DLS RULTSUB3 User manual

ULTIMATE SERIES
SUBWOOFERS
WELCOME
Thank you for buying a DLS ULTIMATE subwoofer.
The subwoofer must be installed correctly in order to work well.
This manual will show you how to install it like a pro. Please
read the entire manual before beginning the installation.
Install the subwoofer yourself if you feel confident with our
instructions and if you have the proper tools. However if you
feel unsure, turn over the installation job to someone better
suited to it.
The speakers are designed for enclosure mounting. In "open
air" installations the power handling capacity is reduced by 30%
from the nominal value. We dont recommend ”open air”
installations for Ultimate subwooers.
CONNECTION OF SUBWOOFER
How to connect depends on what type of amplifier you use.
The best is to follow the instructions given in the manual for the
amplifier. Most amplifiers today have built-in lowpass crossover
and possibilities to connect your subwoofer in bridge mode.
Two 4 ohm subwoofers are often connected in stereo mode
since most amplifiers can´t handle bridge mode loads below 4
ohms.
The UR10, 12 & 15 have dual, four ohm, voice coils. Each voice
coilhasanimpedanceof4ohms.Iftheyareconnectedinseries
the resulting impedance is 8 ohms. If they are connected in
paralleltheresultingimpedanceis2ohms. Make sure toconnect
in a way that don´t ruin the amplifier. If you have a DLS Ultimate
amplifierit´spossibletoconnectthevoicecoilsin parallel, these
ampliers are 1 ohm stable.
SP12 and 15 have dual, two ohm, voice coils which should be
considered when you connect them.
We also recommend the use of a subsonic highpass filter. This
gives a better bass reproduction with less "rumble". In most
DLS amplifiers this feature is already built-in.
For wiring use high class speaker wires, minAWG13 (2.5 mm2).
For example DLS SC 2x2,5.
If you have an amplifier without built-in crossover you must use
a passive crossover between amplifier and subwoofer like in
this example, one crossover for each voice coil.
Component values are for 4 ohms.
Connected with a 12 dB passive low-pass x-over = 10 mH coil
in series and a bipolar capacitor of 300 microFarad in parallel.
Crossover frequency is 95 Hz.
1234567
1
23456
7
1234567
L
+
-C
UR10, UR12, UR15
SP12, SP15
SP15S, SP18S
SUBWOOFER ENCLOSURES, GENERAL
Build your enclosure in a stable and airtight material. The best
is MDF-board, 19 mm, or particle board, 22 mm. Larger
enclosures must have bracing inside to avoid vibrations. The
enclosure must be completely airtight. Use sealing compound
in all joints, also around the cable terminals. The size of the
enclosure is decided by the speaker data.
SEALED ENCLOSURES
Sealed enclosures are easy to build. The size is not critical, but
it can´t be too small. The speaker data such as Fs, Qts, Vas
and X-max decides the size of the enclosure.
Large speakers need larger boxes. Two speakers need a box
of the double size etc. The enclosure must be completely air-
tight.
A sealed enclosure should be filled with acoustic wool up to 75
- 100%.
A sealed enclosure has a lower efficiency than vented
enclosures but they can handle high power and are easy to
build.
A subwoofer in a sealed enclosure creates a tight bass suitable
for the audiophiles listening to classical music, jazz and soft
rock. All the Reference subwoofers are recommended NOT to
use in sealed enclosures.
VENTED ENCLOSURES
A speaker in a vented enclosure has a higher efficiency (3 dB)
and higher power handling capacity than in a sealed enclosure.
In a vented enclosure the sound from the speaker and the port
work together creating a higher sound level. The sound from
the port must come out in the same phase as from the speaker
otherwise the result is bad.
The size of the vented enclosure is decided by the speaker
data just as for the sealed one.
The size of the vehicle often decides the practical size of the
enclosure.Asmallerenclosurehasahigherresonant frequency
than the larger one. The size of the enclosure should not be so
big that the speaker plays below it´s own free air resonance
(Fs), then it looses in power handling capacity.
The port does not have to be fully inside the enclosure as long
as the area and length are correct. Sometimes you need two or
more ports in an enclosure. You can convert from one to two or
more ports as long as the total port area is the same.
All DLS subwoofers works well in vented boxes.
BANDPASS ENCLOSURES
In all bandpass enclosures the speakers are hidden inside the
enclosure, all sound is coming out through the ports. There are
different types of bandpass enclosures and they have in com-
mon that they are a bit more difficult to build. Most DLS
subwoofers can be used in bandpass enclosures.
IMPORTANT!
The speaker cones of UR10,12 & 15 are made of magnesium,
a material of low weight with excellent acoustic qualitys.
We recommend you NEVER to touch the cone body with you
fingers. Remaining deformation of the cone body will occour if
you push it with your fingers.
