1. Introduction
Module A-120 (VCF 1) is a voltage controlled low-
pass filter, which filters out the higher parts of the
sound spectrum, and lets lower frequencies pass
through.
The Cut-Off Frequency determines the point at which
filtering takes effect. You can control this manually, or
by voltage control (filter modulation, for instance by
an LFO). Three CV inputs are available, and the sum
of the voltages from these affects the filter cut-off.
VCF1 is a co-called "transistor ladder" design, with a
cut-off slope of -24 dB/octave, as in various Moog
synthesizers. That’s what gives it its classic, legendary
Moog sound.
Resonance (or Emphasis) is adjustable all the way up
to self-oscillation - in which case the filter behaves like
a sine wave oscillator.
CV 1
Resonance
CV 3
CV 2
A udio In
Lev el
Audio
Out
CV 2
Frequency
A-120
VCF 1
CV 3

A-120 VCF 1 System A - 100 doepfer
2
2. VCF 1 - Overview Controls:
1Freq.: Cut-off frequency control
2CV 2: Attenuator for CV at input "
3CV 3: Attenuator for CV at input §
4Lev.: Attenuator for audio input $
5Res.: Control for setting the filter’s reso-
nance (emphasis)
In / Outputs:
!CV 1: Voltage control input
"CV 2: ditto, level controlled by 2
§CV 3: ditto, level controlled by 3
$Audio In: Input to the filter
%Audio Out: Output from the filter
A-120
VCF 1
CV 2
CV 3
Audio In
CV 2
CV 3
Lev.
Res.
Freq.
CV 1





➀
➁
➂
➃
➄
LOW PASS FILTER
010
010
010
010
010
Audio Out

doepfer System A - 100 VCF 1 A-120
3
3. Controls
1 Freq.
With this control you adjust the Cut-Off Frequency fc,
above which the filter attenuates all frequencies. At 10,
the filter is fully open. The more you turn down this
control, the more the high frequencies are filtered.
The sound becomes mellower and less bright (see
Fig. 1) until at 0 the filter is completely shut, and there
will be no output signal at all.
Fig. 1: White noise put through a low pass filter.
2 CV 2 • 3CV 3
For voltage control or modulation of the cut-off fre-
quency, use these CV inputs "and/or §(see Fig. 1).
Use attenuators 2and/or 3to adjust the control
voltage level.
4 Lev.
Use this attenuator to control the amount of signal
entering the filter input $.
H If the filter’s output distorts, turn this control
down, unless you deliberately want the
sound as a special effect.
5 Res.
With this control you adjust the filter’s resonance
(emphasis) - the parameter which emphasises the
frequencies around the cut-off point fC(see Fig. 2 on
p.4).
Close to its maximum setting, the filter becomes so
resonant that it goes into self-oscillation, and starts
behaving like a sine wave. You can take advantage
of this effect, and use the VCF as an additional oscilla-
tor.
f
c
CV
Out Out
Freq. Freq.
f
c

A-120 VCF 1 System A - 100 doepfer
4
Fig. 2: How resonance affects the response of a low
pass filter
4. In / Outputs
! CV 1
Socket CV 1 is the filter’s standard voltage control
input, and works on the 1V / octave rule, like the
VCOs.
If you patch a modulation source (eg LFO, ADSR) to
this input, the cut-off frequency of the filter will be
modulated by its voltage: ie., the sound color changes
according to the voltage put out by the modulator.
If you use the VCF as a sine wave oscillator, connect
the pitch CV into this socket. Do the same if you want
the filter’s cut-off frequency to track exactly with the
pitch of a note.
" CV 2 • §CV 3
Sockets CV 2 and CV 3 are also voltage control
inputs for the filter. Unlike CV 1, you can control the
level of voltage - the intensity of modulation effect on
the filter - with attenuators 2and 3.
$ Audio In
This is the filter’s audio input socket.Patch in the
output from any sound source (eg. VCO, noise gene-
rator, mixer).
% Audio Out
Filter output %sends out the filtered signal.
f
c
Resonance
Frequency
➨
➨➨
➨
0 db

doepfer System A - 100 VCF 1 A-120
5
5. User examples
The filter’s cut-off frequency can be modulated in
various ways:
• VCF - LFO
Modulation of the cut-off frequency produces cycli-
cal changes of the sound spectrum. At low
frequencies (c. 1 - 5 Hz), you get a "Wah-Wah"-
effect. Modulation in the audio range produces
interesting sounds; the same principles apply here
as with frequency modulation of the A-110 VCO
(see chapter 6).
• VCF - ADSR
Modulation by an envelope results in gradual
change of the sound spectrum. Typical uses
would be the synthesis of electric bass or drum
sounds, and filter sweeps, which slowly sweep
through the audio spectrum, emphasising different
harmonics.
• VCF - Keyboard CV
This modulation produces pitch-related filter ope-
ning: the higher the pitch, the more the filter opens,
and the brighter the sound becomes.
Producing wind FX with A-120 and A-118
D Patch coloured noise into the audio input, and
random voltage CV into CV2. Set the filter CV to 0,
cut-off to a middle value, and the resonance just
below self-oscillation.
D Now turn CV 2 up. A whistling wind sound will
occur. You can control the rate and amount of its
irregularity with controls 3and 4on the A-118, and
the tone colour with the A-118’s controls 1and 2.
Fig. 3: Creating wind effects
Blue
Colored
Random
Output
Rate
A-118
NOISE / RANDOM
Random Control
- +
Red
Level
Resonance
CV 2
Audio In
Level
Audio
Out
CV 2
Frequency
A-120
VCF 1

A-120 VCF 1 System A - 100 doepfer
