Dometic CoolPower MPS-35 User manual

MPS35
Mains rectifier
Installation and Operating Manual. . . . . . . .4
EN
ENERGY & LIGHTING
COOLPOWER
MPS35-IO-16s.book Seite 1 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

MPS35
3
3
1
2
4
1
12 V/24 V
10 A
–
–
+
+
rt/sw
rt
sw
sw
110 – 240 Vw
4
5
2
3
1
2
∅/mm²
l/m
12 V/24 V
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28
0
2
6
10
14
3
MPS35-IO-16s.book Seite 3 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
MPS35
4
Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
6 Mounting the mains rectifier. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
7 Using the mains rectifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8 Maintaining and cleaning the mains rectifier . . . . . . . . . . . . . . . . . . . . . . . . .10
9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
10 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
MPS35-IO-16s.book Seite 4 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
MPS35 Explanation of symbols
5
1 Explanation of symbols
!
!
A
I
2 General safety instructions
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
2.1 General safety
!CAUTION!
•Only use the device only as intended.
•Do not operate the device in wet or damp environments.
•Maintenance and repair work may only be carried out by qualified
personnel who are familiar with the risks involved and the relevant
regulations.
•Persons (including children) whose physical, sensory or mental capa-
bilities or lack of experience and knowledge prevents them from using
the appliance safely should not use this appliance without initial super-
vision or instruction by a responsible person.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
MPS35-IO-16s.book Seite 5 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
General safety instructions MPS35
6
•Electronic devices are not toys!
Keep electrical appliances out of reach of children or infirm persons.
Do not let them use the appliances without supervision.
2.2 Safety when installing the device
!CAUTION!
•Ensure that the device is standing firmly!
The device must be set up and fastened in such a way that it cannot tip
over or fall down.
ANOTICE!
•Do not expose the device to a heat source (such as direct sunlight or
heating). Avoid additional heating of the device in this way.
•For installation on boats:
If electrical devices are incorrectly installed on boats, corrosion dam-
age might occur. Have the inverter installed by a specialist (marine)
electrician.
Electrical cables
!CAUTION!
•Lay the cables so that they cannot be tripped over or damaged.
ANOTICE!
•If cables have to be fed through metal walls or other walls with sharp
edges, use ducts or tubes to prevent damage.
•Do not lay cables which are loose or bent next to electrically conduc-
tive material (metal).
•Do not pull on the cables.
•Do not lay the 110 – 240 Vwmains cable and the 12/24 V DC cable
in the same duct.
•Fasten the cables securely.
MPS35-IO-16s.book Seite 6 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
MPS35 Scope of delivery
7
2.3 Operating the device safely
!CAUTION!
•Note the following basic safety information when using electrical
devices to protect against:
– Electric shock
–Firehazards
–Injury
•Operate the device only if you are certain that the housing and the
cables are undamaged.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified personsin order to
avoid a hazard.
•Even after the fuse triggers, parts of the IU0U automatic charger
remain live.
•Always disconnect the power supply when working on the device.
ANOTICE!
•Make sure the air inlets and outlets of the device are not covered.
•Ensure good ventilation.
3Scopeofdelivery
•Mains rectifier
•Operating manual
4Properuse
The MPS35 mains rectifier (ref. no. 9600000445) is for operating coolers and
refrigerators with BD35F compressors at 110 – 240 Vw.
MPS35-IO-16s.book Seite 7 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Technical description MPS35
8
5 Technical description
The mains rectifier can operate all coolers and refrigerators with BD35F compressors
at 110 – 240 Vw.
With a 110 – 240 Vwmains connection, the rectifier automatically switches from bat-
tery to mains operation.
When disconnected from the 110 – 240 Vwmains supply, the rectifier automatically
switches back to battery operation. Mains operation via the rectifier always takes pri-
ority over battery operation.
5.1 Control elements
6 Mounting the mains rectifier
If you wish to mount the mains rectifier in a fixed position, please observe the follow-
ing mounting instructions:
A
•Do not mount the device
– In wet or damp environments
– In the vicinity of combustible materials
– In areas where there is a danger of explosions
•Make sure the socket is near the device and is easily accessible.
Item
in fig. 1, page 3 Explanation
1 Mains cable
2 Battery input terminals
3 Compressor output terminals
4 Fastening holes
NOTICE!
