Docomo FOMA P905ITV User manual

FOMA®P905iTV
ISSUE DATE:
NAME:
PHONE NUMBER:
MAIL ADDRESS:
INSTRUCTION MANUAL
Easy Search/Contents/Precautions
Before Using the Handset
Voice/Videophone Calls
PushTalk
Phonebook
Sound/Screen/Light Settings
Security Settings
Camera
i-mode/i-motion/i-Channel
Mail
i-αppli
Osaifu-Keitai/ToruCa
One Seg
Full Browser/PC Movie
Data Display/Edit/Management
Music&Video Channel/Music Playback
Other Convenient Functions
Character Entry
Network Services
PC Connection
Overseas Use
Appendix/External Devices
Troubleshooting
Index/Quick Manual
‘08.2

DoCoMo W-CDMA system
Thank you for selecting the “FOMA P905iTV”.
Before or during use of the FOMA P905iTV , make sure that you read this
manual and the separate manuals for other optional devices thoroughly so
that you can use the FOMA P905iTV correctly.
If you feel any inconvenience in reading the manual, contact the DoCoMo
Information Center listed on the back page of this manual.
The FOMA P905iTV is designed to be your close partner. Treat it carefully at
all times to ensure long-term performance.
●Because the FOMA phones use radio waves, they cannot be used in
places where radio waves do not reach, such as inside tunnels,
underground, or in buildings; or the outside where radio waves are weak or
out of the FOMA service area. They may not be used in the high-rise
buildings even when the antennas are unobstructed. You may also
experience interruption of calls even when using without moving while the
radio waves are strong enough for the three antennas to appear on the
display.
●Use the FOMA phone carefully to avoid disturbing other people when in
public, or in crowded or quiet places.
●Since the FOMA phones use radio waves as the medium of
telecommunication, calls may be tapped by the third party. However, the
W-CDMA system automatically supports tapping prevention, so your
conversation will be incomprehensible to the third party.
●The FOMA phones change your voice into digital signals and send them to
the other party. In places where the radio waves are weak, the digital
signals may not be converted correctly, and in such a case, the voice may
sound different from the actual original voice.
●The user hereby agrees that the user shall be solely responsible for the
result of the use of SSL. Neither DoCoMo nor the certifiers as listed herein
make any representation and warranty as for the security in the use of
SSL. In the event that the user shall sustain damage or loss due to the use
of SSL, neither DoCoMo nor the certifiers shall be responsible for any such
damage or loss.
Certifiers: VeriSign Japan K.K., Cybertrust, Inc., GlobalSign K.K.,
RSA Security Inc., and SECOM Trust Systems Co., Ltd.
●This FOMA phone supports FOMA Plus-Area and FOMA High-Speed
Area.
●The FOMA terminal can be used only via the FOMA network provided by
DoCoMo and in DoCoMo’s roaming area.
●It is recommended that you make separate notes of the information (such
as Phonebook entries, schedule events, text memos, record messages,
voice memos, movie memos) stored in the FOMA phone and keep them in
a safe place. Note that we cannot be held responsible for the unlikely
event of loss of the stored contents due to a malfunction, repair, change of
your model, or other mishandling of the FOMA phone.
●You are advised to save your important data files to the microSD memory
card. If you have a personal computer, you can transfer and save the
information such as Phonebook entries, mail messages, schedule events,
and others to the personal computer by using DoCoMo keitai datalink.
For Using This Manual
This FOMA phone supports Kisekae Tool (page 117). If you use
Kisekae Tool to change the design of the Menu display, some
menu configurations change according to the usage frequency
depending on the type of the menu. Further, some menu
numbers that are assigned to the menu items do not apply.
In that case, you cannot operate as described in this manual, so
you are advised to switch to the basic structure menu
(page 118), or reset menu settings (page 118).
You can download the latest information about this manual
from the following DoCoMo web site:
・User’s Manual (PDF file) Download
(
http://www.nttdocomo.co.jp/english/support/manual/index.html )
※The URL and the content of the web site might be modified
without notice.
