DirekTronik HDR10 User manual

1X2 Splitter/2x1 Switch
4K@60Hz YUV4:4:4 18Gbps
Support HDCP2.2, HDR10
Best.nr: 20102370

Operating Instruction
Dear customer
Thank you for purchasing this product. For optimum performance and safety, please
read these instructions carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
TABLE OF CONTENTS
Features
Specifications
Package Contents
Panel Description
Application
EDID Setting
The firmware update
Maintenance
Product Service
Warranty
Features
HDMI 2.0 version (Support 4K@60Hz YUV4:4:4)
Bandwidth upto 18Gbps
HDCP2.2/ HDCP1.4
Support 3D, HDR10, Dolby vision and DTS
Support 2xHDMI in, 2xHDMI out
EDID management and Down Scaler functions
Support Analog 3.5mm stereo out /SPDIF out audio extraction
Support Analog 3.5mm stereo/SPDIF in audio embedded
Support power off memory function
2

Operating Instruction
Specifications
Operating Temperature Range
0℃to +40℃(+32℉to +104℉)
Operating Humidity Range
5 to 90%RH (No Condensation)
Power supply
5V
Maximum power
(work under 4K2K/60Hz)
2W
Max resolution
4k@60Hz YUV4:4:4
Function
HDR10 and Dolby vision
HDMI version
HDMI 2.0
HDCP version
HDCP2.2 / HDCP1.4
Control ways
Switch button and EDID
Distance
1080P: input 8m max; output 8m max
4k@30Hz: input 8m max;output 8m max
4k@60Hz-8bit: input 5m max;output 5m
max 121x68.2x20mm
Dimensions(LxWxH)
Package Contents
1) 1x HDMI Switch
2) 1x 5V/1A DC power adapter
3) 1x User manual
3

Operating Instruction
Panel Description
1. Power and Firmware upgrade USB port 2. Power Indicator
4. SPDIF In
6. HDMI output
3. Indicator light
5. Audio out
7. Audio in 8. HDMI input
9. SPDIF out
10. Menu button:Long press the key for 1.5 seconds or more to open the menu
(Note：LED1~LED6 slow flash twice can release the key) or exit the menu
(Note：LED1~LED6 fast flash twice can release the key); Under the premise of
opening the menu,you press the button to select functions (input source, EDID, Audio
embed and audio unembed, channel), and you can always switch in a loop; When you
select a function, the indicator light of the function will flash (Different functions
correspond to different indicator lights. Please refer to the silkscreen on the back of the
product for details). If there is no next operation after 4S, the LED indicator will go out
and remain in the original state. Plis press set button again can still complete the
function switch.
11. SET button:Long press SET button 5S to restore factory Settings;
4

Operating Instruction
On the premise that the menu has been opened and the menu button is switched to
the corresponding functional Settings,you press the button can complete the video
input source switch,EDID mode Settings,Audio embed and audio unembed setting
and Audio channel selection.
List of functional indicator lights:
LED
1
2
3
4
5
6
FUNC
\
\
Switch
EDID
ENC/DEC
ENC/
DEC-Config
OFF
\
\
HDMI In
1
Default
DEC
Bypass
BLINK
\
\
\
AUTO
ENC-SPDIF
5.1
ON
\
\
HDMI In
2
Copy
ENC-Analog
2.0
Application
1. Connect source devices with input ports of the switch by HDMI Cable.
2. Connect HDMI output port with TV or other HDMI sink devices by HDMI Cable.
3. Connect 5V POWER adaptor with DC power socket.
4. Power on
5

Operating Instruction
Application Diagram
EDID Setting
1. Copy EDID : When pressing the button to switch EDID to Copy mode, LED4
indicator light is always on, giving priority to copy the output1 EDID, it will copy
the output2 EDID when output 1 is empty;
When the output resolution of the signal source is set to be automatic, if the output1 is
4K60Hz TV and the output2 ports is 4K30Hz/1080p TV, the output1 channels is
4K60Hz, and the output2 channel is reduced to 1080P60Hz.
2. Mixed EDID: When you press the button to switch EDID to Mixed mode, LED4
indicator lights will flash, and a group of optimal EDID will be generated at this time
to ensure that images can be output from both output TVs, and the EDID of the two
output TVs has memory function, that is, pulling out one TV will not affect the
other TV;Input to 2.0 BLU-RAY player and set to automatic mode, one output
to 4K60Hz TV, one output to 4K30Hz/1080p TV, both output to 4K30Hz video or
1080P video
6

Operating Instruction
3. Built-in EDID: When the button is switched to the built-in EDID mode, LED4
indicator lights will go out.
Note:
1. Product has the function of Down Scaler
2. Built-in EDID and copy EDID have the function of Down Scaler, which can
reduce the input 4K60Hz to 1080P60Hz output. It should be noted that the
function of Down Scaler only reduces the resolution and does not reduce the refresh
rate, as well as the function of Down Scaler that does not support 4K60Hz YUV422
input signal
3. In the built-in EDID/ copy EDID mode, the input source is set as automatic. When
the output of two TV channels is 4K60Hz and 4K30Hz/1080P60Hz, the output of
videos in one channel is 4K60Hz and videos in the other channel is 1080P60Hz
The firmware update
Pls open the software UART_ISP.exe on the PC, you need select the correct port and
baud rate 115200, enter A1 in port, then you need select the program in path, and
click UPDATE to complete the upgrade.
7

Operating Instruction
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit.
