Care and
excellence
Excellence is part of our philosophy:
in planning, technology, design and service.

Smart solutions just for you
Every laundry is different. That is why we have created such an extensive
range of products to ensure that you can choose the machine that meets
your needs.
Hospitality
Pristine linen and the highest standard
of hygiene make all the difference to your
customer’s satisfaction.
Healthcare
The most demanding hygiene standards
in nursing homes and children’s day
nurseries are met with Electrolux washers.
Launderettes
Perfect results wash after wash with
energy-efficient, low-maintenance
machines.
Apartment House Laundries
Ultra-low noise emissions and easy-to-use
machines with excellent washing
performance make the Electrolux
product range the ideal choice for
residential buildings.
Dry Cleaners
The Electrolux Lagoon™ system is the
only wet-cleaning process in the world
for delicate garments approved
by The Woolmark Company.
Commercial Laundries
Commercial laundries need to be
competitive. That is why our large
industrial machines are designed to
deliver you excellent results with high
energy and cost efficiency.
5electrolux washer extractors 5electrolux washer extractors

Performance Time
Performance Time
Economy
Economy

Economy, performance, time:
the perfect balance
With Compass Control®you can choose the program set-up that suits
you best. Finding the perfect balance between low water and energy
consumption, whilst maximising wash results with shorter processing time.
Economy, Performance, Time
All our machines come with the full range of wash cycles and
programs in the Electrolux wash program library.
You choose the configuration of the machine – with all programs
or your desired selection.
Compass Control®
• Compass Control®machines offer wash program libraries
with our “Wash Triangle” technology for general In-house
laundry needs (hospital, boarding schools, marine
installations etc). Configure the machine to suit your needs:
Using “Economy” programs help to reduce your
running costs. Alternatively should your needs change
you can reconfigure your machine from the library using
“Performance” or “Time”
• Compass Control®machines offer wash programs
developed to specifically suit your needs (healthcare,
restaurants, launderettes, leisure, indoor cleaning etc.)
• Assign your most frequently used programs to our
Quick start button function
60°C (140 °F) programs, Compass Control®washer Traditional washer
without pre-wash Economy ** Performance Time
Wash result * 3 43 3 to 5
Rinse result * 4 54 2 to 4
Water consumption - ltr/kg load 7.7 12.6 10 9 to 14
Energy consumption - kWh/kg load 0.06 0.1 0.08 0.17 to 0.22
Program time - minutes 45 54 36 46 - 55
* Wash and rinse result measured on a scale 1 to 5, where “5” is best (The Swedish Consumer Agency standards)
** Economy is default setting. Time and Performance wash programs can be configured on site.
Performance
Economy
Time
7electrolux washer extractors

All round perfection
An insight into the origins of excellence. Whatever your needs, Electrolux
offers a wide range of products offering the perfect solution for you.
The range consists of 4 main categories: H (high spin), X (extra spin),
M (medium spin) and N (normal spin).
Galvanised steel for
maximum rust protection
W465H
New soft-grip door handle.
Slip lock function – durable
in any demanding
environment
SuperBalance™ always
ensures the correct
extraction force with
lower vibration
Easy-to-use
Compass Control®with
large display and
language selection
Greater flexibility in the
choice of detergent: manual
powder, manual liquid and
automatic liquid
Spray lifters speed-up
the soak and wash
process
Large opening for easy
loading/unloading
Embossed perforation
in inner drum and high
grade stainless steel in
drum assembly for long
lasting life
Smooth rounded
top panel makes
cleaning easy
Industrial steel springs and
shock absorbers for reliable
and low-noise operation
Low dB(A)
electrolux washer extractors8

Our heavy-duty washer extractor range includes W4400H, W4600H,
W4850H and W41100H - All specifically designed for commercial laundries
and larger scale In-house laundry installations.
Main features:
• High extraction force for efficient water removal
• Clarus Control®fully programmable microprocessor
• SuperBalance™ that guarantees the correct extraction force
with less vibration
• Frequency controlled motor for flexible drum actions
• Large door opening for easy loading/unloading
• Prepared for 13 liquid detergent supply signals
• 8 liquid supply connections
• Stainless steel front panels
• Direct steam for faster heating process (all)
Options:
• Electrical heating (W4400H and W4600H)
• Forward tilting or forward/backward tilting for easier loading/unloading
• Front-mounted loading hopper for manual operation (W4400H)
• Hands-off system – fully automatic loading/unloading
(W4850 and W41100H)
• Additional noise insulation panels < 70 dB (A)
• Dual drain valves in re-use systems for optimum water savings
The X-range models with solid frame include W4280X, W4350X and
W4600X. Their compact and robust design makes them ideal for In-house
laundries within the hospitality and healthcare markets.
Main features:
• Exacta Control®with fixed wash programs (not for W4600X)
• Clarus Control®fully programmable microprocessor
• SuperBalance™ guarantees the correct extraction force
with lower vibration
• Frequency controlled motor for flexible drum actions
such as extra gentle speed
• Large door opening for easy loading/unloading
• Prepared for manual or automatic detergent supply
• Stainless steel front panel
• Direct steam for faster heating process (all)
Options:
• Electrical heating (W4350X and W4600X)
• Five compartment supply injector (only W4600X)
• Stainless steel side panels
Design type
Range SOFT SOLID
G-force
mount mount
H • 300-425
X • 220-300
M • 140
N • 81
W4400H
W4280X
9electrolux washer extractors 9electrolux washer extractors

Simply great results
Controls are a crucial part of any machine and the extremely easy to use
controls in the Electrolux range of machines ensure that washing
operations are simplified and perfectly smooth.
Clarus Control®
Clarus Control®monitors
all machine functions:
9 standard and 192
customisable programs.
Our Clarus Control®
microprocessor perfectly
combines timing,
optimal water levels and
temperature to ensure
superior performance with
minimum consumption.
Search ease
The ergonomic knob makes
program selection quick
and simple.
Easy reading
Easy to see Icons make
program identification
simple.
Compass Control®
• Multilingual
• Larger display
• Wash Triangle benefits
• Quick start buttons
• Multi-programmable
Compass Control®
Compass Control®gives you enormous flexibility. It is the perfect solution for general needs in Apartment house laundries
and In-house laundries with our Wash Triangle technology. Compass Control®also offers specific tailor-made wash
programs for differing applications, i.e. healthcare, launderettes, indoor cleaning, quick service restaurants, etc.
You can use the memory card to download new programs which have been
created on your PC or transfer programs quickly and easily from one machine
to another. With our “Wash Program Manager” software package you can
easily generate wash programs for Clarus and Compass controls on your PC.
Quick start
Our quick start options allow you
to preset 2 of your most frequently
used programs.