Before using your FOMA phone

1
Easy Search/Contents/Precautions
Easy Search/ Contents/Precautions
In this manual, illustrations and symbols are used in the explanations so
that you can correctly and easily use the FOMA phone.
≥The operating procedures and displays in this manual are described with the default
settings of the “White” handset. However, the following settings are changed.
・“Display setting” →“Stand-by display”: OFF
・“Display setting” →“Clock” →“Position”: Pattern 2
≥Unless otherwise specified, the descriptions of the operating procedures in this manual
start from the Stand-by display.
≥Operations are described in the method of “Scroll Selection” (see page 32).
≥Displays and illustrations described in this manual are for reference. The actual ones
might differ.
≥In this manual, “Osaifu-Keitai compatible i-αppli which supports the IC card function” is
described as “Osaifu-Keitai compatible i-αppli”.
≥Note that “FOMA P905iTV” is referred to as “FOMA phone” in this manual.
≥In the operating procedures of this manual, key operations are described with
simplified key icons.
≥The functions which use a microSD memory card are described in this manual;
however, you need to obtain a microSD memory card separately to make these
functions available. See page 326 for the microSD memory card.
How to Read/Refer to This Manual By the following search methods, you can find pages where your desired
functions and services are described:
How to Refer to This Manual
Search from the index when you know the names of functions or services.
Search from keywords for the functions you frequently use or the functions that are
convenient if you can know any.
Search from the tabs printed on the cover.
See the next page for details.
Search from the contents that categorize functions.
Search from here to use the main functions.
Search from the function list.
Quick Manual gives you a clear, brief description about basic functions. You can take it
when you go out. Further, Quick Manual “For Overseas Use” is attached, so refer to it
when you use the FOMA phone overseas.
From the Index
From Easy Search
From the Tabs on the Cover
From the Contents 11 P.6
From the Main Functions 11 P.8
From the Function List 11 P.452
From Quick Manual 11 P.518
It is prohibited to copy all or part of this manual without permission.
The instructions contained in this manual may be changed without notice.

2
Easy Search/Contents/Precautions
How to search for “Alarm” is explained here as an example of search method.
Additional service . . . . . . . . . . . . . .432
Additional guidance . . . . . . . . . . .433
Address link function. . . . . . . . . . . .179
Alarm. . . . . . . . . . . . . . . . . . . . . . . .378
Alarm setting . . . . . . . . . . . . . . . . . .386
Answer setting . . . . . . . . . . . . . . . . .65
Antenna. . . . . . . . . . . . . . . . . . . . . . .27
From the Index
11P.510
Search for a function or a service
name as shown on the right.
Search for the function you
frequently use or that is
convenient if you can know any
as shown on the right.
Other things you can do
To reduce the battery consumption .............................. <Power Saver Mode> 115
To scan QR codesor bar codes...................................... <Bar Code Reader> 157
To use the microSD memory card ...........................<microSD Memory Card> 326
To exchange information using infrared rays......... <Infrared DataExchange> 339
To listen to music.................................................................. <MUSIC Player> 363
To use the FOMA phone as an alarm clock .......................................<Alarm> 378
To use the FOMA phone as acalculator .....................................<Calculator> 391
To use the FOMA phone overseas...........................<International Roaming> 442
To bring software programsup to date............................. <Software Update> 496
To bring security up to date ........................................... <Scanning Function> 502
Go to page 378
where “Alarm”
is explained.
From Easy Search
11P.4
i-αppli
Osaifu-Keitai/ToruCa
One Seg
Full Browser/PC Movie
Data Display/Edit/Management
Music&Video Channel/Music Playback
Other Convenient Functions
Character Entry
Network Services
PC Connection
Overseas Use
Appendix/External Devices
Troubleshooting
Index/Quick Manual
Multitask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Multitask> 375
InformingYou of an IncomingCall/Mail Message by Voice
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <ReadingAloud> 376
TurningPower On/Off Automatically at a Specified Time
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Auto Power ON/OFF> 378
UsingAlarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Alarm> 378
UsingCalendar to Manage Schedule . . . . . . . . . . .<Schedule> 381
UsingToDo to Manage Schedule . . . . . . . . . . . . . . . . . <ToDo> 385
SettingOperatingConditionsof Alarm . . . . . <Alarm Setting>386
From the Tabs on the
Cover
11Cover page Search for the function you want
to set in the order of “Cover”
→“First page of Chapter”
→“Description page” as shown
on the right.

