XPower X-3300 User manual

Models: X-3300, X-3500
AIR SCRUBBER
OWNER’S MANUAL

Introduction .............................................................................................................................. 2
Safety Instructions ................................................................................................................... 3
Operation ................................................................................................................................. 4
Specifications .......................................................................................................................... 5
Parts List ............................................................................................................................. 6~7
4-Stage Filtration Systems ...................................................................................................... 8
Maintenance ....................................................................................................................... 9-14
Cleaning of Washable Nylon Pre-Filters .......................................................................... 10
X-3300 Primary Filter Care .................................................................................. ............ 11
X-3500 Primary Filter Care.......................................................................................... 12-13
Filter Replacement ........................................................................................................... 14
Troubleshooting ..................................................................................................................... 15
Warranty / Service ................................................................................................................. 16
Registration Form .................................................................................................................. 18
Index

XPOWER's unique and highly innovative air scrubber purifying systems create a fresh, clean
environment in even difficult areas such as grooming salons. Both the X-3500 & X-3300 feature
an advanced technology 4 stage filtration system along with a powerful 1/3 HP high capacity
motor for spaces up to 1500 sq. ft. Enjoy breathing healthier with your XPOWER Professional
Air Purification Equipment!
Features:
• 4-stage air filtration system
• Low amp usage with high airflow capacity from 550 CFM
• Variable Speed Control
• Easy cord wrap design
• Convenient filter change (clean) light
• Stackable, compact, and lightweight design
• 2 airflow positions – upright (vertical) or horizontal
• Durable and rugged ABS housing
• 1 year limited warranty
Introducon

WARNING: IMPORTANT SAFETY PRECAUTIONS! PLEASE READ COMPLETELY BEFORE
USING PRODUCT!
When using electrical appliances, basic safety precautions should always be followed to reduce
the risk of fire, electric shock, and personal injury, including but not limited to the following:
1. To prevent electric shock, do not operate the unit in standing water. Never plug in or unplug the unit
with wet hands or while standing in water.
2. To avoid risk of injury, do not direct air flow at face or body.
3. Use only with GFCI protected receptacles. Please contact a qualified electrician for verificaton and /
or installaton of a GFCI receptacle if necessary.
4. Do not operate any unit with a damaged cord or plug. Discard Air Scrubbers or return to an authorized
service facility for examination and/or repair.
5. Air Scrubber is an automatically operated device. To reduce the risk of injury, disconnect from power
supply before servicing.
6. Do not run cord under carpet. Do not cover cord with throw rugs, runners, or similar coverings. Do not
route cord under furniture or appliances. Arrange cord away from trac area and where it will not be
tripped over.
7. Do not allow children to play with or around the Air Scrubbers at any time.
8. Do not move or carry the Air Scrubber while unit is operating.
9. Keep air intakes and exhausts clean at all times. Avoid clogging or blocking to prevent the machine
from overheating. Blocking the air intake could result in a fire or electrical hazards.
10. Always place the Air Scrubber on a smooth and level surface for safe operaton.
11. Unplug the unit before performing any maintenance, cleaning, or servicing.
12. Any misuse or abuse of this product will void the warranty.
Safety Instrucons

In order to remove airborne particles from the surrounding environment, XPOWER Air Scrubbers
are designed to draw air through a series of filters and deliver the purest air. Each filter stage
operates with progressively higher efficiency. The unit removes airborne particles like hair, skin
flakes, visible dust, mold spores, pollen, pet dander and miscellaneous debris.
1. XPOWER Air Scrubbers are shipped ready-to-use. Prior to plugging the unit into the power
source, inspect completely for any shipping damage.
2. Carefully place the Air Scrubber upright on a stable, flat dry surface.
3. Plug the electrical cord into the power outlet.
4. The unit can be used in 2 different angle positions: vertical and horizontal.
5. Turn the control knob to desired speed and make sure the unit operates normally.
6. To reduce the risk of injury, close supervision is necessary when the machine is used near
children. Do not allow children to play with, or around the Air Scrubber at any time.
Operaon
Filter Change (Clean) Light
The Red Filter Change Light will illuminate when
accumulated debris is over-saturated, and filter
needs to be cleaned. If the light is still illuminated
after the filters are cleaned, the filter(s) possibly
need to be replaced.

