Docomo P-09A User manual

P-09A
INSTRUCTION MANUAL
ISSUE DATE: ‘09.6
NAME:
PHONE NUMBER:
MAIL ADDRESS:
Easy Search/Contents/Precautions
Before Using the Handset
Voice/Videophone Calls
Phonebook
Sound/Screen/Light Settings
Security Settings
Camera
i-mode/Full Browser
i-αppli/i-Widget
Map/GPS Function
i-motion/Movie/i-Channel/i-concier
Mail
Osaifu-Keitai/ToruCa
1Seg
Data Management
Music
Convenient Functions
Character Entry
Network Services
PC Connection
Overseas Use
Appendix/Troubleshooting
Index/Quick Manual

DOCOMO W-CDMA・GSM/GPRS System
Thank you for selecting the “docomo SMART series P-09A”.
Before or during use of the P-09A, make sure that you read this manual and the
separate manuals for other optional devices thoroughly so that you can use the
P-09A correctly.
If you feel any inconvenience in reading the manual, contact the docomo
Information Center listed on the back page of this manual.
The P-09A is designed to be your close partner. Treat it carefully at all times to
ensure long-term performance.
●Because the FOMA terminals use radio waves, they cannot be used in places
where radio waves do not reach, such as inside tunnels, underground, or in
buildings; or the outside where radio waves are weak or out of the FOMA
service area. They may not be used in the high-rise buildings even when the
antennas are unobstructed. You may also experience interruption of calls
even when using without moving while the radio waves are strong enough for
the three antennas to appear on the display.
●Use the FOMA terminal carefully to avoid disturbing other people when in
public, or in crowded or quiet places.
●Since the FOMA terminals use radio waves as the medium of
telecommunication, calls may be tapped by the third party.
However, the W-CDMA・GSM/GPRS system automatically supports tapping
prevention, so your conversation will be incomprehensible to the third party,
because it is recognized as mere noise.
●The FOMA terminals change your voice into digital signals and send them to
the other party. In places where the radio waves are weak, the digital signals
may not be converted correctly, and in such a case, the voice may sound
different from the actual original voice.
●
The user hereby agrees that the user shall be solely responsible for the result of
the use of SSL/TLS. Neither DOCOMO nor the certifiers as listed herein make any
representation and warranty as for the security in the use of SSL/TLS. In the event
that the user shall sustain damage or loss due to the use of SSL/TLS, neither
DOCOMO nor the certifiers shall be responsible for any such damage or loss.
Certifiers: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K.,
RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., and
Comodo CA Ltd.
●This FOMA terminal supports FOMA Plus-Area and FOMA High-Speed Area.
●The FOMA terminal can be used only via the FOMA network provided by
DOCOMO and in DOCOMO’s roaming area.
●It is recommended that you make separate notes of the information (such as
Phonebook entries, schedule events, text memos, record messages, voice
memos, movie memos) stored in the FOMA terminal and keep them in a safe
place. Note that we cannot be held responsible for the unlikely event of loss of
the stored contents due to a malfunction, repair, change of your model, or
other mishandling of the FOMA terminal.
●You are advised to save your important data files to the microSD card. If you
have a personal computer, you can transfer and save the information such as
Phonebook entries, mail messages, schedule events, and others to the
personal computer by using DOCOMO keitai datalink.
Before using your FOMA terminal
For Using This Manual
This FOMA terminal supports Kisekae Tool (page 105).
If you use Kisekae Tool to change the design of the Menu display,
some menu configurations change according to the usage
frequency depending on the type of the menu. Further, some menu
numbers that are assigned to the menu items do not apply.
You can download the latest information about this manual
from the following DOCOMO website:
・User’s Manual (PDF file) Download
(http://www.nttdocomo.co.jp/english/support/manual/index.html)
※The URL and the content of the website might be modified
without notice.

