Dolphin BC101-PR Quick start guide


BC101ES
DOLPHIN TITAN CHANGING UNIT
› Carrying capacity of more than 400kg
› An alternative design embodying strength, safety and hygiene in a robust
construction
› Ideal for use in public toilets, washrooms or any area particularly vulnerable
to vandalism
› Safety strap operable with one hand
› Aluminium Unit with rounded edges and stainless steel cappings
› Optional liner roll dispenser above the table
› Pneumatic shock absorbers concealed in strong stainless steel mount
casings
› Pneumatic shock absorbers, facilitating smooth and noiseless operation
› Offers your customers a unique service and optimum safety
› Hygienic and a customer-friendly solution
HEIGHT 967 MM
WIDTH 788 MM
PROJECTION CLOSED 105 MM
PROJECTION OPEN 626 MM
PRODUCT CODES
› Linen roll dispenser BC101-PRD
› Paper rolls BC101-PR
TECHNICAL HELPLINE 01424 202224
DOLPHINSOLUTIONS.CO.UK
269
100
967
798
626
Plan
Elevation
Section


BC 101-ES Dolphin Prestige Titan Changing
Unit and Liner Roll Dispenser
User Manual
Please read carefully before use
DOLPHIN

BC 101-ES User Manual www.dolphindispensers.co.uk
INSTALLATION INSTRUCTIONS
SAFETY BABY CHANGING TABLE
Read the Installation Instructions Thoroughly Before Commencing Installation
The design of the safety baby changing table makes it easy to mount in even very small
rooms. The changing table must be mounted onto a wall which is suited to carry the weight
of the table as well as a baby – preferably a solid wall!
Where To Mount the Baby Changing Table
Determine the ideal place to mount the baby changing table. Keep in mind that the depth of
the changing table is 625 mm in open position. The distance from the floor to the lower edge
of the table mountings should be approx. 750 mm (see FIG. 1). Doorways, sinks etc. should
of course also be taken into consideration when choosing where to mount the changing table.
IMPORTANT: Do NOT mount the table in a chlorine-containing environment!
Marking and Drilling Holes
To mount the changing table onto brick, gas concrete or the like, use 10 mm screws and
matching universal plastic dowels – e.g. Fischer fixings type S-12.
When mounting the changing table onto a cavity wall of min. 16 mm (or 2 x 13 mm) plaster
board, we recommend prior mounting of a reinforcement plate of stainless steel, plywood or
the like, onto which the changing table is subsequently mounted. Attach reinforcement plate
to the wall using a considerable number of special metal cavity fixings, Fischer part. no. BC
62328 or equivalent (part. no. BC 62315 for double plate). The changing table itself is also
mounted with these screws and dowels – plus one metal washer per screw hole. For further
details, please refer to the instructions of the dowel supplier.
In places where plaster walls have not yet been finished, we suggest mounting a 16 mm
plywood board on the inside of the plaster wall, rendering the need for a reinforcement plate
on the outside unnecessary.
Mark and drill holes as indicated on FIG. 1. The top holes for the table mountings should be
drilled into solid brick - not into a joint.
IMPORTANT: Be sure to drill the holes for the mountings exactly vertically underneath each
other, or the pneumatic shock absorbers inside the mountings may break!

MOUNTING THE BABY CHANGING TABLE
ݢDisassemble the cover plates of the table mountings by removing the 6
screws (3 on each) with a Torx screwdriver no. 20.
ݣMount the table onto the wall, making sure that it is completely level.
ݤThe changing table is factory pre-adjusted to easily close when given a
slight push from open position.
ݥCheck that the changing table is mounted solidly onto the wall.
ݦCheck that the shock absorbers can pass freely when opening and closing
the table.
ݧReassemble the cover plates onto the mountings.
FIG. 1
PAPER ROLL HOLDER
CHANGING TABLE
The dimensions stated are based
on a work height of approx. 950 mm.
BC 101-ES User Manual www.dolphindispensers.co.uk

BC 101-ES User Manual www.dolphindispensers.co.uk
MOUNTING PAPER HOLDER
The paper holder consists of the following parts:
1 holder
Left-side mountings with lock
Right-side mountings
2 keys
ݢMark and drill holes as indicated on FIG. 1.
ݣFix the mountings onto the wall with 6 mm screws and plugs suited for the
wall type onto which the paper holder is to be mounted.
ݤPlace a paper roll loosely in the paper holder and tip the holder towards the
wall, making the white locking devices click.
Components

