Intellinet 561341 User manual

16-PORT GIGABIT ETHERNET POE+ WEB-
MANAGED SWITCH WITH 2 SFP PORTS
User Manual
Model 561341
INT‐561341‐UM‐0421‐3

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
2
1TABLE OF CONTENTS
2Product Introduction .................................................................................................................................... 4
2.1 Product Overview................................................................................................................................................4
2.2 Features ...............................................................................................................................................................4
2.3 Specifications.......................................................................................................................................................5
2.4 External Component Description .......................................................................................................................6
2.4.1 Front Panel ....................................................................................................................................................................6
2.4.2 Rear Panel......................................................................................................................................................................8
2.5 Package Contents................................................................................................................................................8
3Installing and Connecting the Switch............................................................................................................ 9
3.1 Desktop Installation.............................................................................................................................................9
3.2 Rack-mountable Installation in 19-inch Cabinet................................................................................................9
3.3 Power on the Switch .........................................................................................................................................10
4Connection to the Switch ........................................................................................................................... 11
4.1 Connecting Computer.......................................................................................................................................11
4.2 How to Log in to the Switch..............................................................................................................................11
5Saving the Configuration ............................................................................................................................ 13
6Switch Configuration .................................................................................................................................. 14
6.1 Home..................................................................................................................................................................14
6.1.1 CPU and Memory Status Information........................................................................................................................14
6.1.2 Port Information..........................................................................................................................................................14
6.2 Quick Setup........................................................................................................................................................16
6.3 Port Settings ......................................................................................................................................................17
6.3.1 Basic Config..................................................................................................................................................................17
6.3.2 Port Aggregation .........................................................................................................................................................19
6.3.3 Port Mirroring..............................................................................................................................................................20
6.3.4 Port speed limit ...........................................................................................................................................................21
6.3.5 Broadcast storm ..........................................................................................................................................................22
6.3.6 Port isolation ...............................................................................................................................................................23
6.4 VLAN...................................................................................................................................................................26
6.4.1 Trunk Port Settings......................................................................................................................................................28
6.4.2 Hybrid Port Settings ....................................................................................................................................................29
6.4.3 Setup Example.............................................................................................................................................................30
6.5 Fault/Safety........................................................................................................................................................33
6.5.1 Anti Attack ...................................................................................................................................................................33
6.5.2 Channel Detection.......................................................................................................................................................40
6.5.3 ACL Access Control List ...............................................................................................................................................42
6.6 Power over Ethernet (PoE) ...............................................................................................................................45
6.6.1 PoE Configuration .......................................................................................................................................................45

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
3
6.6.2 PoE Port Configuration ...............................................................................................................................................47
6.6.3 PoE Delay Config .........................................................................................................................................................49
6.7 Spanning Tree Protocol (STP) ...........................................................................................................................50
6.7.1 MSTP Region................................................................................................................................................................53
6.7.2 MSTP Bridge ................................................................................................................................................................54
6.8 DHCP Relay Agent..............................................................................................................................................56
6.8.1 DHCP Relay ..................................................................................................................................................................56
6.8.2 Option82......................................................................................................................................................................56
6.9 DHCP Server.......................................................................................................................................................58
6.9.1 DHCP Config.................................................................................................................................................................58
6.10 Terminal Access Controller Access-Control System (TACACS+)......................................................................61
6.11 Radius.................................................................................................................................................................63
6.11.1 Radius General Config.................................................................................................................................................63
6.11.2 Radius Server Config ...................................................................................................................................................64
6.12 AAA.....................................................................................................................................................................65
6.12.1 Enable Config...............................................................................................................................................................65
6.12.2 Region Config...............................................................................................................................................................65
6.12.3 Server Config ...............................................................................................................................................................66
6.12.4 AAA Authentication.....................................................................................................................................................67
6.13 QoS –Quality of Service....................................................................................................................................69
6.13.1 QoS Rules.....................................................................................................................................................................69
6.13.2 Queue Config...............................................................................................................................................................70
6.13.3 Queue Mapping...........................................................................................................................................................71
6.14 Address Table ....................................................................................................................................................72
6.14.1 Address Table Config...................................................................................................................................................72
6.15 SNMP..................................................................................................................................................................74
6.15.1 SNMP Config................................................................................................................................................................74
6.15.2 RMON Config...............................................................................................................................................................79
6.16 System................................................................................................................................................................83
6.16.1 System Config..............................................................................................................................................................83
6.16.2 System Update ............................................................................................................................................................87
6.16.3 Configuration Management .......................................................................................................................................88
6.16.4 Config Save ..................................................................................................................................................................89
6.16.5 User Accounts..............................................................................................................................................................89
6.16.6 Information Collect .....................................................................................................................................................90
7Warranty..................................................................................................................................................... 91
8Copyright .................................................................................................................................................... 92
9Federal Communication Commission Interference Statement .................................................................. 93

