diversey Taski dorsalino Operating and installation instructions

dorsalino
V016 / 12086-67 1029
I25 I24 I23 I22 I21 I20 I19 I18 I17 I16 I15 I14 tr sv pt pl no nl it fr es en de da cz
*12086-67*

14
Translation of the original instructions of use
Symbols
Intended use of machinery
The TASKI dorsalino is a vacuum cleaner that is intended for commercial use
(e.g. in hotels, schools, hospitals, factories, shopping centres, offices, etc.).
Under strict compliance with these Instructions for Use, it can be used for the
dry cleaning of textile floor and wall coverings.
This machine has been exclusively designed for indoor use only.
Content
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Translation of the original EU Declaration of Conformity . . . . . . . . . 15
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Preparation for operation/Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Beginning work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
End of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Service, maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
General survey. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Safety instructions
Due to their design and construction, TASKI machines comply with health and
safety requirements of the EC guidelines and therefore carry the CE sign.
Important! Switch the machine off when you:
• e.g. carry out cleaning or maintenance work, or convert the machine to
another function
• store it in a suitable room to avoid any unauthorised use of the unit
• leave it standing without supervision
Do this by pulling the power supply cord out of the mains socket.
Store the machine in a dry, dust-free room with a corrosion-free atmosphere.
The temperature must not fall below +10 °C or exceed +35 °C. Low
temperatures, damp and dust can significantly reduce the service life of the
electrical components.
ATTENTION!
Before first start-up, it is essential that you
read the instructions of use and the safety
notes carefully.
Keep the instructions of use in an easily
accessible place so that they can be consulted
at any time.
Non-observance of this information can endanger people and / or
cause servere damage!
Non-observance of this information can lead to malfunctions and
property damage!
Indicates important information regarding the efficient use, non-
observance of which could lead to malfunctions!
Marks work steps that you must carry out in turn.
Modifications to this machine that have not been authorised by
Diversey will lead to the cancellation of the Safety Marks and the
CE Conformity.
Any use of this machine other than its defined intended use could
lead to injuries to persons and damage to the machine and the
working environment.
In such cases, all guarantee and warranty claims will normally
become null and void.
Persons (including children) who are not able to use this machine
safely due to their physical, sensory or mental capabilities or their
lack of experience or knowledge may not operate this machine
without supervision or instruction by a person responsible for their
safety!
Children should be supervised to ensure that they do not play with
the appliance.
Do not use the machine in rooms where explosive and flammable
substances (e.g. petrol, thinners, heating oil, solvents, etc.) are
stored or processed. The electrical or mechanical components of
the machine could lead to ignition of these materials.
Do not use this machine to vacuum toxic, poisonous, caustic or
irritating substances (e.g. acids, alkalis, hazardous dusts, etc.).
The filter system will not adequately retain these kinds of
materials. A possible impairment of the health of the user and of
third parties cannot be excluded.
While operating the machine, take note of the surrounding area
and pay particular attention to third parties and children!
In particular, the speed of the machine must be reduced in unclear
situations, for example, near doors or curves .
STOPSTOP
•
STOPSTOP
STOPSTOP
STOPSTOP
STOPSTOP
STOPSTOP
In case of damage to parts that could affect safety, such as the
tool cover, power supply cord or covers that prevent access to
current-carrying parts, the operation of the machine must be
stopped immediately!
Regularly check the power supply cord for tearing or aging, and
do not put the machine into operation if it is not in a safe and
suitable condition!
Caution:
Repairs to mechanical or electrical parts of the machine must only
be undertaken by Diversey authorised customer service
workshops or experts who are experienced in all relevant safety
regulations.
Minimum requirements on the H05VV-F2x1.0 or H07RN-F2x1.0
power cord.
Caution:
This machine is only intended for use in dry areas, and must not
be used or stored in the open air or under damp conditions.
Caution:
Pay attention to the accident prevention regulations!
Caution:
Only use the tools that are defined in these Instructions for Use
under Accessories or that have been recommended by the TASKI
specialist (Page 17), as other tools could impair safety.
Caution:
The protection of persons is based on the specific national
regulations together with the information provided by the
detergent manufacturer!
Caution:
It is forbidden to plug in or unplug the main power supply cord with
wet hands!
Caution:
Take care not to damage the power supply cord by driving over it.
Avoid crimping, tearing or damaging the power supply cord
through heat, oil, or sharp objects!
Caution:
Please make sure that the voltage stated on the machine label is
the same as the voltage rating of the plug socket!
Noise emission:
TASKI machines and units have been designed so that they
present no danger to health through their noise emission accoring
to the curent state of scientific knowledge.
See the technical information on page 17.
STOPSTOP
STOPSTOP

