INSTRUCTIONMANUAL
SC-03E

Introduction
Thankyouforpurchasing"SC-03E"mobileterminal.
Beforeandduringuseofyourterminal,besureto
thoroughlyreadthisinstructionmanualtoensure
youareabletocorrectlyuseyourterminal.
Manual
■ "クイックスタートガイド(Quickstartguide)"
(includedinbasicpackage)(InJapaneseonly)
Screenviewcontentsandoperationsofbasic
functionareexplained.
■ "Manual"(guideapplicationoftheterminal)(In
Japaneseonly)
Detailedguidanceofeachfunctionandthe
operationsareexplained.
• FromtheHomescreen, andtap"Manual".
Forsomefunctions,tapthewrittencontents,
andyoucanseethecontentorstartthe
functiondirectlyfromthedescription.
• Forthefirsttime,downloadandinstallthe
applicationaccordingtoonscreeninstructions.
• Forinstalling"Manual"applicationifyou
uninstalledit,fromtheHomescreen, →
From"SamsungApps"→ →"Downloads"to
download"Manual"application.
■ "INSTRUCTIONMANUAL"(PDFfile)
Detailedguidanceofeachfunctionandoperations
areexplained.
• DownloadfromNTTDOCOMOwebsite:
http://www.nttdocomo.co.jp/english/support/
trouble/manual/download/index.html
* Youcandownloadtheupdatedinformationof
theQuickstartguide(inJapaneseonly).URL
andthecontentsaresubjecttochangewithout
priornotice.

1
Operationdescriptions
Inthismanual,theoperationstepssuchasthe
menuoperationsaresimplydescribedasfollows.
• "Tap"isanoperationoftouchinglightlythedisplay
oftheterminalwithfinger(P.77).
(Example)Fortapping (Applicationsicon)on
theHomescreentodisplaytheapplicationmenu
andthen,tapping (Googleicon),theoperationis
describedasfollows.
1FromtheHomescreen, →"Google"
• Inthismanual,theoperationstepsandscreen
imagesaredescribedindefaultstatus.The
operationstepsorscreenimageonthe
terminalmayvarybytheserviceyouuseor
applicationyouinstalled.
• Thismanualdescribesinthecaseof"docomo
PaletteUI"astheHomeapplication.Fromthe
Homescreen,tap"Changehome",youcan
switchhomeapplication.
• Theimagesandillustrationusedinthis
manualareexamples.Theymaydifferfromthe
actualdisplays.
• Inthismanual,functionorsettingthatis
availableinmultipleoperationsareexplained
mostlywiththeeasilyunderstandable
operationsteps.
• Inthismanual,"SC-03E"mobileterminalis
usuallyreferredtoas"terminal".Pleasebe
forewarned.
• Reproductionofthecontentofthismanualin
partorinwholeisprohibited.
• Thecontentofthismanualissubjectto
changewithoutnotice.

2Assembling
Accessories/samplesand
options
■ Basicpackage
SC-03E
(includingthewritten
warranty)
BackCoverSC09
Quickstartguide
(Japanese) BatteryPackSC07
USBCableSC 02

3Assembling
■ Samples
microSDcard(2GB) StereoHeadsetwith
Microphone
R
L
■ Mainoptions
HDMIcableSC03
(withoperation
manual)
Otheroptions→ P.448

4Assembling
Contents
Assembling
Getting
started
docomo
PaletteUI
Accessories/samplesand
options……………………………… 2
Contents…………………………… 4
Aboutusageofthisterminal… 8
Safetyprecautions(Always
followthesedirections) …… 11
Handlingprecautions………… 39
Partnamesandfunctions … 53
docomominiUIMcard ……… 56
microSDcard…………………… 59
Batterypack…………………… 62
Charging………………………… 65
TurningpowerON/OFF……… 72
BasicOperation……………… 76
Initialsettings ………………… 109
NotificationLED ……………… 112
Displayandicons …………… 113
UsingQuicksearchbox …… 120
Openingalistofrecently-used
application……………………… 124
Checking/Endingarunning
application……………………… 125
Homescreen…………………… 127
ManagingHomescreen …… 130
Applicationscreen…………… 142
Managingapplications……… 153
Managinggroups……………… 154
Searchingapplications……… 156
SwitchingApplicationscreen
……………………………………… 156
Installing"Recommends"
applications …………………… 157
Homescreeninformation…… 158