Air Scrubber Storage
Air Scrubbers can be stacked
(up to 5) on their sides for
storage. Stacking feature is
not secure for transportation.
Specificaons
- 5 -
MODEL NO.
X-3300 X-3500
VOLTAGE / FREQUENCY
POWER
AMPERAGE
RATED AIRFLOW
SPEEDS (RPM)
UNIT WEIGHT
30.5 lbs 32.8 lbs
UNIT DIMENSIONS (L x W x H)
CORD LENGTH
HOUSING
DUCT (AIR OUTLET) SIZES
FILTER SYSTEM
WF35 - 16" x 16" x 1.4" CF35 - 16” x 16” x 1.4”
Washable PET Purifying Filter Activated Carbon Filter
Washable PET Purifying Filter
Washable PET Purifying Filter
WF35 - 16" x 16" x 1.4" HEPA35 - 16” x 16” x 1.4”
HEPA Filter
FILTER CLEAN/CHANGE LIGHT
STACKABLE
SAFETY CERTIFICATIONS
ETL/CETL
4-STAGE
1
ST
STAGE FILTER
2
nd
STAGE FILTER
3
rd
STAGE FILTER
4
th
STAGE FILTER
Up to 5 units high
Washable Outer Nylon Mesh Filter
NFS16 - 16” x 16”
Washable Nylon Mesh Filter
NFR12 - 12” Ø I.D.
115 V / 60 Hz
Variable Speed Control (950 – 2,400 RPM)
ABS
Indicates when the filters to be cleaned or changed
1/3 HP
2.3 Amps (On Highest Speed)
550 CFM
19.6" x 12.3” x 21.6”
13 ft. / 18AWG
5” x 10.8”
Washable PET Purifying Filter
/

** Actual parts are not limited on this list, contact XPOWER for ordering parts.
Item No.
Parts Name
Item No.
Parts Name
1
2
Air Inlet
3
Inlet Panel
4
Latch
5
16”x16” Nylon Mesh Filter
6
Activated Carbon Filter
7
1.4" ThickHEPA Filter
8
9
Front Housing
10
Pressure Switch
11
Fan
12
Motor
13
HEPA Filter Change Light
14
Speed Control Knob
15
Control Panel
16
Potentiometer
17
Air Outlet Grill
Rear Housing
Parts List
Washable outer nylon mesh filter
Washable

56
1011
12
13
9
14
15
16
17

NFR12
12” Ø I.D.
Washable Outer
Nylon Mesh Filter
NFS16
16” x 16”
Washable Inner
Nylon Mesh Filter
CF35
16” x 16” x 1.4”
Activated Carbon Filter
HEPA35
(16” x 16” x 1.4”)
HEPA Filter
4-Stage Filtraon Systems
1st Stage
2nd Stage
4th Stage3rd Stage
X-3300
X-3500
WF35 (Double Layered)
16” x 16” x 1.4”
Washable PET Purifying Filter

1. To keep the Air Scrubber clean, use a damp cloth to wipe the surface of the housing.
2. Never clean the Air Scrubber unit directly with water (see following pages for proper filter cleaning
instructions).
3. When not in use, unplug and store the Air Scrubber in a dry indoor place out of reach of children.
4. Always disconnect the Air Scrubber from its power source before performing any maintenance or
cleaning.
Maintenance
Basic routine maintenance of filters is required to optimize performance of your air scrubber and
extend the life of primary filters.
Both the XPOWER X-3300 and X-3500 filtration system include easy
to clean, washable nylon pre-filters that should be frequently maintained.
Monitor filters and clean or change out once they become loaded with
particles. The air scrubber begins to reduce airflow and increase
pressure drop. Overly loaded filters not only restrict CFM, they can also
result in a loss of filtration efficiency. XPOWER Air Scrubbers include
on-board pressure sensors that automatically alert the Filter Change
(Clean) Light when the filters need cleaning. The filter may needs to be
changed after using for a quite long period.
Important: Filter Maintenance and Replacement
Loaded Filter