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
4
2PRODUCT INTRODUCTION
Congratulations on your purchase of the 16-Port PoE+ Web-Managed PoE+ Gigabit Ethernet Switch. Before you install
and use this product, read this manual carefully for a full understanding of its functions.
2.1 PRODUCT OVERVIEW
The Web-Managed Gigabit Ethernet Switch provides seamless network connections. It integrates 1000 Mbps Gigabit
Ethernet, 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible package. Each of the 16
10/100/1000 Mbps Auto-Negotiation RJ45 ports support Auto MDI/MDIX function. The switch is a high-performance
upgrade from your old network to a 1000 Mbps Gigabit network. It is essential in solving network bottlenecks that
frequently develop as more advanced computer users and newer applications demand greater network resources. For
efficient management, the switch is equipped with a remote Web interface. The switch can be programmed for
advanced management functions such as Port Management, Link Aggregation, VLAN, Spanning Tree, Multicast, QoS,
Security, Access Control, MAC Address Table, Diagnostics, RMON and Maintenance. Its PoE ports can automatically
detect and supply power to IEEE802.3at-compliant Powered Devices (PD) such as Wireless Access Points, network
cameras or Voice over IP phones.
2.2 FEATURES
• Provides power and data connection for up to 16 PoE network devices
• Save installation costs by delivering data and power over existing network cables
• IEEE 802.3at/af-compliant RJ45 PoE
/
PoE+ output ports
• PoE power budget of 220 watts
• Power output up to 30 watts per port
• Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
• Supports SNMP management
• Two small form-factor pluggable GBIC module slots (SFP)
• Supports VLAN (tag-based and port-based)
• Provides IEEE 802.1x port-based security
• Supports link aggregation (trunking
)
• Supports port mirroring
• Supports jumbo frames up to 9 kBytes
• Supports Rapid Spanning Tree/Spanning Tree protocol
• Broadcast storm control with multicast packet rate settings
• Supports two types of QoS: port-based and DSCP
• LEDs for power, link/activity and PoE
•
Includes 19" rackmount brackets

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
5
2.3 SPECIFICATIONS
Standards
• IEEE 802.1d (Spanning Tree Protocol)
• IEEE 802.1p (Traffic Prioritization)
• IEEE 802.1q (VLAN Tagging)
• IEEE 802.1w (Rapid Spanning Tree Protocol)
• IEEE 802.3ad (Link Aggregation)
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3ab (Twisted Pair Gigabit Ethernet)
• IEEE 802.3ad (Link Aggregation Control Protocol LACP)
• IEEE 802.3az (Energy Efficient Ethernet EEE)
• IEEE 802.3af (Power over Ethernet 802.3at Type 1)
• IEEE 802.3at (Power over Ethernet 802.3at Type 2)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3x (flow control, for full duplex mode)
Power
• Input: 90 – 260 V AC, 50 –60 Hz
• Power consumption: 260 watts (maximum)
Environmental
• Metal housing
• Dimensions: 440 (L) x 208 (W) x 44 (H) [mm] (17.32 (L) x 8.19 (W) x 1.73 (H) [in])
• Weight: 2.5 kg (5.5 lbs.)
•Operating temperature: 0 –40°C (32 –104°F)
• Operating humidity: 10 – 90% RH, non-condensing
• Storage temperature: -20 –90°C (-4 –194°F)
Package Contents
• 16-Port Gigabit Ethernet PoE+ Web-Managed Switch with Two SFP Ports
• Power cable
• User manual
• 19" rackmount brackets

