Docomo FOMA P904i User manual

Manual for Easy Search/
Contents/Precautions
Before Using the Handset
Voice/Videophone Calls
PushTalk
Phonebook
Sound/Screen/Light Settings
Security Settings
Camera
Mail
i-αppli
GPS Function
Osaifu-Keitai/ToruCa
Character Entry
i-mode/i-motion/
i-Channel
Full Browser
Data Display/Edit/Management
Music Playback
Other Convenient Functions
Network Services
Data Communication
Overseas Use
Appendix/External Devices/
Troubleshooting
Index/Quick Manual
’07.5

Before using your FOMA phone
You can download the latest information about this manual from the following
DoCoMo web site:
・User’s Manual (PDF file) Download
(http://www.nttdocomo.co.jp/english/support/manual/index.html)
※The URL and the content of the web site might be modified without notice.
DoCoMo W-CDMA system
Thank you for selecting the “FOMA P904i”.
Before or during use of the FOMA P904i, make sure that you read this manual and the separate
manuals such as for the battery pack thoroughly so that you can use the FOMA P904i correctly.
If you feel any inconvenience in reading the manual, contact the DoCoMo Information Center listed
on the back page of this manual.
The FOMA P904i is designed to be your close partner.
Treat it carefully at all times to ensure long-term performance.
● Because the FOMA phones use radio waves, they cannot be used in places where radio waves do not reach, such as
inside tunnels, underground, or in buildings; or the outside where radio waves are weak or out of the FOMA service area.
They may not be used in the high-rise buildings even when the antennas are unobstructed. You may also experience
interruption of calls even when using without moving while the radio waves are strong enough for the three antennas to
appear on the display.
● Use the FOMA phone carefully to avoid disturbing other people when in public, or in crowded or quiet places.
● Since the FOMA phones use radio waves as the medium of telecommunication, calls may be tapped by the third party.
However, the W-CDMA system automatically supports tapping prevention, so your conversation will be incomprehensible
to the third party.
● The FOMA phones change your voice into digital signals and send them to the other party. In places where the radio
waves are weak, the digital signals may not be converted correctly, and in such a case, the voice may sound different from
the actual original voice.
● It is recommended that you make separate notes of the information stored in the FOMA phone and keep such notes in a
safe place. DoCoMo cannot be held responsible in any way for the loss of data stored in the phone.
● The user hereby agrees that the user shall be solely responsible for the result of the use of SSL. Neither DoCoMo nor the
certifiers as listed herein make any representation and warranty as for the security in the use of SSL. In the event that the
user shall sustain damage or loss due to the use of SSL, neither DoCoMo nor the certifiers shall be responsible for any
such damage or loss.
Certifiers: VeriSign Japan K.K., Cybertrust, Inc., GeoTrust Japan, Inc., RSA Security Inc.,
and SECOM Trust Systems Co., Ltd.
● This FOMA phone supports FOMA Plus-Area.
● The FOMA phone can be used only via the FOMA network provided by DoCoMo and in DoCoMo’s roaming area.
If this is the first time for you to use the FOMA phone, read this manual in the order as described
below. Then you will get acquainted with the outline of preparing and operating procedures for
using your FOMA phone.
1. Check “Safety Precautions” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.12
2. Attach and then charge the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.41
3. Turn on the power, set the initial settings, and check your phone number . . . . . . . . . . . . . . P.45
4. Check the keys on the FOMA phone for their roles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.24
5. Check the meanings of icons that appear on the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.26
6. Learn how to operate the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.31
7. Get well acquainted how to make and receive calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P.52
For those who use the FOMA phone for the first time

1
Easy Search/Contents/Precautions
Easy Search/Contents/Precaut ions
In this manual, illustrations and symbols are used in the explanations so that you can easily understand how to
use the FOMA phone correctly.
p In this manual, the descriptions of the procedure are given with “Menu icon setting” set to “Asphalt”. (See
page 31 and page 144) Also, the descriptions of the display are given with “Display”
→ “Display setting” →
“Stand-by display” set to “OFF” and “Color pattern” set to “Platinum”.
p Operations are described in the method of “Scroll Selection” (see page 31).
p Displays and illustrations described in this manual are for reference. The actual ones might differ.
p In this manual, “Osaifu-Keitai compatible i- α ppli which supports the IC card function” is described as
“Osaifu-Keitai compatible i-
α ppli”.
