DJG Complete Voyager User manual

22
Fill Out For Credit Card
Visa Mastercard
Card Exp. Date:______________________________
Cardholder’s Name:__________________________
Card Number: ______________________________
Signature____________________________________
Read all instructions
BEFORE USING
this child restraint.
KEEP INSTRUCTIONS FOR FUTURE USE.
Para recibir las instrucciones en español,llame al
1-800-544-1108 o solicitarse por escrito al dirección por arriba.
Weight:
40-80 pounds
(18.1-36.3 kg)
Height:
43-52 inches
(110.1-132.1 cm)
This child
restraint is
designed for
use by children
whose:
www.djgusa.com
CCoommpplleetteeVVooyyaaggeerr//VViissttaa,,
SSeelleeccttRRiiddee
BBeelltt--PPoossiittiioonniinnggBBoooosstteerr
IInnssttrruuccttiioonnMMaannuuaall
Eng.4358-4153
Replacement Parts List
NOTE: If requested color is not available,similar color will
be substituted.
PartCost Quantity Total Cost
Seat Pad . . . . . . . .$29.99 X______= $ ______________
Cup Holder . . . . . . .$3.50 X______= $ ______________
Instructions . . . . . . .$0.00 X______= $ ______________
MerchandiseTotal $______________
Shipping and handling: $______________
SalesTax $ ____________
(Indiana,California,Arkansas,and Massachusetts residents add applicable
sales tax.
GrandTotal $ ______________
No shipping and handling on instruction manuals on quantities 6 or less.
Add $.50 for each instruction manual over 6,then add applicable shipping
and handling.Noshippingandhandlingoninstructionsforquantitiesunder6.Add$.50foreachinstructionover6,thenaddapplicableshippingandhandling.
Up to $25.00 . . . . . . . . . .$5.95
$25.01 to $50.00 . . . . . . .$6.95
$50.01 to $75.00 . . . . . . .$8.95
$75.01 to $100.00 . . . . . .$9.95
$100.01 to $150.00 . . . . .$10.95
$150.01 to $200.00 . . . . .$11.95
$200.01 and up . . . . . . . .$13.95
Outside Continental USA $10.00
CUT ON DOTTED LINE
IMPORTANT!
Failure to follow the warnings on the labels
and in the instruction manual can result in
the death or serious injury of your child.
4358-4153 VoyagerVista Eng 8/21/06 2:32 PM Page 1

Before You Begin... Table of Contents
1
Warnings..........................................................................................2-3
WarmWeather Use ........................................................................4
Registration and Recall....................................................................4
Aircraft Installation..........................................................................4
Choosing Restraint and Position ..................................................5
UnderstandingYourVehicle ........................................................6-7
Child Restraint Parts....................................................................8-9
Preparing Child Restraint ......................................................10-13
KnowingYourVehicle Belts ..........................................................14
Belt-Positioning Booster Use ....................................................15
Belt-Positioning Booster Installation....................................16-17
Removing Seat Pad for Cleaning ................................................18
Troubleshooting ..............................................................................19
Warranty ..........................................................................................20
Replacement Parts Order Form ..........................................21-22
Thank you for choosing this car seat,referred to
throughout this manual as a child restraint.The DJG
family is committed to creating a child restraint with the
most comfort and convenience available today.
Remember, parents are a child’s first teachers and
examples.If you always buckle your seat belt,your child
will think it is the natural thing to do. Make it a firm rule
that the vehicle does not go until everyone is buckled
up. Make no exceptions.
No one can predict if use of a child restraint will
prevent injury or death in a particular crash.However,
combined with careful driving,proper use of a child
restraint can lower a child’s risk of injury or death in
most crashes.
Your child’s safety is worth the time it will take to read
and follow these instructions.After reading,if you still
have questions or have any problems with this child
restraint,please contact our Consumer Relations
Department at:
Dorel Juvenile Group,Inc.
Website: www.djgusa.com
Fax: [phone]
MailingAddress: Dorel Juvenile Group,Inc.
P.O.Box 2609
Columbus,IN 47202-2609
Telephone: [phone]
7A.M.to 6 P.M. EST M-TH
7A.M.to 4:30 P.M. EST FRI
On the back of the shell there is an expiration date for
use of this child restraint. Do not use this seat after
the expiration date.
4358-4153 VoyagerVista Eng 8/21/06 2:32 PM Page 3

