Directed Electronics Viper 5601 User manual

Models
Viper 5601
Clifford 2.2
Python 1601
Security and Remote Start
Installation Guide
This product is intended for installation by a professional
installer only! Attempts to install this product by a per-
son other than a trained professional may result in severe
damage to a vehicle’s electrical system and components.
© 2009 Directed Electronics, Vista, CA
N5102 2009-09

Bitwriters with a date code of 6a or older require an IC upgrade (p/n
998M). Some bitwriters with a date code of 6B do not require the IC
upgrade, refer to tech tip # 1112 for more information.
Bitwriter®, Code Hopping™, Doubleguard®, ESP™, Fail-
Safe®, Ghost Switch™, Learn Routine™, Nite-Lite®, Nuisance
Prevention® Circuitry, Revenger®, Silent Mode™, Soft Chirp®,
Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn
Away® are all Trademarks or Registered Trademarks of Direct-
ed Electronics.
The Bitwriter®(p/n
998U) requires chip
version 2.7 or newer to
program this unit.

Contents
Warning! safety first........................................................................................................................ 4
Wiring Diagram ............................................................................................................................. 5
Wiring Connections ........................................................................................................................ 6
Main Harness (H1), 12-pin connector .......................................................................................... 6
H2 Harness, 18-pin connector .................................................................................................... 6
Remote Start, (H3) 10-pin connector ............................................................................................ 6
Door Lock, 3-pin connector......................................................................................................... 7
Adjusting the Sensor........................................................................................................................ 7
Initializing Virtual Tach (not needed w/hardwire tach inputs)................................................................ 7
Learning the Tach (not needed with Virtual Tach) ................................................................................. 8
Neutral safety switch interface .......................................................................................................... 8
Testing the neutral safety switch................................................................................................... 8
Remote Start Shutdown/Startup Diagnostics ....................................................................................... 9
Remote Pairing ............................................................................................................................. 10
Programming System Features ........................................................................................................ 11
Feature Menus .............................................................................................................................. 12
Menu 1 - Security .................................................................................................................... 12
Menu 2 - Convenience............................................................................................................. 14
Menu 3 - Remote start .............................................................................................................. 16
Bitwriter - Only Options ................................................................................................................. 18
Basic Remote Functions.................................................................................................................. 20
Reset and Deletion ........................................................................................................................ 20
Table of Zones .............................................................................................................................. 21
Troubleshooting: Alarm.................................................................................................................. 21
Troubleshooting: Remote Start......................................................................................................... 22

4© 2009 Directed Electronics. All rights reserved.
Warning! safety first
The following safety warnings must be observed at all times:
Due to the complexity of this system, installation of this product must only be performed by an authorized•
Directed Electronics dealer.
When properly installed, this system can start the vehicle via a command signal from the remote control.•
Therefore, never operate the system in an area that does not have adequate ventilation.
The following precautions are the sole responsibility of the user; however, authorized Directed Electronics
dealers should:
Never use a test light or logic probe when installing this unit. Always use a multimeter.•
Never operate the system in an enclosed or partially enclosed area without ventilation (such as a ga-•
rage).
When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote•
start system must be disabled using the installed toggle switch. It is the user’s sole responsibility to prop-
erly handle and keep out of reach from children all remote controls to assure that the system does not
unintentionally remote start the vehicle.
USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT•
TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PAR-
TIALLY ENCLOSED VEHICLE STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.
Use of this product in a manner contrary to its intended mode of operation may result in property damage,
personal injury, or death. Except when performing the Safety Check outlined in this installation guide, (1)
Never remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the
keys in the ignition. The user is responsible for having the neutral safety feature of the vehicle periodically
checked, wherein the vehicle must not remotely start while the car is in gear. This testing should be performed
by an authorized Directed Electronics dealer in accordance with the Safety Check outlined in this product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the
user to fix the problem immediately.
After the remote start module has been installed, test the remote start module in accordance with the Safety
Check outlined in this installation guide. If the vehicle starts when performing the Neutral Safety Shutdown
Circuit test, the remote start unit has not been properly installed. The remote start module must be removed
or properly reinstalled so that the vehicle does not start in gear. All installations must be performed by an
authorized Directed Electronics dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS IN-
TENDED MODE OF OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS
MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT
AND REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. DIRECTED ELECTRONICS WILL
NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
Remote starters for manual transmission pose significant risks if not properly installed and operated. When
testing to ensure the installation is working properly, only remote start the vehicle in neutral gear, on a flat
surface and with a functional, fully engaged parking brake. Do not allow anyone to stand in front of or behind
the vehicle.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission.
Installation in such vehicles may pose certain risk.

5
© 2009 Directed Electronics. All rights reserved.
Wiring Diagram
Valet switch
LED
Control button
Status LED
Control Center
Control Center
Control Center Valet switch
LED
Control button
Status LED
Control Center
Control Center 6111T
CPU1
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
Optional Mux Port
(for additional sensors)
Bitwriter
Port
Neutral Safety
Switch
110 9 8 7 6
12345
1
1 8
51
1 3
10
12
18 10
91
1 12
D2D Port (for external
Xpresskit interface module)
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
ON
IMPORTANT! Neutral Safety
switch must be plugged in
and in the ON position
D2D jumpers; Factory setting is horizontal position.
Most Xpresskit modules use this setting, check the
Xpresskit installation guide for the specific setting.
RF Port
for IVU
Control Center
Temperature
Sensor Door Lock
(see wiring tables)
Remote Start (H3)
(see wiring tables)
Main Harness (H1)
(see wiring tables)
H2 Harness
(see wiring tables)