5Assembling
Calling
Mail/Web
browser
Settings
File
management
Makingacall…………………… 159
Receivingacall ……………… 164
Operationduringacall……… 168
Calllogs ………………………… 172
Makinganinternationalcall
(WORLDCALL)………………… 176
Callsettings…………………… 178
Phonebook……………………… 189
docomobackup ……………… 201
sp-modemail…………………… 202
SMS ……………………………… 203
Email……………………………… 211
Gmail……………………………… 224
EarlyWarning"AreaMail"…… 226
Talk ……………………………… 229
Webbrowser…………………… 231
Settingmenu ………………… 245
Home …………………………… 246
Wirelessandnetwork ……… 247
Device …………………………… 270
Personal ………………………… 287
Accounts………………………… 306
System…………………………… 310
Myfiles…………………………… 319
Bluetooth ……………………… 323
PCconnection………………… 329
AllSharePlay…………………… 333
Usingaprinter………………… 336

6Assembling
Application
International
roaming
dmenu …………………………… 338
dmarket ………………………… 339
PlayStore ……………………… 340
SamsungApps………………… 342
Osaifu-Keitai…………………… 343
ToruCa…………………………… 348
1Seg……………………………… 350
Camera…………………………… 371
Gallery …………………………… 382
Player …………………………… 387
GPS/Navigation ……………… 400
Clock……………………………… 406
SPlanner………………………… 410
SMemo ………………………… 411
VoiceRecorder………………… 418
Calculator ……………………… 421
docomobackup ……………… 422
YouTube………………………… 426
Dictionary ……………………… 428
PolarisOffice…………………… 431
Overviewofinternationalroaming
(WORLDWING)………………… 434
Availableservices …………… 435
Beforeusingtheterminal … 436
Making/Receivingcallsinthe
countryyoustay……………… 440
Settingforoverseasnetwork
connection……………………… 444
AfterreturningtoJapan …… 447

7Assembling
Appendix/
Index
Introductionofoptionsand
relateddevices………………… 448
Sampleaccessories ………… 450
Troubleshooting ……………… 454
SmartphoneAnshinRemote
Support ………………………… 471
WarrantyandAfter-SalesService
……………………………………… 472
Updatingsoftware…………… 477
Mainspecifications ………… 480
SpecificAbsorptionRate(SAR)
ofMobilePhones……………… 487
FCCnotice……………………… 490
FCCRFexposureinformation
……………………………………… 492
Body-wornoperation ………… 493
EuropeanRFExposure
Information……………………… 494
DeclarationofConformity … 495
ExportAdministration
Regulations …………………… 497
IntellectualPropertyRight … 498
CancelingSIMLock ………… 504
Index……………………………… 505

8Assembling
Aboutusageofthisterminal
• TheterminalsupportsLTE,W-CDMA,GSM/GPRS,
andwirelessLAN.
• Becauseyourterminaluseswirelesstransmission,
itmaynotfunctioninlocationswhereitisdifficult
forradiowavestopenetrate,suchastunnels,
undergroundpassagesandsomebuildings,in
areaswhereradiowavesareweak,oroutofXi
serviceareaandFOMAservicearea.Evenwhen
youarehighupinatallbuildingorcondominium
andnothingblocksyourviewoutside,yourterminal
maynotbeabletoreceiveortransmitsignals.
Also,communicationmaybeinterruptedeven
whenthesignalmeteronyourterminalindicates
therearestrongradiowavesandyouarenot
moving(traveling).
• Becauseyourterminalusesradiowavesto
communicate,itispossiblethatathirdpartymay
attempttotapyourcalls.However,LTE,W-CDMA,
GSM/GPRSsystemautomaticallyappliesa
confidentialcommunicationfunctiontoallcalls,
soevenifathirdpartycouldsomehowtapacall,
theyonlyhearnoise.
• Thisterminalencodesvoicecommunicationas
digitaldata.Whenyouareoperatingyourterminal
whilemovingtoalocationsubjecttoweakerradio
waveconditions,thetransmitteddigitaldata
maynotbecorrectlydecodedandasaresult
thedecodedvoicemaydiffersomewhatfromthe
actualvoice.
• ThisterminalsupportsXiArea,FOMAPlus-Area
andFOMAHIGH-SPEEDArea.
• Notedowntheinformationsavedinthisterminal
inaseparatenoteandkeepitsafely.Notethat
DOCOMOassumesnoresponsibilityforanylossof
savedcontentsofdataresultingfrommalfunction,
repair,changingofthemodelorotherhandlingof