How to Refer to This Manual
By the following search methods, you can find pages where your desired functions and services are described:
How to Read/Refer to This Manual
p Note that “FOMA P904i” is referred to as “FOMA phone” in this manual.
p The functions which use a microSD memory card are described in this manual;however, you need to obtain a microSD
memory card separately to make these functions available.See page 347 for the microSD memory card.
p It is prohibited to copy all or part of this manual without permission.
p The instructions contained in this manual may be changed without notice.
From the Index
Search from the index when you know the names of functions or services.
From Easy Search
Search from keywords for the functions you frequently use or the functions that are convenient if you can
know any.
From the Tabs on the Cover
Search from the tabs printed on the cover.
See the next page for details.
From the Contents  P.6
Search from the contents that categorize functions.
From the Main Functions  P.8
Search from the main functions when you want to use.
From the Function List  P.456
Search from the function list.
From Quick Manual  P.530
Quick Manual gives you a clear, brief description about basic functions.You can take it when you go out.
Further, Quick Manual “For Overseas Use” is attached, so refer to it when you use the FOMA phone overseas.
Illustrations for keys
p In this manual, the illustrations for keys are simplified.
For the illustration for keys used in this manual, see
“Phone Parts and Functions” on page 24.
p For the description of the operating procedures in this manual, see page 31.
Actual key Illustration in
this manual
(Body color:Champagne × Circular)
-1
(Body color:Platinum × Frost)
(Body color:Asphalt × Hairline)
(Body color:Rose × Facet)

2Easy Search/Contents/Precautions
How to search for “Alarm” is explained here as an example of search method.
From the Index  P.522
Search for a function or a service name as shown below.
Add to a phonebook entry 114
Add to phonebook (Phone) 109, 114
Add to phonebook (UIM) 109, 114
Additional service 440
Additional guidance 440
Address link function 216
Alarm 390
Alarm setting 398
ANSHIN-KEY area setting 166
ANSHIN-KEY info 166
ANSHIN-KEY lock 163, 166
Answer setting 73
Any key answer 73
Go to page 390
where “Alarm”
is explained.
From Easy Search  P.4
Search for the function you frequently use or that is convenient if you can know any as shown below.
Other things you can do
To reduce the battery consumption ...................139 <Power Saver Mode>
To scan QR codes or Bar codes .......................196 <Bar Code Reader
>
To check the location where you are,
or the surroundings ......................................... 302 <GPS Function>
To use the microSD memory card.....................347
<microSD Memory Card>
To exchange information using infrared rays ....357 <Infrared Data Exchange>
To listen to music............................................... 374 <MUSIC Player>
To use the FOMA phone as an alarm clock ......390 <Alarm>
To use the FOMA phone as a calculator...........402 <Calculator>
To use the FOMA phone overseas....................448 <International Roaming>
To bring software programs up to date..............505 <Software Update>
To bring security up to date ...............................511 <Scanning Function>
Go to page 390
where “Alarm”
is explained.
From the Tabs on the Cover  Cover page
Search for the function you want to set in the order of “Cover” → “First page of Chapter” → “Description
page” as shown below.
