Squareled Hi-Precision 300W LED Profiler MK2 fixed User manual

SquareLED - Hi-Precision 300W LED Proler MK2 xed Focus

Manual | Hi-Precision 300W LED Proler MK2 xed
1. TECHNICAL PARAMETERS
1.1 Electrical Parameters
Input Voltage: 100-240AC 50/60HZ
Power Consumption: 320W
Control Signal: DMX512
Control Channel: 3 channels
DMX input/output interface: XLR 3/5PIN
Power port: Aviation head
Ethernet interface: Optional
Display window: 2.4inch colorfullLCD display
1.2 Mechanical and physical parameters
Light source: 300W COB Light
Color(Light source): White
Color Temperature: 3200K/ 5600K
Color Rendering Index: ≥90
Beam Angle: 5°, 10°, 14°, 19°, 26°, 36°, 50°optional
Luminum: 13000LM
Dimmer: 0-100%
Strobe: 0-20Hz
1.3 3Mechanical and physical parameters
Case Material: Die-casting aluminum/aluminum/Plastic
Protection Grade: IP22
Working Temperature: -20~40°C
Noise: 36db
Net Weight: 11.5 KG
Dimmension: 1187*361*560mm (5°)
887*296*525mm (10°)
837*285*525mm (14°)
768*285*525mm (19°, 26°, 36°, 50°)

Manual | Hi-Precision 300W LED Proler MK2 xed
2. Illumination Chart
2.1 5600K Illumination

Manual | Hi-Precision 300W LED Proler MK2 xed
2.1 5600K Illumination
3. Safety Warning
Notice:
• Professional technical people required to install and maintain this equipment.
• This equipment has passed strict inspection before delivery.
• Users have to obey the safety and notice guide.
• The manufacturer will not responsible for any not according to the instruction normal
operation and without permission
• Since the change of equipment and damages caused by any accident.

Manual | Hi-Precision 300W LED Proler MK2 xed
Important Notice:
• Make sure the power supply within the standard data range
• he xture’s power supply connection line can not connectto any other xtures.
• The xture’s DMX512 signal line can not connect to any other DMX512 signal line.
• Make sure the xture is appropriately earthed before use this xture safely.
• Yellow-green line is earthed line, select the eligible power socket to make sure the safety and ope-
ration; Or cut o the plug and connect the switch directly.
• To avoid the hard collision when installation, using or moving the xture.
4. Installation
4.1 Installation and Method
Horizontal place: Hanging handle can adjust Angle , in order to install the right lamp bracket , as shown
in the gure below.
Hanging place: Notice: ensure the installation position is completely suitable for this product ,to ensure
safe and reliable installation location.
• Use and install the equipment , must be far away from ammable items, to ensure to keep a
distance of 0.3 meters and ammable materials .
• Use the right tools to x the lighting equipment in the proper installation location;
• Device of install lamps must be able to withstand the weight of more than ten times of lamps itself,
and ensure the suspension location with no obvious deformation within an hour;
• Use rope to hang the lamps , the rope used must be able to sustain the weight of more than ten
times of lamps itself. And insure rope must with safety clasp . Approach is to build the insurance
rope around xtures are handle or other xed objects , after the insurance rope end plug tight
buckle and the screw , as shown in the gure below.

Manual | Hi-Precision 300W LED Proler MK2 xed
Horizontal place: Lens cone install as shown in the gure below.
1. Arrow and knob aligned in a straight line
Arrow and knob aligned in a straight line
2. Put lens cone to the box and rotate clockwise
3. Clockwise to stop after the knob on the lens cone and keep in the same line,
and makes the knob body fasten.
4.2 Power connection
• Power cable use 2.5 mm2 copper core.Power in series, the 220V AC power is no more than
8 lamp, Using a 110V AC power can’t more than 4 lamps;
• DMX512 signal cable connect 20pcs xtures Max;When the distance between console and
xture, or distance between two xtures, longer than 50M then add a signal amplier is very
necessary.
• Recommend to plug a terminal in signal output socket of the last xture, which connected in
the end of each signal transmission line. To weld a 120Ω / 1W resistor between the male plug
2 and 3 feet to make a terminal plug. The usage is to reduce the reected wave interference
caused by the end of control signal cable‘s circuit open.

Manual | Hi-Precision 300W LED Proler MK2 xed
4.3 DMX512 Console Connect
• Serial connect the DMX512console and signal cable.
• DMX512address code is reusable.
• DMX512 address code can be any number between 001 to 512.
5. Operation
5.1 Display Window
Dot icon for DMX signal instructions ,do not display when no signal

Manual | Hi-Precision 300W LED Proler MK2 xed
5.2 MENU
• ENTER: Function to the next level submenu and save or conrmation settedfuction data
• UP: Select function sub menu,up cycle adjustment data
• DOWN: Choose function submenu,circulate down to adjust the data values
• MENU: Return to a layer on the menu, or switch to the main menu

Manual | Hi-Precision 300W LED Proler MK2 xed
5.3 Manual Setup-STAT
• Press [ENTER] in menu to static setting
• Press [UP]/[DOWN] or Rolling hand wheel to choose [DIM], [STROBE]
• Press [ENTER] to edit state, Press [UP]/[DOWN] or Rolling hand wheel to set, [DIM] setting data is
0~255, [STROBE] setting data is 0~20Hz
• Press [ESC] or [RETURN] to back to main menu and save automatically
5.4 DMX512Address code setting ADDR
• Press [UP]/[DOWN] or Rolling hand wheel to [ADDR]
• Press [ENTER] to edit state, Press [UP]/[DOWN] to choose the address code between 001 to 512
• Press [ESC] or [ENTER] to back to main menu

Manual | Hi-Precision 300W LED Proler MK2 xed
5.5 Light SET
• Press[ENTER] in menu [SETTING] to Light set operation
• Press [UP]/[DOWN] to choose setting Manuel
• Press[ENTER] in menu [MODE] to [DMX] for signal choose mode
• Press[DIMMING] to setting mode for linear
6. DMX512 Console channel chart
Channel No Channel value Command function
10~255 White 0~100% dimming
20~5 No function
6-255 0~20Hz Strobe
3
0~10 Internally dimming speed
11~40 Linear dimming speed4
41~70 Linear dimming speed3
71~110 Linear dimming speed2
111~140 Linear dimming speed1
141~170 Turn-o linear dimming
171~255 No function

Manual | Hi-Precision 300W LED Proler MK2 xed
