Diono Radian 3 R User manual

Car Seat Instruction Manual
Manual de Instrucciones de Silla de Carro
READ INSTRUCTION MANUAL
before using this child restraint
Radian®3R®
All-In-One Convertible
Convertible Todo-En-Uno
LIRE LE MODE D'EMPLOI
avant d'utiliser ce dispositif de retenuepour enfant
5-120 lb / 2.3-54 kg

2
WE LOVE TO HELP
Hello there, Welcome to the Diono family!
We’ve created
this lovingly engineered car seat to help keep your child
comfortable and safe with all of the goods and none of the
gimmicks. We look forward to lending a helping hand
each and every day.
Any questions?
Diono U.S.: 1-855-463-4666
SPANISH
REGISTER
Certication
Safe Use Guide
Warning
Car Seat After Collision
Parts
Vehicle Seating Locations
Vehicle Seat Belt Types
How To Switch Your Retractor
LATCH
Top Tether
First Setup
A. Unfolding Car Seat
B. Harness Strap Placement
CONTENTS
84
4
6
7-11
12-15
16
18-19
20-21
22-27
28
29-30
31-40

diono.com 3
CONTENTS
C. Buckle Slot Placement
D. Changing Harness Position
E. Buckle Strap Slot Change
F. Harness Tightening
REAR-FACING INSTALLATION
Detachable Rear-Facing Base
Seat Bight
LATCH Installation
Lap/Shoulder Belt Installation
Lap Belt Installation
FORWARD-FACING INSTALLATION
Adjustable Bottom
SafeStop™
80/20 Overhang Guidance
LATCH Installation
Lap/Shoulder Belt Installation
Lap Belt Installation
Lap Belt Cushion
BOOSTER MODE INSTALLATION
Harness Strap Removal
Harness Strap Replacement
Folding Car Seat
Cover Removal
Aircraft Installation
Comfort Features
Care and Maintenance
Warranty
41-50
51-65
66-69
70-71
72-73
74-75
76
77
78
79-80
81-83

4
Please take a few moments to promptly ll out and return the attached card
or register online using the direct link to the manufacturer’s registration
website provided.
Child restraints could be recalled for safety reasons. You must register this
restraint to be reached in a recall. Send your name, address, e-mail address
if available, and the restraint’s model number and manufacturing date to:
Diono U.S., PO Box 77129, Seattle, WA 98177
or call 1-855-463-4666 or register online at: http://diono.com/product-
registration/
For future reference, in the case of a change of address, please take a
moment to ll out the following information:
Model Number:
Manufacture Date:
This information can be found either on the registration card or on the
manufacturing label located on the seat.
For recall information, call the U.S. Government’s Vehicle Safety Hotline at
1-888-327-4236 (TTY: 1-800-424-9153), or go to http://www.NHTSA.gov.
Time. It goes so fast...
Who would have thought that over two decades have passed since
we rst stepped out into the world and started a business dedicated to
family travel.
Well the world has changed a lot, but we’re proud to say that we haven’t
(sure we’ve grown up), but we are still as passionate about what we do
today as we were back then.
Our story is ‘made of Seattle’, a city like no other. This is a place where
creative minds & innovators rub shoulders within a landscape of
adventure; a place where being‘a little dierent’, is the everyday norm.
With a love for design and an understanding of modern parenting, we
strive to create amazing products, so that you andyour little ones can
celebrate the joy in every journey.
People who own Diono products can be found in all four corners of the
big, blue, green ball we all call home. Some are fans & followers, some
are supporters, tweeters, social media magicians, miracle moms and
devoted dads.
Without your passion, pictures, words and stories, we would never hear
your voice. So tell us about your patch of grass, and join in the hustle
and bustle at diono.com.
Share your journey @diono social
or nd the latest news on,
REGISTER THIS CAR SEAT

diono.com 5
Time. It goes so fast...
Who would have thought that over two decades have passed since
we rst stepped out into the world and started a business dedicated to
family travel.
Well the world has changed a lot, but we’re proud to say that we haven’t
(sure we’ve grown up), but we are still as passionate about what we do
today as we were back then.
Our story is ‘made of Seattle’, a city like no other. This is a place where
creative minds & innovators rub shoulders within a landscape of
adventure; a place where being‘a little dierent’, is the everyday norm.
With a love for design and an understanding of modern parenting, we
strive to create amazing products, so that you andyour little ones can
celebrate the joy in every journey.
People who own Diono products can be found in all four corners of the
big, blue, green ball we all call home. Some are fans & followers, some
are supporters, tweeters, social media magicians, miracle moms and
devoted dads.
Without your passion, pictures, words and stories, we would never hear
your voice. So tell us about your patch of grass, and join in the hustle
and bustle at diono.com.
Share your journey @diono social
or nd the latest news on,
OUR STORY

