SF-LM17 MOVING HEAD LIGHT
90W-120w LED
USER MANUAL
1
/
8

Congratulations on purchasing this 120W LED moving head
Thank you for extending your trust in our technology!
For reasons of safety and approval(CE) the personal reconstruction and/or modification of this
product is prohibited.Please observe that damage caused by modifications performed manually to
this device is not covered by the warranty.
This product leaves our works in a perfect condition.Please observe all notes in these operating
instructions to warrant this condition and the safe operation of hte product!
Any damage caused as a result of the non-compliance with these operating instructions leads to
the expiration of any warranty claim.The manufacturer does not accept liability for any damage to
property or for personal injury resulting from the improper handling of the product,or
non-observance of the operating instructions.
Store these operating instructions in a safe place for later reference and pass them to any new
holder when selling or lending or leaving this device in the hands of any other party.
Application According to Purpose
This product is a lighting effect which creates specila light effects with one lamp.Togenerate these
effects,the product must be connected to mains and a DMX-512 compatible controller.
This product is designed for AC100~230V/50~60Hz operation and exclusively for indoor use.
If used for any purpose other than described in these operating instructions,the device may suffer
damage and the warranty expires.Also,any other use is linked with risks such as short
circuits,fire,electrical shock,etc.
The manufacturer's serial number must never be removed as otherwise the warranty expires.
Notes on safety
1. Before Operation
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
Prior to the initial operation of this produc,please do the followings
-Read these operating instructions with great care;
-Study and observe all instructions carefully;
-Ensure that everybody and anybody involved in the installation,operation,transport and storage
of this product is suitably qualified;
-Verify whether any visible damage was caused during transport.lf thepower cord.housing or the
light are damaged,do not operate the device;contact your specialized dealer immediately.
2. Supply Voltage,Mains Cord and Connection to Mains
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
The handling of supply voltage,mains cords and connections to mains calls for particular care
considering the riskfrom a life-threatening electric shock,the risk of fire and the risk of short circuitsl
please observe the following notes in particular:
Products operating on supply voltage should be kept out of the reach of children.Therefore ensure
the permanent supervision if children are in the immediate vicinity of the product!
For commercial facilities the regulations on the prevention of accidents of the respective trade
association must be observed.The operation of this equipment at schools,training facilities,and
hobbyorself-help workshops must be supervised responsibly by trained personnel.
Check the product regularly for any damage to the malns cord! Should you discover any damage
to the malns cord, do not operate or disconnect this product! Secure the product against accidental
operation and contact your specialized dealert.
Always separate the product from mains by holding the mains plug by the handling surface .Never
disconnect by holding the line cord ! Be sure to connect the product exclusively to
2
/
8

AC100~230V/50~60Hz!
Always onsure during installation,operation, transport and when storing the product that the mains
cord is not exposed to possible mechanical damage, or damage caused by humidity,flulds,heat or
cold!
The products cable entry must not be exposed to stress from pull! Create the mains connection
once the product has been installed only .Always connect the mains plug last !
The producct must only be connected to a proper outlet of the public supply grid .Connect the
mains cord to suitable outlets only ! Use entensions cords in compliance with specifications only!
Do not allow the mains cord to come into contact with other cords!
Ensure during instaltation ,operation,transport and storage that none of the cables are freely
exsposed!
Never touch the mains cord ,mains plug and outlet with wet or damp hands !
When not using the product, and prfor to cleaning always disconnect the product from mains! To
do so, hold the mains plug by the handling surface and never pull the mains cord!
Never connect the device to dimmer packe!
3. Housing
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
Always ansure during installation,operation,transport and when storing the product that no shocks
or other forces impact the housing !
The housing must not touch onto any other devices or objects during operation!
Easily flammable materials,e.g. decoration material and other surfaces and objects,must maintain
a minimum distance of 3m to the housing !Walls must maintain a minimum distance of 50cm to the
housing!The device must be installed on a fireproof surface only (no carpet)1 Always ensure
aproper circulation of air.
Do not touch the housing during operation it will heat up .The housing is safe to touch approx .5
minutes following the end of operation!
The device must never be carried via the projector anns.Use the carring handles only !
Fluids must not enter the housing as this could reduce the protective insulation and may trigger
short cirouits which may lead to fatal electrio shocks !If flulds have entered, disconnect the mains
plug immediately and secure the product against unintentional operation and contact yours
specialized dealer! Damage caused as a resuit of fluids entering the housing is exempt from
warranty .
No metal parts or other items must enter the housing as this may reduce the protective insulation
or trigger short circuits which may lead to fatal electric shocks !If metal parts or other items have
entered ,disconnect the mains plug immediately,secure the product against unintentional operation
and contact your specialized dealer!Damage caused by metal parts or other items in the housing is
exempt fromwarrantly.
4. Operating Environment
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
The product must be operated and stored in a dry environment only !Splash
water ,rain,humidlty,fog may reduce the protective insulation which may lead to fatal electric
shocks!The limlt value for relactive humldity is 50% at 45.A minimum distance of 1.5m to a fog
machine must be observed ;fog saturation in the room must not reduce the vislbllity to below 10m .
The product must be operated at a temperature range of between -5 and 45 only.Protect the
product against direct exposure to sulight or other heat,such as from rediators! If the produc is
taken from a cold environment into a warm environment it must only be taken into operation once it
has reached ambient temperature,since the condensation created by the difference in temperature
3
/
8