1
Easy Search/Contents/Precautions
Easy Search/Contents/Precautions
In this manual, illustrations and symbols are used in the explanations so
that you can correctly and easily use the FOMA terminal.
The most operating procedures and displays in this manual are described with the
default settings of the “GOLD” (see page 448) handset. However, the following settings
are changed.
・“Display setting” →“Stand-by display”: OFF
・“Display setting” →“Clock” →“Stand-by clock” →“Position”:Pattern 1
・“Color theme setting”: White
Displays and illustrations described in this manual are for reference. The actual ones
might differ.
In this manual, “Osaifu-Keitai compatible i-αppli which supports the IC card function” is
described as “Osaifu-Keitai compatible i-αppli”.
Note that “P-09A” is referred to as “FOMA terminal” in this manual.
In the operating procedures of this manual, key operations are described with
simplified key icons.
The functions which use a microSD card are described in this manual; however, you
need to obtain a microSD card separately to make these functions available. See
page 344 for the microSD card.
Viewing/Searching This Manual By the following search methods, you can find pages where your desired
functions and services are described:
How to Refer to This Manual
Search from the index when you know the names of functions or services.
Search from keywords for the functions you frequently use or the functions that are
convenient if you can know any.
Search from the tabs printed on the cover.
See the next page for details.
Search from the contents that categorize functions.
Search from here to use the main functions.
Search from the function list.
Quick Manual gives you a clear, brief description about basic functions. You can take it
when you go out. Further, Quick Manual “For Overseas Use” is attached, so refer to it
when you use the FOMA terminal overseas.
From the Index
From Easy Search
From the Tabs on the Cover
From the Contents P.6
From the Main Functions P.8
From the Function List P.448
From Quick Manual P.534
It is prohibited to copy all or part of this manual without permission.
The instructions contained in this manual may be changed without notice.

2
Easy Search/Contents/Precautions
How to search for “Alarm” is explained here as an example of search method.
After-sales services. . . . . . . . . . . . .495
Alarm. . . . . . . . . . . . . . . . . . . . . . . .376
Alarm setting . . . . . . . . . . . . . . . . . .385
Answer setting . . . . . . . . . . . . . . . . .64
Antenna. . . . . . . . . . . . . . . . . . . . . . .23
From the Index
P.524
Search for a function or a service
name as shown on the right.
Search for the function you
frequently use or that is
convenient if you know any as
shown on the right.
Other things you can do
To reduce the battery consumption .............................. <Power Saver Mode> 102
To scan QR codes or bar codes ...................................... <Bar Code Reader> 226
To listen to music.................................................................. <MUSIC Player> 258
To check your location and area information.................<Map/GPS Function> 306
To use the microSD card ...................................................... <microSD Card> 344
To exchange information using infrared rays.........<Infrared Communication> 358
To use the FOMA terminal as an alarm clock.....................................<Alarm> 376
To use the FOMA terminal as a calculator ..................................<Calculator> 390
To use the FOMA terminal overseas........................<International Roaming> 432
To update software programs........................................... <Software Update> 497
Go to page 376
where “Alarm”
is explained.
From Easy Search
P.4
i-αppli/i-Widget
Map/GPS Function
Osaifu-Keitai/ToruCa
Data Management
Music
Convenient Functions
Character Entry
Network Services
PC Connection
Overseas Use
Appendix/Troubleshooting
Multitask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Multitask> 373
Informing You of an Incoming Call/Mail Message by Voice
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Reading Aloud> 374
Turning Power On/Off Automatically at a Specified Time
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Auto Power ON/OFF> 376
Using Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Alarm> 376
Using Calendar to Manage Schedule . . . . . . . . . . .<Schedule> 379
Using ToDo to Manage Schedule . . . . . . . . . . . . . . . . . <ToDo> 384
Setting Operating Conditions of Alarm . . . . . <Alarm Setting> 385
From the Tabs on the
Cover
Cover page
Search for the function you want
to set in the order of “Cover”
→“First page of Chapter”
→“Description page” as shown
on the right.

