dito Unilink 200 User manual

Unilink 200
Quick Installaon Guide

Index
1. Introduction ...........................................2
2. Overview................................................2
3. Before you Begin ....................................2
3.1 CPE Package........................................2
3.2 Getting to know the Unilink200..........2
3.3 LED Indicators .....................................3
3.4 Online Device Management Portal.....4
4. Factory Resetting of Your Unilink 200 ......6
5. Q&A .......................................................7

1. Introduction
This Quick Installaon Guide covers the basic installaon of the
Unilink200.
2. Overview
The CPE is a 5G NR CPE designed toprovide wireless Internet
access for a home or small office.
3. Before you Begin
Check the following items in this package.
3.1 CPE Package
Item
Quanty
Power supply(12V2A)
1
Unilink 200
1
Ethernet cable
1
Device label
2
Gibox label
2
3.2 Geng to know the Unilink200
The figures below are provided only for reference purposes.
Please see the actual product for more details.
1 2 3 4

3.3 LED Indicators
5
6
1. DC：This slot is for inserng the DC charge
2. RJ45: Ethernet connectors 100/1000Mbps
3. USIM: This slot is for inserng 4FF USIM card
4. USB: This slot is for inserng the USB cable
5. WPS：Press this buon for 5 seconds to connected WPS
funcon
6. RST: Press this buon for 5 seconds to restore factory
defaults

LED
Color
Acon
Funcon Descripon
Power
Green On Indicates AC/DC Adaptor is ON and plugged
Off No AC/DC Adaptor
Green Blinking While SW is updang
WPS/Voice
Green Blinking
WPS registraon
While SW is updang
Off No WPS
Ethernet
Green
On
Blinking
ETH is acve
Off No ETH data acve
Green Blinking While SW is updang
WIFI
Green On WIFI is acve and one client connected with AP
Off WIFI no connected
Green Blinking While SW is updang
Connecon
Green On Device connected with network
Off No data connecon
Green Blinking While SW is updang
5G Signal
Green On Good signal, SINR >11dBm, RSRP=-85~-95dBm
Blue On Normal signal, SINR 4~11dBm, RSRP=-95~-105dBm
Red On Weak signal SINR <4dBm, RSRP=-105~-115dBm
3.4 Online Device Management Portal
You can access your Unilink 200 Online Portal to view device
status, change your device sengs, and perform manual soware
Upgrades.
1. While you are connected with Unilink 200 over WiFi or LAN.
Use any web browser and enter hp://192.168.8.1 in the URL
address bar.
2. The login username is “admin” and password can be found on
the device label. Click on Sign In buon to login.

3. From the HOME menu, you can view your device information
and network status like Signal quality, Network name.
4. If network status is showing Connected and you can see IP
addresses in Internet status. That indicates that CPE is connected
with network and ready to use.
5. For WiFi related settings i.e. SSID Name and Password, go to
SETTINGS > Wi-Fi Settings.

4. Factory Resetting of Your Unilink
200
You can reset your Unilink 200 to factory default sengs in two
Ways, Using Reset Buon
1. Make sure your Unilink 200 is powered on.
2. Insert a pin into the Reset pin hole, push down and hold up to
10 seconds. The device will then restore the factory defaults and
reboot.
Using Online Portal (WebGUI)
1. Make sure your Unilink 200 is powered on and you have access
to WebGUI.
2. Go to ABOUT > Backup and Restore, and click on Restore
Factory Defaults buon. The device will then restore the factory
defaults and reboot.
Note:
1. Factory Reset or Restart process, make sure power adaptor is
connected with the Unilink 200 to ensure uninterrupted power
supply.
2. Before turn on CPE, please insert DITO 5G sim card first.
3. Please plug off power adapter first if you would like to plug off
sim card.
Reset pin hole

5. Q&A
The Power LED indicator is not ON.
1. Check if the Power adapter is plugged properly into ACsocket.
2. Check power adapter is connected to Unilink 200 properly.
Note: Use only provided Power Adaptor comes with packaging
along with the device
Web Based Utility (WebGUI) cannot be accessed
1. Ensure that the Unilink 200 is powered on.
2. Ensure that your wireless client is connected and acquired the
IP address from Unilink 200 over Wired or wireless connection.
3. Check with another web browser or try reset the browser cache
Memory.
4.Try Reboot or factory reset the device.
Device cannot access the network
1. Ensure your USIM card is valid and active.
2. Check 5G LED, it should be On. In case, if it is off then login to
WebGUI and check the Network details available on homepage.
3. Network status should be showing Connected. If it is showing
disconnected or connecting, Kindly check network parameters
RSRP, SINR values. SINR value (dB) should be Positive.
RSRP value must be greater than -115dBm. Preferred value
should be around -90 dBm.
4. Try Reboot or factory reset the device.
5. If your laptop or mobile fails to connect CPE via WIFI several times,
you can try:
a) Forget your WIFI password, re-enter the password and try to
connect again.
or
b) Restart your laptop or mobile and try to connect again.