9Assembling
theterminal.
• Youarerecommendedtosaveimportantdatato
microSDcard.
• AswithPCs,someapplicationsthatyouperform
installationmaygivetheterminalinstabilityofthe
operation,ormaysendyourlocationinformationor
personalinformationregisteredtothisterminalto
outsideviatheInternetandtheinformationmay
beusedimproperly.Therefore,verifythesupplier
andoperatingconditionsoftheapplications
beforeusethem.
• OnlythedocomominiUIMcardisavailableforthis
terminal.IfyouhavetheUIMcardortheFOMA
card,exchangeitforthedocomominiUIMcardat
thedocomoShop.
• Thisterminaldoesnotsupportaccessingi-mode
site(programs)andi-αppli,etc.
• Thisterminalautomaticallyperforms
communicationforsomefunctions,forexample,
tosynchronizedata,checkthelatestsoftware,
maintainconnectionwiththeserver,etc.And
whenyoudownloadapplicationsorwatchvideo
etc.,alargeamountofpacketcommunication
chargesareexecuted.Therefore,itishighly
recommendedtousepacketflat-rateservice.
• Dependingonapplicationsorservicesyouuse,a
packetcommunicationfeemaybechargedevenif
youperformWi-Ficommunication.
• ThisterminaldoesnotsupportPublicmode
(Drivingmode).
• Inthisterminal,sounds(videosound,music
shuttersound,etc.)otherthanringtoneandeach
notificationarenotmutedevenwhenSilent(Mute,
Vibrate)isset.
• Followtheinstructionbelowtoviewyourphone
number.FromtheHomescreen, →"Settings"
→"Aboutdevice"→"Status"
• Youcanupdatesoftwareoftheterminaltothe
latestone(P.477).

10 Assembling
• Inthisterminal,functionsmaybeaddedor
operationstepsmaybechangedduetoupgrading
OperatingSystem(OS).Forlatestinformationof
additionalfunctionoroperationsteps,refertoNTT
DOCOMOwebsite.
• WhenOSisupgraded,someapplicationsusedfor
formerOSmaynotworkorunintendedfailuremay
occur.
• Googleapplicationsorservicesaresubjectto
changewithoutpriornotice.
• ForservicesprovidedbyGoogle,thoroughlyread
theTermsofuseofGoogleInc.Andforotherweb
services,readeachtermsofuse.
• Incaseoflossoftheterminal,setthescreento
ensurethesecurityoftheterminal.
• Ifyouloseyourterminal,changepasswordof
onlineserviceaccountsfromPCforthatGoogle
ServicessuchasGoogleTalk,Gmail,GooglePlay,
andFacebook,etc.shouldnotbeusedbyothers.
• Theterminaldoesnotsupportserviceproviders
otherthansp-mode,moperaUorBusinessmopera
Internet.
• Tousetethering,youmustsubscribetosp-mode.
• Dependingonyourpriceplan,packet
communicationfeewhenusingtetheringdiffers.
Usingpacketflat-rateserviceishighly
recommended.
• Fordetails,referto
http://www.nttdocomo.co.jp/english

11 Assembling
Safetyprecautions(Always
followthesedirections)
■ Beforeusingyourterminal,readthe
precautionsbelowtoensuresafeuseand
handling.Afterreadingthismanual,keep
itcarefully.
■ Theseprecautionsareintendedtoprotect
youandothersaroundyou.Readand
followthemcarefullytoavoidinjury,
damagetotheproductordamageto
property.
■ Thesignsbelowdifferentiatebetween
thelevelsofdangerthatcanoccurifthe
productisnotusedwithinthespecified
guidelines.
DANGER
Thissigndenotesthat
deathorseriousinjury
maydirectlyresultfrom
improperuse.
WARNING
Thissigndenotesthat
deathorseriousinjury
mayresultfromimproper
use.
CAUTION
Thissigndenotesthat
minorinjuryordamageto
propertymayresultfrom
improperuse.

12 Assembling
■ Thesymbolsbelowshowspecific
directions.
Dont
Thissymboldenotesthatthe
actionisprohibited.
No
disassembly
Thissymboldenotesthat
disassemblingthephoneorits
componentsisnotallowed.
No
liquids
Thissymboldenotesthatusing
phoneoritscomponentsina
bathroomorotherhighlyhumid
areaisnotallowed.
Nowet
hands
Thissymboldenotesthatusing
thephoneoritscomponentswith
wethandsisnotallowed.
Do
Thissymboldenotesthatan
instructionmustbeobeyedatall
times.
Unplug
Thissymboldenotesthatthe
equipmentshouldbeunplugged.