6
CERTIFICATION
This child restraint system conforms to all
applicable requirements of U.S Federal Motor
Vehicle Safety Standards (FMVSS) 213.
This child restraint is certied for use in aircraft
only when in harness mode.
This child restraint is not certied for use in
aircraft when used in booster mode. Aircraft seats
do not have shoulder belts which are required for
use with this booster.
Diono and the US Federal Aviation Administration (FAA)
strongly urge you to secure your child in a child restraint
system (CRS) or device for the duration of your ight. Please
contact the airline for their specic policies.

diono.com 7
SAFE USE GUIDE
WARNING – failure to follow these instructions
and the product labels can result in serious
injury or death to your child.
Your child’s safety depends on you. Death or serious
injury can occur.
No child restraint can guarantee protection from injury in
every situation, but proper use helps to reduce the risk of
serious injury or death.
Carefully read and understand all instructions and warnings
in this manual. Your child’s safety depends on you knowing
how to setup, install and use this child restraint properly.
Choose the correct mode of use for your child, depending
on their weight and height.
This child restraint is designed for use only with children
who weigh 5–120 lb (2.3–54 kg) and whose height is 57 in
(144 cm) or less in the following modes.

8
SAFE USE GUIDE
DO NOT place this child restraint rear-facing in a vehicle
seating location with an active front air bag.
Choose the proper child restraint belt path
1. REAR-FACING SECTION
2. FORWARD-FACING SECTION
3. BOOSTER MODE SECTION
Choose a suitable location for this child restraint in your
vehicle. REVIEW VEHICLE SEATING LOCATIONS (pg 20).
Install this child restraint tightly in your vehicle. Grab the
sides of the seat where the vehicle seat belt or LATCH strap is
and slide the child restraint side-to-side and front-to-back. If
the seat moves less than 1 in (2.5 cm), it is tight enough.
Secure harness snug and at on your child.
Rear-facing: 5–50 lb (2.3–22.7 kg) and whose height
is 18-44 in (46-112 cm).
Forward-facing: 22–65 lb (10–29.5 kg) and whose
height is 30-57 in (76-145 cm).
Booster: 40–120 lb (18–54 kg) and whose height is
40-57 in (101-145 cm).

diono.com 9
5 lb (2.3 kg)
22 lb (10 kg)
40 lb (18 kg)
50 lb (22.7 kg)
65 lb (29.5 kg)
120 lb (54 kg)
LAP/SHOULDER BELT ONLY
INSTALLATION
REAR-FACING
LATCH/UAS
LAP/SHOULDER BELT
LAP BELT
FORWARD-FACING
LATCH/UAS
LAP/SHOULDER BELT
LAP BELT w/ TOP TETHER
BOOSTER
50 50 50
35
MUST BE
REAR-FACING CAN BE REAR-FACING
22
WITH
SAFESTOP WITHOUT SAFESTOP
40
65
40
65 65
REMOVE 5-POINT HARNESS
WEIGHT
SAFE USE GUIDE
WEIGHT CHART

10
10
SAFE USE GUIDE
Infants who weigh less than 22 lb (10 kg) and are under
1 year old, MUST use this child restraint rear-facing.
For newborn infants, you must consult the infant’s doctor
before using this child restraint. A newborn infant may have
diculty breathing or have other medical problems when
placed in a seated position.
Before installing this child restraint in a vehicle, be sure to
also check the vehicle owner’s manual for information on
proper installation.
Check all installation congurations before discarding the box.
Diono cannot guarantee proper t in all vehicles.
According to accident statistics, children are safer when
properly restrained in the rear seating positions than in
the front seating positions.

diono.com 11
Rear-facing: Harness straps MUST be at or just below
the child’s shoulders. Top of head must be 1.5 in (3.8 cm)
below the top of the car seat shell.
Forward-facing: Harness straps MUST be above the
child’s shoulders. Top of child’s ears MUST be below top of
car seat shell.
Booster mode: Child MUST be
secured using ONLY the vehicle lap/
shoulder belt. Child MUST weigh at
least 40 lb (18 kg), with shoulders
positioned at or above the 4th slot
and remain properly seated for the
entire ride.
ALWAYS install this child restraint in the back seat.
The back seat is the safest place for children 12 and under.
NEVER leave car seat unsecured in your vehicle even
when it is unoccupied. It could injure other occupants in a
sudden stop or collision.
4
SAFE USE GUIDE

