AG SPRAY MC2 Series User manual

Page 1
General Informaon
Thank You and Congratulaons on purchasing your
new three point hitch sprayer. The purpose of this
manual is to assist you in operang and maintaining
your 3-Point sprayer.
Please read it carefully, as it furnishes informaon
which will help you achieve years of trouble-free
operaon. All units can be custom equipped to
meet all your spraying needs. The MC Series
3 Point is designed to t Category II Li Arms.
Any Quesons, Comments or Problems: Call your nearest AG SPRAY Locaon
and speak with one of our Friendly Technical Support Sta.
OWNER’S MANUAL
[5195837 (09/22)]
507-388-6295
800-394-7662
800-634-2026
877-974-7166
MANKATO, MN
NEWTON, KS
PASCO, WA
TEMPE, AZ
877-724-2236
800-274-1025
800-227-4098
701-280-2862
800-637-7172
BAKERSFIELD, CA
COLUMBUS, NE
DOTHAN, AL
FARGO, ND
HOPKINSVILLE, KY
VISIT US ONLINE @
WWW.AGSPRAY.COM
165 Gallon (5303646)
Ag Spray MC2 Series 3 Point Sprayers
165 & 225 Gallon 3-Point Sprayers
225 Gallon (5303647)
WARNING: Cancer and Reproducve Harm.
www.P65Warnings.ca.gov
WARNING: To reduce the risk of injury, the
user must read and understand the operator’s
manual before using this product.

Page 2
Table of Contents
3 - 6 Safety Informaon
6Hooking Up Sprayer
7Sprayer Boom Controls
8-13 Calibrang Sprayer
11 Calibrang Sprayer: Boomless Nozzle Applicaon Charts
12 Calibrang Sprayer: Broadcast & Turf Applicaon Chart 20” Spacing
14 Operang Instrucons
15 Maintenance Instrucons
15 Winterizing Sprayer
16-40 Component Assembly Breakdowns
16 MC2 165 Gallon 3 Point Assembly Breakdown - Base Unit
17 MC2 225 Gallon 3 Point Assembly Breakdown - Base Unit
18-19 MX4 Series Boom Assembly
20-23 479 Series Boom Assembly
24-26 2300 Series Boom Assembly
27 BXT Series Boomless Boom Assembly
28-29 PX4 Series Boomless Boom Assembly
30-31 PX4 Boom Power Fold Opons
32 Hamilton Boomless Nozzle Assembly
BXT Boomless Nozzle Assembly
33 MC 3-PT 22” ProSeries Handgun Kit
MC 3-PT Deluxe Handgun Kit
34 Hose Reel Kit
35 Two Sec Valve Assembly
1-SEC Valve Assembly with 1/2” HB
1-SEC Valve Assembly with 3/8” HB
36 RP-800 Series 8-Roller Pump Assembly
37 Hypro 7560XL Series 8-Roller Pump Assembly
38 MC-Electric Conversion Kits
39 Foam Marker Opon
40 Handwash Opon
41 Warranty Info

Page 3
Important Operaon & Safety Informaon
Read and understand this owner’s manual completely before using the sprayer.
Read each chemical label’s instrucons before handling the chemical.
Improper use of the sprayer or handling of chemicals could result in serious injury or illness for the oper-
ator or nearby persons/animals, or cause damage to the environment.
LISTED BELOW is a summary of safety informaon of parcular importance. See individual secons of this owner’s manual for
more details.
----------------------------------BEFORE YOU BEGIN -------------------------------------
Please read and understand this manual and its instrucons and warnings completely before operang the sprayer.
• Be aware of all safety guidelines, warnings and cauons including those of the tractor manufacturer
• Read and understand the chemical manufacturer’s labels, warnings and instrucons
• Know and fulll all state pescide applicator license requirements
• Familiarize yourself and other operators with the sprayer’s components and how all parts are operated
------------------------------General Safety Guidelines---------------------------------
Every year many unnecessary accidents occur do to improper equipment handling and a disregard for safety precauons.
You, the operator, can avoid accidents by observing the precauons in this secon.
• The operator should be a responsible adult. Do not allow persons to operate this sprayer unl they have displayed a thorough
understanding of sprayer safety precauons and operaonal use!
• All operators must also fulll state pescide applicator license requirements
• Never aempt to operate this sprayer when under the inuence of alcohol or drugs.
• The best defense against accidents is a careful and responsible operator. If your sprayer is equipped with a PTO drive sha, it is
very important to take the proper safety precauons
• Failure to keep body parts or clothing clear of the sprayer’s PTO drive sha could result in serious injury or death. Ag Spray
assumes no liability for any possible injury
• Never step over or work near the PTO drive sha during operaon
• When transporng the sprayer on public roads, always follow state and local regulaons regarding safety and transportaon
requirements
WARNING

Page 4
----------------------------------- Before Operaon --------------------------------------
• Carefully study and understand the owner’s manual
• Read and follow chemical manufacturer’s labels, warnings and instrucons! A material safety data sheet (MSDS) should be
provided by the chemical manufacturer
• To avoid injury from chemical hazards, wear the proper protecve clothing. Each chemical manufacturer’s clothing require-
ments are listed under the “Personal Protecve Equipment (PPE)” secon in the chemical instrucons
• Never exceed your tractor’s load rang
• Do not wear loose-ng clothing which may catch in moving parts
• Give the sprayer a visual inspecon for any worn parts, loose bolts or other visible problems and make any needed repairs
• Make sure the area is clear of any people or obstrucons before using the sprayer
• Before adding chemicals, have all operators pracce operang the sprayer (clean water only) and it’s aachments unl all
operators are completely capable of safe operaon
------------------------------- BEFORE SEASONAL USE ----------------------------------
• CHECK and TEST sprayer with water before adding chemical. Temperature change can cause material ng expansion/
contracon. Serious injury could result from chemical leaks
• REPLACE any worn or frayed hoses. Hose failure can result in serious damage
• INSPECT pressure gauge. Insure the needle rests at zero when all pressure is relieved in the spray system. Failure to have a
properly funconing pressure gauge can result in miss applicaons of chemical
--------------------------------- DURING OPERATION ------------------------------------
• Always be aware of bystanders, parcularly children! Always look before moving the sprayer or engaging the PTO
• Never leave running equipment unaended!
• Keep hands and body parts clear of all moving parts, especially the tractor PTO
• Be aware of dangerous terrain such as holes, slopes, drop-os, banks, rocks and hidden hazards. Operate the tractor and
sprayer up and down slopes, not across
• When operang on inclines, it is especially important that your tractor is equipped with Roll Over Protecon System (ROPS)
• No passengers are allowed on or in the tractor or sprayer at anyme
• Allow for sprayer boom length when making turns
• Remember that accidents can even happen to seasoned operators. Always take your me and follow all safety instrucons
Important Operaon & Safety Informaon

