DIVERSITECH FRED CARBO Manual

DIVERSITECH
Operation & Maintenance Manual
FRED CARBO
Visit our Website for more information on this product
www.diversitech.ca
2500 Alphonse Gariepy, Montreal, Quebec H8T 3M2
Tel: [phone] | Fax: [phone] | [email protected]
OMM-FRC-100[E N]
READ AND SAVE THESE INSTRUCTIONS

Table of Contents
SECTION 1 – SAFETY PRECAUTIONS OF FUME & DUST EXTRACTION/COLLECTION ...............................................................3
1.1 Symbols ....................................................................................................................................................3
1.2 User Responsibility .......................................................................................................................................3
1.3 Fume Extraction Hazards ........................................................................................................................3
1.4 Dust Collection Hazards .........................................................................................................................4
1.5 Safety Stickers .......................................................................................................................................4
1.6 Sound Levels .........................................................................................................................................4
SECTION 2 – SPECIFICATIONS ...................................................................................................................................................5
2.1 Diagram & Description .................................................................................................................................................5
2.2 Specifications ........................................................................................................................................................5,6
2.3 Dimensions ..............................................................................................................................................................7
SECTION 3 – SETUP / INSTALLATION ...................................................................................................................................8
3.1 To Setup or Install Safely ..........................................................................................................................................8
3.2 Un-Packaging ...........................................................................................................................................................8
3.3 Principles of Operation .............................................................................................................................................8
3.4 Selecting a Location .................................................................................................................................................8
3.5 Installation ..............................................................................................................................................................9
3.6 Preparing Unit for Operation ...................................................................................................................................10
SECTION 4 – OPERATION ..................................................................................................................................................10
4.1 To Operate Safely ..................................................................................................................................................10
4.2 Controls .................................................................................................................................................................10
4.3 Pre-use Checklist ...................................................................................................................................................10
SECTION 5 – MAINTENANCE & TROUBLESHOOTING ...........................................................................................................11
5.1 To Maintain this Product Safely ..............................................................................................................................11
5.2 Tools Required ......................................................................................................................................................11
5.3 Routine Maintenance Schedule ...............................................................................................................................12
5.4 Troubleshooting Procedure ....................................................................................................................................13
SECTION 6 – DECOMMISSIONING .......................................................................................................................................14
6.1 To Decommission this Product Safely ......................................................................................................................14
6.2 Tools Required ......................................................................................................................................................14
6.3 Conformity with Recycling Regulations .................................................................................................................14
APPENDIX 1A – ELECTRICAL DIAGRAM MANUAL [120 VAC] Single Phase Power ....................................................................15
APPENDIX 1B – ELECTRICAL DIAGRAM MANUAL [230/460/575v] 3-Phase Power ................................................................16
APPENDIX 2 – MAINTENANCE RECORD ..............................................................................................................................17
APPENDIX 3 – SAMPLES SAFETY STICKERS ...........................................................................................................................20
NOTES...............................................................................................................................19,20,21,22,23
Limited Equipment Warranty ...............................................................................................................................Back Cover
Freight Claims .....................................................................................................................................................Back Cover
Return Material Policy ..........................................................................................................................................Back Cover

!
!
!
!
!
3
SECTION 1 - SAFETY PRECAUTIONS OF FUME & DUST EXTRACTION/COLLECTION
This manual contains specific cautionary statements related to worker safety. To
protect yourself and others, read this manual thoroughly and follow as directed
before use. Not all hazards of fume & dust control are listed in this manual, and
no hazards related to welding, cutting, grinding, painting, deburring or other
applications are listed. Consult a qualified safety professional.
READ
BEFORE
USE
Do not use this equipment:
• To collect smoke, fumes, liquid vapors, or aggressive fumes such as acids.
• If the power cord has been damaged or ground (third prong) removed.
• Without the proper water level in the basin.
DO
NOT
USE
1.1 Symbols
This manual uses
several symbols to
highlight specific
hazards. Be familiar
with these symbols
and when you see
them in this manual,
read adjoining
warning text to
avoid the hazard.
1.2 Users Responsability
• Improper use can be hazardous.
• All users must carefully read and understand this instruction manual prior to use
• No objects, such as tools, should be placed on the machine.
• When moving machine, care should be taken to ensure the users feet remain clear of the wheels.
• Machine weights 441-661 lbs. depending on model, proper care should be taken when moving.
• Motor should not contact any objects, and all motor repairs should be performed while the power switch is off and
the power source is disconnected. Operator should not touch motor during use.
• Blower assembly should not contact any objects, and all blower repairs should be performed while the power switch
is off and the power source is disconnected. Operator should not touch blower during use.
• For maintenance of any and all components, power switch must be off and the power source disconnected
• It is your responsibility to follow all applicable ANSI, OSHA, UL, CSA, National & Local Fire Codes, and other
regulatory guidelines covering the safe use of equipment that extracts fumes, collects dusts, and exhausts
filtered air either indoors or outdoors.
• Before use, inspect the unit for damage and verify it is working properly.
• Only qualified persons should install, operate, maintain, or repair this unit.
• Do not modify or repair the unit with parts or accessories not supplied by the manufacturer.
• Consult filter manufacturer’s instructions for filter use and reuse, including instructions for cleaning.
WARNING!
DANGER!
ELECTRIC
SHOCK
MOVING
PARTS
NOISE
HAZARDS
• Breathing smoke, fumes, or dusts produced in applications such as welding, cutting, grinding, painting, deburring
are hazardous to user’s health. Proper ventilation or use of well maintained fume extraction and/or dust collection
equipment helps the user avoid these hazards.
• Breathable contaminants may not be visible or have an odor.
• Stop operation and leave the area immediately if 1) breathing becomes difficult, 2) experience dizziness,
• 3) impaired vision, 4) or eye/nose/mouth irritation.
1.3 Fume Extraction Hazards