GPS Function
Osaifu-Keitai/ToruCa
Character Entry
Full Browser
Data Display/Edit/Management
Music Playback
Other Convenient Functions
Network Services
Data Communication
Overseas Use
Appendix/External Devices/
Troubleshooting
Index/Quick Manual
Multiaccess . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Multiaccess› 386
Multitask. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Multitask› 386
Informing You of an Incoming Call/Mail Message by Voice . . . . . . . . . . . . . .‹Reading Aloud› 388
Turning Power On/Off Automatically at a Specified Time. . . . . . . . . . . ‹Auto Power ON/OFF› 389
Using Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Alarm› 390
Using Calendar to Manage Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Schedule› 393
Using ToDo to Manage Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .‹ToDo› 397
Setting Operating Conditions of Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .‹Alarm Setting› 398
Using Your Original Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Private Menu Setting› 398
Storing Your Name, Mail Address and Other Information. . . . . . . . . . . . . . . . . ‹Own Number› 399
Recording Voice during a Call or Standby as Voice Memo
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ‹Voice Memo during a Call› ‹Voice Memo› 400
Recording Images during a Videophone Call as a Movie Memo . . . . . . . . . . . ‹Movie Memo› 401
Go to page 390
where “Alarm”
is explained.

3
Easy Search/Contents/Precautions
390 Other Convenient Functions
You can set Alarm to alert you at the specified time
with an alarm tone, animation and illumination. You
can store up to five alarms.
1
m Stationery  Alarm
2
+m-4-4
Alarm
Using Alarm
Setting at purchase OFF
<>
Alarm List
Item Operation/Explanation
(Time setting)
 Enter the time for sounding the alarm.
p Enter the time on 24-hour basis.
p You cannot set the same time as the time
set for the stored alarm.
(Alarm tone)
 Select a type of alarm tone
 Select a folder  Select an alarm tone.
(Auto power
ON)
You can set whether to turn on the power
automatically to make an alarm sound when
the alarm time arrives during power off.
 ON or OFF
(Prefer
manner mode)
You can set the alarm tone which sounds at
the specified time during Manner Mode.
 Select an item.
Prefer manner mode
...Sounds at the same volume as set for
“Alarm volume”.
Prefer alarm
...Sounds at the volume set for this
function.
3
Press l ().
(Snooze
setting)
You can set whether to activate Snooze.If
you set to “OFF”, set the duration that the
alarm tone is to continue sounding.
 ON or OFF
 Enter a ring time (minutes).
p You can enter from “01”through “10”in
two digits.
Item Operation/Explanation
Information
p If the alarm tone sounds during a call, press any key to
stop it.Once again press any key to end the alarm
including Snooze.If the other party on the phone hangs
up, an alarm including Snooze ends.
p When you set the power to automatically turn on and an
alarm to sound, the default alarm tone sounds if the
alarm which is affected by the UIM restrictions has been
selected.
p Turn off the FOMA phone after setting “Auto power ON”
to “OFF”when you are near electronic devices using
high-precision control or weak signals, or where the use
is prohibited such as in airplanes and hospitals.
Function Menu of the Alarm List
Function menu Operation/Explanation
Edit Go to step 2 on page 390.
Display detail You can display the detailed setting for the
alarm.
p You can display also by selecting stored
alarm.
Release this You can set the alarm to “OFF”.
 YES
Release all You can set all alarms to “OFF”.
 YES
Describes the
menu number.
(See page 33)
Describes a function
name. You can find
this name in Index.
You can search for
chapters from tabs.
Note:The page above is a sample.
Describes the
operating
procedures in each
step. (See page 31)
Describes the
options shown on
the display and
their explanations.
Describes cautions or
references required for
using each function.
Describes the item
names shown on the
display. (Some items
may not be available
depending on the
operation.)
Describes the display at an important point in the
procedure. See this while referring to the display
of the FOMA phone you are using. (Values,
settings, and entered characters are for reference.)
Describes the operation
and supplementary
explanation for each
item.
Describes the setting
at purchase.
The “Function List”
also lists the setting at
purchase.
(See page 456)
Describes the title of
each chapter.