6© 2009 Directed Electronics. All rights reserved.
Wiring Connections
Main Harness (H1), 12-pin connector
H1/1 RED/WHITE (-) 200mA AUX/TRUNK OUTPUT
H1/2 RED (+)12VDC CONSTANT INPUT
H1/3 BROWN (+) SIREN OUTPUT
H1/4 WHITE/BROWN PARKING LIGHT ISOLATION WIRE - PIN 87a of onboard relay
H1/5 BLACK (-) CHASSIS GROUND
H1/6 VIOLET (+) DOOR TRIGGER INPUT
H1/7 BLUE (-) TRUNK PIN/ INSTANT TRIGGER INPUT (N/C OR N/O)
H1/8 GREEN (-) DOOR TRIGGER INPUT (N/C* OR N/O)
H1/9 BLACK/WHITE (-) 200mA DOME LIGHT SUPERVISION OUTPUT
H1/10 WHITE/BLUE (-) REMOTE START/ TURBO TIMER ACTIVATION INPUT
H1/11 WHITE PARKING LIGHT OUTPUT
H1/12 ORANGE (-) 500mA GROUND WHEN ARMED OUTPUT
*The Normally Closed setting will only work if one of the vehicle's doors is connected. If more than one door
is to be monitored, then it is recommended to use the Xpresskit DTIMAZDA or tech tip # 1921 on www.direct-
echs.com to interface with these types of vehicles.
H2 Harness, 18-pin connector
H2/1 LIGHT GREEN/BLACK (-) 200mA OEM ALARM DISARM OUTPUT
H2/2 ORANGE/BLACK (-) 200mA AUX 4 OUTPUT
H2/3 GREEN/WHITE (-) 200mA OEM ALARM ARM OUTPUT
H2/4 VIOLET/BLACK (-) 200mA AUX 2 OUTPUT
H2/5 WHITE/BLACK (-) 200mA AUX 3 OUTPUT
H2/6 WHITE/VIOLET (-) 200mA AUX 1 OUTPUT
H2/7 GREY/BLACK (-) DIESEL WAIT TO START INPUT
H2/8 BROWN/BLACK (-) 200mA HORN HONK OUTPUT
H2/9 VIOLET/WHITE TACHOMETER INPUT
H2/10 DARK BLUE (-) 200mA STATUS OUTPUT
H2/11 PINK/WHITE (-) 200mA FLEX RELAY CONTROL OUTPUT
H2/12 ORANGE (-) 200mA ACCESSORY OUTPUT
H2/13 PURPLE (-) 200mA STARTER OUTPUT
H2/14 PINK (-) 200mA IGNITION 1 OUTPUT
H2/15 GREY (-) HOOD PIN INPUT (N/C OR N/O)
H2/16 BLUE/WHITE (-) 200mA 2ND STATUS /REAR DEFOGGER OUTPUT
H2/17 BROWN (+) BRAKE SHUTDOWN INPUT
H2/18 BLACK/WHITE (-) NEUTRAL SAFETY INPUT
Remote Start, (H3) 10-pin connector
H3/1 PINK (+) IGNITION 1 INPUT/OUTPUT
H3/2 RED/WHITE (87) FLEX RELAY +12V INPUT (30A FUSED)
H3/3 ORANGE (+) ACCESSORY OUTPUT
H3/4 VIOLET (+) STARTER OUTPUT (CAR SIDE OF THE STARTER KILL)
H3/5 GREEN (+) STARTER INPUT (KEY SIDE OF THE STARTER KILL)
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
09
11
10
06
08
07
22
66
88
77
1
1
1
1
0
1
1
1
1
0
99
55
1
2
1
2
44
33
ELECTRONICS
R
3
1
4
2
TACHLEARN THREASHOLD
JMP1 OFF ON
CPU1
NOTE: Pin 1 is on the left
TACH threshold OFF:
TACH threshold ON:
Bitwriter
Port
Neutral Safety
Switch
Remote
Start In
Status
LED
Valet
Port
Door Lock/
Unlock Output
Relay Out
Port
H2
Port
110 9 8 7 6
12345
1
1 8
51
1 3
10
12
To change
jumper
settings
1 12
CPU1
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
Bitwriter
Port
Neutral Safety
Switch
Status
LED
Valet
Port
110 9 8 7 6
12345
1
1 8
51
1 3
10
12
TACH threshold OFF:
TACH threshold ON:
To change
jumper settings
18 10
91
1 12
D2D Port
(for external
Xpresskit
interface
module)
Optional Mux Port
(for additional sensors)
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
ON
IMPORTANT! Neutral Safety
switch must be plugged in
and in the ON position
D2D jumpers; Factory setting is horizontal position.
Most Xpresskit modules use this setting, check the
Xpresskit installation guide for the specific setting.
RF Port
for IVU
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
09
11
10
06
08
07
22
66
88
77
1
1
1
1
0
1
1
1
1
0
99
55
1
2
1
2
44
33
ELECTRONICS
R
3
1
4
2
TACHLEARN THREASHOLD
JMP1 OFF ON
CPU1
NOTE: Pin 1 is on the left
TACH threshold OFF:
TACH threshold ON:
Bitwriter
Port
Neutral Safety
Switch
Remote
Start In
Status
LED
Valet
Port
Door Lock/
Unlock Output
Relay Out
Port
H2
Port
110 9 8 7 6
12345
1
1 8
51
1 3
10
12
To change
jumper
settings
1 12

