Dolmar AS4030 User manual

AS4030
AS4035
EN Cordless Chain Saw INSTRUCTION MANUAL 8
FR Tronçonneuse sans Fil MANUEL D’INSTRUCTIONS 20
DE Akku-Kettensäge BETRIEBSANLEITUNG 33
IT Motosega a batteria ISTRUZIONI PER L’USO 46
NL Accukettingzaag GEBRUIKSAANWIJZING 60
ES Electrosierra Inalámbrica MANUAL DE
INSTRUCCIONES 73
PT Motosserra a Bateria MANUAL DE INSTRUÇÕES 87
DA Akku-kædesav BRUGSANVISNING 100
EL Φορητό αλυσοπρίονο ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ 112
TR Akülü Ağaç Kesme KULLANMA KILAVUZU 127

Fig.1
345
78
14
15
17
9
1011
12
1920
22
18
13
16
26
21
1
Fig.2
1
2
3
Fig.3
21
Fig.4
2

1
2
Fig.5
21
3
Fig.6
1
2
Fig.7
1
23
23
Fig.8
1
2
Fig.9
1
Fig.10
3

12
Fig.11
12
Fig.12
2
3
4
1
4
Fig.13
1
Fig.14
1
Fig.15
1
2
3
Fig.16
1
Fig.17
1
2
Fig.18
4

Fig.19
Fig.20
Fig.21
1
2
Fig.22
Fig.23
Fig.24
Fig.25
1
2
Fig.26
5

22
11
31
Fig.27
30
30
55 55
Fig.28
1
2
Fig.29
30 1/5
1
Fig.30
Fig.31
Fig.32
Fig.33
1
2
Fig.34
6

1
2
Fig.35
1
2
Fig.36
7

8ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: AS4030 AS4035
Overall length (without guide bar) 270 mm
Rated voltage D.C. 36 V
Net weight *1 4.2 kg
*2 4.7 - 4.9 kg 4.8 - 5.0 kg
Standard guide bar length 300 mm 350 mm
Recommended guide bar
length with 90PX 250 - 400 mm
with 91PX 250 - 400 mm
Applicable saw chain type
(refer to the table below) 90PX 91PX
Standard sprocket Number of teeth 6
Pitch 3/8″
Chain speed 0 - 20 m/s
(0 - 1,200 m/min)
Chain oil tank volume 200 cm3
• Due to our continuing program of research and development, the specications herein are subject to change without notice.
• Specications may differ from country to country.
*1:
Weight, with largest battery cartridge and empty oil tank, and without guide bar and chain, according to EN ISO 11681-2.
*2: The lightest and heaviest combination of weight, according to EPTA-Procedure 01/2014. The weight may differ
depending on the attachment(s), including the battery cartridge.
Applicable battery cartridge
BL1830 / BL1830B / BL1840 / BL1840B / BL1850 / BL1850B / BL1860B
• Some of the battery cartridges listed above may not be available depending on your region of residence.
WARNING: Only use the battery cartridges listed above. Use of any other battery cartridges may cause injury and/or re.
Saw chain, guide bar, and sprocket combination
Saw chain type 90PX
Number of drive links 46 52
Guide bar Guide bar length 300 mm 350 mm
Cutting length 294 mm 350 mm
Pitch 3/8″
Gauge 1.1 mm
Type Sprocket nose bar
Sprocket Number of teeth 6
Pitch 3/8″
Saw chain type 91PX
Number of drive links 46 52
Guide bar Guide bar length 300 mm 350 mm
Cutting length 294 mm 350 mm
Pitch 3/8″
Gauge 1.3 mm
Type Sprocket nose bar
Sprocket Number of teeth 6
Pitch 3/8″
WARNING: Use appropriate combination of the guide bar and saw chain. Otherwise personal injury may
result.

9ENGLISH
Symbols
The followings show the symbols used for the equip-
ment. Be sure that you understand their meaning before
use.
Read instruction manual.
Wear safety glasses.
Wear ear protection.
Wear a helmet, goggles and ear protection.
Use appropriate protection for foot-leg and
hand-arm.
This saw is to be used by properly trained
operators only.
Do not expose to moisture.
Maximum permissible cut length
Always use two hands when operating the
chain saw.
Beware of chain saw kickback and avoid
contact with bar tip.
Direction of chain travel
Saw chain oil adjustment
Ni-MH
Li-ion Only for EU countries
Do not dispose of electric equipment or
battery pack together with household waste
material!
In observance of the European Directives,
on Waste Electric and Electronic
Equipment and Batteries andAccumulators
and Waste Batteries andAccumulators
and their implementation in accordance
with national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.
Intended use
The tool is intended for cutting branches and pruning
trees. It is also suitable for tree service.
Noise
The typicalA-weighted noise level determined accord-
ing to EN ISO 11681-2:
Model AS4030
Sound pressure level (LpA) : 89 dB(A)
Sound power level (LWA) : 103 dB (A)
Uncertainty (K) : 3 dB(A)
Model AS4035
Sound pressure level (LpA) : 89 dB(A)
Sound power level (LWA) : 103 dB (A)
Uncertainty (K) : 3 dB(A)
NOTE:
The declared noise emission value(s) has been
measured in accordance with a standard test method
and may be used for comparing one tool with another.
NOTE: The declared noise emission value(s) may also
be used in a preliminary assessment of exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
use of the power tool can differ from the declared
value(s) depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to EN ISO 11681-2:
Model AS4030
Work mode: cutting wood
Vibration emission (ah,W) : 3.2 m/s2
Uncertainty (K) : 1.5 m/s2
Model AS4035
Work mode: cutting wood
Vibration emission (ah,W) : 3.2 m/s2
Uncertainty (K) : 1.5 m/s2
NOTE: The declared vibration total value(s) has been
measured in accordance with a standard test method
and may be used for comparing one tool with another.
NOTE: The declared vibration total value(s) may also
be used in a preliminary assessment of exposure.
WARNING: The vibration emission during
actual use of the power tool can differ from the
declared value(s) depending on the ways in which
the tool is used especially what kind of workpiece
is processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).