3
Easy Search/Contents/Precautions
378
Other Convenient Functions
You can set Alarm to alert you at the specified time with an alarm tone,
animation and illumination. You can store up to five alarms.
1mStationeryAlarm
Highlight an alarm and press
l()
Do the followingoperations.
2Press l().
+m-4-4
<Alarm>
UsingAlarm
Item Operation/Explanation
Alarm Youcan set whether to validate or invalidate the alarm.
ON or OFF
Time Enter the time for soundingthe alarm.
pYoucannot set the same time as the time set for the stored
alarm.
Tone Select a type of alarm toneSelect a folder
Select an alarm tone.
Volume Use Boto adjust the volume.
pIf youset “Step”, the alarm tone issilent for about three
seconds, and then the volume stepsup every about three
seconds, from Level 1 through Level 6.
Prefer manner
mode
Youcan set the alarm tone which soundsat the specified time
during Manner Mode.
ON or OFF
ON. . . . . Soundsat the same volume as set for “Alarm volume”.
OFF. . . . Soundsat the volume set for thisfunction.
The icon appearson the desktop.
“”. . . . Displayed when an alarm isset for today (except the setting for past time).
“”. . . . Displayed when an alarm isset for tomorrow or onward only.
pIf youset “Display setting”
→ “Clock” → “Clock display”to “OFF”, or set “Alarm”of the
stored schedule event/ToDo item to “OFF”, the iconsare not displayed.
Function Menu while Alarm isdisplayed
Function menu Operation/Explanation
Edit Go to step 1 of “Using Alarm”on page 378.
Detail Youcan display the stored alarm contents.
Set thisYoucan validate the stored alarm.
YES
pYoucan validate also by pressing Oo().
Set all Youcan validate all the stored alarm.
YES
Delete
(Delete this)
Delete thisYES
Delete
(Delete all)
Enter you Terminal Security CodeYES
Information
pDuring acall, the alarm tone soundsat the level set for “Volume”(earpiece volume).
pWhen youset the power to automatically turn on and an alarm to sound, the default
alarm tone soundsif the alarm which isset with the UIM restrictionshas been
selected.
pTurn off the FOMA phone after setting “Auto power ON”to “OFF”when youare near
electronic devicesusing high-precision control or weak signals, or where the use is
prohibited such as in airplanesand hospitals.
When you set an alarm for “Alarm”, “Schedule”, and “ToDo”
Note: The page above is a sample.
Menu number
(See page 34)
Function name
You can find this in
Index.
Operating
procedure
(See page 32)
Reference display
(Characters and settings
are for reference.)
Options and their
explanations
Items shown on the
display
(Some items cannot
be executed.)
Operation and
supplementary
explanation for each
item
Operations related to
the function and
explanations for
supplementary
operations
Chapter title
You can
search by
chapter.