may destroy the device!
Protect the product against dus!Dust may reduce the protective insulation,which may cause fatal
electric shocks!
The product must be operated at altitudes ranging beween 20m below and 3000m above sea level
only!
The product must not be operated during thunder storms;risk of destruction from surge voltages!
The product must be operated at a minimum distance of 0.5m to lit objects only!
5. Installation
ATTENTION：
RISK OF SHORT CIRCUIT！
A
TTENTION：
RISK OF SHORT CIRCUIT！
This product can be operated suspended or as stand-alone system.
Should your lighting effect show any signs of damage,do not install the device!In this case,have
your lighting effect repaired by your specialized dealer.The manufacturer does not accept
responsibility or liability for damage to property or personal injury resulting from an improperly
installation!
As a stand-alone system the device must be installed vertically on an absolute
planar,firm,fireproof,shock-
and vibration-free surface.The installation of this lighting effect must be carried out by trained and
professional staff!The installation of this lighting must only be carried out with the appropriate
materials!
The suspended installation of this lighting effect necessitates a suitable suspension system!The
lighting effect must never be fixed swinging freely in the room.No individuals should linger
underneath the lighting effect during suspended installation!
It is a must to install this device with a second independent fixture.Such second fixture must
guarantee in the event of failure of the main fixture that no assembly parts will fall down.Use the
fixture on the undersurface only.
The light effect unit must be attached via two certified hooks and omega bracket to a tie-bar
system.Use the screw threads on the undersurface only.
It must be ensured that an expert inspects the mechanical and safety-relevant installation prior to
the initial operation and following major modifications,prior to the renewed operation.It must be
ensured that an expert inspects the mechanical and safety-relevant installation at least once a
year.It must be ensured that an expert inspects the mechanical installation and the installation of
relevance to safety within the framework of an acceptance test at least every four years.
The installation fixture must be as such that it can withstand for a period of 60minutes 10 times the
load capacity without harmful deformation.
It is prohibited for any individual to unnecessarily stay or pass beneath the installation during any
type of assembly work.
The light effect unit must be secured by a safety arrester cable if fly-mounted.The cable must
withstand 12 times the weigh of the light effect unit Use arrester cables equipped with quick closing
links.The dropping distance must not exceed 20 cm.Defect arrester cables or arrester cables that
have already been exposed to stress must not be used.
6. Operation
Controls
Link all DMX devices with a DMX-512 controller by using a standard,3-pin DMX cable.Connect the
output of the first device with the input of the second device and the output of the second device
with the input of the third device and so on.
Connect the mains plug to an outlet.
4
/
8