Page 5
-------------------------------General Chemical Safety----------------------------------
• READ and FOLLOW all chemical label’s instrucons and warnings
• AVOID inhaling, ingesng or coming into contact with any chemicals
• KNOW applicable licensing and regulatory requirements for the chemical you plan to use
• KNOW emergency procedures before handling chemicals
• WEAR protecve clothing, eye protecon and chemical resistant gloves when lling, using and cleaning the sprayer. Wear
addional protecve gear, such as facemask or apron, as recommended on the chemical label
• EXERCISE EXTRA CAUTION around children or pets. Pescides are especially toxic to them. Keep sprayer and spray materi-
als away from them at all mes
• DO NOT MIX OR POUR chemicals in an enclosed, unvented area
• DO NOT USE ammable or corrosive chemicals in the sprayer
• FLUSH the sprayer with clean water aer every use AND before switching chemicals
• STORE pescides in a correctly labeled container and in a secure locaon
• MONITOR the health of operators frequently exposed to pescides, as recommended by the chemical label or local/federal
regulaons
---------------------------- Chemical Applicaon Safety -------------------------------
• INSPECT and PREPARE sprayer before each use as directed
• DO NOT TURN ON POWER to sprayer unl ready to spray in order to avoid unintended spray release
• MAKE SURE NOZZLES ARE ORIENTED IN THE PROPER DIRECTION before starng the sprayer. As incorrectly posioned nozzle
may spray chemicals on you or others
• KEEP sprayer and spray materials away from children and pets. Pescides can be especially toxic to children and animals
------------------------------ Pump Safety Precauons ---------------------------------
• Never pump ammable or explosive uids such as gasoline, fuel oil, kerosene, etc.
• Never pump acids (i.e. acid ferlizer) with super rollers. For acid ferlizer, Hypro recommends the Silver Series casngs with
Teon rollers
• Never run the pump dry! Never pump faster than, or above, the maximum recommended speed and pressure
• Never pump liquids at temperatures higher than the recommended maximum temperature (140° F/60° C). Do not exceed this
temperature
• Before servicing your pump, disconnect the power, release all pressure and drain all liquids
Important Operaon & Safety Informaon

Page 6
--------------------------------- Following Operaon ------------------------------------
• Following operaon, it is very important that you completely rinse the enre sprayer and all of it’s components of all chemical
residue
• Following operaon, stop the tractor unit, set the brakes, disengage PTO sha, shut o the engine and remove the ignion key
• Park the sprayer on a hard level surface
• Store the sprayer away from human and livestock acvity
• Do not permit children to play on or around sprayer
Your MC Series 3 Point sprayer is designed to allow for Category II 3 Point hitch. The hitch design will t most brands of 3 Point
Quick Tach. The unit comes standard with Category II lower link pins (1 1/8”) and top link pin (1”). Once the lower link arms of the
tractor are connected to the MC lower pins, install 3/8”-7/16” retainer pins (NOT Included) to hold the lower arms in place.
If using a CAT II Quick Tach: bushings should be added (NOT Supplied) to match your Quick Tach System.
Important Operaon & Safety Informaon
Hooking Up the Sprayer
Top Link Pin
Insert Retainer Pins
(NOT Included)
Lower Link Pins

Page 7
Familiarize yourself with the sprayer controls before use. Your sprayer may be equipped with
manual or electric (oponal) boom controls.
If your sprayer is equipped with the manual lever controls:
• Boom Secon On/O Valve--OFF when the lever is down or in
the horizontal posion, it is ON when the lever is up or in the
vercal posion.
• Pressure Relief/Regulang Valve. - loosen the jam nut and screw
the knob down to increase pressure and up to decrease pres-
sure. Once desired pressure is obtained, ghten jam nut.
• Pressure Gauge - Monitor sprayer pressure. DO NOT exceed
100psi. Exceeding 100psi can cause premature gauge failure.
If your sprayer is equipped with electric controls:
Determine the best locaon for the control box in the vehicle cab, according to the
following guidelines:
• Switches should be within easy reach
• Controller bracket should rest on a at surface
• 12 volt DC power source must be accessible.
The Electric Control Kit power cord comes with a 3 pin convenience plug.
If your Tractor is not equipped with that type power plug, a Socket 25A
is included in the kit.
The Socket 25A plug will have to be wired into the tractor.
See Socket 25A Wiring Diagram to the right for wiring details
Socket 25A
Socket 25A Wiring Diagram
Sprayer Boom Controls
Pressure Relief/Regulang Valve
Boom Secon
On/O Valve
Pressure Gauge

Page 8
Calibrang the Sprayer
When spraying with a boom, the sprayer must be calibrated to ensure proper spray coverage and to combat over-applicaon or
under applicaon. Before calibrang the sprayer, it is important to familiarize yourself with the operang instrucons.
The calibraon process is simplied when broken down into the following three steps:
1. Determine the speed of the tractor
2. Determine the nozzle size and use the calibraon chart to nd the correct pressure seng
3. Set the pressure accordingly using the pressure regulang valve
1. Determining the Speed
It is important to determine what speed the tractor will be traveling at, while spraying. While some tractors have speedometers, it
is sll recommended that speed is calculated for all tractors for accuracy purposes. To determine the speed follow these steps:
1. Set the tractor throle to operate between 75%-100% of the tractor’s RPM range. This will allow the pump to operate at full
volume
2. Measure a 200 foot or 300 foot distance on a eld or a surface similar to where you will be spraying
3. Drive the tractor and sprayer (tank half-full is opmal) across the measured distance at a constant rate of speed. There should
be no changes in speed while you are measuring the me. This should be a comfortable speed for spraying
4. Have someone measure the amount of me (in seconds) it takes to travel the measured distance
5. Your speed can be found by entering your data into the equaon below or by consulng the speed table
Speed (MPH) = (Distance (FT) x 60)/(Time (Seconds) x 88)
_____(MPH) = _____(FT) x 60/ _____(SEC) x 88
Note: When calculang tractor speed be sure to
select a gear that allows the tractor to operate be-
tween 75%-100% of the tractor’s RPM range. This will
allow the pump to operate at full volume. Selecng a
higher gear will not allow the pump to work
eciently.
Note: All calibraon must be done with clean water only! Note: it is helpful for future references to record the exact
RPM and gear that was used to aain the desired speed
Tractor RPM Tractor Gear = Speed
___________ ___________ _________________
100 Ft. 200 Ft. 300 Ft.
1.0 68 sec. 136 205
2.0 34 68 102
3.0 23 45 68
4.0 17 34 51
5.0 14 27 41
6.0 11 23 34
7.0 9.7 19 29
8.0 8.5 17 26
9.0 7.6 15 23
10.0 6.8 14 20
Speed Chart
Time Required in seconds
to travel a distance of
Speed in M.P.H.
(Miles Per Hour)