BC 101-ES User Manual www.dolphindispensers.co.uk
Components

BC 101-ES User Manual www.dolphindispensers.co.uk
Spare Parts
Position No. Part No Description
1 BC 65524 Hood for mounting bracket, complete, left
2 BC 65525 Hood for mounting bracket, complete, right
3 BC 65541 Crank
4 BC 65546 Mounting bracket, complete, left
5 BC 65547 Mounting bracket, complete, right
6 BC 65534 Spacer Ø25 mm, for spindle
7 BC 65531 End flange, left
8 BC 65532 End flange, right
9 BC 20040 Nut M5, stainless, self-locking
10 BC 65516 Aluminium table-top, 790 mm, white
11 BC 20038 Nut M6, stainless
12 BC 20047 Tight-fitting bolt M5 6x60 mm
13 BC 20041 Allen bolt, stainless, M6 x 25 mm
14 BC 20057 Locking ring Ø40 DIN 472
15 BC 65562 Spherical bearing
16 BC 20042 Allen bolt for crank (setscrew), stainless, M6 x 16 mm
17 BC 65402 Gas spring, 330 N, (Bansbach)
BC 65407 Gas spring, 350 N, (Scandiloc)
BC 65406 Gas spring replacement set with crank, screws etc.
18 BC 20065 Spacer, polyamide, Ø5.2 x Ø10 x 3
(only for installation with part. no.: 65402)
BC 20855 Spacer, nylon, Ø5.3 x Ø10 x 1
(only for installation with part. no.: 65407)
19 BC 20044 Screw, countersunk, stainless, M4 x 10, torx
20 BC 20053 Screw, stainless, M6 x 20 mm, torx
21 BC 20835 Spacer, flat, stainless, A2, M5 x 10
22+23+24 BC 65551 Safety belt complete with buckle
25 BC 40068 Screw, stainless, M4 x 12 mm, torx
BC 65520 Measuring band
BC 65630 Pictogram, door
DOLPHIN
Bell-Chem Products Company
Haywood Way, Hastings, TN35 4PL
Tel: 01424 202224
Fax: 01424 205200
www: dolphindispensers.co.uk

BABY CHANGE
INSTALLATION INSTRUCTIONS

NAPPY CHANGING UNIT INSTALLATION
Stainless Steel Units
STEEL UNITS
Each stainless steel unit can either
be surface-mounted or recessed.
A matching stainless steel cover
frame is available for surface-
mounted installations.
RECOMMENDED MOUNTING HEIGHT TO BASE OF UNIT:
Standard – 900mm
Wheelchair – 750mm
•In all mountings, the flat fender washer must be inserted
underneath the finishing washer: installing the unit using only
the finishing washer may result in the washer biting directly
into the body of the unit with consequent damage and loss
of stability.
•Nappy changing units are no stronger than the anchors or
substrates to which they are attached and as such must be
firmly secured in order to support the loads for which they
are intended.
RECESSED FIXING IN
MASONRY
Each unit has six recess mounting holes.
Form the opening in the brick or
blockwork wall, incorporating an
appropriate lintel to span the opening.
Install rough timber fixing grounds and
screw fix the changing unit to the
reveals of the opening using minimum
5mm screws.
Before final tightening, insert packing
shims as necessary for alignment and to
obviate any distortion on tightening.
Use either flat head screws with
finishing washers and flat washers or
pan head wood screws with flat
washers, making sure that consideration
is given to the operating clearance and
that the back flange of the unit neatly
masks the opening and the termination
of the wall finish.
RECESSED FIXING IN
STUDWORK
Timber double stud blocking is
necessary around the opening.
After locating the unit within the
framed opening, insert packing shims as
necessary for alignment and snug fitting.
Secure the unit to the blocking using
minimum 5mm flat head wood screws
with finishing washers and flat washers
or pan head wood screws with flat
washers, making sure, as with all fixing
methods, that consideration is given to
the operating clearance.
SURFACE MOUNTING
The unit can be fixed directly through
the back plate using screws and
appropriate wall plugs and plastic caps
to cover the screw heads.
A matching stainless steel cover frame
is available for surface-mounted
installations which engages the changing
unit with a snap fit.The cover frame
covers the otherwise exposed edges
and provides a neat finishing surround.

POLYETHYLENE UNITS
Each unit has four mounting ports based on a traditional
400mm stud spacing.
Two additional ports are provided for optional use.
All fixings are supplied with each unit to cater for fixing to
either solid masonry or studded wall constructions.
FIXING TO MASONRY
Secure the unit to brick and concrete block substrates
using four 5mm x min.75 mm wood screws into
proprietary wall plugs.
The flat fender washer is to be inserted underneath the
finishing washer. Finally, insert the snap-fit plastic covers in
each fixing port to cover the fixings.
ALTERNATIVE FIXING METHOD TO STUDWORK
The BC 100-EH/BC 100-EV unit can be fitted with the EZ Mount backer plate
to provide an alternative method of fixing to studded walls.
Two galvanised steel mounting bars are supplied, one pre-fixed to the rear of
the unit and the other loose for fixing to the wall.The wall bar has a multitude
of fixing holes to cater for variable stud positions.
1Mark out and drill
fixing holes. Insert
toggle. 2Twist toggle freely to
gain purchase on the
supporting member.
There should be a
minimum cavity clearance
of 65mm to allow the
toggle bar to turn.
3Push the integral disc
along the toggle to
make a snug purchase on
the wall face.The toggle
strands are rachetted to
hold the disc in place.
4Cut off the surplus
projection of the
toggle and offer up the
unit for fixing.
5Align and engage the
fixing bolt in the
threaded toggle bar with
washers engaged.The flat
fender washer is to be
inserted underneath the
finishing washer. Finally,
insert the snap-fit plastic
covers in each fixing port.
RECOMMENDED MOUNTING
HEIGHTS:
Standard – 900mm
Wheelchair – 750mm
NAPPY CHANGING UNIT INSTALLATION
Polyethylene Units
Cover cap
Toggle
Fixing to studwork

Dolphin Solutions Ltd
Southpoint, Compass Park,
Junction Road
Bodiam,TN32 5BS,
United Kingdom
T +44 (0)1424 202 224
dolphinsolutions.co.uk
© Dolphin Solutions Ltd

SOUTHPOINT, COMPASS PARK,
BODIAM, ROBERTSBRIDGE,
TN32 5BST, UNITED KINGDOM
+ 44 (0)1424 202 224 TEL
+ 44 (0)1424 205 200 FAX
dolphinsolutions.co.uk