Also think of the speaker weight when you mount it. If you don´t
mount it properly it can get loose.
Active filter Amplifier
Connection in mono bridge mode with an active x-over. Voice
coils connected in series. If you have a 1 ohm stable amplifier
the voice coils should be connected in parallel for best
performance (for example on a DLS monoblock).
Valid from 2003-12-01

UR10 UR12 UR15
Size 25 cm (10") 30 cm (12") 37,5 cm (15")
Impedance 2 x 4 ohm 2 x 4 ohm 2 x 4 ohm
Nom. power (RMS) 400 W (max 700) 500 W (max 800) 500 W (max 800)
Freq. range 25 Hz- 2 kHz 20 Hz-2 kHz 15 Hz- 2 kHz
Sensitivity 85,6 dB 87,2 db 90 dB
Voice coil diameter 75 mm (3”) 75 mm (3”) 75 mm (3”)
Voice coil height 42 mm (1,65”) 42 mm (1,65”) 42 mm (1,65”)
Re 1,92 ohm* 1,6 ohm* 1,93 ohm* * Data measured with
Voice coil inductance, 1 kHz 0,8 mH 0,89 mH 0,89 mH VC connected in parallel
BL product 13,1 16,1 13,9
X-max +-14 mm (0,55”) +-14 mm (0,55”) +-14 mm (0,55”)
Suspension compliance CMS 80,2 82 146
SD- Effective piston area 314,6 cm2452,3 cm2854,8 cm2
Resonant freq. (Fs) 42,3 Hz 36,1 Hz 27,5 Hz
Vas (liters) 13,9 24 116,7
Vas (ft3) 0,5 0,85 4,12
Qms 5,62 4,98 4,31
Qes 0,40 0,32 0,40
Qts 0,37* (0,7 with single VC) 0,3* (0,6 with single VC) 0,36* (0,57 with single VC)
Cone material Magnesium Magnesium Magnesium
Magnet weight 180 oz (5,1 kg) 200 oz (5,67 kg) 200 oz (5,67 kg)
Magnet diameter 7,1" (180 mm) 8,7" (220 mm) 8,7" (220 mm)
Installation depth 5,24" (133 mm) 5,9" (150 mm) 6,93" (176 mm)
Mounting hole 9,29" (236 mm) 11,1" (282 mm) 14,17" (360 mm)
Outer diameter 10,39" (264 mm) 12,2" (310 mm) 15,35" (390 mm)
Weigth 20 lb (9,1 kg) 28,66 lb (13 kg) 29,54 lb (13,4 kg)
TECHNICAL SPECIFICATIONS FOR DLS ULTIMATE SUBWOOFERS
RECOMMENDED ENCLOSURES FOR UR10, UR12 & UR15
VENTED ENCLOSURE
Subwoofer Volume (liters/ft3) Port Damping F3 Fb
UR10* vol: 19 / 0,67 3” x 40 cm/15,75” Line inside 40,1 Hz 40,0 Hz
UR12* vol: 27,4 / 0,95 3” x 33 cm/ 13” Line inside 37,4 Hz 34,0 Hz
UR15/par vol: 57 / 2,01 4” x 24 cm/9,45” Line inside 51,2 Hz 39,8 Hz
UR15/ser vol: 52 / 1,84 4” x 24 cm/9,45” Line inside 43 Hz 39,8 Hz
* voice coils in either series or parallel
SEALED ENCLOSURE
UR10 single voice coil:
15 liters / 0,53 ft3
F3: 49,9 Hz
UR12 single voice coil:
16 liters / 0,56 ft3
F3: 49,8 Hz
UR15 single voice coil:
55 liters / 1,94 ft3
F3: 52,4 Hz
use only one voice coils in sealed enclosures
The speaker is installed in Vb1
playing into chamber Vb2 where the
port(s) are installed.
F3 = approximative lower frequency for vented
boxes in Hz. Often called F-3 dB point = the point
where the power is 50% lower.
Fb = Box resonant frequency
SEALED BANDPASS
UR12 (VC in parallel, 2 ohm
Vb1 Vb2 Port Vb2
19,5 11,16 1x6,8x32 cm
0,69 ft30,39 ft31 x 3" x 12,6" (US)
F3 Vb1: 40,5 Hz, Vb2: 73,6 Hz
UR15 (VC in parallel, 2 ohm)
Vb1 Vb2 Port Vb2
41,13 55,4 1x16x27 cm
1,45 ft31,96 ft31 x 6" x 10,6" (US)
F3 Vb1: 50 Hz, Vb2: 102,5 Hz
Vb1=rear, Vb2=front
RUNNING-IN PERIOD
Allow the speaker to play for at least 15-
20 hours. After this time the
performance is correct.
