DNA Designer Audio RVS358 User manual

RVS358
Instruction Manual
3.5” TFT CLIP ON REAR VIEW MIRROR
www.dnaaudio.com.au
g

3
Specifications & Contents ...…………………………..……….......…...…4
Safety…...................…………………………..…………......................…6
Monitor Controls.…………......………….............................................…7
On Screen Display Settings....………….............................................…8
Wiring.................…………......………….............................................…9
Installation.…………......………….....................................................…10
Thank you for purchasing this DNA Designer Audio product. It is designed
to give you many years of enjoyment. DNA Designer Audio recommends
installation by a professional installer.
Read this manual carefully prior to installation.
Index

4
Supply Voltage: 12V DC (9~16V nominal)
Ground: 12V Negative
Power Consumption: 70mA
General features:
Screen Size: 3.5 inch
Pixels: 320 (H) x 3RGB x 240(V)
Dot Pitch: 0.073 (H) x 0.219 (V) mm
Pixel Configuration: RGB Stripe
Active Area: 70.08 (H) x 52.56 (V) mm
Surface Treatment: Hard Coating
Operation Temperature: -20 ~ +70 Degrees
Storage Temperature: -30 ~ +80 Degrees
View Angle (U/D/L/R) 65/65/50/65
Brightness (nits): 400
Contrast Ratio: 500
TV System: Auto Switching NTSC/PAL
Video Input Level: 1Vp-p,75Ω
Video Input Signal: Standard Composite Video
Video Scan Direction: Up/Down, Left/Right scan selectable
Video Input Channel: 1 CH standard, up to 2 CH
NOTE: Specifications and design are subject to modification without notice due to improvement in technology.
Contents:
LCD Monitor Housing•
Wiring loom including power and video cables•
Instruction booklet•
Specifications & Contents

5
Safety
Alteration or modifications carried out without appropriate authorization may
invalidate the users right to operate the equipment and void warranty. Read this
manual carefully prior to installation.
WARNING - USE THIS PRODUCT SAFELY
Be sure you fully understand the following safety information:
This system is to act as a reversing aid in conjunction with a reversing•
camera.
In most countries it is illegal to watch tv/video while driving. Please check•
with your local laws. Safe driving should always be your priority.
Do not attempt any modifications or repairs on the unit, this could result in•
void warranty. Contact you nearest DNA Designer Audio dealer.
Disconnect this negative battery terminal prior to installation.•
Note:
Do not use and store the player in dusty, hot or humid environment.
FUSE REPLACEMENT – WARNING!
Never replace any fuse with one of a higher value than the fuse supplied
with your unit. Using a higher current rated fuse may cause damage to
your unit and/or electrical wiring.

6
Monitor Controls
1. Power ON/OFF
2. V1 Mode:
Press to select video source 1
3. V2 Mode:
Press to select video source 2
4. Down Buttons
This button is used to decrease parameters in the on screen display menu
5. On Screen Display Menu (OSD)
This button enables the on screen display menu
6. Up Buttons
This button is used to increase parameters on the on screen display menu
1.
2.
3.
4.
5.
6.

7
On Screen Display
1. Press the “POWER” key on monitor to turn on the monitor.
2. Press the “OSD” key on monitor, the OSD (ON SCREEN DISPLAY) menu
will be shown on the display as below.
BRIGHTNESS
CONTRAST
HUE
SATURATION
SHARPNESS
RESET
EXIT
3. Press “OSD” key on monitor to select the adjustment item. Then press
“UP “ or “DOWN” key to adjust the new setting value.
Each adjustment item is shown as below:
BRIGHTNESS Adjustment
Pressing UP key, the screen color gets brighter.
Pressing DOWN key, the screen color gets darker.
CONTRAST Adjustment
Pressing UP key, increases the intensity.
Pressing DOWN key, decreases the intensity.
HUE Adjustment
Pressing UP key, increases the green tones.
Pressing DOWN key, increases the red tones.
SATURATION Adjustment
Pressing UP key, the screen color gets richer .
Pressing DOWN key, the screen color gets lighter.
SHARPNESS Adjustment
Pressing UP key, increases the sharpness.
Pressing DOWN key, decreases the sharpness.
RESET Adjustment
Returns all setting to factory values.
EXIT Adjustment
Allows you to exit the OSD systems.

8
Wiring
Using the wires provided complete the video and power connections in your
vehicle as shown in the diagram below.
Linking with reversing light (12V )
1
+12V
RED
BLACK
-3Amp .
2
1
(WHITE )
(WHITE)
RED WIRE
BROWN WIRE
FUSE - 2 Amp
(ACC)
BLACK WIRE
VIDEO INPUT 2
(YELLOW)
VIDEO INPUT 1
REVERSING CAMERA
SOLD SEPARATELY
GROUND
VIDEO SOURCE 1
(DVD player,video game, etc
Linking with reversing light (12V)

9
Attach to existing reverse mirror•
Route all cables to the desired mounting position ensuring cables•
are free from sharp metal.
Both bottom clips are spring loaded for easy mounting.•
Attach and plug in wiring. see page 8 for wiring diagram.•
Installation
Trouble Shooting.
1. No power - Ensure Acc is turned on.
- Check 2 Amp fuse.
2. Does not automatically switch to reverse camera. (input 2)
- Ensure brown wire is connected to reverse light (+Ve)
- Ensure reverse camera is connected to video input 2 (white RCA)