Cautions or
references for using
each function
Lower sub-menu item
of the Function menu

4
Easy Search/Contents/Precautions
Easy Search
To retrieve the operation for the desired function with simple
words, refer to the following:
To know convenient functions for making calls
To/Not to notify your phone number to the other party
....................................................................................<Caller ID Notification> 46
To switch to a videophone call during a voice call
...........................................................................<Switch to Videophone Call> 53
To change a volume level of the other party’s voice ....................... <Volume> 67
To put a call on hold during a call.................................................... <Holding> 68
To do the following when you cannot answer calls
To put an incoming call on hold before answering ......................... <On Hold> 68
To convey the message that you need to refrain from talking on the phone
...........................................................................<Public Mode (Drive Mode)> 69
............................................................................. <Public Mode (Power Off)> 69
To record voice/video messages.......................... <Record Message Setting> 71
To change melody or illumination
To adjust the ring volume........................................................ <Ring Volume> 67
To change ring tones according to callers......................<Add to Phonebook> 90
To change ring tones........................................................<Select Ring Tone> 106
To know incoming calls by vibrator .................................................<Vibrator> 108
To silence the keypad sound................................................<Keypad Sound> 109
To activate Manner Mode...................................................... <Manner Mode> 110
To change colors/lighting patterns of Call indicator for incoming calls
.................................................................................................. <Illumination> 119
To change/know display settings
To know the meaning of marks (icons) on the display .....................<Display> 30
To change the menu display .................................................. <Simple Menu> 36
To change the Stand-by display (Wallpaper) ...................... <Display Setting> 112
To display a calendar on the Stand-by display..............................<Calendar> 112
To change the character size ...............................................<Character Size> 124
To make full use of mail
To send Deco-mail ...................................................................... <Deco-mail> 194
To send images ....................................................................... <Attachments> 198
To sort and save mail automatically ..............................................<Auto-sort> 217
To make full use of camera
To shoot with the photo light...................................................... <Photo Light> 153
To change the shooting size...................................................... <Image Size> 153
To save to the microSD memory card .................<Storage Setting (Store In)> 154
To display shot images......................................................... <Picture Viewer> 302

5
Easy Search/Contents/Precautions
※1 This is a pay service.
※2 This is a pay service which is available on a subscription basis.
To use the FOMA phone with a sense of security
To lock the FOMA phone from away when it gets lost .... <Omakase Lock>※1131
To keep Phonebook entries from prying eyes .........................<Secret Mode> 134
To reject calls without a caller ID ..............................<Call Setting without ID> 137
To reject calls from the phone numbers not
in the Phonebook ............................................................ <Reject Unknown> 138
To separately store Phonebook and other data
files in preparation for their erasure.................... <Data Security Service>※2138
To make full use of One Seg
To watch One Seg programs................................................. <Activate 1Seg> 268
To record One Seg programs............ <Record Video> <Record Still Images> 276
To book/To set timer recording for One Seg programs
...............................................................<Book Program> <Timer Recording> 277
To change settings of video and audio...................................<User Settings> 282
Other things you can do
To reduce the battery consumption .............................. <Power Saver Mode> 115
To scan QR codes or bar codes ...................................... <Bar Code Reader> 157
To use the microSD memory card ...........................<microSD Memory Card> 326
To exchange information using infrared rays......... <Infrared Data Exchange> 339
To listen to music.................................................................. <MUSIC Player> 363
To use the FOMA phone as an alarm clock .......................................<Alarm> 378
To use the FOMA phone as a calculator .....................................<Calculator> 391
To use the FOMA phone overseas...........................<International Roaming> 442
To bring software programs up to date............................. <Software Update> 496
To bring security up to date ........................................... <Scanning Function> 502
≥The operating procedures for frequently used functions are summarized in Quick
Manual. (See page 518)

6
Easy Search/Contents/Precautions
Contents
How to Read/Refer to This Manual ... 1
Easy Search........................................4
Contents .............................................6
Main Functions of FOMA P905iTV....8
Making Full Use of FOMA P905iTV!
...........................................................10
Safety Precautions .......................... 12
Notes on Handling........................... 18
Intellectual Property Rights............ 22
Accessories and Main Options ...... 24
Before Using the
Handset
25
Phone Parts and Functions, Display,
Method for Selecting Menu, Simple Menu,
UIM (FOMA Card), Battery, Charging, Power ON/OFF,
Select Language, Initial Setting, Set Time,
World Time Watch, Caller ID Notification, Own Number,
etc.
Voice/Videophone
Calls
49
Making a Call/Videophone Call, Call Records,
Chaku-moji, WORLD CALL, Hands-free,
Receiving a Call/Videophone Call, Volume,
Ring Volume, Public Mode (Drive Mode),
Public Mode (Power Off), Record Message Setting,
Chara-den, etc.
