dlb AIJGO-22LCD User manual

www.dlb.hu +36 27 502 [e-mail]
INSTRUCTION
MANUAL
AIJGO22LCD
PERSONAL GROUNDING TESTER WITH LCD
DISPLAY AND DUAL FOOT ELECTRODE

TABLE OF CONTENTS
About the product ............................................ 3
Technical informations......................................... 4
Parts of the tester ............................................. 6
Items supplied with the tester .................................. 7
Assembly instructions ......................................... 8
Operation instructions .......................................13
Calibration instructions ....................................... 14

3
ABOUT THE PRODUCT
ӹTester for checking personal grounding before entering an ESD protected area
(EPA)
ӹTesting footwear system and wrist strap/groundable ESD smock system at the
same time
ӹCan be used to test a groundable ESD smock system
ӹTest result indication on LCD display, with LED light and sound
ӹSelectable test modes: Footwear sytem test only, or footwear system and wrist
strap/groundable ESD smock system combined test
ӹFor indoor use only
The AIJGO-22LCD is an easy-to-use tester for checking personal grounding before
entering an ESD protected area (EPA). High load-bearing construction, it may be a
good choice if speed and security are important factors due to the large number of
entrances. Tester with LIGHT BAR system – such AIJGO products have a steel touch
button, the measured results are indicated by LED lights. The type of test can be
changed according to the entrance regulations: only footwear system test or the
combined test of the footwear system and wrist strap/groundable ESD smock
system. Thanks to the dual foot electrode, the tester simultaneously measures the
resistance of the right and left foot relative to the hand. After the test, the measured
values are displayed on the built-in LCD display. The tester can be connected to a
gate using the relay output (e.g. to a turnstile entrance gate, swing gate, etc.). It can
be installed on an entrance gate, table, wall or stand.
The tester is supplied with manufacturer’s calibration certicate, dual foot electrode,
mounting plate and universal holder.
CE declaration
We declare that the AIJGO-22LCD product complies with the requirements of IEC
61340-5-1, ANSI/ESD S20.20 and Directive 2001/95/EC (General product safety).

4
Resistance values indicated as acceptable by the tester
Default setting when measuring footwear system 100 KΩ – 35 MΩ
An upper value of 100 MΩ can be set using the red switch at the bottom of the tester. However, after setting a dierent
limit from the one used previously, the device must be restarted for the change to take eect.
Default setting when measuring wrist strap/
groundable ESD smock system 750 KΩ – 35 MΩ
TECHNICAL INFORMATIONS
Test voltage 100 V DC
Wrist strap/groundable ESD smock system
connection:
With a combined 10 mm snap, 4 mm banana
plug socket
Power supply 12 V DC
Relay outputs
0,5 A/60 V
Pass relay (Normally Open) with green wire
Fail relay (Normally Open) with red wire
Sizes
215 x 195 x 55 mm (tester)
500 x 630 x 970 mm (tester+stand with dual
foot electrode, assembled), the touch button
emerges from it beyond this, the tester extends
14 cm backwards beyond the platform. The
size of the platform itself (for tester version with
stand): 500 x 490 x 20 mm.
Tilt angle of the stand: 5 degrees

5
AIJGO-22LCD Personal grounding tester with LCD display, dual foot electrode, mounting
plate and universal holder
AIJGO-STA Stand for AIJGO tester
Order codes
Mounting plate sizes

6
PARTS OF THE TESTER
1. Steel touch button with 9 RGB LEDs
2.
Combined 4 mm banana plug and 10 mm snap
socket for connecting wrist strap/groundable
ESD smock
3.
Switch for test type selection: if the upper
position is selected, the footwear system and
wrist strap/groundable ESD smock system are
tested, if the lower position is selected,
only the footwear system is tested
4. LCD display
1
2
3
4
5. Green 4 mm banana plug socket:
calibration test point
5
6.
8-pin socket which can be used to connect
foot electrode wires and relay output wires,
but if you place the tester on a stand, it is also
worthwhile to connect the power supply
through this.
7.
Switch for setting the footwear system
measurement resistance limit value; after
setting a dierent limit from the one used
previously, the device must be restarted for the
change to take eect
8. 12 V power supply connection socket
6
7
8

7
ITEMS SUPPLIED WITH THE TESTER
1. Dual foot electrode with wire and relay connector
In case of a tester version which is to be
mounted on wall/table/entrance gate
In case of a tester version which is to be
mounted on stand
2. Universal holder
In case of a tester version which is to be mounted
on wall, x the tester on the universal holder in
the direction shown in the picture
In case of a tester version which is to be mounted on
table/entrance gate, x the tester on the universal
holder in the direction shown in the picture
In case of a tester version which is to be mounted on stand, x the tester on the universal holder in
any of the two directions above
3. Mounting plate