Revised data for UR10 valid from production date 2003-07-01.
Revised data for UR12 valid from production date 2003-12-01.

TECHNICAL SPECIFICATIONS FOR DLS ULTIMATE SUBWOOFERS
SP12 SP15 SP15S SP18S
Size 30 cm (12") 37,5 cm (15") 37,5 cm (15”) 45 cm (18”)
Impedance 2 x 2 ohm 2 x 2 ohm 4 x 2 ohm 3 x 2 ohm
Nom. power (RMS) 500 W (max 800) 500 W (max 800) 500 W (max 800 ) 500 W (max 800 )
Maxiumum power for SPL use 1200 W 1200 W 2000 W 2000 W
Freq. range 20 Hz- 2 kHz 15 Hz-2 kHz 15 Hz - 1 kHz 13 Hz - 1 kHz
Sensitivity 97,3 dB 99,9 db 88,1 dB 90,5 dB
Voice coil diameter 75 mm (3”) 75 mm (3”) 75 mm (3”) 100 mm (4”)
Voice coil height 32 mm (1,26”) 32 mm (1,26”) 28 mm (1,1”) 32 mm (1,1”)
Re 1,27 ohm* 1,25 ohm* 1,8 ohm** 2,2 ohm**
Voice coil inductance, 1 kHz 0,52 mH 0,57 mH 0,96 mH 1,16 mH
BL product 8,73* 8,49* 9,53** 12,07**
X-max +-12 mm (0,47”) +-12 mm (0,47”) +-12 mm (0,47”) +-12 mm (0,47”)
Suspension compliance CMS 344 240 753 936
SD- Effective piston area 452,3 cm2754,8 cm2754,8 cm2
Resonant freq. (Fs) 30,5 Hz 33,2 Hz 39 Hz 31,9 Hz
Vas (liters) 98,76 191,7 72,4 177
Vas (ft3) 3,48 6,77 2,55 6,25
Qms 4,42* 4,22* 6,94** 5,33**
Qes 0,25* 0,35* 1,07** 0,8**
Qts 0,24* 0,32* 0,92** 0,7**
Cone material Paper Paper Paper Paper
Magnet weight 200 oz (5,67 kg) 200 oz (5,67 kg) 200 oz (5,67 kg) 200 oz (5,67 kg)
Magnet diameter 8,7" (220 mm) 8,7" (220 mm) 8,7" (220 mm) 8,7" (220 mm)
Installation depth 5,71" (145mm) 6,89" (175 mm) 6,89" (175 mm) 8,66” (220 mm)
Mounting hole 11,22" (285 mm) 14,17" (360 mm) 14,17" (360 mm) 16,9” (430 mm)
Outer diameter 12,4" (315 mm) 15,35" (390 mm) 15,35" (390 mm) 18,3” (465 mm)
Weigth 28,66 lb (13 kg) 29,54 lb (13,4 kg) 29,54 lb (13,4 kg) 43,65 lb (19,8 kg)
* Data measured with VC connected in parallel ** Data measured on single voice coil
VENTED ENCLOSURES FOR SP12 & SP15
VENTED ENCLOSURE
Subwoofer Volume (liters/ft3) Port Damping F3 Fb
SP12 single VC vol: 41,9 / 1,48 4” x 35 cm/13,8” Line inside 38,1 Hz 38,6 Hz
SP12 par. VC vol: 36,9 / 1,30 3” x 25 cm/9,84” Line inside 30 Hz 32 Hz
SP12 ser. VC vol: 40,4 / 1,43 4” x 17 cm/6,7” Line inside 50 Hz 50 Hz
SP15 single VC vol: 60 / 2,12 2x4” x 35 cm/13,8” Line inside 53 Hz 45,0 Hz
SP15 ser. VC vol: 60,55 / 2,14 2x4” x 37 cm/14,5” Line inside 44,7 Hz 44,0 Hz
BANDPASS ENCLOSURES
SP12, single VC
Vb1 Vb2 Port Vb2
29,4 17,3 1x10,2x29 cm
1,04 ft30,61 ft31x4"x11,4" (US)
F3 Vb1: 40 Hz, Vb2: 102 Hz
SP15 , single VC
Vb1 Vb2 Port Vb2
52,8 58,3 2x16x25 cm
1,86 ft32,05 ft32 x 6" x 9,8" (US)
F3 Vb1: 50 Hz, Vb2: 111,6 Hz
Vb1=rear, Vb2=front
The speaker
is installed in
Vb1 playing
into chamber
Vb2 where the
port(s) are
installed.
F3 = approximative lower frequency for vented
boxes in Hz. Often called F-3 dB point = the point
where the power is 50% lower.
