displayit E20C User manual

20’ Ensemble Tension Fabric Trade Show Display Kit E20C
Assembly Instructions
59” x 101” Arch-Top 59” x 101” Arch-Top
95” x 91” Flat-Top
1. Straighten and assemble all
bungeed poles.
2. Assemble the frame by aligning
the stickers as seen in the frame
diagram above.
4. Attach the feet to the frame as
seen in the diagram above.
3. Pull pillowcase graphic over frame
and zip bottom closed.
13
2
4
5
6
7
8910
11
12
13
14
13
2
4
5
6
7
8910
11
12
13
14
12
345
6
7
8
9
1011121314
15
16
17
18
Foot push button holes
face forward
Foot push button holes
face forward
Foot push button holes
face forward

1. Assemble the frame together as
referenced in Diagram A.
3. Place countertop on support pole.
Pull lever to lock onto frame.
4. Mount S-shaped support clip to
frames underneath countertop.
2. Attach counter frame to 3-nub foot.
Diagram A
5. Mount monitor bracket to frames at
desired height. Ensure hook faces
downward.
6. Screw monitor bracket to back of
monitor. Ensure adjustment knob is
facing left is monitor from back.
7. Slide monitor down into bracket until
it clicks into place.
Monitor weight must not
exceed 8 pounds.
lbs
Ensemble Mini-Counter with Monitor Mount
Assembly Instructions

1. Align the C-Clamp hole with the
graphic hole. Insert stando knob
through holes.
2. Twist stando knob until secure.
Do not overtighten.
3. Attach C-Clamp to frame in desired
location.
Wing Arrangement Options:
Wings may be oriented inward or outward from display.
Inward Outward
Ensemble Wing and Header Clips
Assembly Instructions