4Easy Search/Contents/Precautions
Easy Search
To retrieve the operation for the desired function with simple words, refer to the following:
To know convenient functions for making calls
To/Not to notify your phone number to the other party.... 48 <Caller ID Notification>
To switch to a videophone call during a voice call ... 58 <Switch to Videophone Call>
To change a volume level of the other party’s voice..... 75 <Volume>
To put a call on hold during a call........................76 <Holding>
To do the following when you cannot answer calls
To put an incoming call on hold before answering.... 76 <On Hold>
To convey the message that you need to
refrain from talking on the phone ......................77
<Public Mode (Drive Mode)>
......................79 <Public Mode (Power Off)>
To record voice/video messages.........................80 < Record Message Setting >
To change melody or illumination
To adjust the ring volume ....................................75 <Ring Volume>
To change ring tones according to callers.........109 <Add to Phonebook>
To change ring tones.........................................128 <Select Ring Tone>
To know incoming calls by vibrator....................130 <Vibrator>
To silence the keypad sound.............................132 <Keypad Sound>
To activate Manner Mode..................................134 <Manner Mode>
To change colors/lighting patterns of Call
indicator for incoming calls..............................147
< Illumination Setting >
To change/know display settings
To know the meaning of marks (icons) on the display
.............................................................................26 <Display>
To change the menu display ...............................35 <EASY Mode>
To change the Stand-by display (Wallpaper) ....137 <Display Setting>
To display a calendar on the Stand-by display...... 137 <Calendar>
To change the character size ............................153 <Character Size>
To make full use of mail
To send Deco-mail............................................236 <Deco-mail>
To send images .................................................240 <Attachments>
To sort and save mail automatically ..................260 <Auto-sort>

5
Easy Search/Contents/Precautions
※ 1 This is a pay service.
※ 2 This is a pay service which is available on a subscription basis.
To make full use of camera
To shoot with the photo light..............................191 <Photo Light>
To change the shooting size..............................192 <Image Size Setting>
To save to the microSD memory card ...............193
< Storage Setting (Store In) >
To display shot images......................................322 <Picture Viewer>
To use the FOMA phone with a sense of security
To lock the FOMA phone from away
when it gets lost ..............................................161 <Omakase Lock>
※1
To lock the FOMA phone automatically
when you are away from it or have lost it........163 <ANSHIN-KEY Lock>
To keep Phonebook entries from prying eyes .... 172 <Secret Mode>
To reject calls without a caller ID.......................175 <Call Setting without ID>
To reject calls from the phone numbers
not in the Phonebook ......................................176 <Reject Unknown>
To separately store Phonebook and other
data files in preparation for their erasure ........177 <Data Security Service>
※2
Other things you can do
To reduce the battery consumption ...................139 <Power Saver Mode>
To scan QR codes or Bar codes .......................196 <Bar Code Reader
>
To check the location where you are,
or the surroundings ......................................... 302 <GPS Function>
To use the microSD memory card.....................347
<microSD Memory Card>
To exchange information using infrared rays ....357 <Infrared Data Exchange>
To listen to music...............................................374 <MUSIC Player>
To use the FOMA phone as an alarm clock ......390 <Alarm>
To use the FOMA phone as a calculator...........402 <Calculator>
To use the FOMA phone overseas....................448 <International Roaming>
To bring software programs up to date..............505 <Software Update>
To bring security up to date ...............................511 <Scanning Function>
p The operating procedures for frequently used functions are summarized in Quick Manual.(See page 530)

6Easy Search/Contents/Precautions
Contents
How to Read/Refer to This Manual ...................................1
Easy Search........................................................................ 4
Contents..............................................................................6
Main Functions of FOMA P904i......................................... 8
Making Full Use of FOMA P904i! .................................... 10
Safety Precautions .......................................................... 12
Notes on Handling ........................................................... 17
Intellectual Property Rights ............................................ 20
Accessories and Main Options ...................................... 22
Before Using the Handset
23
Phone Parts and Functions, Display, Method for Selecting Menu, EASY Mode,
Guide, UIM (FOMA Card), Battery, Charging, One-push Open,
Power ON/OFF, Select Language, Initial Setting, Set Time,
Caller ID Notification, Own Number, etc.
Voice/Videophone Calls
51
Making a Call/Videophone Call, WORLD CALL, Switching between a Voice Call and
Videophone Call, Call Records, Chaku-moji, Hands-free, Receiving a Call/
Videophone Call, Answer Setting, Volume, Ring Volume, Public Mode (Drive Mode),
Public Mode (Power Off), Record Message Setting, Chara-den, etc.