Page 9
Calibrang the Sprayer
2. Determine the nozzle size and use the calibraon chart
Always follow the chemical manufacturers label recommendaons for applicaon rate (GPA). There are ve things you will need to
know to be able to gure your nozzle size and pressure seng. They are:
1. Applicaon rate — GPA or GAL/1000 Sq. Ft.
2. Speed — MPH
3. Width — Nozzle Spacing (in inches) for broadcast boom spraying
— Spray width (in inches) for boomless nozzles
4. Spraying Pressure — Follow chemical label recommendaons for pressure/droplet size requirements
5. Soluon weight and conversion factor (CF)
Spraying Soluons Other than Water
Since all the tabulaons are based on spraying water, which weighs 8.34 lbs. per USA gallon, conversion factors must be used when
spraying soluons which are heavier or lighter than water. To determine the proper size nozzle for the soluon to be sprayed, rst
mulply the desired GPM or GPA of soluon by the rate conversion factor. Then use the new converted GPM or GPA rate to select
the proper size nozzle and pressure.
Example: Desired applicaon rate is 20 GPA of 28% Nitrogen. Determine the
correct nozzle size as follows:
GPA (Soluon) x Conversion Factor = Converted GPA
20 GPA (28% x 1.13 = 22.6 GPA (Water), the applicator should choose a
nozzle size that will supply 22.6 GPA of water at the desired pressure.
See the appropriate Applicaon Chart for your boom spraying nozzle or
boomless nozzle. Using the tractor speed, nozzle width or spray width,
nozzle size being used and desired gallons per acre (GPA), nd the
pressure (psi) necessary to achieve the desired GPA.
Example for tradional boom sprayer: Assume you have found your tractor speed to be 6 MPH, your nozzle spacing is 20”, and
you want to spray 15 GPA and your sprayer has blue AIXR11003VP nozzles. Upon looking at the applicaon chart, you will nd that
you should set the sprayer’s pressure at about 40 psi in order to apply about 15 GPA.
Example for boomless sprayer: Assume you have found your tractor speed to be 5 MPH, your nozzle will cover 216 inches (18 Ft)
mounted 48” height above the target spray zone, and you will want to spray 15 GPA and your sprayer has yellow XT024 nozzles.
Upon looking at the applicaon chart, you will nd that you should set the sprayer’s pressure at about 50 psi in order to apply
about 15 GPA.
Useful Formulas
GPM =GPA x MPH x W GPM —Gallons Per Minute
(Per Nozzle) 5,940 GPA —Gallons Per Acre
GAL/1000 Sq. Ft. —Gallons Per 1000 Square Feet
GPM =GAL/1000 Sq. Ft. x MPH x W MPH —Miles Per Hour
(Per Nozzle) 136 W—Nozzle Spacing (in inches) for broadcast spraying
—Spray width (in inches) for single nozzle,
Band spraying or Boomless spraying
Weight of Solution
Specific
Gravity
Conversion
Factors
7.0 lbs. per gallon .84 .92
8.0 lbs. per gallon .96 .98
8.345 lbs. per gallon
(Water)
1.00 1.00
9.0 lbs. per gallon 1.08 1.04
10.0 lbs. per gallon 1.20 1.10
10.66 lbs. per gallon
(28% Nitrogen)
1.28 1.13
11.0 lbs. per gallon 1.32 1.15
12.0 lbs. per gallon 1.44 1.20
14.0 lbs. per gallon 1.68 1.30

Page 10
Calibrang the Sprayer
3. Adjusng the Sprayer Pressure
Once you have found the correct pressure (psi) seng, you must now adjust the sprayer to that pressure seng. Before you adjust
the sprayer’s pressure, it is important to follow these steps:
1. Make sure the sprayer tank is at least half full of clean water and the tank supply shuto valve to the pump is open.
2. Make sure the pressure relief valve is backed out so at least 4 threads are showing. If not, loosen the jam nut and screw the
knob out unl at least 4 threads can be seen.
3. Make sure the valves to the agitator are open, if equipped.
4. With the booms on, idle tractor and engage the tractor PTO to start the pump. Slowly increase tractor RPM, paying aenon
to the sprayer pressure gauge. (Do NOT spike the sprayer pressure gauge). If you over pressurize the spray system you can
damage the pressure gauge and sprayer plumbing. Increase the tractor’s RPM unl you reach RPM that was used to set the
tractor’s speed.
5. Adjust the pressure relief valve to reach your desired psi for your speed and GPA. This is achieved by loosening the jam nut on
the pressure relief valve and screwing the knob in to increase pressure and out to decrease pressure. Once you have reached
your desired pressure, ghten the jam nut to lock the pressure control knob. If you can not achieve enough pressure, slowly
close the agitaon valve. Tighten the valve nut to lock the agitaon valve, if equipped.
You have successfully calibrated the sprayer.
PISTON TYPE PRESSURE RELIEF/REGULATING VALVE
Bypasses excess liquid. Adjustable to maintain control of line pressure at any pressure within the valve operang range.
Selected pressure seng rmly held in place by locknut. Extra large passages to handle large ows.
• Polypropylene with stainless steel spring
• Excellent chemical resistance
• EPDM O-Rings
• For pressure to 150 p.s.i.
• 1/4” port for pressure gauge
• 3/4” NPT (M) inlet & (F) outlet connecons
Fimco # Mfg. Part #
5143199 23120-3/4-PP
5143200 23120-1/2-PP
5168717 PK-AB23120-KIT
Description
Pressure Relief Valve (3/4" NPT)
Pressure Relief Valve (1/2" NPT)
Repair Kit, Items Marked * *
* * Available only in Repair Kit
♦ ♦ Only Available in Complete Assembly