3
Easy Search/Contents/Precautions
376
Convenient Functions
You can set Alarm to alert you at the specified time with an alarm tone,
animation and illumination. You can store up to 12 alarms.
1mStationeryAlarmHighlight an
alarm and press l()
Do the following operations.
2Press l().
+m-4-4
<Alarm>
Using Alarm
Alarm You can set whether to validate or invalidate the alarm.
ON or OFF
Time Enter the time for sounding the alarm.
pYou cannot set the same time as the time set for the stored
alarm.
Tone Select a type of alarm toneSelect a folder
Select an alarm tone.
Volume Use Boto adjust the volume.
pIf you set “Step”, the alarm tone is silent for about three
seconds, and then the volume steps up every about three
seconds, from Level 1 through Level 6.
Prefer manner
mode
You can set the alarm tone which sounds at the specified time
during Manner Mode.
ON or OFF
ON. . . . . Sounds at the same volume as set for “Alarm volume”.
OFF. . . . Sounds at the volume set for this function.
The icon appears on the Stand-by display.
“”. . . Displayed when an alarm is set for today (except the setting for past time).
“”. . . Displayed when an alarm is set for tomorrow or onward only.
pIf you set “Alarm”of a schedule event/ToDo item to “OFF”, the icon is not displayed.
Function Menu while Alarm is Displayed
Edit Go to step 1 of “Using Alarm”on page 376.
Detail You can display the stored alarm contents.
Set this You can validate the stored alarm.
YES
pYou can validate also by pressing Oo().
Set all You can validate all the stored alarm.
YES
Delete
Delete this YES
Delete all Enter you Terminal Security CodeYES
Information
pIf the alarm tone sounds during a call, press any key to stop it. Once again press any
key to end the alarm including Snooze. If the other party on the phone hangs up, an
alarm including Snooze ends.
pDuring a call, the alarm tone sounds at the level set for “Volume”(earpiece volume).
pTurn off the FOMA terminal after setting “Auto power ON”to “OFF”when you are near
electronic devices using high-precision control or weak signals, or where the use is
prohibited such as in airplanes and hospitals.
When you set an alarm for “Alarm”, “Schedule”, and “ToDo”
Note: The page above is a sample.
Menu number
(See page 34)
Function name
You can find this in
Index.
Operating
procedure
(See page 32)
Reference display
(Characters and settings
are for reference.)
Options and their
explanations
Items shown on the
display
(Some items cannot
be executed.)
Operation and
supplementary
explanation for each
item
Operations related to
the function and
explanations for
supplementary
operations
Chapter title
You can
search by
chapter.
Cautions or
references for using
each function
Lower sub-menu item
of the Function menu

4
Easy Search/Contents/Precautions
To retrieve a desired function with simple words, refer to the following:
Easy Search
To know convenient functions for making calls
To/Not to notify your phone number to the other party
....................................................................................<Caller ID Notification> 45
To switch to a videophone call during a voice call
...........................................................................<Switch to Videophone Call> 51
To change a volume level of the other party’s voice ....................... <Volume> 65
To put a call on hold during a call.................................................... <Holding> 66
To do the following when you cannot answer calls
To put an incoming call on hold before answering ......................... <On Hold> 66
To convey the message that you need to refrain from talking on the phone
.....................................................................Using Public Mode (Drive Mode) 67
....................................................................... Using Public Mode (Power Off) 67
To record voice/video messages.......................... <Record Message Setting> 68
To change melody or illumination
To adjust the ring volume........................................................<Ring Volume> 65
To change ring tones according to callers......................<Add to Phonebook> 78
To change ring tones........................................................<Select Ring Tone> 92
To know incoming calls by vibrator .................................................<Vibrator> 94
To mute the keypad sound...................................................<Keypad Sound> 95
To activate Manner Mode...................................................... <Manner Mode> 96
To change colors/lighting patterns of Call indicator for incoming calls
.................................................................................................. <Illumination> 106
To change/know display settings
To know the meaning of marks (icons) on the display .....................<Display> 26
To change the Stand-by display (Wallpaper) ...................... <Display Setting> 99
To display a calendar on the Stand-by display..............................<Calendar> 99
To change the menu display .......................................... <Menu Icon Setting> 104
To change the font size ....................................................<Font Size Setting> 109
To make full use of mail
To send Deco-mail ...................................................................... <Deco-mail> 133
To send images ....................................................................... <Attachments> 140
To sort and save mail automatically ..............................................<Auto-sort> 159
To make full use of camera
To change the shooting size...................................................... <Image Size> 222
To save to the microSD card ...........................................................<Store In> 223
To display shot images......................................................... <Picture Viewer> 318