7
© 2009 Directed Electronics. All rights reserved.
H3/6 RED IGNITION 1 +12V INPUT (30A FUSED)
H3/7 PINK/WHITE (30) FLEX RELAY OUTPUT (car side of ign, acc or starter wire)
H3/8 PINK/BLACK (87a) FLEX RELAY INPUT (key side of ign, acc or starter wire if needed)
H3/9 RED/BLACK ACCESSORY/STARTER RELAY +12V INPUT (30A FUSED)
H3/10 NC No Connection
Door Lock, 3-pin connector
1 BLUE (-) 500mA UNLOCK OUTPUT
2 EMPTY NOT USED
3 GREEN (-) 500mA LOCK OUTPUT
Adjusting the Sensor
Adjusting the sensor with the 1way remote control:
Disarm the system, turn the ignition Off and close all the doors.1. Press and hold the2.
A U X
button of the remote control for 8 seconds (If Car 2 mode is on, ignore the Car
Select LED flash after 3 seconds) or until the amber LED turns on.
Press and hold the3.
A U X
button 1.5 seconds or until the amber led flashes then comes on solid.- The control
module emits one long chirp, confirming that it has entered adjustment mode.
Press the4.
A U X
,
A U X
or
A U X
buttons to adjust the sensor level.
Note: You can test the new setting by cautiously impacting the vehicle with increasing intensity until the
siren chirps, indicating the impact level required to fully trigger the alarm.
•
A U X
button: Pressing this button increases the sensitivity one level. The siren chirps twice confirming the
sensitivity adjustment.
•
A U X
button: Pressing this button decreases the sensitivity one level. The siren chirps once confirming the
sensitivity adjustment.
•
A U X
button: Pressing this button resets to default level 7. The siren chirps three times.
To exit the shock sensor adjustment mode from the 1 way remote control:
Press and release the
A U X
button any time during programming to go back to the main menu. Press and hold
for 1.5 seconds in the main menu to exit programming.
To exit the shock sensor adjustment mode from the control module:
Open an entry point or turn on the ignition, the control module emits one long chirp exiting adjustment
mode.
Initializing Virtual Tach (not needed w/hardwire tach inputs)
To program Virtual Tach:
After the install is complete,1. remote start the engine. The programming operation may require 3 cranks of
the starter before the engine starts and runs. Do not turn off the remote start if this happens, it is a normal
programming operation.
Once the engine begins running, let it run for at least 30 seconds.2. Using the Remote, send the Remote start command to turn remote start off. Virtual Tach is programmed.3. To reset Virtual Tach, go into the Reset and Deletion section of this guide. Virtual Tach cannot be reset with
the Bitwriter.
Note: Virtual Tach cannot be used in MTS Manual Transmission Mode. It is also not recommended for diesel
trucks.
Virtual Tach handles disengaging the starter motor during remote starting – it does not address over-rev. If the
customer wants to have the over-rev protection capability, the tach wire must be connected.
10A FUSE
MINI ATM
RPN: 8540
LIGHT FLASH POLARITY
(10A (MAXIMUM) FUSE JUMPER)
+ -
09
11
10
06
08
07
22
66
88
77
1
1
1
1
0
1
1
1
1
0
99
55
1
2
1
2
44
33
ELECTRONICS
R
3
1
4
2
TACHLEARN THREASHOLD
JMP1 OFF ON
CPU1
NOTE: Pin 1 is on the left
TACH threshold OFF:
TACH threshold ON:
Bitwriter
Port
Neutral Safety
Switch
Remote
Start In
Status
LED
Valet
Port
Door Lock/
Unlock Output
Relay Out
Port
H2
Port
110 9 8 7 6
12345
1
1 8
51
1 3
10
12
To change
jumper
settings
1 12

8© 2009 Directed Electronics. All rights reserved.
Important: After successfully learning Virtual Tach, a small minority of vehicle starters
may over crank or under crank during remote start. The Bitwriter can be used fine tune
the starter output time in 50mS increments to compensate for such an occurrence.
Learning the Tach (not needed with Virtual Tach)
To learn the tach signal:
Start1. the vehicle with the key. Within 5 seconds, press and hold the Control button.
After 3 seconds the status LED on your Control Center lights constant when the tach signal is learned.2. Release3. the Control button.
Note: When the tachometer is programmed the main unit automatically enters the Tachometer engine check-
ing mode.
Neutral safety switch interface
Some vehicles do not have an electrical neutral safety switch. Instead, the vehicle has a mechanical neutral
safety switch that physically interrupts the starter wire and is used when the vehicle is in any drive gear. If the
remote start is interfaced before this switch, it will provide protection from starting in gear. However, some
vehicles combine the column shift mechanism and the mechanical neutral safety switch into one mechanical
part.
Important: You must complete the remote start system installation before doing the follow-
ing test. Ensure that the remote start system is functioning normally. This includes connect-
ing to the brake as a shut-down.
Testing the neutral safety switch
Make sure there is adequate clearance to the front and rear of the vehicle because it may move slightly.1. Make sure the hood is closed and there are no remote start shut-downs active.2. Set the emergency brake.3. Turn the key to the “run” position, this releases the shifter.4. Place the car in drive (D).5. Place your foot directly over the brake pedal, but do not depress it. Be ready to step on the brake if the6. starter engages.
Activate the remote start system.7. If the starter engages, immediately depress the brake to shut the remote start system down. If the8. starter does not engage, no additional safety
system is required.
If the starter engages and the vehicle is a General Motors product or Dodge Dakota pickup, refer to
www. directechs.com for Document 1008 under the Resource tab. For an alternative shut-down method
which prevents the starter from engaging. If the vehicle is not a General Motors product or a Dodge
Dakota pickup, please call Directed Electronics Technical Support for an alternative shut-down method.
Do not return the vehicle to the customer until this feature is properly installed!