12
!WARNING! !DEATH OR SERIOUS INJURY CAN OCCUR!
!
!
Never place this child restraint rear-
facing in a vehicle seating location with
an active front air bag. Death or serious
injury may occur. If an air bag inates,
it can hit the child or child restraint with
enough force to cause serious injury or
death to your child. For vehicles with side
passenger air bags, refer to your vehicle
owner’s manual for information on your
child restraint installation.
Take care to secure the child properly. Snugly adjust the
harness straps provided with this child restraint around
your child. A snug strap should not allow any slack. It lies
in a relatively straight line without sagging. It does not
press on the child’s skin or push the child’s body into an
unnatural position.
For any questions or concerns please contact diono at:
Diono U.S.:
1-855-463-4666 or online at www.diono.com

diono.com 13
!DEATH OR SERIOUS INJURY CAN OCCUR! !
!
EXPIRATION
• DO NOT use the child restraint if any part is damaged
or broken, expired ten year of date of purchase (8
years in 5-point harness, 2 years in booster), missing
instructions, missing parts, or if the straps are cut,
frayed, or damaged in any way. Call to nd out if the
damaged part or parts can be replaced.
Diono U.S.: 1-855-463-4666
SAFE PRACTICES
• DO NOT leave loose objects, such as books, bags,
etc., in the back of the vehicle. In the event of a sharp
turn, sudden stop, or collision, loose objects can be
thrown around and possibly cause serious injury to
vehicle occupants.
• ALWAYS check all surfaces of restraint before securing
your child. In warm weather, child restraints can
become very hot. Do not allow children to play with
vehicle seat belts.

14
!WARNING! !DEATH OR SERIOUS INJURY CAN OCCUR!
!
!
• DO NOT use any accessories, inserts or products not
included with this child restraint, unless approved by
Diono. Items not tested with this child restraint could
injure your child.
• NEVER remove harness from child restraint without
following the proper removal and installation
instructions.
• DO NOT use child restraint without seat cover installed.
• ALWAYS check seat belt or LATCH connectors to ensure
all buckles are securely latched.
• NEVER leave child unattended. Do not allow children to
play in or around the child restraint. Child may become
tangled in harness straps and suocate or strangle.
• ALWAYS keep child properly secured in harness
whenever child is in child restraint.

diono.com 15
!DEATH OR SERIOUS INJURY CAN OCCUR! !
!
• DO NOT use child restraint in any conguration not
shown in the instructions.
• DO NOT modify your child restraint.
• NEVER install in a seat that is rear-facing, side-facing or
on the back of a folded down vehicle seat.
• ALWAYS secure this child restraint with the vehicle’s
child restraint anchorage system (LATCH) if available OR
the vehicle seat belt.
• NEVER use the restraint system in a vehicle seating
position where it cannot be secured tightly. A loosely
installed restraint system will not protect your child
in a collision.
• DO NOT use the LATCH system to attach this child restraint
rear-facing when restraining a child weighing more than
35 lb (15.8 kg) or forward-facing when restraining a child
weighing more than 40 lb (18 kg).

16
CAR SEAT USE AFTER A COLLISION
UNITED STATES
The U.S. National Highway Trac Safety
Administration (NHTSA) recommends that car seats be
replaced following a MODERATE or SEVERE collision
in order to ensure a continued high level of collision
protection for child passengers. In the U.S., car seats
do not automatically need to be replaced following a
MINOR collision.
NHTSA defines a MINOR crash as one in which ALL of
the following apply:
• The vehicle was able to be driven away from the
crash site.
• The vehicle door nearest the car seat was not
damaged.
• None of the passengers in the vehicle sustained any
injuries in the crash.
• If the vehicle has air bags, the air bags did not
deploy during the crash; and
• There is no visible damage to the car seat.
NEVER use a car seat that has been involved in a
MODERATE or SEVERE collision.

diono.com 17
NOTES

18
RADIAN 3 RX
US
i
PARTS
12
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
20
18 19
A
B

diono.com 19
PARTS
1. LATCH Storage
2. Top Tether
3. SafeStop™
4. Instruction Manual Storage
5. Harness Straps
6. Harness Strap Hook
7. Forward-Facing Belt Path
8. Chest Clip
9. Harness Pads
10. Buckle
11. Buckle Pad
12. Harness Release
13. Harness Adjuster Strap
14. Expandable Side Wings
15. Rear-Facing Belt Path
16. Upper Booster Belt Guides
17. Booster Belt Guide
18. Detachable Rear-Facing Base
19. Lap Belt Cushion
20. 80/20 Overhang Guidance
The following products can be purchased online or
through customer service at:
Diono U.S.:
1-855-463-4666 or online at www.diono.com
A. Belt Locking Clip
B. Top Tether Extension Strap

20
VEHICLE SEATING LOCATIONS
!
INSTALL CHILD RESTRAINT CORRECTLY
NEVER place this child restraint rear-facing in a
vehicle seating location with an active frontal air bag.
If the airbag inates, it can cause serious injury or death
to your child. For vehicles with side air bags, refer to your
vehicle owner’s manual for information on your child
restraint installation.