Fix the mains rectifier in upright position only. In case you have to install
the rectifier in a different position put the rectifier in a fire resistant hous-
ing to prevent any fire being roused to other objects by hot plastic trip-
ping through the air slots.
MPS35-IO-16s.book Seite 8 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
MPS35 Using the mains rectifier
9
•The place of installation must be well-ventilated. A ventilation system which is at
least equivalent to the air openings in the device must be present for installations
in closed housings.
•The air intake on the underside or the air outlet on the back of the device must
remain clear.
•The installation surface must be level and sufficiently sturdy.
➤Fasten the mains rectifier with screws through the fastening holes in the front and
the rear of the device (fig. 14, page 3).
7 Using the mains rectifier
!
A
!
➤Determine the required cross section of the cable in relation to the cable length
according to fig. 3, page 3.
Key for fig. 3, page 3
WARNING!
Do not reverse the polarity. If the poles are reversed device may over-
heat and be damaged.
NOTICE!
Replace defective fuses with new ones of the same rating (15 A slow-
blow).
WARNING!
Protect the positive connecting cable to the battery by an external fuse
of 10 A (fig. 24, page 3).
Insert the fuse as near as possible to the battery.
Co-ordinate axis Meaning Unit
l Cable length m
∅Cable cross section mm²
MPS35-IO-16s.book Seite 9 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Maintaining and cleaning the mains rectifier MPS35
10
➤Connect the mains rectifier according to the circuit diagram in fig. 2, page 3.
Key for fig. 2, page 3:
8 Maintaining and cleaning the mains
rectifier
!
A
➤Occasionally clean the device with a damp cloth.
Item Explanation
1 Mains cable
2 Battery input terminals
3 Compressor output terminals
4Fuse(not included in scope of delivery)
5 Battery
rt red
sw black
WARNING! Danger of electrocution!
Always disconnect the mains plug before you clean and service the
device.
NOTICE! Danger of damaging the device!
Never clean the device under running water or in dish water.
Do not use abrasive cleaning agents or hard objects during cleaning as
these can damage the device.
MPS35-IO-16s.book Seite 10 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
MPS35 Guarantee
11
9Guarantee
The statutory warranty period applies. If the product is defective, please contact the
manufacturer's branch in your country (see the back of the instruction manual for the
addresses) or your retailer.
For repair and guarantee processing, please include the following documents when
you send in the device:
•A copy of the receipt with purchasing date
•A reason for the claim or description of the fault
10 Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
MPS35-IO-16s.book Seite 11 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

EN
Technical data MPS35
12
11 Technical data
Battery operation
CoolPower MPS35
Reference number: 9600000445
Rated input voltage: 110 – 240 Vw, 50/60 Hz
Input voltage range: 100 – 250 Vw
Input current: 1 A
Rated output voltage: 25 Vg
Idle output voltage: 29 Vg
Rated output current: 3 A
Peak output current (for 0.3 s): 12 A
Constant output power 110 W
Operating temperature range: 0 °C to +40 °C
Fuse: 15 A slow-blow
Dimensions (W x H x D): 115 x 55 x 160 mm
Weight: 0.7 kg
Certifications:
Input voltage: 12/24 Vg
Output voltage: 12/24 Vg
Input/output current: max. 10 A
MPS35-IO-16s.book Seite 12 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

AUSTRALIA
Dometic Australia Pty. Ltd.
1 John Duncan Court
Varsity Lakes QLD 4227
1800 212121
[phone]
Mail: [email protected]
AUSTRIA
Dometic Austria GmbH
Neudorferstraße 108
A-2353 Guntramsdorf
[phone]
[phone]
Mail: [email protected]
BENELUX
Dometic Branch Office Belgium
Zincstraat 3
B-1500 Halle
[phone]
[phone]
Mail: [email protected]e
BRAZIL
Dometic DO Brasil LTDA
Avenida Paulista 1754, conj. 111
SP 01310-920 Sao Paulo
[phone]
[phone]
Mail: [email protected].br
DENMARK
Dometic Denmark A/S
Nordensvej 15, Taulov
DK-7000 Fredericia
[phone]
[phone]
Mail: [email protected]k
FINLAND
Dometic Finland OY
Mestarintie 4
FIN-01730 Vantaa
[phone]
[phone]
Mail: [email protected]
FRANCE
Dometic SAS
ZA du Pré de la Dame Jeanne
B.P. 5
F-60128 Plailly
[phone]
[phone]
Mail : [e-mail]
HONG KONG
Dometic Group Asia Pacific
Suites 2207-11 · 22/F · Tower 1
The Gateway · 25 Canton Road,
Tsim Sha Tsui · Kowloon
[phone]
[phone]
Mail: [email protected]
HUNGARY
Dometic Zrt. Sales Office
Kerékgyártó u. 5.