9
© 2009 Directed Electronics. All rights reserved.
Remote Start Shutdown/Startup Diagnostics
Shutdown diagnostics: If the remote start activates but fails to stay running, the remote start module has the
ability to inform you of what may have caused the remote start failure. Before performing shutdown diagnos-
tics it is important that you let the remote start shut off on its own i.e. let it attempt to start 3 times then shut
down, if this is not done the unit will report the shutdown you used to shut off the remote start.
Note: Shutdown diagnostics does not report if the vehicles factory immobilizer is causing the problem.
To perform shutdown diagnostics:
With the ignition Off,1. press and hold the Control button (on Control Center).
Turn2. the ignition On and then back Off while holding the Control button.
Release3. the Control button.
Press4. and release the Control button. The status LED flashes to report the last shutdown for one minute or
until the ignition is turned on, as shown in the following table:
Status LED Flashes Shutdown Mode
1 flash Runtime expired
2 flashes Over-rev shutdown
3 flashes Low or no RPM
4 flashes Transmitter shutdown (or optional push button)
5 flashes (+) Brake shutdown
6 flashes (-) Hood shutdown
7 flashes Timer mode/Turbo mode/Manual mode error *
8 flashes Neutral safety shutdown
9 flashes Low battery (voltage mode)
10 flashes Alarm triggered **
11 flashes Wait-to-start input timed out
* Timer mode error: Ignition is on or shutdown input is active when activating timer mode.
Turbo mode error: Turbo mode is programmed off, engine is not on or shutdown input is active.
Manual mode error: MTS mode not enabled.
** Alarm was triggered during remote start sequence.
Startup Diagnostics: If the vehicle fails to activate the remote start, the remote start module will flash the park-
ing lights on the vehicle to notify you of what caused the no-start situation.
Parking Light Flashes
5 flashes Brake wire is active
6 flashes Hood pin wire is active
7 flashes Manual transmission mode is enabled and not initialized.
8 flashes Neutral safety wire has no ground or the neutral safety switch is Off.

10 © 2009 Directed Electronics. All rights reserved.
Remote Pairing
Prepare the vehicle system to be Paired with a new remote
Open1. a door.
Turn2. the key to the ON position.
Within 5 seconds3. press and release the Control button on the Control Center one time.
Within 5 seconds,4. press and hold the Control button on the Control Center. The status LED will flash one
time and the siren then chirps to confirm the vehicle is ready for remote pairing.
Release5. the Control button and proceed below.
Note: If no remote pairing results, the system will exit after 60 seconds.
Prepare the 1-way remote control to be Paired with the system:
Make sure the remote is set for the desired Car 1 (Default) or Car 2 operation for the system it will be paired
with.
Press and hold the1.
A U X
button for 8 seconds.
Note: If Car 2 mode is on, ignore the Car Select LED flash after 3 seconds.
Wait for the Transmit LED to light solid. Release the2.
A U X
button.
Press the3.
A U X
button for 1 second. The transmit LED will blink 3 times.
Within 5 seconds, press the4.
A U X
button.
The vehicle siren will chirp. You have now successfully learned the remote to the vehicle remote start and5. security system.
Press the6.
A U X
button two times to exit learn routine on the remote. The transmit LED will turn off when exit-
ing.

11
© 2009 Directed Electronics. All rights reserved.
Programming System Features
The System Features Learn Routine dictates how the unit operates. It is possible to access and change most of
the feature settings using the Control button.
Open1. a door.
Turn2. the ignition on, then off.
Select3. a Menu. Press and hold the Control button. The number of siren chirps indicates the menu num-
ber. 1 chirp indicates menu 1, 2 chirps - menu 2 and 3 chirps for menu 3.
When the desired menu chirps are heard,4. release the Control button.
Select5. a Feature. Press and release the Control button the number of times corresponding to the feature
you wish to change. Then press and hold one more time to select the features.
Program6. the Feature. While holding the Control button, you can program the feature using the remote
control.
For features with only two options;
A U X
= option 1 while
A U X
= option 2.
For features with more than two options;
A U X
selects the options in ascending order, while
A U X
selects them in
descending order.
Note: Pressing
A U X
button resets the feature to the factory default.
Once a feature is programmed:
Other features can be programmed within the same menu•
Another menu can be selected•
The learn routine can be exited if programming is complete•
To access another feature in the same menu:
Press1. and release the Control button the number of times necessary to advance from the feature you just
programmed to the next one you want to program.
Then2. press the Control button once more and hold it.
To select another menu:
Press1. and hold the Control button.
After 3 seconds, the unit advances to the next menu and the siren chirps, indicating which menu has been2. accessed.
The learn routine exits if any of the following occurs:
The open door is closed•
The ignition is turned On•
There is no activity for 30 seconds•
The Control button is pressed too many times•