4
• Do not use or install equipment where any potential for combustible fumes or dusts are present, until a qualified
person has indicated it is safe to do so.
• Never use or install equipment where the potential for combustible fumes or dusts are present without a
fire/explosion protection system.
• If you are unsure if the product you purchased is correct for your application, call DiversiTech at 1-800-361-3733.
1.4 Dust Collection Hazards
• This machine is equipped with safety stickers to remind operators of the inherent dangers during use and
maintenance.
• The stickers are only reminders, and all safety precautions contained in this manual must be well understood and
adhered to by all users.
• See Appendix 5: Sample Safety Stickers for example of stickers applied to machine.
1.5 Safety Stickers
!
• This machine can emit sound pressure levels in excess of 70dB(A).
• Appropriate ear protection is required when the machine is running.
• Sound levels are highest directly in front of the machine.
• The machine must be turned OFF when performing any maintenance on the machine.
• Extended exposure to sound pressure levels greater than 85dB(A) can cause permanent injury
to the ears.
• Users should be conscious of the danger and refrain from placing the ear near the silencer
outlet.
1.6 Sound Levels

Carbon
Canisters
Intake
Capture
Arm
Blower
Assembly
5
SECTION 2 - SPECIFICATIONS
2.1 Diagram & Description
1. 1.5 HP 120V 1PH AC Blower Assembly,
2. 1200 CFM
3. Choice of 2x50 lbs Carbon canister or 2x75lbs Carbon canister
4. Max operating temperature for the Carbon is 175 degrees Fahrenheit
2.2 Specifications

CONTAMINENT ACCUMULATION
Twist lock Flange.
No tools required.
Parts made of high
impact
resistant polycarbonate.
High quality galvanized
steel.
High capacity prefilter
•20mm thickness
•Low air resistance
•Antibacterial
•High capacity: 670g/M²
•Flame retardant
High porosity virgin
extruded
activated carbon 4 mm.
Specially designed to
remove VOC.
66 mm bed thickness
Convenient elastic
band easing
installation of
media prefilter.
Rubber gasket to
ensure air tight fitting.
Twist lock End Cap.
No tools required.
15.4”
6

2.3 Dimensions
7

3.1 To Setup or Install Safely
!
• Do not place unit near flammables or combustible surface.
• Refer to SECTION 2: Specifications, to know the electrical requirements of the unit you are
installing and ensure adequate input power that is properly sized, rated, and protected.
• This unit must be grounded for safe operation.
3.2 Un-Packaging
3.3 Principles of Operation
8
SECTION 3 - SETUP / INSTALLATION
1. Immediately upon receiving the unit, carefully examine the carton for damage during transit.
2. Use lift forks to move.
3. Remove packing material.
4. Avoid tipping or inverting during handling.
5. The item serial number, model, and electrical ratings are listed on the nameplate. Record this information in
the Maintenance Record provided in APPENDIX 2: Maintenance Record, or your own preventative maintenance system.
This product is designed to capture volatile compounds from certain industrial applications. When operating, air is drawn
into the capture arm, and, into the Carbon Canisters, and then finally exhausted out.
This product consists of four basic components:
1. A structure for housing all components
2. A motor blower assembly
3. Electrical assemblies
4. Carbon Canister(s)
In air pollution control, adsorption is employed to remove volatile organic compounds (VOCs) from low to medium concentration
air streams. Adsorption itself is a phenomenon where air molecules passing through a bed of solid particles are selectively
held there by attractive forces. The Carbo unit uses twin carbon cylinders that contain either 50lbs or 75 lbs each. Air sampling
is recommended to effectively determine when the carbon is saturated. This saturation point will depend on frequency
of use and the concentration of VOC being pulled through the carbon canisters.
The Diversitech Canisters are shipped ready for installation with the activated carbon pre-installed. The Carbo system
should be as close to the emission source as possible.
Once the carbon reaches a certain VOC content, saturation, the unit should be shut down and the canister should be
replaced. The old carbon or canister is then returned to a reclamation center or disposed of following local environmental
laws and guidelines.
When controlling organic compounds, it is recommended that the humidity be maintained below 50%. Higher levels of
humidity will fill the carbon pores and reduce the carbon’s ability to adsorb the emissions.
3.4 Selecting a Location
• Choose a location where the unit will be used, near the operator.
• Choose a location sufficiently close to a grounded power source.

