DiroDi ClassX User manual

ClassX
ASSEMBLY GUIDE
DiroDi

CONTACT
US
Address
G18, 425 Smith Street, Fitzroy VIC 3065
Melbourne, Australia
Phone
1800 571 930
E-mail
[email protected]
@ dirodiofficial
Website
www.dirodi.com.au

TABLE OF
CONTENTS

STEP 0
Tools required
STEP 1
Opening the box
STEP 2
Removing protective materials
STEP 3
Handlebars assembly
STEP 5
Front mudguard, carrier & light assembly
STEP 6
Rear basket assembly
06
08
13
18
28
36
STEP 4
Front wheel assembly
21

STEP 7
Installing pedals
STEP 8
Adjusting the saddle
STEP 9
Pumping the tyres
STEP 10
Removing thick rubber hairs on tyres
STEP 11
V brake adjustment
41
44
46
48
50
STEP 12
Rear derailleur adjustment
52
STEP 13
Operating the bike
57

STEP 0
Tools required

DiroDi ClassX Assembly Guide - Tools required
07
Tools required for the assembly:
1x 8mm wrench
1x 10mm wrench
1x 15mm wrench
1x Adjustable wrench
1x 4mm Allen key
1x 5mm Allen key
1x 6mm Allen key
1x screw driver
1x Scissor
> 1

STEP 1
Opening the box

DiroDi ClassX Assembly Guide - Opening the box
09
1. Cut the plastic straps of the bike carton
(photos 1 & 2).
2. Open the carton door and take care so that the
staples do not cut you (photo 3).
> 1 > 2
> 3

10
3. Remove the protective foams (photos 4 & 5).
4. Remove the small accessories box (photo 6).
> 6
> 5
> 4
DiroDi ClassX Assembly Guide - Opening the box

11
5. Remove the front carrier (photo 7).
6. Lay the carton on the floor and pull the bike out of
the carton (photo 8).
It is better to put a mat in front of the carton so that
the bike frame does not get scratched.
> 7
> 8
DiroDi ClassX Assembly Guide - Opening the box

12
7. Put the bike on a standing position (photo 9).
> 9
DiroDi ClassX Assembly Guide - Opening the box

STEP 2
Removing protective
materials

DiroDi ClassX Assembly Guide - Removing protective materials
14
1. Remove all protective material from the bike
(photos 1 & 2).
** Please take care so that the bike frame does not get
scratched.
> 1 > 2
2. Remove the front wheel off the pedal.
In order to release the wheel from the pedal, it might
be easier if you lift the rear wheel and turn the left
pedal anti-clockwise a bit and then remove the
wheel from the pedal (photo 3).
> 3

15
4. Remove the plastic fork protector from the front fork
(photo 5).
> 5
3. Find the small bag of 4 small bolts, which will be
used for rear basket assembly.
The plastic bag is usually attached to the bike's front
forks (photo 4).
DiroDi ClassX Assembly Guide - Removing protective materials
> 4

16
5. Remove the steel fork protector from the front fork
by loosening the nuts on both sides (photos 6 & 7).
DiroDi ClassX Assembly Guide - Removing protective materials
> 6 > 7
6. Remove the plastic cap from the handlebar stem
(photo 8).
> 8

17
7. Open the accessories box (photo 9).
(Which includes the power adapter, basic assembly tools, front
light, pedals, bike's manual and LCD's manual)
DiroDi ClassX Assembly Guide - Removing protective materials
> 9
8. After all protective materials are removed, your
bike should look the same as that in photo 10.
> 10

STEP 3
Handlebars assembly

DiroDi ClassX Assembly Guide - Handlebars assembly
19
1. On some versions of ClassX, a plastic washer is
provided, which should be put on top of the bike
head tube (photos 1 & 2).
2. Rotate the forks of the bike by 180 degree anti-
clockwise (photos 3 & 4).
After the adjustment is done, the bike brakes shoud
be in front of the forks.
> 1
> 3 > 4
> 2

20
3. Insert the stem into the headtube, adjust the height
and angle of the handlebars and fasten the two bolts
on the stem (photos 5,6 & 7).
4. Now adjust the angle of the display (photos 8 & 9).
DiroDi ClassX Assembly Guide - Handlebars assembly
> 8 > 9
> 5 > 6 > 7