12 © 2009 Directed Electronics. All rights reserved.
Feature Menus
Default settings are Opt. 1 (in bolder type). New features are bold with grey background.
Menu 1 - Security
Menu
Item Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1
System Arming Mode
Active
Passive Arm
w/o lock Passive Arm w/lock Auto re-arm w/o lock Auto re-arm w/ lock
2
Panic Mode On Ign Off only Off
3
Confirmation Chirps
On w/Warn
chirps On
On w/Warn
chirps Off Off w/ Warn chirps On Off w/ warn chirps Off
4
Siren Duration
30 sec.
60 sec.
5
Ign-controlled Locks
No Ign- locking
Lock & Unlock Lock Only Unlock Only
6
Door Lock Pulses
Single
Double Unlock
Only Double Lock Only Double Lock & Unlock
7
Door Lock Output Duration
0.8 sec.
3.5 sec. 0.4 sec.
8
Ignition Controlled 2nd Unlock 2nd unlock on
Ign-control after
first unlock
2nd unlock on
Ign-control with
first unlock
9
Comfort Closure
No Comfort
Closure
Comfort Clo-
sure 1 Comfort Clo- sure 2
10 Horn Function Full Alarm Only Siren Function
20 ms Siren Function 30 ms Siren Function 40 ms Siren Function 50 ms
11 Hood Switch type
Normally Open
Normally
closed
12 Sensor Full trigger Single Double
13 Door Switch Type Normally open Normally
closed
14 Trunk Switch Type Normally open Normally
closed
15 Remote Button unlock (Ign off) On Off
1. System Arming mode
Active: the transmitter must be used to arm the system1. Passive Arm w/o lock: after exiting the vehicle the system will automatically arm. The doors will not2. lock
Passive Arm w/lock: after exiting the vehicle the system will automatically arm and lock the doors3. Auto re-arm w/o lock: if the vehicle is not entered after receiving a disarm command, the system will4. automatically re-arm. The doors will not lock
Auto re-arm w/lock: if the vehicle is not entered after receiving a disarm command, the system will5. automatically re-arm and lock the doors
2. Panic Mode
On: the Panic output can be activated at any time1. Ign Off Only : the Panic output can be activated only when the ignition is off2. Off: the Panic output is defeated3.
3. Confirmation Chirps
On w/Warn Chirps On: arm, disarm, and sensor warn-away chirps are active1. On w/Warn Chirps Off: arm and disarm chirps are active, warn-away chirps are defeated2. Off w/Warn Chirps On: arm and disarm chirps are defeated, warn-away chirps are active3. Off w/Warn Chirps Off: arm, disarm, and sensor warn-away chirps are defeated4.

13
© 2009 Directed Electronics. All rights reserved.
4. Siren Duration
30sec: the siren output for full trigger activations and Panic mode is 30 seconds1. 60sec: the siren output for full trigger activations and Panic mode is 60 seconds2.
5. Ign-controlled Locks
No Ign-locking: the door lock/unlock outputs will not activate when ignition is turned on/off1. Lock & Unlock: the door lock & unlock output will activate when ignition is turned on & off2. Lock Only: the door lock output will activate when ignition is turned on3. Unlock Only: the door unlock output will activate when ignition is turned off4.
6. Door Lock Pulses
Single: the door lock & unlock outputs will pulse once1. Double Unlock only: the unlock output only will pulse twice2. Double Lock Only: the lock output only will pulse twice3. Double Lock & Unlock: the lock & unlock outputs will pulse twice4.
7. Door Lock Output Duration
0.8sec.: the door lock output pulses will be 800mS in duration1. 3.5sec.: the door lock pulses will be 3.5 seconds in duration2. 0.4 sec.: the door lock pulses will be 400mS in duration3.
8. Ignition Controlled 2nd Unlock
After first unlock: for Ign-controlled unlocking, the 2nd unlock will activate 800mS after the first (driver1. door) unlock
With first unlock: for Ign-controlled unlocking, the 2nd unlock will activate at the same time as the first2. (driver door) unlock
9. Comfort Closure
No comfort Closure: Comfort Closure is defeated when arming1. Comfort Closure 1: the door lock pulse (or 2nd pulse for double pulses) will remain on for 20 sec-2. onds.
Comfort Closure 2: 800mS following the end of the door lock pulse (or 2nd pulse for double pulses);3. the door lock output will turn on again for 20 seconds.
10. Horn Function
Full Alarm Only: the horn output will pulse only during full trigger events.1. Siren Function 20/30/40/50ms: The horn output will emulate the siren output with selectable chirp2. output timing to compensate for OEM horn inefficiency.
11. Hood Switch Type
Normally Open: for vehicles with a hood switch that rests at ground when the hood is OPEN1. Normally Closed: for vehicles with a hood switch that rests at ground when the hood is CLOSED2.
12. Sensor Full Trigger
Single: full trigger activation of only one sensor is required to fully trigger the alarm1. Double: full trigger activation of two sensors within a ten second period is required to fully trigger2. the alarm.
13. Door Switch Type
Normally Open: for vehicles with door switches that rest at ground when the door is OPEN1. Normally Closed: for vehicles with door switches that rest at ground when the door is CLOSED2.
14. Trunk Switch Type
Normally Open: for vehicles with a trunk switch that rests at ground when the trunk is OPEN1. Normally Closed: for vehicles with a trunk switch that rests at ground when the trunk is CLOSED2.
15. Remote Button Unlock (Ign off)
On: a message telling the remote control to unlock the keypad is sent each time the vehicle ignition1. is turned off
Off: no message is sent2.