8
ASSEMBLY INSTRUCTIONS
Stand version
1.
Retool the red switch on the bottom of the
tester to the desired position, if necessary, to
set the measurement resistance limit of the
footwear system.
However, after setting a dierent limit from the
one used previously, the device must be restarted
for the change to take eect.
2. Fix the tester with screws on the universal
holder
3. Remove the protecion foil from the foot
electrode plates
4. Connect the wires from the stand to the wires of
the platform
5. Place the stand on the platform and x it with
screws
6. Connect the wires of the dual foot electrode
and the relays, also the adapter to the tester –
all using the 8-pin connector

9
7. Fix the tester with the universal holder on the
stand
8.
Ask a qualied electrician to connect the
gate to the EPH network of the building. For
information on connecting the re alarm wiring,
see below.
9. Connect the device to mains voltage
10. The tester is ready to use

10
Wall version
1.
Retool the red switch on the bottom of the
tester to the desired position, if necessary, to
set the measurement resistance limit of the
footwear system.
However, after setting a dierent limit from the
one used previously, the device must be restarted
for the change to take eect.
2. Screw the mounting plate to the wall
3. Fix the tester to the universal holder with
screws in the direction shown in the picture
4. Connect the wires of the dual foot electrode
and the relays using the 8-pin connector and
also the adapter
5. Slide the tester with the holder onto the
mounting plate
6. Remove the protecion foil from the foot
electrode plates

11
7. Connect the device to mains voltage
8. The tester is ready to use

12
Entrance gate or table top version
1.
Retool the red switch on the bottom of the
tester to the desired position, if necessary, to
set the measurement resistance limit of the
footwear system.
However, after setting a dierent limit from the
one used previously, the device must be restarted
for the change to take eect.
2. Fix the tester to the universal holder with
screws in the direction shown in the picture
3. Connect the wires of the dual foot electrode
and the relays using the 8-pin connector and
also the adapter
4. Remove the protecion foil from the foot
electrode plates
5. Connect the device to mains voltage
6. The tester is ready to use

13
OPERATION INSTRUCTIONS
1. Step with both feet on the middle of the foot
electrode plates
2. When testing a wrist strap/groundable ESD
smock system, connect the wrist strap/
groundable ESD smock to the tester socket
3. Touch both halves of the steel touch button at
the same time and keep your hand on it while
testing is in progress
4. You can read the result on the LCD display, the
tester will also give a light and sound signal
Interpreting the colour coding of the touch button
(WS: wrist strap/groundable ESD smock system, LF: footwear system – left foot
RF: footwear system – right foot):
WS: OK
LF: OK
RF: OK
WS: FAIL
LF: OK
RF: OK
WS: OK
LF: FAIL
RF: OK
WS: OK
LF: OK
RF: FAIL
WS: FAIL
LF: FAIL
RF: FAIL
WS: OK
LF: FAIL
RF: FAIL
WS: FAIL
LF: OK
RF: FAIL
WS: FAIL
LF: FAIL
RF: OK

14
CALIBRATION GUIDE
Foot electrode calibration
1. Place a measuring electrode on the foot
electrode you want to measure and connect it
to a resistance decade
2. Connect the calibration test point of the tester
to the resistance decade
3. To calibrate, adjust the knobs on the resistance
decade and start testing by touching both parts
of the touch button simultaneously
Wrist strap/groundable ESD smock connection calibration
1. Connect the wrist strap/groundable ESD smock
connection to a resistance decade
2. Connect the calibration test point of the tester
to the resistance decade

15
3. To calibrate, adjust the knobs on the resistance
decade and start testing by touching both parts
of the touch button simultaneously
Table to evaluate the results
Calibration
parameters
Accepted maximum
deviation downwards
from expected value
Lower limit
value Expected value Upper limit value
Accepted maximum
deviation upwards
from expected value
Footwear system test
(lower limit) - 20% 80 KΩ 100 KΩ 120 K Ω + 20%
Footwear system test
(upper limit) - 10% 31,5 MΩ 35 MΩ 38,5 MΩ + 10%
Wrist strap/groundable
ESD smock system test
(lower limit) - 20% 600 KΩ 750 KΩ 900 KΩ + 20%
Wrist strap/groundable
ESD smock system test
(upper limit) - 10% 31,5 MΩ 35 MΩ 38,5 MΩ + 10%