Safety
Filter
9
3.5 Installation
Correct
Rotation
Each machine is wired for correct rotation. Should you need to service the unit’s motor, upon restart, make sure that the
motor is turning in the right direct, as marked on the motor.
If not already installed, install the carbon canisters onto the plenum. The canisters are held in place with a safety bar to
prevent any accidental tipping. Once in place install the safety filter around the canister.

3.6 Preparing Unit for Operation
10
• Before plugging unit in to an input power source, look at the manufacturer’s label located on the exterior of
the unit and ensure the source is correctly sized in terms of Voltage and Amperes.
• Check that the Carbon filter is properly installed.
• Prior to use in your application, turn the unit ON, and perform a function test. To do so:
1. Turn switch to ON position for a few seconds to check that the motor rotation is correct.
2. LOOK: Is the unit level, stable, and that nothing is obstructing the extraction path.
3. Start the unit
4. LISTEN: Does the motor and suction sound smooth and within expected volumes.
5. FEEL: Place your hand on top of the unit and sense for unexpected vibration. Place you hand in front of
the intake hood/surface and sense for expected level(s) of suction.
• Inform all potential users of this equipment where they may find and review this manual.
!
• Read and understand SECTION 1: Safety Precautions and SECTION 4: Operation before use
• Read and understand all Material Safety Data Sheets and Manufacturer’s instructions of all
process materials, consumables, and equipment used in conjunction with this equipment.
• Keep away from all mechanical moving parts including motor, gears, and other pinch points.
• Do not use product without first confirming if a Spark Arrestor is required and installed for
the type of dust, or fumes you are extracting and/or collection. If you are unsure, call a
DiversiTech representative at 1-800-361-3733.
4.1 To Operate Safely
4.2 Controls
• Read and understand SECTION 1: Safety Precautions and ensure SECTION 3: Installation has been followed.
• Before plugging unit in to an input power source, make sure that the capture arm is not interfering with adjacent
equipment or personnel.
• Before collecting fumes, VOC, or other contaminated air, consult your Diversitech representative to make sure that you
have the right carbon canister for the intended use.
4.3 Pre-Use Checklist
SECTION 4 - OPERATION

!
SECTION 5 - MAINTENANCE & TROUBLESHOOTING
5.1 To Maintain this Product Safely
!
!
5.2 Tools Required
!
11
• Read and understand SECTION 1: Safety Precautions and SECTION 4: Operation before
maintenance.
• Do not breathe the dust collected from product while changing/cleaning filters or performing
maintenance on this product.
• Disconnect power before performing any maintenance on unit, including filter inspection. The
input power to this unit is high voltage, and touching any live electrical parts can cause fatal
shocks or severe burns. Do not touch live electrical parts.
• Keep away from all mechanical moving parts including motor, gears, and other pinch points
while operating.
• Operating this unit causes some parts to heat to a point that will burn bare hands. Before
maintenance allow parts to cool, or use proper tools and personal protection equipment during
maintenance.
• Machine must be turned off when performing any maintenance.
• Appropriate ear protection is required according to jurisdiction.
SLUDGE VAC
EYE
PROTECTION RESPIRATOR GLOVES
WASTE
CONTAINER

5.3 Routine Maintenance Schedule
Frecuency Manual Reference
Pre-Use
• Perform pre-use inspection to ensure operating correctly.
Daily Inspection
• Inspect all equipment surfaces for dust buildup, and wipe down as needed.
• Inspect carbon filters for signs of dust buildup, and service as needed.
• Check that the gasket between the housing and the carbon canister is not damaged.
• Turn unit on, and adjust the capture arm distance to the source so as to capture the maximum amount of fumes.
As Required – Replace Filter
1. Replace after-filter media when it appears torn or dirty.
2. Replace Carbon canisters after air sampling or every 6 months depending on usage and concentration of fumes
being collected.
Every (12) months Inspect Basic Components
1. Clean unreadable labels and exterior surfaces.
2. Wash cabinet internal assemblies with warm water mixed with mild detergent (Allow 12 hours to dry before use).
3. Inspect controls for loose wiring.
4. Examine motors for signs of unusual wear.
The manufacturer recommends the following routine maintenance based on light-duty use in normal operating conditions.
Service more frequently if the unit is used in severe conditions.
12