14 © 2009 Directed Electronics. All rights reserved.
Menu 2 - Convenience
Menu
Item Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 One-time Bypass One time
bypass Off One time
bypass On
2 Nuisance Prevention On Off
3 Override Pulse count 12 3 4 5
4 Door Trigger Error Chirp On Off
5 Ign-controlled Dome light On Off
6 OEM Alarm Disarm w/Aux-
Trunk On Off
7 OEM Alarm Disarm Output With Unlock Before Unlock Remote Start
Only
8 OEM Alarm Disarm Pulses 12
9 Aux 1 Output type Validity Latch Latch/reset/ign 30 sec. Timed Off (5)/2nd
unlock (6)
10 Aux 1 Linking No Linking Link to Arm Link to Disarm Link to Arm/
disarm Link to Remote Start only
11 Aux 2 Output Type Validity Latch Latch reset/ign 30 sec. Timed Off (5)/2nd
unlock (6)
12 Aux 2 Linking No Linking Link to Arm Link to Disarm Link to Arm/
Disarm Link to Remote Start only
13 Aux 3 Output Type Validity Latch Latch reset/ign 30 sec. Timed Off (5)/2nd
unlock (6)
14 Aux 3 Linking No Linking Link to Arm Link to Disarm Link to Arm/
Disarm Smart Key Control (Link to
Remote Start
Off)
15 Aux 4 Output Type Validity Latch Latch reset/ign 30 sec. Timed Off (5)/2nd
Unlock (6)
16 Aux 4 Linking No linking Link to Arm Link to Disarm Link to Arm/
Disarm Link to Remote Start Only
17 Aux/Trunk Output type Validity Off 2nd unlock
1. One-time Bypass
Off: One-Time Bypass is not available1. On: the One-Time Bypass feature will defeat Passive Arming once and, if Armed by remote control,2. will defeat Comfort Closure and Aux outputs linked to Arming
2. Nuisance Prevention
On: sensors that trigger excessively will be defeated until they have been stable for more than one1. hour
Off: sensors will not be defeated if triggered excessively2.
3. Override Pulse Count
1-5: sets the number of presses (1-5) on the Control Button required to override the alarm system•
4. Door Trigger error Chirp
On: if the door trigger is active when arming, the siren will emit a chirp and a message will be sent1. to the 2way remote control as an alert
Off: an active door trigger when arming will not create an alert output2.
5. Ign-controlled Dome light
On: the dome light output will activate when the ignition is turned off1. Off: the dome light output will not activate when the ignition is turned off2.
6. OEM Alarm Disarm w/Aux/Trunk (H2/1 wire)

15
© 2009 Directed Electronics. All rights reserved.
On: the OEM Alarm Disarm wire will pulse as programmed when the Aux/Trunk output is activated1. Off: the OEM Alarm Disarm wire will not pulse when the Aux/Trunk output is activated2.
7. OEM Alarm Disarm Output (H2/1 wire)
With Unlock: the OEM Alarm Disarm wire will pulse as programmed at the same time as the unlock1. (Blue) wire
Before Unlock: the OEM Alarm Disarm wire will pulse as programmed before the unlock wire2. Remote start only: the OEM Alarm Disarm wire will pulse as programmed during remote start only3.
8. OEM Alarm Disarm Pulses (H2/1 wire)
1: the OEM Alarm Disarm wire will pulse once per operation1. 2: the OEM Alarm Disarm wire will pulse twice per operation2.
9. Aux 1 Output Type (H2/6 wire)
Validity: when the Aux command is received the wire will turn on and remain on until the command1. ceases
Latch: when the Aux command is received the wire will turn on and remain on until the command is2. received again
Latch/reset/Ignition: when the Aux command is received the wire will turn on and remain on until the3. command is received again or the ignition is turned on/off
Timed: when the Aux command is received the wire will turn on for the programmed time duration4. (default 30sec)
Off: the output will not activate for a remote control command, use this option when the Aux com-5. mand controls an external device such as a garage door module
2nd unlock: the wire will operate as 2nd unlock and will not activate for remote control commands6.
10. Aux 1 Linking
No Linking: the Aux output will not activate for a remote control command1. Link to Arm: the Aux output will activate for the Arm command2. Link to Disarm: the Aux output will activate for the Disarm command3. Link to Arm/Disarm: the Aux output will activate for the Arm & Disarm commands4. Link to Remote Start: the Aux output will activate for any Remote Start activation5.
11. Aux 2 Output Type
Refer to Aux 1 Output Type descriptions•
12. Aux 2 Linking
Refer to Aux 1 Linking descriptions•
13. Aux 3 Output Type
Refer to Aux 1 Output Type descriptions•
14. Aux 3 Linking
Options 1-4: Refer to Aux 1 Linking descriptions•
Option 5: SmartKey Control (Link to Remote Start Off): The Aux output will pulse once following•
Remote Start shut down for vehicles with push button engine stop operations. During runtime, if any
door is opened remote start will shut down immediately and pulse the output.
15. Aux 4 Output Type
Refer to Aux 1 Output Type descriptions•
16. Aux 4 Linking
Refer to Aux 1 Linking descriptions•
17. Aux/Trunk Output Type
Refer to Aux 1 Output Type descriptions•

Menu 3 - Remote start
Menu
Item Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 Transmission Mode Manual Automatic
2 Engine Checking Mode Virtual Tach Voltage Off Tachometer
3 Cranking Time 0.6 sec. 0.8 sec. 1.0 sec. 1.2 sec. 1.4 (5)/ 1.6
(6)/ 1.8 (7)
2.0 (8)/ 4.0
(9)
4 Remote Start Runtime 12 min. 24 min. 60 min.
5 Activation Pulse Count 12
6 Turbo Mode No Turbo Mode
On-1 min. On-3 min. On-5 min. On- 10 min.
7 Timer Mode Runtime 12 min. 3 min. 6 min. 9 min.
8 Flex Relay Function Ignition 2 Accessory 2 Starter 2
9 Diesel Start Delay Wait-to Start
input Timed 15 sec. Timed 30 sec. Timed 45 sec.
10 Accessory during Diesel Start
Delay On Off
11 Status 2 Output Status Latch Rear
Defogger Pulse Rear Defogger
12 Parking Light Output Constant Pulsed Off
13 Anti-grind Output On Off
14 Tach Mode Starter Release Normal Increase Decrease
15 Vehicle Temp
Auto Report Off On
16 Remote Start Safelock Off On
1. Transmission Mode
Manual: requires ‘Tachometer’ for the Engine Checking Mode, and requires the user to successfully1. perform a procedure when parking the vehicle before remote starter will engage
Automatic: uses any of the Engine Checking Modes and does not require any special procedures2. when parking
2. Engine Checking Mode
VirtualTach: battery voltage drop/rise during cranking determines when the starter output is released.1. During runtime, constant voltage level is monitored to determine if the engine is running
Voltage: starter output during cranking is a programmed duration (Set in Cranking Time). During2. runtime, constant voltage level is monitored to determine if the engine is running
Off: starter output during cranking is a programmed duration (Set in Cranking Time). The remote start3. will keep the ignition/accessories active for the programmed runtime whether the engine is running
or not
Tachometer: tachometer input signal during cranking and runtime to determine when the starter out-4. put is released and if the engine is running.
3. Cranking Time
0.6/0.8/1.0/1.2/1.4/1.6/1.8/2.0/4.0 seconds: determines the starter output duration during•
cranking for the ‘Voltage’ and the ‘Off’ Engine Checking Mode options
4. Remote Start Runtime
12/24/60 minutes: sets engine runtime during normal remote start operations•
5. Activation Pulse Count
1/ 2 pulses: sets the number of remote control commands received or Activation Input required to•
activate and de-activate remote start