Page 11
Calibrang the Sprayer
Calibraon Chart
There are many dierent sizes and styles of spray ps available to meet your
spraying needs. If you need further informaon, please contact an Ag Spray Service
Center for assistance.
Please Note: Flow rates are calculated using fresh water.
Always remember to double check applicaon rates.
Boomless Nozzle Applicaon
Hypro Boom X Tender
Boomless Nozzles
NOTE: 90° nozzles have the same GPA, but 1/2 GPM and swath
NOTE: Applicaon rates are based on overall swath widths listed at 48” height. Refer to operang instrucons if using a dierent swath.
HAMILTON BOOMLESS NOZZLES
4 5 6 8 10 12 15 20 2 3 4 5
30 0.9 8.9 7.1 5.9 4.5 3.6 3.0 2.4 1.8 0.41 0.27 0.20 0.16
40 1.0 9.9 7.9 6.6 5.0 4.0 3.3 2.6 2.0 0.45 0.30 0.23 0.18
50 1.1 10.9 8.7 7.3 5.4 4.4 3.6 2.9 2.2 0.50 0.33 0.25 0.20
60 1.2 11.9 9.5 7.9 5.9 4.8 4.0 3.2 2.4 0.55 0.36 0.27 0.22
30 1.3 10.9 8.7 7.3 5.4 4.4 3.6 2.9 2.2 0.53 0.35 0.26 0.21
40 1.5 12.5 10.0 8.3 6.3 5.0 4.2 3.4 2.5 0.61 0.41 0.30 0.24
50 1.7 13.7 11.0 9.2 6.9 5.5 4.6 3.7 2.8 0.67 0.45 0.33 0.27
60 1.8 15.0 12.0 10.0 7.5 6.0 5.0 4.0 3.0 0.73 0.49 0.37 0.29
30 1.7 13.6 10.9 9.0 6.8 5.4 4.5 3.6 2.7 0.62 0.42 0.31 0.25
40 2.0 16.0 12.8 10.6 8.0 6.4 5.3 4.3 3.2 0.73 0.49 0.37 0.29
50 2.2 17.6 14.1 11.7 8.8 7.0 5.9 4.7 3.5 0.81 0.54 0.40 0.32
60 2.4 19..2 15.3 12.8 9.6 7.7 6.4 5.1 3.8 0.88 0.59 0.44 0.35
30 2.1 16.2 13.0 10.8 8.1 6.5 5.4 4.3 3.2 0.75 0.50 0.37 0.30
40 2.4 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 0.85 0.57 0.43 0.34
50 2.7 20.9 16.7 13.9 10.4 8.4 7.0 5.6 4.2 0.96 0.64 0.48 0.38
60 2.9 22.4 17.9 15.0 11.2 9.0 7.5 6.0 4.5 1.03 0.69 0.51 0.41
30 3.7 31.6 25.3 21.1 15.8 12.6 10.5 8.4 6.3 1.45 0.97 0.72 0.58
40 4.3 36.7 29.4 24.5 18.3 14.7 12.2 9.8 7.3 1.68 1.12 0.75 0.67
50 4.8 41.0 32.8 27.3 20.5 16.4 13.7 10.9 8.2 1.88 1.25 0.94 0.75
60 5.3 45.2 36.2 30.2 22.6 18.1 15.1 12.1 9.0 2.08 1.38 1.04 0.83
30 6.9 68.3 54.6 45.5 34.2 27.3 22.8 18.2 13.7 3.14 2.09 1.57 1.25
40 8.0 79.2. 63.4 52.8 39.6 31.7 26.4 21.1 15.8 3.64 2.42 1.82 1.45
50 8.9 88.1 70.5 58.7 44.1 35.2 29.4 23.5 17.6 4.04 2.70 2.02 1.62
60 9.8 97.0 77.6 64.7 48.5 38.8 32.3 25.9 19.4 4.45 2.97 2.23 1.78
30 14.5 128.0 103.0 85.4 64.1 51.3 42.7 34.2 25.6 5.88 3.92 2.94 2.35
40 16.7 148.0 118.0 98.4 73.8 59.0 49.2 39.4 29.5 6.78 4.52 3.39 2.71
50 18.7 165.0 132.0 110.0 82.6 66.1 55.1 44.1 33.1 7.59 5.06 3.79 3.03
60 20.5 181.0 145.0 121.0 90.6 72.5 60.4 48.3 36.2 8.32 5.54 4.16 3.33
30 18.6 144.0 115.0 95.9 71.9 57.5 48.0 38.4 28.8 6.60 4.40 3.30 2.64
40 21.5 166.0 133.0 111.0 83.1 66.5 55.4 44.3 33.3 7.63 5.09 3.82 3.05
50 24.0 186.0 149.0 124.0 92.8 74.3 61.9 49.5 37.1 8.52 5.68 4.26 3.41
60 26.3 203.0 163.0 136.0 102.0 81.4 67.8 54.2 40.7 9.34 6.22 4.67 3.73
16
14
15
16
14
13
15
215
(3/4")
Nozzle
Size
(MNPT)
Pressure
(PSI)
Flow
Rate
(GPM)
43
(3/8")
80
(1/2")
167
(3/4")
15
(1/4")
20
(1/4")
24
(1/4")
Gallons per Acre
GAL/1000 Sq. Ft.
MPH
MPH
10
(1/4")
Swath (Ft)
at 40 PSI
48" High
13
3 MPH 4 MPH 5 MPH 8 MPH 10 MPH
30 1.7 44' 6.4 4.8 3.8 2.4 1.9
40 2.0 46' 7.2 5.4 4.3 2.7 2.2
50 2.2 48' 7.6 5.7 4.5 2.9 2.3
60 2.4 50' 7.9 5.9 4.8 3.0 2.4
30 3.7 50' 12.2 9.2 7.3 4.6 3.7
40 4.2 50' 13.9 10.4 8.3 5.2 4.2
50 4.6 52' 14.6 10.9 8.8 5.5 4.4
60 5.0 52' 15.8 11.9 9.5 5.9 4.8
30 5.1 54' 15.6 11.6 9.3 5.8 4.7
40 5.9 54' 18.0 13.5 10.8 6.8 5.4
50 6.7 56' 19.7 14.8 11.8 7.4 5.9
60 7.1 58' 20.2 15.1 12.1 7.6 6.1
#20
Operating Data for 1800 Nozzles
Gallons per Acre
Orifice
No.
PSI
GPM
180°
Swath
180°
#5
#10

