Direct Supply Attendant Series User manual

Please keep and refer to this Owner’s Manual.
Thank you for purchasing a Direct Supply®Attendant®compressor nebulizer from
Direct Supply®Equipment & Furnishings™. Please read this entire guide carefully and
keep it for future reference. This guide will provide you with instructions, warnings,
warranty information and other important information about your Direct Supply Attendant
Compressor Nebulizer. Share this information with your housekeeping, nursing and
maintenance staff to help ensure the compressor nebulizer is used and cared for properly.
1-800-634-7328 ■directsupply.com
Direct Supply®Attendant®
Compressor Nebulizer
Owner’s Manual

2
Please keep and refer to this Owner’s Manual.
Table of Contents
Table of Contents
Definitions and Symbols ................................................................................................... 3
Introduction/Indications for Use ...................................................................................... 3
Warnings ............................................................................................................................. 4
Directions for Use............................................................................................................... 5
Cleaning ............................................................................................................................. 6
Storage ............................................................................................................................... 7
Product Specifications....................................................................................................... 8
Limited Warranty ............................................................................................................... 9
Customer Service ............................................................................................................ 10

1-800-634-7328 ■directsupply.com 3
Definitions and Symbols
& Introduction/Indications for Use
Definitions and Symbols
NOTE: Indicates a tip.
CAUTION: Indicates correct operating or maintenance procedures in order to
prevent damage to or destruction of the equipment or other property
WARNING: Calls attention to a potential danger that requires correct procedures
or practices in order to prevent personal injury.
•:Attention. Read the instructions.
DEVICE: Your Direct Supply Attendant Compressor Nebulizer
YOU and YOUR: The facility, community or other entity that has purchased the device.
WE, US and OUR: Direct Supply Manufacturing, Inc.
Introduction/Indications for Use
The Direct Supply Attendant compressor nebulizer is a compact medical device
designed to deliver physician-prescribed medication to the bronchial lung
passages through inhalation.
It is developed for the treatment of asthma, allergies and other respiratory
disorders. It creates a stream of air that travels through a clear tube to the
nebulizer. When air enters the nebulizer, it will convert the prescribed medication
into aerosol mist for inhalation.
Your compressor nebulizer should be used under the supervision of a licensed
physician and/or a respiratory therapist. We encourage you to thoroughly read
this Owner’s Manual to learn about the features of this product. Any use of this
product other than its intended use should be avoided.
This device is a tool to assist the caregiver as part of an overall care plan, and not
a substitute for appropriate monitoring, diagnosis, training, care or treatment.
Other devices may be required. This device is intended for use by trained and
licensed healthcare providers in normal, indoor conditions.

4
Warnings
Warnings
• WARNING – To avoid electrical shock: Keep the unit away from water. Do not
immerse the power cord or the unit in liquid. Do not use while bathing. Do not
reach for a unit that has fallen into water - immediately unplug the unit.
• WARNING – Never operate the unit if it has any damaged parts (including
power cord), if it has been dropped or submersed in water. Promptly send it to a
service center for examination and repair.
• WARNING – The unit should not be used where flammable gas, oxygen or
aerosol spray products are being used.
• WARNING – Disconnect the unit from the electrical outlet before cleaning,
filling and after each use.
• WARNING – Do not use other attachments unless recommended by manufacturer.

