Dolphin YG30CEWD User manual

3
Pre-Assembly
HOMEDEPOT.COM/HomeDecorators
Please contact 1-800-986-3460 for further assistance.
IMENSIONS
TOOLS REQUIRED
Phillips
screwdriver
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA 4Screw
4ScrewBB
4
Expansion bolt
CC
1Hex wrenchDD
5EE
4Drawer handle screwFF
Carpenters Silicone
sealant
level
VANITY AND COUNTERTOP D
35.8 in.
18.3 in.
35 in.
33.2 in.
17.7 in.
Screw
Handle
10 Vanity screw
GG
2
HH
2II
Long screw
AA BB CC DD EE FF
GG HH II JJ
Door handle screw 1JJ

HOMEDEPOT.COM/HomeDecorators
Please contact 1-800-986-3460 for further assistance.
4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A V 1ydobytina
1potkniSB
1Lower iron frameC
1D
4
Iron legs
E
Upper iron frame
A
D
C
F
E
B
1
Shelf board F

5
Assembly
HOMEDEPOT.COM/HomeDecorators
Please contact 1-800-986-3460 for further assistance.
1
2
□
Put the lower iron frame (C) upside down, and install the
iron legs (E) onto the lower iron frame (C) by using screws
(AA) according to the marks A-B-C-D on the iron legs (E)
and lower iron frame (C). Do not install the screws (AA) too
tight here.
□
Install the upper iron frame (D) to the iron legs (E) with
screws (CC). Then tighten the screws (AA) on the lower
iron frame (C).
Installing the handles 3 Installing the sink top
Installing the iron structure and vanity body
□ Apply a small
Adjust the level screws on the bottom of the iron legs (E),
bead of silicone (not included) around the
top perimeter of the vanity body (A).
□
□
Carefully place the sink top (B) on the top of the vanity
body (A). Wipe away any excess silicone.
NOTE:
A hex wrench (DD) is included to
make the installation easier.
C
E
DD
AA
NOTE:
In order to make the vanity more steady,
we suggest to connect the vanity to the wall by using
long screws (HH) and expansion bolts (II).
□
Install the shelf board (F) to the lower iron frame (C)
with screw (BB).
F
BB
□Put the vanity body (A) upside down, and install the
upper iron frame (D) to the vanity body (A) with
vanity screws (GG).
C
back
GG
A
D
□ Install the handles (EE) to the door and drawers with drawer
handle screws (FF) and door handle screw (JJ).
HH
II
EE
FF
JJ
D
CC
B
A
E
DD
CC

Maintenance
To protect your bath furniture, we suggest the following:.
□Avoid placing your furniture in direct sunlight, as sunlight causes fading.
Clean up spills immediately. Use a blotting rather than a wiping action. Water left over a long period of time will cause white spots in
□
□
Care and Cleaning
For best results in cleaning and polishing your bath furniture, we recommend the following:
□Dust frequently with a clean, soft, dry, lint-free cloth. Clean the surface by rubbing in the direction of the grain.
as a barrier
he sheen
Clean the outside surface with mild soap, warm water, and a soft cloth.
On stubborn stains, use a powdered detergent and damp sponge or nylon scouring pad.
Never use abrasive scouring powders, cleansers, or pads because they will scratch, damage, and dull the surface.
□
□
□
□
6
HOMEDEPOT.COM/HomeDecorators
Please contact 1-800-986-3460 for further assistance.

AA 4Vis
Vis
Vis
Clé Allen
Poignée
Vis de poignée de tiroir
Vis pour la vanité
Longue vis
Boulon d'expension
Vis de poignée de porte
4BB
4CC
1DD
5EE
4FF
10GG
2HH
3
2II
JJ
Pré-assemblage
DIMENSIONS DU COMPTOIR ET DU MEUBLE-LAVABO
MATÉRIEL INC
Pièce Description Quantité
LUS
REMARQUE : Matériel non représenté à la taille réelle.
OUTILS NÉCESSAIRES
Niveau Sealant en
Silicone
Tournevis
Phillips
HOMEDEPOT.COM/HomeDecorators
Composez le 1-800-986-3460 pour de l'aide supplémentaire
35, 8 po.
18, 3 po.
35 po.
33, 2 po.
17, 7 po.
AA BB CC DD EE FF
GG HH II JJ
1