- 10 -
NFR12 & NFS16 - Outer and Inner Nylon Mesh Filters are washable. These Pre-filters will protect
the inner filters from larger particles and therefore extend the life and usage of the primary 3rd & 4th
Stage filters. Always make sure the Air Scrubber is turned off before removing filters. Before cleaning,
remove all debris from both the inner and outer nylon mesh filters, then, rinse with water and lay flat on
a clean and dry surface to dry completely before re-installing. The NFR12 and NFS16 filters are used
for X-3300 and X-3500 air scubbers as first two stages. Both filters needs to be cleaned frequently,
especially for the Outer Nylon Mesh Filter NFR12.
Cleaning of Washable Nylon Pre-Filters
Fig. 1
Turn off the machine
before cleaning the
mesh filter
Fig. 3
Let filter dry on
a clean and flat
surface
Fig. 4
Re-install the clean,
dry filter
Fig. 2
Remove particles
before rinsing with
water

- 11 -
WF35 – Two layers of washable PET Purifying Filters are featured with the X-3300 Air Scubber.
These filters trap smaller contaminants to alleviate allergies and other common respiratory problems.
The Primary WF35 filters require a simple maintenance routine for effective performance.The Filter
Change Light will light up when filters need attention. Always make sure that the Air Scrubber is turned
off before removing filters.
Cleaning X-3300 PET Purifying Filters (WF35):
1. Remove filters and lay them on a flat clean surface
2. Use a vacuum or clean cloth to remove loose debris
3. Rinse thoroughly with water
4. Lay on a flat surface on top of a clean cloth to completely dry before reinstalling
X-3300 Primary Filter Care
ATTN: ONLY the X-3300 Features
4 Washable Filter Stages. DO NOT
WET X-3500 Model primary Filters
(Carbon CF35 & HEPA35)

- 12 -
CF35 - Activated Carbon Filters are used to remove contaminants and impurities through the process
of chemical absorption. The CF35 captures a wide variety of volatile organic compounds that includes
smoke, food odors, fumes from paint and paint thinners, sewer odors and more. Carbon Filters can be
reused if the adsorbed substances are removed. This process is known as 'regeneration'. Simply
heating the spent carbon at a given temperature for an adequate length of time can regenerate activated
carbon to the point where it can be reused. The CF35 fits the X-3500 model; it is placed inside the
housing in front of the HEPA filter. Always make sure that the Air Scrubber is turned off when removing
the carbon filter. Never use water to clean the CF35 filters. Use vacuum or clean cloth and lay it flat on
a clean and dry surface. For best results, put the CF35 under the sun and leave it there for a couple of
hours. The capacity of the carbon filter will vary widely depending on conditions, but it should be replaced
when a decline of effectiveness is noted.
X-3500 Primary Filter Care

- 13 -
HEPA35 – HIGH EFFICIENCY PARTICULATE AIR FILTER, also known as HEPA filter, ensures
superior air quality inside our homes and protects us from a wide range of health risks associated with
indoor air pollution. the filter is designed and implemented to trap even the tiniest contaminants
(approximately 99.97% of all particles measuring 0.3 microns) that aren’t usually captured by traditional
air filters, in order to prevent allergies and other common respiratory problems. The HEPA filter requires a
simple maintenance routine, which can be performed in a timely and cost-effective manner. To maximize
HEPA filter life, be sure to clean/change the pre-filters regularly. The Filter Change Light will light up when
filters need attention. Always make sure that the Air Scrubber is turned off before removing the HEPA
filter. Never use water to clean the HEPA filter. Use vacuum or clean cloth and lay it flat on a clean, dry
surface. When putting the HEPA filter back into the machine, make sure the side with the gasket is facing
the motor housing to prevent air leakage.
X-3500 Primary Filter Care (cont’d)