5.4 Troubleshooting Procedure
Motor
Operating
NO INTERMITTENTLY
Perform
Bi Weekly
Maintenance
(Section 5.3)
Turn Unit
On
Motor
Operating
Motor
Operating
Low
Air Flow
Check Input
Power
Air Flow
Restricted
Check Motor Rotation/
Reverse Phase
NO
Air Flow
Restricted
Check Filter Load
Replace if required
Unit Operates
Properly
Call for Service
1(800)361-3733
[email protected]
Call for Service
1(800)361-3733
[email protected]
Call for Service
1(800)361-3733
[email protected]
YES
YES YES
YES
YES
YES
NONO
NO
13

!
SECTION 6 - DECOMMISSIONING
6.1 To Decommission this Product Safely
!
!
6.2 Tools Required
!
• Read and understand SECTION 1: Safety Precautions and SECTION 4: Operation before
maintenance.
• Do not breathe the dust collected from product while changing/cleaning filters or performing
maintenance on this product.
• Disconnect power before performing any maintenance on unit, including filter inspection. The
input power to this unit is high voltage, and touching any live electrical parts can cause fatal
shocks or severe burns. Do not touch live electrical parts.
• Keep away from all mechanical moving parts including motor, gears, and other pinch points
while operating.
• Operating this unit causes some parts to heat to a point that will burn bare hands. Before
maintenance allow parts to cool, or use proper tools and personal protection equipment during
maintenance.
• Machine must be turned off when performing any maintenance.
• Appropriate ear protection is required according to jurisdiction.
6.3 Comformity with Recycling Regulations
14
1. Combination wrench set
2. Socket Wrench set
3. Screwdriver set
These tools above are required for unit dismantling.
• All dismantling procedures should be made in compliance with appropriate laws governing the recycling and
disposal of materials.
• This machine may contain, but is not limited to:
1. Steel
2. Plastic
3. Rubber
4. Electrical Conductors
5. Aluminum
6. Paint
7. Carbon Filter
8. Dust and Debris from use

15
WARNING
Do not route auxiliary contact cable
in the same conduit as motor cable
NOTE
Specic transformer wiring may
differ depending on voltage
conguration.
Units in brackets [ ] refer to imperial
system values
1.5 HP [120v]
TEFC Motor
60 Hz
[120 VAC 60 hz]
Power Supply
Motor
[120v] Single-Phase Power
Disconnect power before performing any maintenance on unit, including filter
inspection. The input power to this unit is high voltage, and touching any live
electrical parts can cause fatal shocks or severe burns. Do not touch live electrical
parts.
APPENDIX 1A - ELECTRICAL DIAGRAM MANUAL
ELECTRIC
SHOCK
HAZARD

16
WARNING
Do not route auxiliary contact cable
in the same conduit as motor cable
NOTE
Specic transformer wiring may
differ depending on voltage
conguration.
Units in brackets [ ] refer to imperial
system values
3HP [230/460/575v]
TEFC Motor
3600 RPM 60 Hz
[230/ 460/575v 60 hz]
Power Supply
Motor
[230/460/575v] 3-Phase Power
Disconnect power before performing any maintenance on unit, including filter
inspection. The input power to this unit is high voltage, and touching any live
electrical parts can cause fatal shocks or severe burns. Do not touch live electrical
parts.
APPENDIX 1B - ELECTRICAL DIAGRAM MANUAL
ELECTRIC
SHOCK
HAZARD

APPENDIX 2 - MAINTENANCE RECORD
17
DiversiTech Inc. authorizes this page to be photocopied or otherwise reproduced as needed for management of
maintenance records.
MANUFACTURER: DIVERSITECH INC. MODEL N° MOBILE CARBON
FILTRATION UNIT
SERIAL N°
SERVICE LOCATION: CONTROL N°
Date Description of Service Serviced By Location Comments
Only use manufacturer approved replacement parts on this unit.

18
APPENDIX 5 - SAMPLE SAFETY STICKERS
The machine is marked with a wet filtration safety sticker to remind the operator of safe working practices:
The machine is marked with safety stickers in appropriate places to remind the operator of safe working practices.

19
NOTES

20
NOTES