PushTalk
79
What is PushTalk?, Making a PushTalk Call,
Add Member, Receiving a PushTalk Call,
PushTalk Phonebook,
Setting PushTalk Calling/Receiving, etc.
Phonebook
89
Available Phonebooks,
Add to Phonebook (FOMA phone/UIM),
Group Setting, Search Phonebook,
No. of Phonebook, Two-touch Dial, Voice Dial,
Data Security Service, etc.
Sound/Screen/
Light Settings
105
Select Ring Tone, Vibrator, Manner Mode,
Display Setting, Backlight, Menu Icon Setting,
Kisekae Tool, Feel Settings, Illumination, Desktop Icon,
Font, Character Size, etc.
Security Settings
127
Passwords, Change Security Code,
Releasing PIN Lock, Lock All, Omakase Lock,
Self Mode, Personal Data Lock, Keypad Dial Lock,
Secret Mode, Mail Security, Call Setting without ID,
Reject Unknown, etc.
Camera
141
Before Using Cameras, Still Image Shoot,
Moving Image Shoot, Settings for Shooting Images,
Setting Image Size/Image Quality,
Bar Code Reader, Text Reader
i-mode/i-motion/
i-Channel
163
What is i-mode?, iMenu, My Menu,
Change i-mode Password, Enter URL, Bookmark,
Screen Memo, Download, i-mode Settings,
SSL Certificate, Client Certificate, What is i-motion?,
What is i-Channel?, etc.
Mail
189
i-mode Mail, Deco-mail, Template, Attachments,
Photo-sending, Mail Auto-receive, Receive Option,
Check New Message, Message R/F,
What is Emergency Alert “Area Mail”?, Chat Mail, SMS,
Web Mail, etc.
i-αppli
233
What is i-αppli?, i-αppli Download,
i-αppli Run, iαppli Settings,
Starting i-αppli Automatically, i-αppli Stand-by Display,
iαppli(microSD)
Osaifu-Keitai/
ToruCa
253
What is Osaifu-Keitai?, What is iC Transfer Service?,
Osaifu-Keitai Compatible i-αppli, What is ToruCa?,
Obtain ToruCa Files, ToruCa Viewer, ToruCa File List/
Detailed ToruCa File Display, ToruCa Settings,
IC Card Lock

7
Easy Search/Contents/Precautions
One Seg
263
What is One Seg?, Before Using One Seg,
Channel Setting, Activate 1Seg,
Program Guide i-αppli, Data Broadcasting, TVlink,
Recording One Seg, Book Program/Timer Recording,
User Settings
Full Browser/
PC Movie
285
Full Browser, Full Browser Settings,
What is PC Movie?, Downloading PC Movies,
PC Movie Player
Data Display/Edit/
Management
299
Data Box, Picture Viewer, i-motion Player,
Video Player, Chara-den, Melody Player,
Kisekae Tool, microSD Memory Card,
Managing Folders, Infrared Data Exchange,
iC Communication, PDF Viewer, etc.
Music&Video
Channel/
Music Playback
353
What is Music&Video Channel?, Setting Programs,
Playing Back/Operating Programs,
Playing Back Music, Saving Music Files,
MUSIC Player, Playlist
Other Convenient
Functions
373
Multiaccess, Multitask, Reading Aloud, Alarm,
Schedule, ToDo, Own Number, Voice Memo,
Movie Memo, Call Data, Calculator, Text Memo,
UIM Operation, Bluetooth, Reset Settings, Initialize, etc.
Character Entry
405
Character Entry, Mode 1 (5-touch),
Common Phrases, Cut/Copy/Paste, Own Dictionary,
Learned Words, Download Dictionary,
Mode 2 (2-touch), Mode 3 (NIKO-touch)
Network Services
415
Check New Messages, Voice Mail, Call Waiting,
Call Forwarding, Nuisance Call Blocking,
Caller ID Request, Dual Network, Service Numbers,
Remote Control, Multi Number, 2in1, OFFICEED, etc.