PushTalk
93
What is PushTalk?, Making a PushTalk Call, Receiving a PushTalk Call,
PushTalk Phonebook, Setting PushTalk Calling/Receiving, etc.
Phonebook
107
Phonebook, Add to Phonebook (FOMA phone/UIM), Group Setting,
Search Phonebook, Two-touch Dial, Voice Dial, etc.
Sound/Screen/Light
Settings
127
Select Ring Tone, Vibrator, Voice Announce, Manner Mode, Display Setting,
Private Window, Backlight, Color Pattern, Menu Icon Setting, Feel Settings,
Illumination Setting, Desktop Icon, Font, Clock Display, etc.
Security Settings
155
Passwords, Change Security Code, UIM Setting, Releasing PIN Lock, Lock All,
Self Mode, Personal Data Lock, Keypad Dial Lock, Secret Mode, Mail Security,
Restrictions, Call Setting without ID, Reject Unknown, etc.
Camera
179
Still Image Shoot, Moving Image Shoot, Settings for Shooting Images,
Setting Image Size/Image Quality, Bar Code Reader, Text Reader, etc.
i-mode/i-motion/i-Channel
203
What is i-mode?, i Menu, My Menu, Change i-mode Password, Bookmark,
Screen Memo, Download, i-mode Settings, Message R/F,
SSL Certificate, Client Certificate, What is i-motion?,
What is i-Channel?, etc.
Mail
229
i-mode Mail, Deco-mail, Template, Attachments, Photo-sending,
Mail Auto-receive, KirariMail, Receive Option, Check New Message,
Auto-sort, Chat Mail, SMS (Short Messages), etc.
i- α ppli
273
What is i- α ppli?, i- α ppliDownload, i- α ppliRun, Starting i- α ppliAutomatically,
i-
α ppliStand-by Display, Settings for when Running i- α ppli, i α ppli(microSD)
Osaifu-Keitai/ToruCa
291
What is Osaifu-Keitai?, What is iC Transfer Service?,
Osaifu-KeitaiCompatible i-
α ppli, What is ToruCa?, Obtain ToruCa Files,
ToruCa Viewer, ToruCa File List/Detailed ToruCa File Display,
ToruCa Settings, IC Card Lock

7
Easy Search/Contents/Precautions
GPS Function
301
What is GPS?, Position Location, Provide Location, Notify of Location,
GPS Settings, etc.
Full Browser
311
Full Browser, Full Browser Settings
Data Display/Edit/
Management
319
About Data Box, Picture Viewer, Original Animation, i-motion Player,
Chara-den, Melody Player, microSD Memory Card, Infrared Data Exchange,
iC Communication, PDF Viewer, AV Output, etc.
Music Playback
371
Playing Back Music, Saving Music Files, MUSIC Player, Playlist,
About SD-Jukebox
Other Convenient
Functions
385
Multiaccess, Multitask, Alarm, Schedule, ToDo, Private Menu Setting, Own
Number, Voice Memo, Movie Memo, Call Data, Calculator, Free Memo,
UIM Operation, Bluetooth, Reset Settings, Initialize, etc.
Character Entry
415
Character Entry, Common Phrases, Cutting/Copying/Pasting,
Own Dictionary, Learned Words, Download Dictionary, etc.
Network Services
425
Check Network Information, Voice Mail, Call Waiting, Call Forwarding,
Nuisance Call Blocking, Caller ID Request, Dual Network, English Guidance,
Service Numbers, In-call Management, Remote Access, MultiNumber, 2in1,
Additional Service, etc.