Page 12
Calibrang the Sprayer
BROADCAST & TURF APPLICATION CHART—20” SPACING
4 5 6 7 8 10 12 14 16 18 20 2 3 4 5
15 0.06 4.5 3.6 3.0 2.5 2.2 1.8 1.5 1.3 1.1 1.0 0.9 0.20 0.14 1.00 0.08
30 0.09 6.7 5.3 4.5 3.8 3.3 2.7 2.2 1.9 1.7 1.5 1.3 0.31 0.20 0.15 0.12
40 0.10 7.4 5.9 5.0 4.2 3.7 3.0 2.5 2.1 1.9 1.7 1.5 0.34 0.23 0.17 0.14
60 0.12 8.9 7.1 5.9 5.1 4.5 3.6 3.0 2.5 2.2 2.0 1.8 0.41 0.27 0.20 0.16
80 0.14 10.4 8.3 6.9 5.9 5.2 4.2 3.5 3.0 2.6 2.3 2.1 0.48 0.32 0.24 0.19
100 0.16 11.9 9.5 7.9 6.8 5.9 4.8 4.0 3.4 3.0 2.6 2.4 0.55 0.36 0.27 0.22
115 0.17 12.6 10.1 8.4 7.2 6.3 5.0 4.2 3.6 3.2 2.8 2.5 0.58 0.39 0.29 0.23
15 0.09 6.7 5.3 4.5 3.8 3.3 2.7 2.2 1.9 1.7 1.5 1.3 0.31 0.20 0.15 0.12
30 0.13 9.7 7.7 6.4 5.5 4.8 3.9 3.2 2.8 2.4 2.1 1.9 0.44 0.30 0.22 0.18
40 0.15 11.1 8.9 7.4 6.4 5.6 4.5 3.7 3.2 2.8 2.5 2.2 0.51 0.34 0.26 0.20
60 0.18 13.4 10.7 8.9 7.6 6.7 5.3 4.5 3.8 3.3 3.0 2.7 0.61 0.41 0.31 0.25
80 0.21 15.6 12.5 10.4 8.9 7.8 6.2 5.2 4.5 3.9 3.5 3.1 0.72 0.48 0.36 0.29
100 0.24 17.8 14.3 11.9 10.2 8.9 7.1 5.9 5.1 4.5 4.0 3.6 0.82 0.55 0.41 0.33
115 0.25 18.6 14.9 12.4 10.6 9.3 7.4 6.2 5.3 4.6 4.1 3.7 0.85 0.57 0.43 0.34
15 0.12 8.9 7.1 5.9 5.1 4.5 3.6 3.0 2.5 2.2 2.0 1.8 0.41 0.27 0.20 0.16
30 0.17 12.6 10.1 8.4 7.2 6.3 5.0 4.2 3.6 3.2 2.8 2.5 0.58 0.39 0.29 0.23
40 0.20 14.9 11.9 9.9 8.5 7.4 5.9 5.0 4.2 3.7 3.3 3.0 0.68 0.45 0.34 0.27
60 0.24 17.8 14.3 11.9 10.2 8.9 7.1 5.9 5.1 4.5 4.0 3.6 0.82 0.55 0.41 0.33
80 0.28 20.8 16.6 13.9 11.9 10.4 8.3 6.9 5.9 5.2 4.6 4.2 0.95 0.64 0.48 0.38
100 0.32 23.8 19.0 15.8 13.6 11.9 9.5 7.9 6.8 5.9 5.3 4.8 1.09 0.73 0.55 0.44
115 0.34 25.2 20.2 16.8 14.4 12.6 10.1 8.4 7.2 6.3 5.6 5.0 1.16 0.77 0.58 0.46
15 0.15 11.1 8.9 7.4 6.4 5.6 4.5 3.7 3.2 2.8 2.5 2.2 0.51 0.34 0.26 0.20
30 0.22 16.3 13.1 10.9 9.3 8.2 6.5 5.4 4.7 4.1 3.6 3.3 0.75 0.50 0.38 0.30
40 0.25 18.6 14.9 12.4 10.6 9.3 7.4 6.2 5.3 4.6 4.1 3.7 0.85 0.57 0.43 0.34
60 0.31 23.0 18.4 15.3 13.2 11.5 9.2 7.7 6.6 5.8 5.1 4.6 1.06 0.70 0.53 0.42
80 0.35 26.0 20.8 17.3 14.9 13.0 10.4 8.7 7.4 6.5 5.8 5.2 1.19 0.80 0.60 0.48
100 0.40 29.7 23.8 19.8 17.0 14.9 11.9 9.9 8.5 7.4 6.6 5.9 1.36 0.91 0.68 0.55
115 0.42 31.2 24.9 20.8 17.8 15.6 12.5 10.4 8.9 7.8 6.9 6.2 1.43 0.95 0.72 0.57
15 0.18 13.4 10.7 8.9 7.6 6.7 5.3 4.5 3.8 3.3 3.0 2.7 0.61 0.41 0.31 0.25
30 0.26 19.3 15.4 12.9 11.0 9.7 7.7 6.4 5.5 4.8 4.3 3.9 0.89 0.59 0.44 0.35
40 0.30 22.3 17.8 14.9 12.7 11.1 8.9 7.4 6.4 5.6 5.0 4.5 1.02 0.68 0.51 0.41
60 0.37 27.5 22.0 18.3 15.7 13.7 11.0 9.2 7.8 6.9 6.1 5.5 1.26 0.84 0.63 0.50
80 0.42 31.2 24.9 20.8 17.8 15.6 12.5 10.4 8.9 7.8 6.9 6.2 1.43 0.95 0.72 0.57
100 0.47 34.9 27.9 23.3 19.9 17.4 14.0 11.6 10.0 8.7 7.8 7.0 1.60 1.07 0.80 0.64
115 0.51 37.9 30.3 25.2 21.6 18.9 15.1 12.6 10.8 9.5 8.4 7.6 1.74 1.16 0.87 0.70
15 0.21 15.6 12.5 10.4 8.9 7.8 6.2 5.2 4.5 3.9 3.5 3.1 0.72 0.48 0.36 0.29
30 0.30 22.3 17.8 14.9 12.7 11.1 8.9 7.4 6.4 5.6 5.0 4.5 1.02 0.68 0.51 0.41
40 0.35 26.0 20.8 17.3 14.9 13.0 10.4 8.7 7.4 6.5 5.8 5.2 1.19 0.80 0.60 0.48
60 0.43 31.9 25.5 21.3 18.2 16.0 12.8 10.6 9.1 8.0 7.1 6.4 1.47 0.98 0.73 0.59
80 0.49 36.4 29.1 24.3 20.8 18.2 14.6 12.1 10.4 9.1 8.1 7.3 1.67 1.11 0.84 0.67
100 0.55 40.8 32.7 27.2 23.3 20.4 16.3 13.6 11.7 10.2 9.1 8.2 1.88 1.25 0.94 0.75
115 0.59 43.8 35.0 29.2 25.0 21.9 17.5 14.6 12.5 11.0 9.7 8.8 2.01 1.34 1.01 0.80
15 0.24 17.8 14.3 11.9 10.2 8.9 7.1 5.9 5.1 4.5 4.0 3.6 0.82 0.55 0.41 0.33
30 0.35 26.0 20.8 17.3 14.9 13.0 10.4 8.7 7.4 6.5 5.8 5.2 1.19 0.80 0.60 0.48
40 0.40 29.7 23.8 19.8 17.0 14.9 11.9 9.9 8.5 7.4 6.6 5.9 1.36 0.91 0.68 0.55
60 0.49 36.4 29.1 24.3 20.8 18.2 14.6 12.1 10.4 9.1 8.1 7.3 1.67 1.11 0.84 0.67
80 0.57 42.3 33.9 28.2 24.2 21.2 16.9 14.1 12.1 10.6 9.4 8.5 1.94 1.30 0.97 0.78
100 0.63 46.8 37.4 31.2 26.7 23.4 18.7 15.6 13.4 11.7 10.4 9.4 2.15 1.43 1.07 0.86
115 0.68 50.5 40.4 33.9 28.9 25.2 20.2 16.8 14.4 12.6 11.2 10.1 2.32 1.55 1.16 0.93
15 0.31 23.0 18.4 15.3 13.2 11.5 9.2 7.7 6.6 5.8 5.1 4.6 1.06 0.70 0.53 0.42
30 0.43 31.9 25.5 21.3 18.2 16.0 12.8 10.6 9.1 8.0 7.1 6.4 1.47 0.98 0.73 0.59
40 0.50 37.1 29.7 24.8 21.2 18.6 14.9 12.4 10.6 9.3 8.3 7.4 1.71 1.14 0.85 0.68
60 0.61 45.3 36.2 30.2 25.9 22.6 18.1 15.1 12.9 11.3 10.1 9.1 2.08 1.39 1.04 0.83
80 0.71 52.7 42.2 35.1 30.1 26.4 21.1 17.6 15.1 13.2 11.7 10.5 2.42 1.61 1.21 0.97
100 0.79 58.7 46.9 39.1 33.5 29.3 23.5 19.6 16.8 14.7 13.0 11.7 2.69 1.80 1.35 1.08
115 0.85 63.1 50.5 42.1 36.1 31.6 25.2 21.0 18.0 15.8 14.0 12.6 2.90 1.93 1.45 1.16
15 0.37 27.5 22.0 18.3 15.7 13.7 11.0 9.2 7.8 6.9 6.1 5.5 1.26 0.84 0.63 0.50
30 0.52 38.6 30.9 25.7 22.1 19.3 15.4 12.9 11.0 9.7 8.6 7.7 1.77 1.18 0.89 0.71
40 0.60 44.6 35.6 29.7 25.5 22.3 17.8 14.9 12.7 11.1 9.9 8.9 2.05 1.36 1.02 0.82
60 0.73 54.2 43.4 36.1 31.0 27.1 21.7 18.1 15.5 13.6 12.0 10.8 2.49 1.66 1.24 1.00
80 0.85 63.1 50.5 42.1 36.1 31.6 25.2 21.0 18.0 15.8 14.0 12.6 2.90 1.93 1.45 1.16
100 0.95 70.5 56.4 47.0 40.3 35.3 28.2 23.5 20.2 17.6 15.7 14.1 3.24 2.16 1.62 1.30
115 1.02 75.7 60.6 50.5 43.3 37.9 30.3 25.2 21.6 18.9 16.8 15.1 3.48 2.32 1.74 1.39
15 0.49 36.4 29.1 24.3 20.8 18.2 14.6 12.1 10.4 9.1 8.1 7.3 1.67 1.11 0.84 0.67
30 0.69 51.2 41.0 34.2 29.3 25.6 20.5 17.1 14.6 12.8 11.4 10.2 2.35 1.57 1.18 0.94
40 0.80 59.4 47.5 39.6 33.9 29.7 23.8 19.8 17.0 14.9 13.2 11.9 2.73 1.82 1.36 1.09
60 0.98 72.8 58.2 48.5 41.6 36.4 29.1 24.3 20.8 18.2 16.2 14.6 3.34 2.23 1.67 1.34
80 1.13 83.9 67.1 55.9 47.9 42.0 33.6 28.0 24.0 21.0 18.6 16.8 3.85 2.57 1.93 1.54
100 1.26 93.6 74.8 62.4 53.5 46.8 37.4 31.2 26.7 23.4 20.8 18.7 4.30 2.86 2.15 1.72
115 1.36 101.0 80.8 67.3 57.7 50.5 40.4 33.7 28.9 25.2 22.4 20.2 4.64 3.09 2.32 1.86
15 0.61 45.3 36.2 30.2 25.9 22.6 18.1 15.1 12.9 11.3 10.1 9.1 2.08 1.39 1.04 0.83
30 0.87 64.6 51.7 43.1 36.9 32.3 25.8 21.5 18.5 16.1 14.4 12.9 2.97 1.98 1.48 1.19
40 1.00 74.3 59.4 49.5 42.4 37.1 29.7 24.8 21.2 18.6 16.5 14.9 3.41 2.27 1.71 1.36
60 1.22 90.6 72.5 60.4 51.8 45.3 36.2 30.2 25.9 22.6 20.1 18.1 4.16 2.77 2.08 1.66
80 1.41 104.7 83.8 69.8 59.8 52.3 41.9 34.9 29.9 26.2 23.3 20.9 4.81 3.21 2.40 1.92
100 1.58 117.3 93.9 78.2 67.0 58.7 46.9 39.1 33.5 29.3 26.1 23.5 5.39 3.59 2.69 2.16
115 1.70 126.2 101.0 84.2 72.1 63.1 0.5 42.1 36.1 31.6 28.1 25.2 5.80 3.86 2.90 2.32
15 0.92 68.3 54.6 45.5 39.0 34.2 27.3 22.8 19.5 17.1 15.2 13.7 3.14 2.09 1.57 1.25
30 1.30 96.5 77.2 64.4 55.2 48.3 38.6 32.2 27.6 24.1 21.5 19.3 4.43 2.96 2.22 1.77
40 1.50 111.4 89.1 74.3 63.6 55.7 44.6 37.1 31.8 27.8 24.8 22.3 5.12 3.41 2.56 2.05
60 1.84 136.6 109.3 91.1 78.1 68.3 54.6 45.5 39.0 34.2 30.4 27.3 6.27 4.18 3.14 2.51
80 2.12 157.4 125.9 104.9 89.9 78.7 63.0 52.5 45.0 39.4 35.0 31.5 7.23 4.82 3.61 2.89
100 2.37 176.0 140.8 117.3 100.6 88.0 70.4 58.7 50.3 44.0 39.1 35.2 8.08 5.39 4.04 3.23
115 2.54 188.6 150.9 125.7 107.8 94.3 75.4 62.9 53.9 47.1 41.9 37.7 8.66 5.77 4.33 3.46
Nozzle
Size
Pressure
(PSI)
Flow
Rate
(GPM)
Gallons per Acre
20-inch Nozzle Spacing
GAL/1000 Sq. Ft.
20-inch Nozzle Spacing
MPH
MPH
015
01
015
02
025
03
035
04
05
06
08
010