PC Connection
435
Available Data Communication, Before Using, Preparation
Flow for Data Transmission (OBEX™ Communication),
Preparation Flow for Data Communication, AT Command,
CD-ROM, DoCoMo Keitai Datalink
Overseas Use
441
Outline of International Roaming (WORLD WING),
Available Services, Confirmation for Using,
Making a Call from the Country You Stay,
Receiving a Call, Set Roaming Guidance,
Network Services, etc.
Appendix/
External Devices/
Troubleshooting
451
Function List, Options and Related Equipment,
Troubleshooting, Error Messages, Warranty and
Maintenance Services, i-mode Trouble Diagnosis Site,
Software Update, Scanning Function, Specifications,
SAR, Export Administration Regulations, etc.
Index/
Quick Manual
509
Index, Quick Manual, Quick Manual “For Overseas
Use”

8
Easy Search/Contents/Precautions
FOMA (Freedom Of Mobile multimedia Access) is the name of the
DoCoMo service based on the W-CDMA format, authorized as one of the
world’s standards for third-generation mobile telecommunication
systems (IMT-2000).
Main Functions of FOMA P905iTV
Remarkable i-mode!
i-mode is an online service that enables you to get useful information from i-mode
menu sites (programs) or i-mode web pages. This service also enables you to send or
receive mail messages with ease.
◆ i-mode mail/Deco-mail/Decomail-pictograph 11P.190, P.194, P.300
Besides mail text, you can attach up to 2 Mbytes of files or 10 files (JPEG, ToruCa,
PDF, etc.) in total. The FOMA phone supports Deco-mail/Decomail-pictographs, so
you can change the character color, character size, and background color of mail text,
and insert images and moving pictographs.
◆Mega i-αppli 11P.234
By downloading i-αppli programs from sites, you can enjoy playing games or have
stock price information or weather forecasts updated automatically. As the large
capacity mega i-αppli is supported, you can enjoy playing high-resolution 3D games
and full-length role playing games.
◆High-Speed Area Supported 11P.436
FOMA High-Speed Area is supported so that high speed communication is available
with download speed of up to 3.6 Mbps and upload speed of up to 384 kbps.
◆International Roaming 11P.442
You can use your FOMA phone, phone number, and mail address overseas as they
are. (Supported only in 3G area)
Voice calls, videophone calls, i-mode, i-mode mail, SMS, and network services are
available.
“しゃべって翻訳 for P (Speech Translation for P)”, which translates spoken Japanese
into English and spoken English into Japanese, is pre-installed.
◆Chaku-uta Full®/Uta-hodai/Music&Video Channel※/Video Clips
11P.184, P.354, P.361, P.363
This FOMA phone supports Chaku-uta Full®that enables you to download a whole
music file and Uta-hodai that enables you to enjoy listening music as much as you like
at a flat rate.
This FOMA phone also supports Music&Video Channel that, just by setting up
beforehand, automatically downloads music programs in the night. You can watch
programs containing moving images on your P905iTV. Further, this FOMA phone
supports up to 10 Mbytes of i-motion movies, so it also supports Video Clip that
enables you to enjoy a whole music clip file.
≥“Chaku-uta Full” is a registered trademark of Sony Music Entertainment Inc.
※This is a pay service which is available on a subscription basis.
◆Osaifu-Keitai/ToruCa 11P.254, P.256
By downloading Osaifu-Keitai compatible i-αppli, you can replenish electronic money
from a site into the IC card in the FOMA phone and check your account for the balance
and usage details. In addition, the “DCMX” i-αppli program that provides the DoCoMo
credit service is pre-installed. Further, “iC transfer service” is supported so that you can
easily move data from the existing IC card to a new one when you replace your FOMA
phone such as at the time of phone model change.
ToruCa is an electronic card that you can obtain from scanning devices or sites and
can easily exchange using mail or infrared data exchange.
◆Kisekae Tool 11P.117, P.325
By downloading the displays of your favorite characters from an i-mode site, you can
change the Stand-by display or Menu display at a time.
You can change the order of displayed menus on P905iTV according to the frequency
of use to customize the Menu display as you like.