H-1147 Budapest
[phone]
[phone]
Mail: [e-mail]
ITALY
Dometic Italy S.r.l.
Via Virgilio, 3
I-47122 Forlì (FC)
[phone]
[phone]
Mail: [e-mail]
JAPAN
Dometic KK
Maekawa-Shibaura, Bldg. 2
2-13-9 Shibaura Minato-ku
Tokyo 108-0023
[phone]
[phone]
Mail: [email protected]p
MEXICO
Dometic Mx, S. de R. L. de C. V.
Circuito Médicos No. 6 Local 1
Colonia Ciudad Satélite
CP 53100 Naucalpan de Juárez
Estado de México
[phone]
[phone]
Mail: [email protected].mx
NETHERLANDS
Dometic Benelux B.V.
Ecustraat 3
NL-4879 NP Etten-Leur
[phone]
[phone]
Mail: [email protected]l
NEW ZEALAND
Dometic New Zealand Ltd.
Unite E, The Gate
373 Neilson Street
Penrose 1, Auckland
[phone]
[phone]
Mail: [email protected]
NORWAY
Dometic Norway AS
Østerøyveien 46
N-3232 Sandefjord
[phone]
[phone]
Mail: [e-mail]
POLAND
Dometic Poland Sp. z o.o.
Ul. Puławska 435A
PL-02-801 Warszawa
[phone]
[phone]
Mail: [email protected]
PORTUGAL
Dometic Spain, S.L.
Branch Office em Portugal
Rot. de São Gonçalo nº 1 – Esc. 12
2775-399 Carcavelos
[phone]
[phone]
Mail: [email protected]
RUSSIA
Dometic RUS LLC
Komsomolskaya square 6-1
RU-107140 Moscow
[phone]
[phone]
Mail: [email protected]
SINGAPORE
Dometic Pte Ltd
18 Boon Lay Way 06–140 Trade Hub 21
Singapore 609966
[phone]
[phone]
Mail: [email protected]
SLOVAKIA
Dometic Slovakia s.r.o. Sales Office Bratislava
Nádražná 34/A
900 28 Ivánka pri Dunaji
/[phone]
Mail: [e-mail]
SOUTH AFRICA
Dometic (Pty) Ltd.
Regional Office
South Africa & Sub-Saharan Africa
2 Avalon Road
West Lake View Ext 11
Modderfontein 1645
Johannesburg
[phone]
[phone]
Mail: [email protected]
SPAIN
Dometic Spain S.L.
Avda. Sierra del Guadarrama, 16
E-28691 Villanueva de la Cañada
Madrid
[phone]
[phone]
Mail: [email protected]
SWEDEN
Dometic Scandinavia AB
Gustaf Melins gata 7
S-42131 Västra Frölunda
[phone]
[phone]
Mail: [e-mail]
SWITZERLAND
Dometic Switzerland AG
Riedackerstrasse 7a
CH-8153 Rümlang
[phone]
[phone]
Mail: [email protected]
UNITED ARAB EMIRATES
Dometic Middle East FZCO
P. O. Box 17860
S-D 6, Jebel Ali Freezone
Dubai
[phone]
[phone]
Mail: [email protected]
UNITED KINGDOM
Dometic UK Ltd.
Dometic House, The Brewery
Blandford St. Mary
Dorset DT11 9LS
[phone]
[phone]
Mail: [e-mail]
USA
Dometic RV Division
1120 North Main Street
Elkhart, IN 46515
[phone]
GERMANY
Dometic WAECO International GmbH
Hollefeldstraße 63 · D-48282 Emsdetten
[phone] · [phone]
Mail: [e-mail]
www.dometic.com
4445101675 07/2016
MPS35-IO-16s.book Seite 144 Mittwoch, 20. Juli 2016 7:09 19
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]