Operating the product for the first time may generate smoke and odour,this is not a defect.Avoid
dis/connecting the product repeatedly and quickly from/with mains!Always wait 15 minutes prior to
the next dis/connection!
The device starts not until a self-testing and starting time.If the moving head is ready to start,push
and roll the function wheel.The LCD display shows the options,as below:
7. Lamps
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
During operation,the lamps will reach temperatures of up to 600OC.Touching the lamps may cause
serious burns!Objects coming into contact with the lamps during and shortly after opration may
catch fire!
Disconnect the product from mains prior to installing or before changing a lamp!Allow a lamp to
cool for approx.15minutes before exchanging it!
Never touch a lamp with bare hands!If damaged or deformed,a lamp must be exchanged!
When exchanging the lamp be sure to use suitable lamps only.Lamps with greater performance
generate excessive heat for the product;risk of fire!Damage resulting from the use of an unsuitable
lamp is exempt from warranty!
Never connect the lighting effect to the mains prior with opened housing.
8. Fuse
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
Disconnect the product from the mains prior before changing a fuse.
Only replace the fuse by a fuse of same type and rating! An incorrect fuse could damage of
destruct the lighting effect.
Replace a fuse by levering the fuse holder cover with an appropriate screwdriver.Remove the old
fuse and place the fuse inside the holder.Replace the fuse holder and insert it.
Never connect the lighting effect to the mains prior with opened housing.
9. Cleaning
ATTENTION：
DANGER OF LIFE！RISKOF FIRE！
RISK OF SHORT CIRCUIT！
The product must be freed regularly from dust,other deposits and contamination as this may
reduce the protective insulation,which may lead to a fatal electric shock!
Before cleaning,always disconnect the product from mains!
This product should be cleaned with a moist cloth only;never use aggressive cleaning
agents,solvents or benzine for cleaning.
Ensure that the product is completely dry before operating it again again after cleaning!
ATTENTION：
FRAGILE!
To avoid damage caused during transport,wrap the product in its original packaging only and
handle it with great care during transport!
10. Menu settings
1. Version: brand,model,version,number,lamp use time
2. Address: Set DMX address
3. Pan reverse: On (reversed) Off (normal)
5
/
8

4. Tilt reverse: On (reversed) Off (normal)
5. Pan/Tilt speed: from 01-16, to set the speed for Pan/Tilt movement
6. Pan/Tilt mode: 8bit, 16bit, when set as 8bit, the channels Pan fine and Tilt fine will be disabled,
the fixture has 15 channels now.
7. Lamp mode: On (lamp on); Off (lamp off)
8. Reset: lighting reset; time restore (can be set password afterwards to prevent unwanted
modifying); Motor restore (can be set password afterwards to prevent unwanted modifying);
exit.
9. Channel data: 01:Shutter; 02:Dimmer; 03:Lamp/reset; 04:Pan/tilt speed; 05:Pan; 06:Tilt;
07:Pan fine; 08:Tilt fine; 09:Color wheel; 10: gobo 1; 11:gobo 1 rotation; 12: gobo 2; 13:gobo 2
rotation; 14:Prism/macros; 15:Prism rotation; 16: Zoom; 17:Focus; 18:Focus fine; 19:Exit.
When connected with a DMX controller, the channel value can not be changed, only show
channel DMX value. While there is no DMX controllers, you can control the fixture by this item,
select some channel, roll the encoder wheel to adjust DMX value,
10. Display: language(English Chinese or some other language according to your requirement );
Backlight time: open(always on ), 30 seconds; Back-brightness: 1-4, from dark to bright; exit.
11. Motor adjust: 01:Pan; 02:Tilt; 03:Color; 04: gobo 1; 05:Gobo 1 rotation; 06: gobo 2; 07:Gobo 2
rotation; 08:Prism; 09:Prism rotation; 10: Zoom; 11:Focus; 12:Motor zero(can be set password
afterwards to prevent unwanted modifying); 13:Save (can be set password afterwards to
prevent unwanted modifying); 14: Exit.
12. Control: Control select(DMX, master, music, prog, these function have not been finished now,
they would be finished afterward according to your suggestion); auto run program(select the
program you want to run in certain mode); auto run speed (set running speed for program).
13. Help info: include copyright, company information, etc.
14. Exit
11. DMX PROTOCOL
Channel
16
Bit 8 Bit Function DMX
value
Feature Note
000-009 Full off
010-049 Full on
050-089 Strobe from slow to fast
090-129 Pulse effect opening,increasing
130-169 Pulse effect closing,increasing
170-209 Random strobe with decreasing speed
1 1 Strobe
210-255 Full on
2 Dimmer 000-255 Dimming from 0-100%
000-009 No function
010-019 Shutter off when pan and tilt movement
020-029 Shuttter off when changing color
030-039 Shutter off when changing gobo
040-049 No function
050-059 Shutter off when pan and titt movement and color changing
060-069 Shutter off when pan and titt movement and gobo changing
3 3
070-079 Shutter off when pan and titt movement changing
6
/
8