17
© 2009 Directed Electronics. All rights reserved.
6. Turbo Mode
No turbo Mode: Turbo mode is not available1. On – 1/3/5/10 minutes: Turbo Mode is available and, when activated, the engine will run for the2. duration set per the selected option
7. Timer Mode Runtime
12/3/6/9 minutes: sets the runtime when the engine is started by the Timer Mode and SmartStart•
features
8. Flex Relay Function
Ignition 2: the relay will emulate the Ignition 1 output during remote start1. Accessory 2: the relay will emulate the Accessory 1 output during remote start2. Starter 2: the relay will emulate the Starter output during remote start3.
9. Diesel Start Delay
Wait-to-start input: (-) input on the Grey/black (H2/7) WTS wire will delay the starter output until the1. ground ceases.
Timed 15/30/45 seconds: delays the starter output per the selected option, the WTS wire does not2. function.
10. Accessory during Diesel Start Delay
On: the Accessory outputs (H/3 high current and H2/12 low current) will be ON during diesel start1. delay
Off: the Accessory outputs (H/3 high current and H2/12 low current) will be OFF during diesel start2. delay
11. Status 2 Output (Dark Blue H2/10 wire)
Status: the output will activate before the ignition outputs turn on, and de-activate after they turn off1. during remote start
Latch rear defogger: the output activates 10 seconds after start if the interior temperature is below2. 55F. It turns off after 10 minutes or upon remote start off
Pulse rear defogger: the output activates (for 800mS) 10 seconds after start if the interior temperature3. is below 55F.
12. Parking Light Output
Constant: the lights will turn on solid during remote start1. Pulsed: the lights will pulse on/off during remote start2. Off: the lights will be off during remote start3.
13. Anti-grind Output
On: the high current starter relay will be activated during remote start as anti-grind protection.1. Off: the high current starter relay will not be activated during remote start, no anti-grind protection2. is available.
14. Tach Mode Starter Release
Normal: the starter output will release normally during cranking (50% of the learned tachometer1. value)
Increase: the starter output will release later during cranking (at 35% of the learned tachometer2. value)
Decrease: the starter output will release sooner during cranking (at 35% of the learned tachometer3. value)
15. Vehicle Temp Auto Report
Off: the report during remote start is defeated1. On: the report is sent every 2 minutes during remote start if the temperature has changed (+/-) 12. degree since the last report
16. Remote start Safelock
Off: the Door lock and Factory Alarm Re-arm outputs will maintain the current status (locked/un-1.

18 © 2009 Directed Electronics. All rights reserved.
locked) during remote start and after shut down
On: the Door lock and Factory Alarm Re-arm outputs will arm/lock the vehicle during remote start2. and after shutdown
Bitwriter - Only Options
If programming with the Bitwriter®, the learn routine can be locked or unlocked. If the learn routine
has previously been locked, it must be unlocked with Bitwriter® - this cannot be done manually with
the Control button.
The Bitwriter® gives you access to a wider range of system options. These features and the adjustments
that may be programmed are described in the table below.
Menu
Item Feature Default Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 Zone 4 Sensor Type* None Shock/Omni Field Distur-
bance Tilt Sensor Glass Break (5)/Ultra- sonic (6)
2 Siren Duration 30 sec. Options: 1 to 180 sec.
3 Aux/Trunk Icon Type* Trunk Window Sunroof Audio Lights/Left dr/Right dr/
Rear Hatch
4 Aux 1 Timed Output 30 sec. Options: 1 to 90 sec.
5 Aux 1 Icon Type* Pulsed Trunk Window Sunroof Audio/Lights/Left dr/
Right dr/Rear Hatch/
Timed/Latched
6 Aux 2 Timed Output 30 sec. Options: 1 to 90 sec.
7 Aux 2 Icon Type* Pulsed Trunk Window Sunroof Audio/Lights/Left dr/
Right dr/Rear Hatch/
Timed/Latched
8 Aux 3 Timed Output 30 sec. Options: 1 to 90 sec.
9 Aux 3 Icon Type* Pulsed Trunk Window Sunroof Audio/Lights/Left dr/
Right dr/Rear Hatch/
Timed/Latched
10 Aux 4 Timed Output 30 sec. Options: 1 to 90 sec.
11 Diesel Start Delay Timer 15 sec. Options: 1 to 90 sec.
12 Timer Mode Runtime 12 min. Options: 1 to 16 min.
13 Timer Mode Starts 6 starts Options: 1/2/3/4 to 24 (Starts) in increments of 2
14 Timer mode intervals 3 hr. Options: 1/2/3/4 to 24 in 2 hour increments
15 Smart start low temp 0° (F) Options: OFF, -20° to 70° in 10° increments
16 Smart start high temp 100° (F) Options: OFF, 40° to 130° in 10° increments
17 Smart start low battery (volts) 10.5V Options: OFF, 9V to 12.5V in 0.5V increments
18 Sensor 1 Level 7Options: 0 to 15 in increments of 1
19 Starter Release Fine Tune 6
(normal) Options: 0 to 20 in increments of 1
20 Feature Programming Unlocked Locked
21 Transmitter Programming Unlocked Locked
22 Remote Start Runtime 12 min. Options: 1 to 60 min.
23 Virtual Tach Fine tune Not Initial-
ized Options: Not initialized, 0 to 1000 in 50 millisecond increments
* Not available on 1-way remote