5
Easy Search/Contents/Precautions
※1 This is a pay service.
※2 This is a pay service which is available on a subscription basis.
To use the FOMA terminal with a sense of security
To lock the FOMA terminal from away when it gets lost
......................................................................................... <Omakase Lock>※1115
To keep Phonebook entries from prying eyes .........................<Secret Mode> 120
To reject calls without a caller ID..............................<Call Setting without ID> 122
To reject calls from the phone numbers that are not
in the Phonebook ............................................................ <Reject Unknown> 123
To separately store Phonebook and other data
files in preparation for their erasure.................... <Data Security Service>※2124
To make full use of 1Seg
To watch 1Seg programs ...................................................... <Activate 1Seg> 233
To record 1Seg programs.................. <Record Video> <Record Still Images> 240
To set TV Timer/Timer Recording for 1Seg programs
.......................................................................<TV Timer> <Timer Recording> 241
To change settings of video and audio...................................<User Settings> 246
Other things you can do
To reduce the battery consumption .............................. <Power Saver Mode> 102
To scan QR codes or bar codes ...................................... <Bar Code Reader> 226
To listen to music.................................................................. <MUSIC Player> 258
To check your location and area information.................<Map/GPS Function> 306
To use the microSD card ...................................................... <microSD Card> 344
To exchange information using infrared rays.........<Infrared Communication> 358
To use the FOMA terminal as an alarm clock.....................................<Alarm> 376
To use the FOMA terminal as a calculator ..................................<Calculator> 390
To use the FOMA terminal overseas ........................<International Roaming> 432
To update software programs........................................... <Software Update> 497
To update security ......................................................... <Scanning Function> 502
The operating procedures for frequently used functions are summarized in Quick
Manual. (See page 534)

6
Easy Search/Contents/Precautions
Contents
Viewing/Searching This Manual . . . . .1
Easy Search . . . . . . . . . . . . . . . . . . . . . .4
Contents . . . . . . . . . . . . . . . . . . . . . . . . .6
Main Functions of P-09A. . . . . . . . . . . .8
Precautions. . . . . . . . . . . . . . . . . . . . . 10
Handling Precautions . . . . . . . . . . . . 16
Standard Accessory Kit and Main
Options . . . . . . . . . . . . . . . . . . . . . . . . 20
Before Using the
Handset
21
Part Names and Functions, Display,
Desktop Icon, Selecting Menu, Guide,
UIM (FOMA Card), Battery, Charging, Power ON/OFF,
Select Language, Set Time, Caller ID Notification,
Own Number, etc.
Voice/
Videophone Calls
47
Making a Call/Videophone Call, Call Records,
Chaku-moji, Receiving a Call/Videophone Call, Volume,
Ring Volume, Public Mode, Record Message Setting,
Chara-den, etc.
Phonebook
77
Available Phonebooks,
Add to Phonebook (FOMA terminal/UIM),
Group Setting, Search Phonebook, Edit Phonebook,
Delete Data, No. of Phonebook, 2-touch Dial,
Voice Dial
Sound/Screen/
Light Settings
91
Select Ring Tone, Vibrator, Manner Mode,
Display Setting, Backlight, Menu Icon Setting,
Kisekae Tool, Set to Machi-chara, Illumination,
Font, etc.
Security Settings
111
Security Codes, Change Security Code,
Releasing PIN Lock, Lock All, Omakase Lock,
Self Mode, Personal Data Lock, Keypad Dial Lock,
Secret Mode, Call Setting without ID, Reject Unknown,
Reset Settings, Initialize, etc.
Mail
129
i-mode Mail, Deco-mail, Decome-Anime, Template,
Attachments, Mail Auto-receive, Receive Option,
Check New Messages, Message R/F,
Early Warning “Area Mail”, Chat Mail, SMS, etc.
i-mode/
Full Browser
177
i-mode, iMenu, My Menu, Change i-mode Password,
Full Browser, Last URL, Enter URL, Bookmark,
Screen Memo, Download, Upload, i-mode Settings,
Certificate, etc.
i-motion/Movie/
i-Channel/i-concier
205
i-motion/Movie, Download i-motion/Movie,
Movie Auto Play Setting, i-Channel, i-concier
Camera
213
Before Using Camera, Still Image Shoot,
Moving Picture Shoot, Settings for Shooting,
Setting Image Size/Image Quality, Bar Code Reader
1Seg
229
1Seg, Before Using 1Seg, Channel Setting,
Activate 1Seg, i-αppli Program Guide,
Data Broadcasting, TVlink, Recording 1Seg,
TV Timer/Timer Recording, User Settings
Music
249
Music&Video Channel, Set Program,
Playing/Operating Programs, Playing Music,
Saving Music Files, MUSIC Player, Playlist