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
6
2.4 EXTERNAL COMPONENT DESCRIPTION
2.4.1 Front Panel
The front panel of the switch consists of 16 10/100/1000 Mbps RJ-45 ports, two SFP ports, one Console port, one
Reset button and a series of LED indicators as shown below.
10/100/1000 Mbps RJ-45 ports (1~16):
Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or 1000 Mbps. Each has a corresponding
10/100/1000 Mbps LED.
SFP ports (SFP1, SFP2):
Designed to install the SFP module and connect to the device with a bandwidth of 1000 Mbps. Both ports have a
corresponding 1000 Mbps LED.
Console port (Console):
Designed to connect with the serial port of a computer or terminal for monitoring and configuring the switch.
Reset button (Reset):
To restore the system factory default settings, press the reset button for five seconds while the device is powered on.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
7
LED indicators:
The LED indicators will allow you to monitor, diagnose and troubleshoot any potential problem with the switch, its
connection or attached devices.
The following chart shows the LED indicators of the switch along with explanation of each indicator.
LED
COLOR
STATUS
STATUS DESCRIPTION
Power
Red
On
Power On
Off
Power Off
LINK/ACT/
Speed
(1~16)
10/100 Mbps:
Amber
On
A device is connected to the port
Off
No device is connected to the port
1000 Mbps:
Green
Flashing
Sending or receiving data
SFP1
SFP2
Green
On
A device is connected to the port
Off
No device is connected to the port
Flashing
Sending or receiving data
POE
Orange
On
An IEEE 802.3af/at-compliant powered device (PD) is
connected to the port, and the PoE switch supplies
power successfully.
Off
No powered device is connected to the port.
Flashing
There may be a short circuit or PoE power
overload. Disconnect the device from this port
immediately.
Reset
Press for 15 seconds –20 seconds in order to
reset all settings to factory default values.
Release the button, once the LEDs start flashing.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
8
2.4.2 Rear Panel
AC Power Connector:
Power is supplied through an external AC power adapter. It supports AC 100-240V, 50/60Hz.
Grounding Terminal:
Ground the switch through the PE cable on the AC cord or with a separate ground wire.
2.5 PACKAGE CONTENTS
Before installing the switch, make sure that the following items are enclosed. If any part is missing or damaged, contact
your Intellinet agent immediately.
•16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
•Power cable
•Quick Installation Guide
•User manual (on CD)
•Two mounting ears and eights screws