10 ENGLISH
EC Declaration of Conformity
For European countries only
The EC declaration of conformity is included asAnnex A
to this instruction manual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listed below may result in electric shock, re and/or
serious injury.
Save all warnings and instruc-
tions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Cordless Chain saw safety warnings
1. Keep all parts of the body away from the saw
chain when the chain saw is operating. Before
you start the chain saw, make sure the saw
chain is not contacting anything.A moment of
inattention while operating chain saws may cause
entanglement of your clothing or body with the
saw chain.
2. Always hold the chain saw with your right
hand on the top handle and your left hand on
the front handle. Holding the chain saw with a
reversed hand conguration increases the risk of
personal injury and should never be done.
3.
Hold the power tool by insulated gripping sur-
faces only, because the saw chain may contact
hidden wiring. Saw chains contacting a "live" wire
may make exposed metal parts of the power tool
"live" and could give the operator an electric shock.
4. Wear safety glasses and hearing protection.
Further protective equipment for head, hands,
legs and feet is recommended.Adequate protec-
tive clothing will reduce personal injury by ying
debris or accidental contact with the saw chain.
5. Always keep proper footing.
6.
When cutting a limb that is under tension be alert
for spring back. When the tension in the wood bres
is released the spring loaded limb may strike the
operator and/or throw the chain saw out of control.
7. Use extreme caution when cutting brush and
saplings. The slender material may catch the saw
chain and be whipped toward you or pull you off
balance.
8. Carry the chain saw by the front handle with
the chain saw switched off and away from your
body. When transporting or storing the chain
saw always t the guide bar cover. Proper
handling of the chain saw will reduce the likelihood
of accidental contact with the moving saw chain.
9. Follow instructions for lubricating, chain ten-
sioning and changing accessories. Improperly
tensioned or lubricated chain may either break or
increase the chance for kickback.
10. Keep handles dry, clean, and free from oil and
grease. Greasy, oily handles are slippery causing
loss of control.
11. Cut wood only. Do not use chain saw for pur-
poses not intended. For example: do not use
chain saw for cutting plastic, masonry or non-
wood building materials. Use of the chain saw for
operations different than intended could result in a
hazardous situation.
12. Causes and operator prevention of kickback:
Kickback may occur when the nose or tip of the guide
bar touches an object, or when the wood closes in
and pinches the saw chain in the cut. Tip contact in
some cases may cause a sudden reverse reaction,
kicking the guide bar up and back towards the opera-
tor. Pinching the saw chain along the top of the guide
bar may push the guide bar rapidly back towards
the operator. Either of these reactions may cause
you to lose control of the saw which could result in
serious personal injury. Do not rely exclusively upon
the safety devices built into your saw. As a chain saw
user, you should take several steps to keep your
cutting jobs free from accident or injury.
Kickback is the result of tool misuse and/or incor-
rect operating procedures or conditions and can be
avoided by taking proper precautions as given below:
• Maintain a rm grip, with thumbs and ngers
encircling the chain saw handles, with both
hands on the saw and position your body
and arm to allow you to resist kickback
forces. Kickback forces can be controlled by
the operator, if proper precautions are taken.
Do not let go of the chain saw.
► Fig.1
• Do not overreach and do not cut above
shoulder height. This helps prevent unin-
tended tip contact and enables better control
of the chain saw in unexpected situations.
• Only use replacement bars and chains spec-
ied by the manufacturer. Incorrect replace-
ment bars and chains may cause chain
breakage and/or kickback.
• Follow the manufacturer’s sharpening and
maintenance instructions for the saw chain.
Decreasing the depth gauge height can lead
to increased kickback.
13. Before starting work, check that the chain
saw is in proper working order and that its
condition complies with the safety regulations.
Check in particular that:
• The chain brake is working properly;
• The run-down brake is working properly;
•
The bar and the sprocket cover are tted correctly;
• The chain has been sharpened and ten-
sioned in accordance with the regulations.
14. Do not start the chain saw with the chain cover
being installed on it. Starting the chain saw with
the chain cover being installed on it may cause
the chain cover to thrown out forward resulting in
personal injury and damage to objects around the
operator.