Page 13
Calibrang the Sprayer
AIXR11002VP Nozzles
Based on the minimum overlap required to obtain
uniform distribuon with 110° ps and 20” spacing.
Suggested Minimum Spray Height: 16”-18” above
what is being sprayed (to plant, not ground).
Opmum Spray Height: 20”
Pressure
(psi)
Capacity
(GPM)
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
8
MPH
15 .18 53.6 26.8 17.8 13.4 10.7 8.9 6.7
20 .21 62.4 31.2 20.8 15.6 12.5 10.4 7.8
30 .26 77.2 38.6 25.8 19.3 15.4 12.9 9.7
40 .30 88.0 44.0 29.8 22.0 17.8 14.9 11.1
15 .18 .61 .41 .31 .24
20 .21 .71 .48 .36 .29
30 .26 .88 .59 .44 .35
40 .30 1.0 .68 .51 .41
Gallons Per
Acre
Based on Water
Gallons Per
1000 Sq. Ft.
Based on Water
AIXR11003VP Spray Tip Rate Chart (20" Spacing)
Based on the minimum overlap required to obtain
uniform distribuon with 110° ps and 20” spacing.
Suggested Minimum Spray Height: 16”-18” above
what is being sprayed (to plant, not ground).
Opmum Spray Height: 20”
• 110° wide, tapered at spray angle with air inducon technology for beer dri management
• Made of 2-piece UHMWPE polymer construcon which provides excellent chemical resistance, including acids, as well as
exceponal wear life
• Compact size to prevent p damage
• Excellent for systemic products and dri management
AIXR11003VP Nozzles
Pressure
(psi)
Capacity
(GPM)
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
8
MPH
15 .12 23.50 11.70 7.80 5.90 4.70 5.9 4.5
20 .14 27.50 13.70 9.10 6.90 5.50 6.9 5.2
30 .17 33.30 16.60 11.10 8.30 6.70 8.4 6.3
40 .20 39.30 19.70 13.10 9.80 7.90 9.9 7.4
15 .12 .54 .27 .18 .13 .11
20 .14 .64 .32 .21 .16 .13
30 .17 .76 .38 .26 .19 .15
40 .20 .90 .45 .30 .22 .18
Gallons Per
Acre
Based on Water
Gallons Per
1000 Sq. Ft.
Based on Water
AIXR11002VP Spray Tip Rate Chart (30" Spacing)
Pressure
(psi)
Capacity
(GPM)
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
8
MPH
10
MPH
15 .15 19 11.1 8.9 7.4 5.6
20 .18 23 13.4 10.7 8.9 6.7
30 .22 28 16.3 13.1 10.9 8.2
40 .25 32 18.6 14.9 12.4 9.3
15 .15 0.51 0.34 0.26 0.20
20 .18 0.61 0.41 0.31 0.24
30 .22 0.75 0.50 0.37 0.30
40 .25 0.85 0.57 0.43 0.34
AIXR110025VP Spray Tip Rate Chart (20" Spacing)
Gallons Per
Acre
Based on Water
Gallons Per
1000 Sq. Ft.
Based on Water
Based on the minimum overlap required to obtain
uniform distribuon with 110° ps and 20” spacing.
Suggested Minimum Spray Height: 16”-18” above
what is being sprayed (to plant, not ground).
Opmum Spray Height: 20”
AIXR110025VP Nozzles