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
9
3INSTALLING AND CONNECTING THE SWITCH
This chapter describes how to install your Web-Managed Gigabit Ethernet PoE+ Switch and make connections to it. The
following steps will help prevent damage to the device and maintain proper security:
•Place the switch on a stable surface or desktop to minimize the chances of it falling.
•Make sure the switch works in the proper AC input range and matches the voltage labeled on the switch.
•To prevent electrocution, do not open the switch’s chassis, even if it fails to receive power.
•Make sure that there is proper heat dissipation from and adequate ventilation around the switch.
•Make sure the surface on which the switch is placed can support the weight of the switch and its accessories.
3.1 DESKTOP INSTALLATION
When installing the switch on a desktop (if not in a rack), attach the enclosed rubber feet to the bottom corners of it to
minimize vibration. Allow adequate space for ventilation between the device and the objects around it.
Figure 4 - Desktop Installation
3.2 RACK-MOUNTABLE INSTALLATION IN 19-INCH CABINET
The switch can be mounted in an EIA standard-sized, 19-inch rack, which can be placed in a wiring closet with other
equipment. To install the switch, follow these steps:
Attach the mounting brackets on the switch’s side panels (one on each side) and secure them with the screws provided.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
10
Figure 5 - Bracket Installation
Use the screws provided with the equipment rack to mount the switch on the rack and tighten it.
Figure 6 - Rack Installation
3.3 POWER ON THE SWITCH
The switch is powered on by connecting it to an outlet using the AC 100-240V 50/60Hz internal high-performance power
supply.
AC Electrical Outlet:
It is recommended to use a single-phase, three-wire receptacle with a neutral outlet or multifunctional professional
receptacle. Be sure to connect the metal ground connector to the grounding source on the outlet.
AC Power Cord Connection:
Connect the AC power connector on the back panel of the switch to an external receptacle with the included power cord,
then check that the power indicator is ON. When it is ON, the corresponding LED is illuminated.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
11
4CONNECTION TO THE SWITCH
4.1 CONNECTING COMPUTER
Use standard Cat5/5e Ethernet cables (UTP/STP) to connect the switch to end nodes as described below. Switch ports
will automatically adjust to the characteristics (MDI/MDI-X, speed, duplex) of the device to which they are connected.
Figure 7 - PC Connect
The LNK/ACT/Speed LEDs for each port are illuminated when the link is available.
4.2 HOW TO LOG IN TO THE SWITCH
As the switch provides Web-based management login, configure your computer’s IP address manually to log on to the
switch. The default settings of the switch are shown below.
Parameter
Default Value
Default IP address
192.168.2.1
Default Username
admin
Default Password
1234 (or the device serial number)
Log on to the configuration window of the switch through following steps:
1. Connect the switch with the computer NIC interface.
2. Power on the switch.
3. Check whether the IP address of the computer is within this network segment: 192.168.2.xxx (“xxx” range is 2-
254); for example, 192.168.2.100.
4. Note: The default password is either “1234”, or the serial number found on the bottom of the device. All later
model switches (2020 onwards) use the serial number as the password.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
12
Open the browser, and go to the URL http://192.168.2.1. The switch login window appears, as shown below.
Enter the Username and Password (the factory default Username is admin and the Password is 1234 or the device serial
number), and then click “LOGIN” to log in to the switch configuration window as below.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
13
5SAVING THE CONFIGURATION
The Intellinet 16-Port Gigabit Ethernet PoE+ Web-Managed Switch provides a myriad of configuration options, many of
which are designed for experienced network administrators and aren’t easy to configure. It would be a real shame if all
the configuration data was lost after a power failure or after the switch was restarted. In order to make the configuration
permanent, it needs to be saved.
Here is how:
If you do not perform this function, you risk losing all the settings after the switch restarts.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
14
6SWITCH CONFIGURATION
This chapter describes how to use the web-based management interface (Web UI) for this switch.
6.1 HOME
6.1.1 CPU and Memory Status Information
This section provides a quick overview of the switch’s basic system resources in terms of memory utilization and CPU
load. If you mouse-over any of these sections, additional details are revealed.
If the CPU load is unusually high, or if the available memory or Flash memory is getting low, you may need to restart the
Intellinet switch to free up system resources. Initiate the reboot via the SYSTEM -> SYSTEM CONFIG -> SYSTEM RESTART
menu.
6.1.2 Port Information
A green squares indicate the port link is up at Gigabit speeds (port 1 in the example above). A red squares indicates that a
PoE device is connected (port 2). A gray squares indicate the port link is down.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
15
6.1.2.1 Port Information, Equipment Configuration and Port Statistics
This section provides real-time information about the ports, basic settings and traffic statistics.
Item
Description
Port Information
Displays the port number. The nomenclature is as follows:
Gi = Gigabit Ethernet
0/ = Switch 0 (which means this device)
1-18 = Port number. Ports 17 and 18 are SFP module slots.
Description
Optional description for the port, as entered in the basic port configuration.
Input Flow (bps)
Inbound traffic rate, measured in "bits per second.”
Output Flow (bps)
Outbound traffic rate, measured in "bits per second.”
Open State
ON = Port is activated in the basic port configuration and will accept connections
from networking devices.
OFF = Port is deactivated in basic port configuration.
Status