Fb = Box resonant frequency
SEALED ENCLOSURE
SP15: 54,5 liters, F3: 67,5 Hz
1,92 ft3
(Use only one voice coil)
SEALED ENCLOSURE
FOR SP15
SPL ENCLOSURES FOR SP12, 15, 15S, 18S
The enclosure examples can be used only for the reproduction of normal
music. If you want to use these subwoofers for SPL competition, which
they are designed for, the design of an enclosure is more complicated.
The vehicle must be modified in many ways and the enclosure must be
individually designed for each vehicle type and also for the different
competition classes.
You are welcome to contact DLS for advices.
On our website www.dls.se /support you will find some helpful hints (PDF
document) regarding the build of SPL competition vehicles.
RUNNING-IN PERIOD
Allow the speaker to play for at least 15-
20 hours. After this time the
performance is correct.

HINTS & TIPS FOR ”DO IT YOURSELF” ENCLOSURE BUILDERS
DLS Svenska AB
P.O. Box 13029
SE-40251 Göteborg, Sweden
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.dls.se


 Technical Assistance
For technical assistance ask the shop where the product was
soldorthe distributor in your very country.Youcanalwaysphone
the DLS Helpdesk in Sweden + 46 31 840060 or send an e-
mail to [email protected]
Information can also be found on our WEB-site www.dls.se
We follow a policy of continuous advancement in development.
For this reason all or part of specifications & designs may be
changed without prior notice.
WARRANTY SERVICE
This speaker is covered by warranty, depending on the
conditions in the country where it is sold. If the speaker is retur-
ned for service, please include the original dated receipt with
the product.
ABOUT THE RECOMMENDED ENCLOSURES
The performance of these recommended enclosures will vay
from vehicle to vehicle. It is more difficult to get a tight and well
defined bass in a SEDAN vehicle because of the tightness
between trunk and interior of the vehicle. In this case a band-
pass box could be a better choise.
- All volumes are inside measures.
- Volumes occupied by speaker and ports have already been
added to the given enclosure volumes.
- Use conical bass ports for best result. (DLS BP-75 or BP-
110). If the ports are too long for the box you can use a bend.
Either cut the tube and glue it together in angle, or use factory
made tube bends. It´s easier to use the factory made ones. The
total length must be the same as for a straight tube. Make the
measure in the center of the tube.
The port opening inside the enclosure must not be closer to an
interior wall than 3” (75 mm), otherwise it will have negative
effects on the airflow.
- The enclosure must be very steady and completely air-tight.
Use 22 mm particle board or 19 mm MDF-board. The particle
board has a self resonant frequency of 14 Hz while the MDF
has a resonant frequency of approx. 400 Hz. It´s important to
dosometypeof bracing inside the enclosure to avoid vibrations.
Volume taken up by bracing should be added to the enclosure
volumes.
ENCLOSURE DAMPING
Most enclosures should be damped inside with syntetic
(acoustic) wool or damping mat (line). Attach the damping ma-
terial on the wall opposite from the speaker and port. A sealed
enclosure should be filled up to 70-100% with acoustic wool.
In a vented enclosure the speaker and port should be on the
sameside, otherwise afade-outof some frequenciescanoccour.
In most vehicles, except for SEDAN cars, the speaker and port
should be directed backwards for best result.
ENCLOSURE PLACING IN DIFFERENT TYPES OF
VEHICLES
In small vehicles like VW Golf, Peugeot 306 and similar the
bassboxshouldbe installed with both speaker and port directed
backwards.Alternativelyboothspeakerandport can be directed
upwards. This way of mounting is valid for all types of vehicles
where the trunk is incorporated with the inner compartment.
In sedan vehicles with the passenger compartment separated
from the trunk, the enclosure should be installed with booth
speaker and port directed towards the rear seat. Some cars
have an opening in the middle of the rear seat for loading skis
etc. You can install the enclosure behind this opening and direct
speaker or port through this opening. There must be some free
space in front of the port, (between the rear seat and the port
opening).
Inlarge vehicles likestationwagonsthebest sound is achieved
withthe enclosure installed behindtherear seat with boothspea-
ker and port directed backwards. Alternatively you can install
the enclosure on one side of the luggage compartment.
CALCULATE YOUR ENCLOSURE
Box volumes:
Whencaculatingthevolumeofanenclosureyousimplymultiply
the width (W) x heigth (H) x depth (D).
Use measures in dm and you will get the answer in liters.
A trapezoid box is calulated as below:
Vol=width (W) x heigth (H) x upper depth (UD) + lower depth (LD)
2
THE SUBWOOFER
Be sure to measure the
inside dimensions.
upper
suspension
voice coil pole plate
magnet
spider
chassis dust cap
speaker cone
T-yoke
W
H
UD
LD
