without charge from 8:00 a.m. to 5:00 p.m.
CST, Monday - Friday, excluding Dinex®holidays,
and outside those hours at Dinex®’s then prevailing
service rates and subject to the availability of
personnel.
With respect to Dinex®’s warranty for the services it
provides to the Customer, the Customer’s exclusive
remedy shall be the re-performance of the services
by Dinex®. The foregoing remedies are Customer’s
exclusive remedies and Dinex®’s sole liability for
warranty claims under this warranty statement. This
exclusive remedy shall not have failed of its essential
purpose (as that term is used in the Uniform
Commercial Code) as long as Dinex®remains willing
to repair or replace defective Warranted Products
within a commercially reasonable time after being
notified of Customer’s warranty claim.

Smart•Therm®
9
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
LIMITATIONS
THESE WARRANTIES ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES, WHETHER
WRITTEN, ORAL, EXPRESSED, IMPLIED OR
STATUTORY. EXCEPT AS PROVIDED HEREIN,
NO EXPRESS OR IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE, QUIET
ENJOYMENT, SYSTEM INTEGRATION AND DATA
ACCURACY, WILL APPLY. THERE ARE NO
WARRANTIES THAT EXTEND BEYOND THOSE
DESCRIBED IN THIS DOCUMENT AND NO PRIOR
STATEMENTS BY ANY OF DINEX®’S
REPRESENTATIVES SHALL MODIFY OR EXPAND
THESE WARRANTIES. DINEX®AND DINEX®’S
AFFILIATES AND REPRESENTATIVES SHALL
HAVE NO LIABILITY TO CUSTOMER FOR (1) ANY
SPECIAL, PUNITIVE, INCIDENTAL, INDIRECT OR
CONSEQUENTIAL DAMAGES ARISING OUT OF
OR IN CONNECTION WITH THE WARRANTED
PRODUCTS, REGARDLESS OF WHETHER SUCH
LIABILITY SHALL BE CLAIMED IN CONTRACT,
TORT, EQUITY OR OTHERWISE, (2) ANY
ASSISTANCE NOT REQUIRED UNDER DINEX®’S
QUOTATION OR (3) ANYTHING OCCURRING
AFTER THE WARRANTY PERIOD ENDS.
DINEX®’S STANDARD WARRANTIES ONLY
APPLY TO END-USER-PURCHASERS LOCATED
IN THEUNITED STATES AND CANADA. ANY SALE
TO END-USER- PURCHASERS OUTSIDE THE
UNITED STATES AND CANADA WILL BE
SUBJECT TO COMMERCIAL TERMS
SPECIFICALLY AGREED BY DINEX®AND THE
END-USER PURCHASER. DINEX®MAKES NO
WARRANTY, EXPRESS OR IMPLIED, TO END
USER PURCHASERS OUTSIDE THE UNITED
STATES OR CANADA UNLESS OTHERWISE
EXPRESSLY AGREED IN WRITING.
These warranties do not apply to, and Dinex®shall
not have any obligation to Customer hereunder with
respect to, any warranty claim resulting from or
arising out of: (i) normal wear and tear; (ii) damage
caused by shipping or accident; (iii) damage caused
by improper installation, repair or alteration not
performed by Dinex®; (iv) the use of the Warranted
Product in combination with any software, tools,
hardware, equipment, supplies, accessories or any
other materials or services, not furnished by Dinex®
or recommended in writing by Dinex®; (v) the use of
the Warranted Product in a manner or environment,
or for any purpose, for which Dinex®did not design or
license it, or inconsistent with Dinex®’s
recommendations or instructions on use including,
but not limited to, power supply requirements
identified in Product Specifications; (vi)any alteration,
modification or enhancement of the Warranted
Product by Customer or any third party not authorized
or approved in writing by Dinex®; (vii) Warranted
Product manufactured to meet customer
specifications or designs; or (viii) any accessories or
supplies or other equipment or products that may be
delivered with the Warranted Product.
In addition, these warranties do not cover: (i) Any
defect or deficiency (including failure to conform to
Product Specifications) that results, in whole or in
part, from any improper storage or handling, failure to
maintain the Warranted Products in the manner
described in any applicable instructions or
specifications, inadequate backup or virus protection
or any cause external to the Warranted Products or
beyond Dinex®’s reasonable control, including, but
not limited to, power failure and failure to keep
Customer’s site clean and free of dust, sand and
other particles or debris; (ii) the payment or
reimbursement of any facility costs arising from repair
or replacement of the Warranted Products; (iii) any
adjustment, such as alignment, calibration, or other
normal preventative maintenance required of
Customer; and (iv) expendable supply items.

Operating and Maintenance Manual
2023 CFS Brands- Dinex
®| Oklahoma City, OK 73131
www.cfsbrands.com | 800.654.8210 Manual No. STSIV_2023A
Smart•Therm®