Connect: A networking device is connected to the port and has an active link.
Disconnect: No device is connected to the port.
VLAN
If the port belongs to a VLAN, its ID is displayed here. ID 1 = default.
Trunk Port
Yes = The port is part of an LACP trunking group.
No = The port is not part of an LACP trunking group.
This tab displays information about various functions and provides a short-cut that allows direct configuration of that
part of the switch settings.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
16
This tab displays real-time information about the data packets for each port.
6.2 QUICK SETUP
The Intellinet 16-Port Gigabit Ethernet PoE+ Web-Managed Switch provides a setting that offers direct access to some of
the core functions of the device, namely VLAN, trunking, device IP address and admin password. Even though the
function is called “Quickly Set,” there is no need to rush. Take as much time as you like with the configuration.
Refer to subsequent sections in this user guide for additional information about the individual functions.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
17
6.3 PORT SETTINGS
6.3.1 Basic Config
Access the parameters related to each of the 18 ports. The screen is divided into two sections. The upper section displays
an image of the 18 ports of the Intellinet switch. In order to make changes to a port, simply click to select it.
Create a selection of multiple ports at once:
Once one port or multiple ports are selected, make changes to the port settings.
Item
Description
Port description
Optional description for the port. A maximum of 80 characters can be provided. No
special characters or spaces are allowed.
Port speed
10M: Force a connection to be made at 10 Mbps.
100M: Force a connection to be made at 100 Mbps.
1000M: Force a connection to be made at 1000 Mbps.
Auto: The switch and connected device negotiate the best possible connection speed.
Flow control
IEEE 802.3x flow control is the process of managing the rate of data transmission
between two nodes (i.e., the switch and a connected network client) to prevent a fast
sender from overwhelming a slow receiver. It provides a mechanism for the receiver
to control the transmission speed, so that the receiving node is not overwhelmed with
data from the transmitting node. That sounds like it is a good thing, and it is. So why is
the option by default set to “disabled"? The short answer is because you normally
don’t need it and because it can, in very rare instances, have a negative impact on the
overall performance in your network. The TCP protocol already provides its own flow
control mechanism, allowing a sender to throttle back the speed if the receiver is
having problems keeping up.
Port status
ON: Activate the port.
OFF: Disables the port. No connections to it can be made.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
18
Item
Description
Working mode
This parameter controls the duplex mode. In a full-duplex system, both parties can
communicate to the other simultaneously. An example of a full-duplex device is a
telephone; the parties at both ends of a call can speak and be heard by the other party
simultaneously. In networking terms, full duplex allows receiving and transmitting of
data at the same time, whereas half duplex does not. If the telephone is an example
for full duplex, then a push-to-talk CB radio or "walkie-talkie" represents half duplex.
The switch can either receive or send data, but it can never happen simultaneously.
Unless you have a specific reason not to do so, this should be left in “Auto” mode.
Cross line order
Auto MDI-X automatically detects the required cable-connection type and configures
the connection appropriately, removing the need for crossover cables to interconnect
switches or for connecting PCs peer-to-peer. As long as it is enabled on either end of a
link, either type of cable can be used. For auto MDI-X to operate correctly, the data
rate on the interface and duplex setting must be set to "auto." When two auto MDI-X
ports are connected together, which is normal for modern products, the algorithm
resolution time is typically < 500 ms. However, a ~1.4 second asynchronous timer is
used to resolve the extremely rare case (with a probability of less than 1 in 5×1021) of a
loop where each end keeps switching. If you don’t understand any of this, simply leave
this value on “Auto.”
The screen also shows a table that lists all 18 ports along with their parameters. The “mega frame” value refers to jumbo
frames, which are Ethernet frames with more than 1500 bytes of payload. Define the size of the jumbo frames in the
section SYSTEM -> SYSTEM CONFIG.
Clicking the pencil allows editing the port settings, exactly the same way as directly selecting the port(s) as
shown on the previous page.

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
19
6.3.2 Port Aggregation
Port aggregation is a method of using multiple Ethernet ports in parallel to increase throughput beyond what a single
connection could sustain and to provide redundancy in case one of the links should fail. As this is essentially a grouping of
ports into one logical unit, we call them Link Aggregation Groups, or “LAG” for short.
This page is used to set up LAGs. Create up to eight different LAGs; each can have up to eight member ports. Each LAG
can be given a custom name, and you must select the ports for the LAG. The example below shows an LAG group set up
with four member ports.
Item
Description
Aggregate port number
This is the link aggregation group (LAG) number
Please select the port to join the aggregate port
Select the member ports that belong to this LAG

16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports
20
6.3.3 Port Mirroring
Port mirroring is the ability of a network switch to
send a copy of network packets seen on a switch
port or ports to a network-monitoring device
connected to another switch port (i.e., a
computer equipped with a packet sniffer utility).
The Intellinet 16-Port Gigabit Ethernet PoE+ Web-
Managed Switch provides up to four groups for
port-mirroring settings.
The example below shows setting up one mirror
group where all traffic occurring on port 1 is being
mirrored to port 16.