WARNING
!
According to accident statistics,children
are safer when properly restrained in the
rear seating positions than in the front
seating positions.
Never place a child less than one-year old
forward-facing.
Check vehicle instructions for more
information about air bag/child restraint use.
The vehicle belt must stay tight at the
belt path. If you don’t,your child could be
seriously injured or killed.
Never take your child out of the child
restraint or try to tend to your child’s needs
while the vehicle is moving. Never leave
child unattended.
Do not use a child restraint with damaged
or missing parts.
Do not substitute parts or try to modify
the child restraint in any way.
Do not use a child restraint that has been
in a crash.You must get a new child
restraint.
Failure to follow these warnings could
result in the serious injury or death of your
child. To help you recognize those
instructions which are most critical for
your child’s safety, we use this symbol :
2
WARNING
!
Use the child restraint only on vehicle
seats that face forward.Do not use on seats
that face the sides or rear of the vehicle.
Check the vehicle belt before each use.
Use only if the belt can be tightened
properly and securely.
This child restraint should be securely
belted in the vehicle even when not in use.In
a crash or sudden stop,an unsecured child
restraint could injure other occupants.
Do not use this child restraint if the
midpoint of your child’s head is above the
top of the child restraint’s back.
Dorel Juvenile Group does not recommend
the use of any child restraint accessories
except those provided by DJG.
Never allow any child to play with this
child restraint;it is not a toy.
Do not remove any of the warning labels
or other labels on the child restraint.
Placing your child in a hot child restraint
may result in burns.
Do not use this child restraint without the
seat pad.
Read instructions for other warnings.
3
4358-4153 VoyagerVista Eng 8/21/06 2:32 PM Page 5

4
Registration and Recall Information
This child restraint is not certified for aircraft use. Aircraft
seats are not equipped with lap/shoulder belts,which are
required for use with this child restraint.
Aircraft Installation
5
Child restraints could be recalled for safety reasons.You
must register this restraint to be reached in a recall. Fill
out the registration card attached to the child restraint or
send your name,address and the restraint’s model number
and manufacturing date to:
Dorel Juvenile Group,Inc.
P.O.Box 2609,Columbus,IN 47202-2609
Attn:Consumer Relations or call 1-800-544-1108
You can now register your child restraint online at
www.djgusa.com. Please do not send in your
registration card if you registered your child restraint
online.
For recall information,call the U.S.Government's
Vehicle Safety Hotline at 1-888-327-4236 (TTY:1-800-
424-9153),or go to http://www.NHTSA.gov.
Choosing Restraint and Position
Your child’s height,weight and age determine how your
child restraint should be placed in the vehicle and which
restraint should be used.
40-80 lbs (18.1-36.3 kg)
43-52 in.(110.1-132.1 cm)
and Over 1Year Old
Belt-Positioning Booster
using vehicle
lap/shoulder belt
combination
Child and child restraint face
the front of the vehicle and
are placed in the back seat.
General and Warm Weather Use
To help protect your vehicle seat’s upholstery from
damage, use a towel underneath and behind child
restraint.
To avoid your child being seriously burned,take
the following precautions:
1.Park in the shade or where sun does not
directly hit the child restraint.
2.Cover the child restraint with a sheet or blanket
when not in use.
3.Check for hot seat and buckles before placing child in
child restraint.
4358-4153 VoyagerVista Eng 8/21/06 2:32 PM Page 7

6
Your vehicle’s features may be considerably different than
those pictured here. Consult your vehicle owner’s manual
to help identify your vehicle’s specific features.
Understanding Your Vehicle
A
B
C
E
7
D
A.Anchor Bracket
ForTopAnchorage Strap
(Forward-Facing Only)
B. LATCHAnchors
(In seat bight)
C.Seat Buckles
D.Air Bag
(Consult your vehicle
owner’s manual for all air
bag locations)
E.Seat Bight
(Where seat cushions
meet)
4358-4153 VoyagerVista Eng 8/21/06 2:32 PM Page 9