15
I25 I24 I23 I22 I21 I20 I19 I18 I17 I16 I15 I14 tr sv pt pl no nl it fr es en de da cz
Translation of the original EU Declaration of Conformity
We hereby declare that the product described below both in this basic design
and con-struction and in the version marketed by us conforms to the relevant
health and safety related requirements of the appropriate EU Directive.
This declaration shall cease to be valid if modifications are made to the product
without our approval.
Applicable EU Directives:
Directive 2006/42/EC of the European parliament and of the council of
17 May 2006 on machinery, and amending Directive 95/16/EC (recast)
Directive 2004/108/EC of the European parliament and of the council of
15 December 2004 on the approximation of the laws of the Member States re-
lating to electromagnetic compatibility and repealing Directive 89/336/EEC
Harmonised standarts applied:
EN 60 335-1: 2009-12-01/EN 60 335-2-69: 2009/EN 62 233: 2009-01-01/
EN 55 014-1: 2010-04-01/EN 55 014-2: 2009-08-01/
EN 61 000-3-2: 2006-12-01/EN 61 000-3-2: 2006-A1:2009/
EN 61 000-3-2: 2006-A2:2009/EN 61 000-3-3: 2009-08-01
It is ensured through internal measures that series-production units conform at
all times to the requirements of current EU Directives and relevant standards.
The signatories act on behalf of company management and with full power of
attorney.
Overview
1Suction hose holding device
2Body cover with hose connector
3Back padding
4Carrying belt
5Fastening clamp
6Body
7Body belt with special accessory holder
8Power supply cord
9On/Off switch
10 Coarse filter
11 Cotton filter (filter cloth)
Preparation for operation/Operation
Beginning work
Possible uses
End of operation
Designation: Dry vacuum cleaner for commercial use
Product: Vacuum Cleaner
Name: dorsalino
Model: S10 (220-240VAC/50-60Hz, 900W)
Serial number: see rating label at the machine
Trademark:
Producer: Eurosteam, 76770 Le Houlme - France
Person authorised to compile the technical file:
Stephan Engler
Diversey Europe B.V. Utrecht
Zweigniederlassung Münchwilen
CH-9542 Münchwilen
Le Houlme, 21.07.2010
P. Julin
General Manager
• Assemble the suction accessory and check that the double-filter paper sack
and the filter cloth are installed.
• 2Insert the suction hose [2] into the hose
connector [1] until it locks in.
• Place the machine on your back and adjust the
carrying belts to your body.
• Lock in the fastening of the body belt and then
adjust it.
• Plug the power supply cord into the mains socket.
• Switch the machine on (ON/OFF).
A bleed hole cover with which the suction force can be regulated is mounted
on the tube bend.
• The 3-part suction tube can be used in various lengths.
e.g. use as 3-part on floors, as 2-part on steps, etc.
• If the suction hose is removed completely, upholstered furniture and hard-
to-access locations can be vacuumed using the corresponding accessory.
• Switch the machine off (ON/OFF) and pull the power supply cord out of the
mains socket.
If necessary, wait a moment before removing the double-filter
paper sack, in order to let the dust settle.
• The full double-filter paper sack must be disposed of according to national
regulations.
• Press the two fastening clamps upwards.
2
5
8
34 1
6
79
10
11
2
1