080-089 Shutter off when changing color or gobo
090-099 Shutter off when pan and titt movement and color and gobo
changing
100-109 Shutter off when pan and tilt moverment and gobo changing
110-119 Shutter off when pan and titt movement and color and gobo
changing
120-239 No function
240-249 Reset after 3s
Reset
/Shutter off
250-255 No function
4 4 Pan/tilt
speed 000-255 Pan/Tilt speed adjustment from fast to slow
5 5 Pan 000-255 0-540°pan movement
6 6 Tilt 000-255 0-280°tilt movement
7 Pan fine 000-255 16 bit pan movement
8 Tilt fine 000-255 16 bit tilt movement
000-009 White
010-019 Color1
020-029 Color2
030-039 Color3
040-049 Color4
050-059 Color5
060-069 Color6
070-079 Color7
080-199 1*7color mixing
200-229 Color wheel CCW rotation from slow to fast,Rainbow effect
9 7 Color
wheel
230-255 Color wheel CW rotation from slow to fast,Rainbow effect
000-009 White
010-019 Gobo1
020-029 Gobo2
030-039 Gobo3
040-049 Gobo4
050-059 Gobo5
060-069 Gobo6
070-079 Gobo7
080-099 Gobo7 shaking from slow to fast
100-119 Gobo6 shaking from slow to fast
120-139 Gobo5 shaking from slow to fast
140-159 Gobo4 shaking from slow to fast
160-179 Gobo3 shaking from slow to fast
180-199 Gobo2 shaking from slow to fast
200-219 Gobo1 shaking from slow to fast
220-239 White shaking from slow to fast
10 8
Gobo
wheel 1
240-255 Gobo wheel CCW flowing withIncreasing speed
000-169 Forwards gobo rotation with your pushing of fader
170-199 Gobo shaking,increasing in amplitudeAnd speed
200-229 Backwards gobo rotation with decreasing speed
230-255 Forwards gobo rotation with decreasing speed
179-199 White shaking from slow to fast
200-229 Gobo wheel CCW flowing withIncreasing speed
11 9 Gobo wheel 2
rotation
230-255 Gobo wheel CW flowing with Increasing speed
000-009 White
010-019 Gobo1
020-029 Gobo2
030-039 Gobo3
040-049 Gobo4
050-059 Gobo5
060-069 Gobo6
12 10 Gobo
wheel 2
070-089 Gobo6 shaking from slow to fast
7
/
8

8
/
8
090-109 Gobo5 shaking from slow to fast
110-129 Gobo4 shaking from slow to fast
130-149 Gobo3 shaking from slow to fast
150-169 Gobo2 shaking from slow to fast
170-189 Gobo1 shaking from slow to fast
190-209 White shaking from slow to fast
210-229 Gobo wheel CCW flowing withIncreasing speed
230-255 Gobo wheel CW flowing withIncreasing speed
000-169 Forwards gobo rotation with your pushing of fader
170-199 Gobo shaking,increasing in amplitudeAnd speed
200-229 Backwards gobo rotation with decreasing speed
230-255 Forwards gobo rotation with decreasing speed
179-199 White shaking from slow to fast
200-229 Gobo wheel CCW flowing withIncreasing speed
13 11
Gobo
wheel 2
rotation
230-255 Gobo wheel CW flowing with Increasing speed
000-009 No function
010-079 Prism
14 12
Prism and
gobo
Macros
effect 080-255 Prism and gobo macros effect
000-169 Prism rotation with your pushing of fader
170-199 Prism shaking,increasing in amplitude And speed
200-229 Backwards prism rotation with decreasing speed
15 13
Prism
rotation
And
amplitude
adjustment
230-255 Forwards prism rotation with decreasing speed
000-049 No function
16 14 Zoom 050-255 Zoom
17 15 Focus 000-255 adjustment from far to near
18 Focus Fine 000-255 Fous Fine
12. Technical Information
Voltage: AV100~240V/50~60Hz Net Weight: 15Kg
Lamp: 13.1V/7.5A/100~120W LED(America) Gross Weight: 17Kg
Total Power: 190W Size(Max): 380 x 320 x 630mm
Fuse: .5A/250V Packing Size: 490 x 450 x 700mm1
DMX Channel: 18/15 DMX512 channel Step Motor: 11 PCS
Please note: All Information is subject to change without prior notice.