1-800-634-7328 ■directsupply.com 5
Directions for Use
Directions for Use
• Note: Prior to initial operation, the nebulizer should be thoroughly cleaned.
Step 1: Place your compressor nebulizer on a flat and stable surface. Be sure that
you can easily reach the controls when you are seated.
Step 2: Open the clear cover and remove the inside accessories.
Note: Prior to initial operation, the nebulizer should be thoroughly cleaned
referring to the “Cleaning” section in this manual.
Step 3: Gently twist the top part of the nebulizer counter-clockwise to disassemble
the nebulizer.
Step 4: Fill the bottom section of the nebulizer with the medication prescribed by
your physician. Be sure that the cone is put inside the bottom section.
Step 5: Gently twist the top part clockwise to re-assemble the nebulizer. Be sure
the two sections fit well.
Step 6: Attach one end of air tube to the base of the nebulizer.
Step 7: Attach the other end of air tube to the air tube connector located on the
front of the compressor.
Step 8: Attach to the top section of nebulizer.
Step 9: Plug the power cord into an appropriate electrical outlet. Make sure at this
stage, the power switch is at “OFF” status.
Step 10: Press power switch to begin your prescribed treatment.
• Note:
The compressor motor has a thermal protector which will shut off the unit before
the unit is overheated. When the thermal protector shuts the unit off, please:
a) Switch off the unit.
b) Unplug the unit from the electrical outlet.
c) Wait 30 minutes for the motor to cool down before another treatment. Make
sure the air openings are not obstructed.
Step 11: When treatment is finished, shut off the unit and unplug it from the
electrical outlet.

6
Cleaning
Cleaning
It is recommended that the nebulizer and mouthpiece are thoroughly cleaned with
hot water after each use and cleaned with a mild detergent after the last treatment
of the day. If your physician or respiratory therapist specifies a different cleaning
procedure, follow their instructions.
Cleaning Notes:
a) Do not immerse the unit in water. It may damage the unit.
b) Disconnect the unit from the electrical outlet before cleaning.
c) Clean all necessary parts after each use as instructed in this guidebook.
Rinsing (after each treatment):
Step 1: Disconnect the air tube, nebulizer and mouthpiece.
Step 2: Gently twist the nebulizer to open it.
Step 3: Rinse the nebulizer and mouthpiece with water.
Step 4: Dry them with clean soft towel or let air dry.
Step 5: Reassemble the nebulizer when completely dry and put these parts in a
dry, sealed container.
Disinfections:
Please follow the following steps to disinfect your nebulizer unless otherwise
specified by your physician. It is suggested that the unit is disinfected after the last
treatment of the day.
Step 1: Use one part white vinegar with three parts distilled water. Make sure
mixed solution is enough to submerge the nebulizer, mouthpiece.
Step 2: Complete above Rinsing Steps 1-3.
Step 3: Wash the nebulizer, mouthpiece in warm water and a mild detergent. Then
wash them in hot tap water.
Step 4: Submerge these parts in the vinegar and water solution for 30 minutes.
Step 5: Complete above Rinsing Steps 3-5.
Cleaning the Compressor:
Step 1: Wipe daily with a damp cloth.
Step 2: Do not use any powdered cleaners or soap pads, which may damage
the finish.
Filter Change:
Step 1: Do not use cotton or any other materials. Do not wash or clean the filter. Only
use filters supplied by your distributor. And do not operate without a filter.
Step 2: Change the filter every 30 days or when the filter turns gray.
Step 3: Changing procedure:
a) Remove the filter cover.
b) Replace the used filter with a new one.
c) Replace the filter cover.

1-800-634-7328 ■directsupply.com 7
Storage
Storage
Store the device in a cool, dry place. Do not store near heaters or other devices
that could physically damage the product. Always store the device with the plug
disconnected from a power source.

8
Product Specifications
Product Specifications
Power AC 120V, 60 Hz (230V/ 50 Hz available)
Power Consumption 180VA
Medication Capacity 5 ml
Particle Size 0.5 to 10 μm
MMAD 4 μm
Sound Level Less than 60 dB at 1 meter
Average Nebulization Rate ≥0.2ml/min
Compressor Pressure Range 29 to 43 Psi (200 to 300 KPa/2.0 to 3.0 bar)
Operating Pressure Range 10 to 16 Psi (70 to 110 Kpa/0.7 to 1.1 bar)
Liter Flow Range 6 ~ 8 LPM
Operating Temperature Range 10˚C to 40˚C (50˚F to 104˚F)
Operating Humidity Range 10 to 95% RH
Storage Temperature Range -20˚C to 70˚C (-4˚F to 158˚F)
Storage Humidity Range 10 to 95 % RH
Dimension (L x W x H) 285 x 170 x 95 mm (8.3" x 7.7" x 5.9")
Weight 4.3 lbs (2.0kg)
Standard Accessories Nebulizer, Air Tube, Mouth Piece, Filters (5 pcs)
Optional Accessories Adult Mask
UL Classified E239062