13 Assembling
■ Precautionscontainthedescriptionbelow.
1.Handlingtheterminal,batterypack,
adapter,USBconnectioncableanddocomo
miniUIMcard(common) ……………… P.14
2.Handlingtheterminal…………………… P.18
3.Handlingbatterypack…………………… P.24
4.Handlingadapter ………………………… P.27
5.HandlingdocomominiUIMcard……… P.30
6.Handlingmobilephonesnearelectronic
medicalequipment ……………………… P.31
7.Materiallist………………………………… P.33
8.Handlingsamples(microSDcard(2GB)/
StereoHeadsetwithMicrophone)…… P.35

14 Assembling
1. Handlingtheterminal,battery
pack,adapter,USBconnection
cableanddocomominiUIMcard
(common)
DANGER
Dont
Donotuse,store,orleavethe
terminal,batterypack,adapter,or
docomominiUIMcardinaplace
subjecttohightemperature(such
asclosetofireorheatingdevices,
insidekotatsu,underdirectsunlight,
orinacaronanextremelyhotday).
Maycausefire,burnsorinjuries.
Dont
Donotputtheterminalintoheating
cookingdevicesuchasmicrowave
ovenorhigh-pressurecontainer.
Maycausefire,burns,injuries,electric
shock.
No
disassembly
Donotattempttodisassembleor
modifytheequipment.
Maycausefires,burns,injuries,electric
shock.
No
liquids
Donotlettheterminalgetwetwith
water,drinkingwater,urineofpet
animals,etc.
Maycausefire,burns,injuries,electric
shock.

15 Assembling
Do
Usethebatterypackandadapter
specifiedbyNTTDOCOMOforthe
terminal.
Maycausefire,burns,injuries,electric
shock.
WARNING
Dont
Donotthrowtheequipment,orgive
excessiveforceorhardshocktoit.
Maycausefire,burns,injuries,electric
shock.
Dont
Keepconductivematerials(metal
pieces,pencillead,etc.)from
comingincontactwiththeexternal
connectionjackorheadphone
connectionjack.Donotputthose
materialsinsidetheterminal.
Maycausefire,burns,injuries,electric
shock.
Dont
Donotcoverorwraptheterminal
withablanket,etc.whileusingor
charging.
Maycausefireorburns.

16 Assembling
Do
TurntheterminalOFFandstop
chargingbeforeenteringaplacesuch
asagasstationwhereflammable
gasesaregenerated.
Thegasmaycatchfire.
WhenusingOsaifu-Keitaiinaplacesuch
asagasstation,turnOFFtheterminal
beforeusingit.(WhenOsaifu-Keitailock
isactivated,deactivateitbeforeturning
OFFtheterminal.)
Do
Iftheequipmentstartsgivingoffa
strangesmell,overheats,becomes
discoloredordeformedduringuse,
chargingorinstorage,immediately
performthefollowingoperations.
• Removethepowerplugfromall
outletsorcigarettelightersockets.
• TurntheterminalOFF.
• Removethebatterypackfromthe
terminal.
Maycausefire,burns,injuries,electric
shock.

17 Assembling
CAUTION
Dont
Donotleavetheequipmenton
unstableorslopingsurfaces.
Theterminalmayfallandcauseinjuries.
Dont
Donotstoretheequipmentin
extremelyhumid,dustyorhotareas.
Maycausefire,burns,electricshock.
Do
Childrenusingtheequipmentshould
beinstructedinproperoperation
byanadult.Makesuretheyare
followingtheinstructionswhenusing
theterminal.
Maycauseinjuries.
Do
Storetheequipmentoutofreachof
smallchildren.
Maybeaccidentallyswallowedorcause
injuries.
Do
Becarefulespeciallywhenusingthe
terminalconnectedtotheadapter
continuouslyforalongtime.
Ifyouareplayinggame,watching1Seg,
etc.whilechargingthebatteryfora
longtime,theterminal,batterypackand
adaptermaybeheated.
Directlytouchingahotpartforalong
time,youmayhaveredness,itchingor
rashonyourskin,oritmayresultinlow-
temperatureburnsdependingonyour
constitutionand/orhealthcondition.

18 Assembling
2.Handlingtheterminal
WARNING
Dont
Donotlightenthelightneareyes.
Especially,whenyoucapturebabies
orinfants,keeptheterminal1mor
moreawayfrombabiesandinfants.
Visiondisabilitymayresult.
Accidentmayresultfrombeingshocked.
Dont
Donotputforeignobjectssuchas
liquidlikewater,metalpiecesor
burnablethingsintodocomominiUIM
cardormicroSDcardslot.
Maycausefire,burns,injuries,electric
shock.
Dont
Donotturnonthelightandfacethe
devicetodrivers.
Maydisturbdrivingandcauseaccident.