Page 14
Operang Instrucons
Before operang the sprayer, it is important that you read this enre manual and know all the safety precauons. Always take your
me and be alert when operang your sprayer. This will allow you to safely spray without accident or interrupon.
Spraying with the Boom
1. Calibrate the sprayer using the calibraon instrucons and applicaon charts. This will determine what pressure to spray at in
order to achieve the desired Gallons per Acre (GPA).
2. Connect the PTO coupler and torque bar to the tractor.
3. Fill the tank with some water in order to set the pressure and test for leaks.
4. Prepare the sprayer for spraying. Open the ball valve on the sucon line, make sure the boom valves are o and make sure the
spray gun is closed (if applicable).
5. Start the tractor and engage the pump. The tractor should be running at the RPM rate determined when you calibrated your
sprayer. Ensure that the pump is primed and that there are no leaks in any of the lines.
6. Using the relief valve (manual controls), or pressure adjustment switch (electric controls), adjust the sprayers pressure to the
pressure rang found when you calibrated your sprayer. You may need to readjust the pressure when you open the boom
control valves.
7. You may now ll the tank with the amount of water and chemicals recommended by the chemical manufacturer. Before lling
the tank make sure the pump is disengaged.
8. Aer lling the tank, engage the pump and allow an ample amount of me for the jet agitator to mix the water and chemicals.
Note: See chemical instrucons for necessary agitaon me. You are now ready to begin spraying.
9. Upon arriving at the spraying locaon, unfold booms (if applicable), engage pump, open the boom control valves and make
sure the pressure seng is correct. While spraying always remember to maintain constant level of speed and RPM (rates
found when calibrated).
Spraying with the Spray Gun
1. Connect the pump’s PTO coupler and torque bar.
2. Fill the tank with some water in order to set the pressure and test for leaks.
3. Make sure the spray gun is closed and the booms are o.
4. Start the tractor and engage the pump. Ensure that the pump is primed and that there are no leaks in any of the lines.
5. Adjust the sprayer’s pressure using the relief valve to your desired seng. When you open the spray gun, you may need to
readjust the pressure.
6. You may now ll the tank with the amount of water and chemicals recommended by the chemical manufacturer. Before lling
the tank make sure the pump is disengaged.
7. Aer lling the tank, engage the pump and allow an ample amount of me for the jet agitator to mix the water and chemicals.
Note: See chemical instrucons for necessary agitaon me. You are now ready to begin spraying.
8. Upon arriving at the spraying locaon, engage the pump and make sure the pressure seng is correct. Adjust the gun to the
desired spray paern when spraying.

