DMX Scene10cas User manual

Scene10cas USA & Canada
Casambi Scene Controller/Selector
DMX Engineering LLC
hp://dmx.engineering
Product Descripon
Scene10cas is a Casambi “Gateway” device designed to ulize a connecon to a standard
0-10VDC analog dimming master controller to provide remote selecon of pre-dened
Casambi Scenes and Scene Intensity. Scene10cas is connected between a 12-24 VDC
Class 2 power supply and a two-channel 0-10VDC master.
Scene10cas decodes both 0-10VDC channels, and provides Scene selecons by mapping
the rst 0-10V channel into voltage segments, which are then selected depending on the
voltage level. The second 0-10VDC channel provides 0-100% intensity selecon for the
selected Casambi Scene.
Voltage trim and hysteresis values are also provided to implement installaons where the
0-10VDC levels may not be full range, or are noisy due to installaon factors.
Scene10cas can be congured with the Casambi app which can be downloaded free of
Compable devices:
iPhone 4S or later
iPad 3 or later
iPod Touch 5th gen or later
Android 4.4 or later devices
produced aer 2013 with full
BT 4.0 support
Technical Data
Input
Voltage range: 12-24 VDC, Class 2
No-load input current: 30 mA
0-10VDC Input (A and B) Conguraon
2-wire analog 0-10VDC, two channels
1mA source current, input must sink for control
Top and boom “trim” and hysteresis user pro-
grammable Casambi Vendor Parameters
Scene Control/Selecon
Number of Scenes—determines the voltage win-
dow range for each Scene. For example, if 4
Scenes are desired, this sets the voltage window
to 2.5V (10V/4 = 2.5V)per Scene
Channel 1—Scene selecon
Channel 2—Intensity level
Radio transceiver
Casambi CBM003B Radio Module
Operang frequencies: 2.401-2.483 Ghz
Maximum output power: typ. +8 dBm
-103 dBm RX sensivity in long-range mode
Operang condions
Ambient temperature, ta: -13...+113°F (-25...+45°
C)
Max. case temperature, tc: +167°F (+75°C)
Storage temperature: -13...+167°F (-25...+75°C)
Max. relave humidity: 0...80%, non-cond.
Connectors
Wire range, solid & stranded: 0.5 - 1.5 mm2
14 - 22 AWG
Dimensions: 2.2 x 1.2 x 0.7 inch
72.6 x 30.0 x 18.0 mm
Weight: 0.8 oz (23 g)
0-10VDC Casambi Scene Selector
with Casambi CBM003 Long Range Radio
Cercaons
FCC ID: 2ALA3-CBM002A
IC: 22496-CBM002A
Conforms to UL STD 916
Cered to CSA STD C22.2#205
Typical Connecon Diagram
Mechanical Data
DMX Engineering LLC
9221 E. Baseline Road, Suite 109-492
Mesa, AZ 85209
+ -
12-24VDC
Class 2
Power
Supply
0-10VDC In A
0-10VDC In B
Ground
0-10VDC A
0-10VDC B
RETURN
Scene10cas
dmx.engineering
INPUT 12-24 VDC, 30mA,
Use Class 2 power supply
+ -
0-10VDC Scene
Controller
**RATED FOR INDOOR USE ONLY**

Installaon
Connect a Class 2 power supply with 12-24 VDC output voltage to the input connector of Scene10cas. Make sure not to use a constant current LED
driver and make sure that the cable polarity is correct. The product has two 0-10VDC analog posive input connecons, plus one common
(RETURN) ground. Connect the 0-10VDC load wires to a 0-10VDC master of your choice to give you 0-10VDC control of your Casambi Scene lighng
network. Add Scenes to the Casambi network, the Scene10cas will allow up to 10 Scenes to be selected.
Using the Casambi app, go to Gateways, and press on the Scene10cas device, and add it to your Casambi network. Now press on the Scene10cas
icon, and scroll to the boom of that screen. Note at the boom of this screen there are 16 user programmable parameters—Number of Scenes,
High and Low Trim, and Hysteresis for each channel, plus 10 Scene selectors. First choose how many Scenes you are wanng to control, and not
that this now divides the 10V span into “voltage segments” which now depending on the input voltage to channel A, will now select Scenes. The
Trim ne tune the boom and top analog voltage input, and hysteresis allows for managing inputs that may be noisy. Then select up to 10 Scenes
from your pre-dened Scenes in your Casambi network.
Scene10cas should not be placed in a metal enclosure, such as metal juncon boxes. Metal will aenuate radio signals which are crucial to the oper-
aon of the product. If the product will have to installed into a juncon box, make sure to use a plasc juncon box. Scene10cas is an ETL Listed
Open-Type device which means that it will have to be used together with a Class 2 power supply with maximum output power of 100 VA. The prod-
uct can be installed outside of juncon box. Make sure to comply with Naonal Electric Code in installaon and when selecng installaon wires.
Range
The range between two Scene10cas’s or between a Scene10cas and a smart phone can vary depending on obstacles and surrounding material. In
open air the range between two Scene10cas can be in excess of 200 , but if the unit is encapsulated into a metal structure, the range can be only
few feet. Therefore, thorough tesng is high suggested. Casambi uses mesh network technology so each Scene10cas acts also as a repeater. When
tesng the network, it is important to test that each unit can be controlled from any point of the network covered area.
Compliance Statement
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operaon.
Warning
Changes or modicaons not expressly approved by DMX Engineering and Design LLC could void the user’s authority to operate the equipment.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protecon against harmful interference in a residenal installaon. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instrucons, may cause harmful interference to radio communicaons. However, there is no guarantee that interference
will not occur in a parcular installaon. If this equipment does cause harmful interference to radio or television recepon, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Radiaon Exposure Statement for Canada
This device complies with Industry Canada’s licence-exempt RSSs. Operaon is subject to the following two condions:
(1) This device may not cause interference
(2) This device must accept any interference, including interference that may cause undesired operaon of the device.
This equipment is exempt from the roune RF exposure evaluaon requirements of RSS-102. This equipment should be installed and operated with a minimum dis-
tance of 20 cm between the antenna and the user or bystanders.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitaon est autorisée aux deux condions sui-
vantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’ulisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est suscepble d’en compromere le fonconnement.
Ce matériel n’est pas sujet à l’évaluaon habituelle d’exposion RF selon RSS102. Ce matériel devrait être installé et exploité en gardant une distance minimale de 20
cm entre l’antenne et l’ulisateur ou les spectateurs.
Informaon in this document is subject to change.
Copyright DMX Engineering LLC 2023
Scene10cas User Guide v2.02 USA and Canada