19
© 2009 Directed Electronics. All rights reserved.
Zone 4 Sensor Type: sets the Zone 4 (Sensor 2) name to be displayed in the Text Field for Warn-away1. and Full Trigger activations
Siren Duration: sets the Full Trigger output duration in 1 second intervals up to 180 seconds.2. Aux/Trunk Icon Type: sets the Accessory animation to be displayed on the screen when the Aux/Trunk3. output is activated/de-activated
Aux 1 Timed Output: sets the output duration in 1 second intervals up to 90 seconds for Aux 14. Aux 1 Icon Type: sets the Accessory animation to be displayed on the screen when the Aux 1 output is5. activated/de-activated
Aux 2 Timed Output: sets the Aux 2 “Timed” output in 1 second intervals up to 90 seconds6. Aux 2 Icon Type: sets the Accessory animation to be displayed on the screen when the Aux 2 output is7. activated/de-activated
Aux 3 Timed Output: sets the Aux 3 “Timed” output in 1 second intervals up to 90 seconds8. Aux 3 Icon Type: sets the Accessory animation to be displayed on the screen when the Aux 3 output is9. activated/de-activated
Aux 4 Timed Output: sets the Aux 4 “Timed” output in 1 second intervals up to 90 seconds10. Diesel Start Delay Timer: sets the delay before engine crank in 1 second intervals up to 90 seconds for11. diesel engine vehicles
Timer Mode Runtime: sets the duration of runtime when the engine is started by the Timer Mode and Smart12. Start features
Timer mode Starts: sets the number of times the engine will be started by the Timer Mode and Smart Start13. features
Timer mode Intervals: sets the number of hours between engine starts by the Timer Mode and Smart Start14. features
Smart Start Low Temperature: sets the low temperature threshold required for Smart Start to start the15. engine
Smart Start High Temperature: sets the high temperature threshold required for Smart Start to start the16. engine
Smart Start Low battery (Volts): sets the low battery level threshold required for Smart Start to start the17. engine
Sensor 1 level: directly sets the sensor level of the on-board shock sensor18. Starter Release Fine Tune: adds or subtracts crank time in Tachometer mode in order to overcome engine19. types that short crank or over-crank on the first start attempt
Feature Programming: locks and unlocks the user’s ability to enter the feature menus and manually20. change the main unit programming using the Control Center
Transmitter Programming: locks and unlocks the user’s ability to enter the remote control/Reset menu and21. manually change any functions using the Control Center
Remote Start Runtime: sets the duration of runtime when the engine is started by remote command22. VirtualTach Fine tune: adds or subtracts crank time in VirtualTach mode in order to overcome engine types23. that short crank or over-crank on the first start attempt

20 © 2009 Directed Electronics. All rights reserved.
Basic Remote Functions
See Owner’s guide for functionality details on the remote control.
Reset and Deletion
If a feature/virtual tach needs to be reset or the remote controls need to be deleted, use the following proce-
dure.
Open a door. (The GREEN wire, H1/8, or the VIOLET, H1/6 must be connected.)1. Turn the ignition to the ON position (The heavy gauge pink wire must be connected).2. Within 10 seconds, press and release the Control button: 2 times if you want to delete remotes, 3 times3. to reset features or 4 times to reset virtual tach.. These function steps are described next.
Step 2:
Delete remotes: This feature erases all remotes from the memory of the security system. This is useful
in cases when a customer’s remote is lost or stolen.
Note: This does not reset the programmed features of the security system or reset the Virtual Tach
setting.
Step 3:
Reset Features: This resets features all of the security system to the factory default settings.
Note: This feature does not delete the remotes from the security system or reset the Virtual Tach set-
ting
Step 4:
Virtual Tach Reset: Deletes all previously learned values for Virtual Tach, and on the next remote start
sequence the unit begins virtual tach initialization.
Note: The “Zap” feature on the Bitwriter does not reset the Virtual tach setting.
Once you have selected the function step, press the Control button once more and hold it. The LED flashes4. and the siren chirps to confirm the selected functional step. Do not release the Control button
While holding the control button, press the5.
A U X
button on the remote control. The unit chirps to confirm that
the feature has been successfully reset.
Once the feature is reset, the Control button can be released.
Long Term Event History
The system stores the last two full triggers in memory. These are not erasable. Each time the unit sees a full
trigger, the older of the two triggers in memory is replaced by the new trigger. To access long term event
history:
With the ignition Off,1. press and hold the Control button (on Control Center).
Turn2. the ignition On.
Release3. the Control button.
Within 5 seconds,4. press and release the Control button. The status LED flashes in groups indicating the last
two zones that triggered the unit for 1 minute or until the ignition is turned off. Refer to table of zones.
Note: The Warn Away triggers are not stored to memory and is not reported.