Page 15
Maintenance Instrucons
Roune Maintenance
It is very important to perform roune maintenance on your sprayer before and aer each use. Good maintenance pracces will
help to guard against sprayer breakdowns or accidents.
1. It is recommended to perform a visual and physical inspecon for any worn parts, loose bolts or other visible problems. Make
all necessary repairs before spraying. Please contact an authorized Ag Spray dealer to order parts or to receive technical help.
2. Aer each use, it is important to rinse the sprayer and all components by running a good quality tank cleaner (Tank Neutralizer
and Cleaner) through the system (if no tank cleaner is available, you may substute a good grade of dish soap for this step.
Turn pump on and circulate through the sprayer for 15 minutes and then spray out through boom and handgun nozzles. Rell
sprayer part way with clean fresh water and repeat. Rinsing the sprayer aer use will greatly improve the life of the pump and
other components.
3. Failure to properly rinse the sprayer and all components
aer each use, will void the manufacturer’s warranty.
Note: All rinsates must be sprayed in eld according to
chemical regulaons!
4. The screen of the in-line lter on the sucon line should be
taken out and rinsed. Note: Be careful not to lose the gasket
in the lter bowl. The lter will leak without this gasket.
5. Tip strainer (if applicable), should also be taken out and
rinsed aer each use. Tips strainers are small screens that
are located behind each spray nozzle on the boom.
Pump Maintenance
1. Follow all pump safety precauons and warnings. Following these guidelines will help to ensure many years of smooth and
trouble-free service.
2. Flush the pump, as directed in roune maintenance, aer every use. It is also very important to winterize your pump to pre-
vent freezing and corrosion. Please see Winterizing your Sprayer secon below for instrucons.
3. Aer many years of use, you may nd that your pump is leaking or has experienced a decrease in performance. You may need
to change the seals and rollers. Contact an authorized Ag Spray Dealer for parts and technical support.
Drain the Tank
MC2 Series sprayers are equipped with a drain valve. The valve points towards the back of the sprayer. To drain, close the sucon
valve and open the drain valve.
Winterizing your Sprayer
It is essenal that you winterize your sprayer to avoid damage and to allow for opmal performance. The winterizaon process
should be undertaken before freezing condions and/or aer each season of use. Failure to winterize your sprayer will void the
manufacturer’s warranty.
1. Verify that the tank is empty and rinsed out. Pour 1-2 gallons of RV nontoxic anfreeze into the tank. It is not recommended to
use engine anfreeze. Engine anfreeze can be harmful to humans, animals, crops and the environment.
2. Engage the pump and spray with the boom and spray gun (if applicable). Make sure that the anfreeze has been pumped
through the enre system, including all spray nozzles.
3. See pump manufacturers operators manual for proper winter storage of your sprayer pump.
4. Before spraying in the spring, it is recommended to ush the sprayer with fresh water to cleanse it of the anfreeze and any
other buildup. It would also be benecial to do a thorough inspecon of all sprayer components before spraying.
Cap
Screen
Gasket
Bowl

Page 16
MC2 165 Gallon 3-PT Component Breakdown & Parts List
Not Shown:
EPDM34 11 Ft. 3/4” - 200 PSI EPDM Spray Hose KF1300BLK 4 Ft. 1”-50 PSI Kanaex Sucon Hose
Control Assembly
Detail
Tank Drain w/Strainer
Assembly Detail
MC2-165-3PT-BLU
#5303646-BLU
Drain Valve
Sucon Valve

Page 17
MC2 225 Gallon 3-PT Component Breakdown & Parts List
Control Assembly
Detail
Tank Drain w/Strainer
Assembly Detail
Not Shown:
EPDM34 11 Ft. 3/4” - 200 PSI EPDM Spray Hose KF1300BLK 4 Ft. 1”-50 PSI Kanaex Sucon Hose
MC2-225-3PT-BLU
#5303647-BLU
Drain Valve
Sucon Valve

Page 18
MX4 Series Boom Component Breakdown & Parts List
Typical
Nozzle Assemblies (5282579)
Check Valve Cap: 5046113
Diaphragm: 5063132
See
Detail B
See
Detail B
See Next Page for
Harness Detail
MX408QJ (5303666) 8-Nozzle Boom
MX410QJ (5303667) 10-Nozzle Boom
See
Detail B
See
Detail B
See Next Page for
Harness Detail
See
Detail B
See
Detail B
See Next Page for
Harness Detail
Detail B
Boom Wings
MX412QJ (5303668) 12-Nozzle Boom
LH RH
See Detail C
Typical
Nozzle Connecons
Detail C

Page 19
MX4 Series Boom Component Breakdown & Parts List
MX408QJ (5303666) 8-Nozzle Boom Harness
MX410QJ (5303667) 10-Nozzle Boom Harness
MX412QJ (5303668) 12-Nozzle Boom Harness
Opposite Side
Has Typical
Hose and Nozzle
Conguraon
Nozzle Assemblies (5056125)

Page 20
479 Boom Assembly Component Breakdown & Parts List
See Detail E
479-8-8767
Outer Boom Hinge
479-8 & 479-10
Detail A
See Detail A
See Detail B
See Detail C
See Detail D
See Detail A
See Detail B
See Detail C
See Detail D
See Detail A
See Detail B
See Detail C
See Detail D
See Detail E
479-10-8767
479-6-8767
Detail B
Detail C Detail D
Detail E