Data Communication
441
Available Data Communication, Before Using,
Preparation Flow for Data Communication, AT Command, About CD-ROM,
DoCoMo KeitaiDatalink
Overseas Use
447
Outline of International Roaming (WORLD WING), Available Services,
Confirmation for Using, Making a Call from the Country You Stay,
Receiving a Call, Network Search Mode, PLMN Setting,
Operator Name Display, Roaming Setting, Overseas Service
Appendix/External Devices/
Troubleshooting
455
Function List, Jacket Style and Non-Jacket Style, Options and Related Equipment,
Troubleshooting, Error Messages, Warranty and Maintenance Services,
i-mode Trouble Diagnosis Site, Software Update, Scanning Function,
Specifications, Export Administration Regulations, etc.
Index/Quick Manual
521
Index, Quick Manual, Quick Manual “For Overseas Use”

8Easy Search/Contents/Precautions
FOMA (Freedom Of Mobile multimedia Access) is the name of the DoCoMo service based on the W-CDMA
format, authorized as one of the world’s standards for third-generation mobile telecommunication systems
(IMT-2000).
Main Functions of FOMA P904i
Remarkable i-mode!
i-mode is an online service that enables you to get useful information from i-mode menu sites (programs) or web pages
supporting i-mode by using the screen of an i-mode phone.This service also enables you to send or receive mail messages
with ease.
◆ i-mode mail/Deco-mail/
Decomail-pictograph  P.230, P.236, P.469
Besides mail text, you can attach up to 2 Mbytes of files or
10 files (JPEG, ToruCa, PDF, etc.) in total.The FOMA
phone supports Deco-mail/Decomail-pictographs and you
can change the character color, character size, and
background color of mail text, so you can compose
pleasant mail messages to send.
◆Mega i- α ppli/i- α ppli DX P.274
By downloading i- α ppliprograms from sites, you can enjoy
playing games or have stock price information or weather
forecasts updated automatically.As the large capacity
mega i-
α ppliis supported, you can enjoy playing high-
resolution 3D games and full-length role playing games.
With i-
α ppliDX software, you can have more fun of i- α ppli
by linking with information inside the i-mode phone such
as the Phonebook entries or mail messages.
■ Support intuition games
You can enjoy playing i- α ppliprograms such as the games
supporting the motion tracking which enables you to
operate i-
α ppliprograms by inclining or swinging the
FOMA phone.
◆Chaku-uta Full®/Uta-hodai
P.374, P.372
Chaku-uta Full
®
enables you to obtain a whole music file
from a music distribution site for playback or for setting it as
a ring tone.At the flat rate, you can enjoy listening to music
as much as you like;for example, Uta-hodaienables you to
obtain a whole music file from the membership music site
on monthly fee basis.
p “Chaku-uta Full” is a registered trademark of Sony Music
Entertainment Inc.
◆Video Clips P.224
As up to 10 Mbytes of i-motion movie in H.264 format of
high compression rate is supported, you can enjoy a whole
range of music clip, or high-quality video clips such as
movies or animations.
◆ Osaifu-Keitai/ToruCa  P.292, P.294
By downloading Osaifu-Keitaicompatible i- α ppli, you can replenish electronic money from a site into the IC card in the
FOMA phone and check your account for the balance and usage details.As the “DCMX” i-
α ppliprogram that provides the
DoCoMo credit service is pre-installed, your FOMA phone as “Osaifu-Keitai” has now become more and more a convenient
tool in your daily life.Further, “iC transfer service” is supported so that you can easily move data from the existing IC card to
a new one when you replace your FOMA phone such as at the time of model change.
ToruCa is an electronic card that you can obtain from scanning devices (reader/writer) or sites and can easily exchange
using mail or infrared data exchange.
◆ International Roaming  P.448
You can use your FOMA phone, its phone number, and
mail address overseas as they are.(In 3G roaming area
only)
Voice calls, videophone calls, i-mode, i-mode mail, SMS,
and network services are available.
◆GPS P.302
You can obtain the location information of the FOMA
phone using radio waves transmitted from the GPS
satellites.You can use that obtained location information
to bring up a map of your current location and search for
information of the surrounding area, notify of your location
by attaching to mail, and navigate yourself to the place
where you want to go.(The navigation i-
α ppliprogram is
pre-installed.)