16
Cleaning the machine
Heavy soiling of the coarse filter
Service, maintenance and care
The correct maintenance of the machine is a pre-condition for trouble-free
running and a long life.
Service intervals
TASKI machines are built to the highest quality standards. This is supported by
internationally recognised quality control procedures. Electrical and mechanical
parts are subject to wear or aging if used for long periods of time.
Service centre
Should you contact us due to a malfunction or for placing an order, please
always state the type, description and the serial number of your machine.
You can find this information on the name plate of your machine, and the
address of your nearest TASKI partner can be found on the last page of this
manual.
Malfunctions
• Lift off the body cover and remove the double-
filter paper sack.
• Then pull the new double-filter paper sack with the rubber flange over the
hose connector.
Lightly soiled cloth filter.
• Brush off or using another vacuum cleaner, suck off the dirt.
Heavily soiled cloth filter.
• Wash the cloth filter in the washing machine (max. 30° C/86° F).
• Allow the damp filter cloth to dry in the air.
Caution:
Never install a wet or damp filter cloth as this could damage the
motor!
The machine may only be operated with a functional filter cloth!
The filter cloth must not be dried in a tumbler drier!
Caution:
Never clean the machine with high water pressure or a water
hose.
The ingress of water into the machine may cause considerable
damage to mechanical or electrical parts.
• Wipe down the machine, the cable and the accessory with a damp cloth.
• Remove the coarse filter.
• Clean the filter under running water, or replace
if necessary.
Let the coarse filter dry out completely before
re-inserting it.
• Press the dried or new coarse filter back into its
position.
Caution:
The coarse filter must not be dried in a tumble drier!
The machine must never be operated without the coarse filter!
• Replace the body cover again.
• Press the two fastening clamps downwards.
Caution:
Only TASKI branded spare parts must be used, otherwise
warranties and liabilities will be omitted!
Symbols:
◊= after use, ◊◊ = every week
Activity ◊◊◊ page
Check double-filter paper sack, replace if necessary 15
Clean coarse filter and sponge filter, replace if necessary 15
Clean the machine with a damp cloth 15
• In order to maintain operational reliability and availability for use, the service
must be carried out after 500 working hours or at least once a year.
Under rough or extreme working conditions and / or insufficient maintenance,
shorter intervals may be necessary.
Malfunction Possible causes Troubleshooting page
Machine is not
running
ON/OFF switch (ON/OFF)
switched off
• Switch the ON/
OFF switch on 15
No power supply • Plug the power supply cord into
the mains socket.
Power supply cord
defective •Replacethe power supply cord 15
ON/OFF switch defective • Call for technical
assistance
Motor not turning • Call for technical
assistance
Machine
switches off
during operation.
Self-resetting temperature
sensor has been tripped
• Check that the
double-filter paper
sack is not
overfilled
• Check the suction
accessory
The machine will
switch on again
once the motor
turbine has cooled
down (approx. 10-
20 min.)
Poor vacuum
performance
Hose or squeegee nozzle
blocked (e.g. piece of
wood, material remnant)
• Remove the
blockage
Double-filter paper sack
full •Replace 15
Suction hose not
connected •Check 15
Cloth filter soiled • Clean or replace 15
Coarse filter soiled • Clean or replace 16

17
I25 I24 I23 I22 I21 I20 I19 I18 I17 I16 I15 I14 tr sv pt pl no nl it fr es en de da cz
Transport
The accessory must be removed. Transport is carried out with the machine in a
lying position. The machine must be adequately secured before transportation.
Disposal
When it has reached the end of its operational life, the machine and its
accessories must be disposed of according to the national regulations. Your
TASKI partner can support you with proper disposal upon notification.
Technical data
Accessories
General survey
Machine dorsalino
S 10
type
Rated voltage 220-240V AC
Frequency 50-60 Hz
Rated power 900 W
Power supply cord length 15 m
Machine weight 5.4 kg
Dimensions (L x W x H) 52x32x30 cm
Assessed sound level LPA according to EN
60704-1
70 dB(A)
Electrical protection class II
Nr. Article S10
8504190 Disposable Paper Dust Bags (pack of 10 pieces) X
8500560 Universal dust nozzle 30 cm X
8503280 Suction hose 2.2 m complete X
8503980 Suction lance 3-part X
8500430 Conicle coupling X
8500510 Brush nozzle X
8500520 Radiator nozzle X
8500530 Pipe suction nozzle set (2 pieces) X
8500540 Upholstery nozzle X
8500550 Notch nozzle X
16324-18 Coarse filter X
8500520
8500510
8500540
8500550
8500530
8500560
8503280
8500430
8503980
8504190