Always wear a respirator and personal protective gear when removing or replacing filters. Lay
the Air Scrubber flat, unlock top latch of the housing, open the inlet panel and remove filters.
- 14 -
Precautionary Measure When Cleaning and Changing Filters
An air scrubber captures particles that can be hazardous to human health.
During the process of changing filters, decontamination, or performing
maintenance, large concentrations of captured particles can become
airborne in the immediate area. For these reasons, air scrubber operators
should wear appropriate personal protection equipment (PPE) when
performing any type of service on an air scrubber. A NIOSH-approved
respirator is always essential for these tasks. If you’ve used the air scrubber
for mold remediation or in another environment with known contaminants,
you should also consider wearing gloves, eye protection and coverall NIOSH-Approved
Respirator Mask
The particles captured by a filter can cause adverse human health effects once they are released into
the air. For this reason, you should dispose of used filters with care. You should place used filters in a
plastic bag and seal the top before disposing. Always follow local regulations before disposing.
Disposal of Filters
The filters may need to be changed after certain period of time depending on your usage and the life of
each type of filters.
All filter accessories are available for purchase directly from XPOWER's headquarters in California.
Please call our Customer Service at [phone] or email us at [email protected].
Filter Replacement

SYMPTOM POSSIBLE CAUSE ACTION
Motor not
running
Switched off
Make sure unit is plugged in and switch is turned to
ON mode
Power failure Checkoutlet/change to another outlet
Wiring failure Contact XPOWER for service/repair.
Scraping noise
from fan
Obstruction at the intake or exhaust of fan Remove obstruction
Fan broken Contact XPOWER for service/repair
Weakair flow Obstructed vents and/or filters Clean out vents/inlets/filters
Change light
illuminated
Insufficient airflow caused by clogged filters
Replace the filters
Troubleshoong
- 15 -

XPOWER Limited Warranty (USA)
XPOWER’s Limited Warranty covers the unit (excludes POWER CORD & FILTERS) from defects
in material and crasmanship. The Warranty covers normal use for a term of one year from
the original date of purchase including parts, labor, and one way shipping. Non-conguous
states must pay for roundtrip freight. A purchase receipt must be provided.
Important!
This warranty does not cover or apply to defects due directly or indirectly to misuse, abuse,
disassembly, alteraon, corrosive chemicals, improper voltage, fire, flood, negligence,
accident, improperly or incorrectly performed maintenance or repair, or failure to perform
necessary maintenance or repair, or if the use of this product is not in compliance with the
instrucons and specificaons for its use
For Warranty service and parts replacement (US customer only), you must:
A. Call 1-855-855-8868 for a RMA (Return-Merchandise-Authorizaon) number.
B. Have original proof of purchase.
C. Use the original undamaged packaging or an industrial cerfied packaging method.
End user will be responsible for shipping the unit (with RMA Number showing on the
shipping label) to the XPOWER Service Department. XPOWER will inspect, assess and advise
the repairs needed and the applicable cost, if any.
For users outside the US, please contact an XPOWER Distributor in your country or region for
Warranty service and parts replacement.
Service
- 16 -

XPOWER Pet Products for Professional Grooming Industry
Force Dryers
B-3 (2 HP / 8 Amps / 130 CFM) - with vacuuming feature
Stand Dryers
B-16 (1/4 HP / 12 Amps / 300 CFM)
B-18 (1/3 HP / 18 Amps / 380 CFM)
Cage Dryers
X-430TF w/ 430MDK (1/3 HP / 3.8 Amps / 2000 CFM)
X-800TF w/ 800MDK (3/4 HP / 7.5 Amps / 3200 CFM)
B-4 (3 HP / 10 Amps / 150 CFM) -with vacuuming feature
B-8 (4 HP / 12 Amps / 150 CFM) - brushless DC motor with heater
B-25 (4 HP / 12 Amps / 160 CFM) - double motor
B-24 (3 HP / 12 Amps / 150 CFM) - with heater
B-27 (6 HP / 19 Amps / 180 CFM) - double motor
Air Purificaon:
APDS-1 - Air Purificaon & Drying System
X-3300 / X-3500 - Air Scrubbers

For your product warranty, please complete and mail / fax this form to XPOWER MANUFACTURE, INC.
Address: 220 Clary Ave., San Gabriel, CA 91776. Tel: [phone] Fax: [phone]
Warranty Registration
Company Name / Contact Person / Title
State / Province Zip Country
(for US customer only)
(For your convenience, register your product online at xpower.ws)