7
Easy Search/Contents/Precautions
i-αppli/i-Widget
269
i-αppli, i-αppli Download, i-αppli Run, iαppli Settings,
Starting i-αppli Automatically, iαppli Call,
i-αppli Stand-by Display, iαppli Data, i-Widget,
Start Widget Appli
Osaifu-Keitai/
ToruCa
293
Osaifu-Keitai, iC Transfer Service, IC Card Content,
IC Card Lock, Check IC Owner, ToruCa,
Receive ToruCa Files, ToruCa Viewer,
ToruCa File List/Detailed ToruCa File Display,
ToruCa Settings
Map/GPS Function
305
Using GPS Function, Position Location,
Map/GPS Compatible i-αppli, Provide Location,
Notify of Location, Location History, GPS Settings
Data Management
315
Picture Viewer, i-motion Player, Movie Player,
Video Player, Chara-den, Machi-chara, Melody Player,
Kisekae Tool, microSD Card, Voice Recorder,
PDF Viewer, etc.
Convenient
Functions
371
Multiaccess, Multitask, Reading Aloud,
Auto Power ON/OFF, Alarm, Schedule, ToDo,
Multi Key Long Press Setting, Own Number, Call Data,
Calculator, Bluetooth Function, Check Settings, etc.
Character Entry
403
Character Entry, Mode 1 (5-touch), Common Phrases,
Cut/Copy/Paste, Own Dictionary, Learned Words,
Download Dictionary, Mode 2 (2-touch),
Mode 3 (NIKO-touch)
Network Services
413
Check New Messages, Voice Mail, Call Waiting,
Call Forwarding, Nuisance Call Blocking,
Caller ID Request, Dual Network, Service Numbers,
Remote Control, Multi Number, 2in1, OFFICEED, etc.
Overseas Use
431
Outline of International Roaming (WORLD WING),
Available Services, Confirmation for Using,
Making a Call at the Country You Stay,
Receiving a Call, 3G/GSM Setting,
Set Roaming Guidance, Network Services, etc.
PC Connection
441
Available Data Communication,
Before Using Data Communication,
Setup Flow for Data Transfer (OBEX™ Communication),
Setup Flow for Data Communication, AT Command,
CD-ROM, DOCOMO Keitai Datalink
Appendix/
Troubleshooting
447
Function List, Options and Related Devices,
Troubleshooting, Error Messages, Warranty and
After-sales Services, i-mode Fault Diagnosis Site,
Software Update, Scanning Function, Main Specifications,
SAR, Export Administration Regulations, etc.
Index/
Quick Manual
523
Index, Quick Manual,
Quick Manual “For Overseas Use”

8
Easy Search/Contents/Precautions
Main Functions of P-09A
◆i-concier P.210
i-concier is a service that enables you to receive useful information from a character
(Machi-chara image) on the Stand-by display and download schedule event
(i-schedule) files for your convenience.
Downloaded i-schedule events or ToruCa files are automatically updated to the latest
information, and the address information of shops/companies, etc. is automatically
added to the Phonebook.
◆i-αppli Call P.287
i-αppli call is a useful function for online games that enables your content provider or
third party to give notice to your opponent to start the specified corresponding
application.
◆International Roaming P.278, P.432
Your FOMA terminal, phone number, and mail address are available overseas (3G/
GSM areas are supported).
Further, “日英版／日中版 しゃべって翻訳 for P (J-E/J-C Speech Translation for
P)”, which translates words into English or Chinese if you talk in Japanese, and into
Japanese if in English or Chinese, is pre-installed.
◆i-Widget P.290
i-Widget is a useful function that enables you to easily access the tools and
commonly-used contents (Widget Appli) such as a calculator, clock, TV program list,
and stock prices information.
By launching the i-Widget display, you can check your desired latest information at a
glance.
◆i-mode P.178
You are now enabled to check websites more easily for information by enhanced
operational performance, and to enjoy various moving picture contents as Flash®
Video and Windows Media®Video are supported.
◆1Seg P.230
You can watch 1Seg programs of the terrestrial digital broadcasting for mobile
objects. The light sensor automatically adjusts the backlight in accordance with the
ambient brightness, and the LCD AI compensates the image quality in accordance
with the brightness.
◆Bluetooth Function P.395
The wirelessly-connected FOMA terminal and a Bluetooth device enable you to talk
or listen to music while you are carrying the FOMA terminal in your bag.
◆Impressive Liquid Crystal Display
You can display still images and moving pictures in the Full Wide VGA (480 dots x
854 dots) display of approx. 3.0 inches and can enjoy watching 1Seg programs on
the impressive display.
◆Feel＊Mail P.164
Animation of 45 characters and illumination reproduce the atmosphere of mail
messages. Pleasant animation appears and illumination lights according to the
contents of mail message.