1-800-634-7328 ■directsupply.com 9
Limited Warranty
Limited Warranty
We offer to you, as the original purchaser, a warranty for the Direct Supply
Attendant Compressor Nebulizer. Our warranty applies for the limited warranty
period stated below. If any device or device part listed below is defective in
material or workmanship during the applicable limited warranty period, we will
repair or replace it at our cost. Please note that the decision to repair or replace
a device or device part will be at our discretion. Our warranty applies only if the
device is properly maintained by the original purchaser for normal, indoor use and
does not cover normal wear and tear, modification of the device or damage caused
by abuse, improper use, failure to maintain, use which exceeds the published
device limitations or the combination of any device with another product. In
addition, our warranty does not cover fading, characteristics or natural variations in
fabric, texture, colorfastness, stains, spills or exposure to chemicals, odors, heat or
light. In certain cases, we may provide you repair or adjustment instructions and/
or replacement parts, and ask you to perform a repair or adjustment or replace a
defective part. Our warranty gives you specific legal rights, and you may also have
other rights, which vary, from state to state. Please note that our limited warranty
period begins when we ship the device to you. The limited warranty period and our
obligations under the warranty end once you transfer the device to someone else,
or at the end of the applicable limited warranty period identified below, whichever
is earlier.
Warranty Period
(Parts)
Anticipated Usable
Device Life
Direct Supply Attendant
Compressor Nebulizer
(excluding accessories)
5 years 5 years
DIRECT SUPPLY MANUFACTURING, INC. MAKES NO IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE; THESE AND ALL
OTHER IMPLIED WARRANTIES ARE SPECIFICALLY DISCLAIMED. TO THE FULLEST
EXTENT ALLOWED BY LAW, DIRECT SUPPLY MANUFACTURING, INC. WILL NOT
BE LIABLE FOR ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL OR PUNITIVE
DAMAGES, OR LOST PROFITS THAT MAY RESULT FROM THE DEVICE OR YOUR
USE OF OR INABILITY TO USE THE DEVICE, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. OUR TOTAL LIABILITY TO YOU, IF ANY, IS LIMITED TO THE
PRICE OF THE DEVICE OR SERVICE GIVING RISE TO YOUR CLAIM.
Some states do not allow an exclusion or limitation of incidental or consequential
damages or how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you. If implied warranties are not excluded, and to the
extent allowed by law, we limit any and all implied warranties to the applicable
warranty period identified above. Except for rights under any applicable state law,
the remedies provided under this warranty are your sole and exclusive remedy for
any breach of our warranty and state the entire limit of our responsibilities.

10
Customer Service
Customer Service
Our promise to you is that you will have a convenient and easy ordering
experience, receive a quality device and enjoy outrageous customer service. If
you have any questions about the compressor nebulizer you have purchased
or would like to request warranty service, please contact us at: Direct Supply®
Equipment & Furnishings™, 1-800-634-7328, 6767 North Industrial Road,
Milwaukee, WI 53223, [email protected]

1-800-634-7328 ■directsupply.com 11

#4895
1-800-634-7328 ■directsupply.com
Date of Printing: September 2011
This product is available to purchase exclusively through Direct Supply®Equipment & Furnishings™, a division of Direct Supply, Inc.
Distributed by Direct Supply Manufacturing, Inc. 6699 N Industrial Road, Milwaukee, WI 53223.
© 2011 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply®and all associated logos are the registered trademarks of
Direct Supply, Inc.
